Summary of Contents for SpeeCo LS401105
- Page 1 15 TON HORIZONTAL 28 TON VERTICAL/HORIZONTAL LOG SPLITTER LOG SPLITTER MODEL NO. LS401105 (40110500) MODEL NO. LS401105H (401105H0) ASSEMBLY & OPERATING INSTRUCTIONS Owner’s Manual THIS SAFETY ALERT SYMBOL IDENTIFIES IMPORTANT SAFETY MESSAGES IN THIS MANUAL. LS79-726-0210 Rev 5...
-
Page 2: Table Of Contents
Table of Contents Page(s) Important Safety Information......................... 1-6 Intended Use ......................... 1 Personal Protective Equipment ....................Safety Decals ........................General Safety ........................Preparation of the Log ......................Work Area ........................... Operation of the Log Splitter ....................Repair and Maintenance Safety ..................... Hydraulic Safety ........................ -
Page 3: Important Safety Information
WARNING: Read and thoroughly understand all instructions and safety information before assembling or operating this log splitter. Failure to do so may cause serious injury or death. Do not allow anyone to operate this log splitter who has not read this manual. As with all power equipment, a log splitter can be dangerous if assembled or used improperly. - Page 4 PART NUMBER: 52055200 LOCATION:TOP, FRONT END OF HYDRAULIC CYLINDER PART NUMBER: 52023200 LOCATION: HYDRAULIC TANK LOWER TANK, RIGHT CORNER PART NUMBER: 51018900 LOCATION: TOP OF HYDRAULIC CYLINDER Page 2...
-
Page 5: General Safety
GENERAL SAFETY Failure to follow these instructions may result in serious injury or death. EVER NEVER allow children to operate this log splitter. NEVER allow adults lacking proper instructions and understanding to operate this log splitter. KEEP all people and pets a minimum of 10 feet away from your work area when operating this log splitter. Only the operator is to be near the log splitter during use. -
Page 6: Repair And Maintenance Safety
KNOW how to stop the log splitter and disengage the controls before operating it. NEVER place hands or feet between the log and splitting wedge or ram during forward or reverse stroke. Serious injury or death could result. NEVER straddle or step over the log splitter during operation. NEVER reach or bend over the log splitter to pick up a log. -
Page 7: Hydraulic Safety
HYDRAULIC SAFETY The hydraulic system of your log splitter requires careful inspection along with the mechanical parts. Be sure to replace frayed, kinked, cracked or otherwise damaged hydraulic hose and components. NEVER check for leaks of hydraulic fluid with your hand. Fluid escaping from a small hole can be almost invisible. Escaping fluid under pressure can have sufficient force to penetrate skin causing serious personal injury or even death. -
Page 8: Towing Safety
IMPORTANT NOTE: This log splitter is equipped with an internal combustion engine and should not be used on or near any unimproved forest- covered, brush-covered or grass-covered land unless the engine’s exhaust system is equipped with a spark arrester meeting applicable local or state laws (if any). -
Page 9: Assembly Instructions
The engine manufacturer recommends lead-free gasoline only. Please note that this log splitter is available with either a SpeeCo 6.5 HP or a Honda GC 190 engine. Please follow the appropriate instructions for your engine. -
Page 10: Engine Oil Recommendations
ENGINE OIL RECOMMENDATIONS SpeeCo 6.5 HP Use 4-stroke automotive detergent oil. SAE 10W-30 is recommended for general use. Refer to the SAE Viscosity Grades chart on page 17 of your engine owner’s manual for average temperature ranges. The engine manufacturer recommends using API SERVICE Category SE or SF oil. -
Page 11: Towing
To Start a Warm Engine 1) Move the throttle lever to the FAST position. 2) Leave the choke lever in the OFF position. 3) Pull the starter grip until the engine starts. To Stop the Engine 1) Move the throttle lever to the SLOW position. 2) Move the throttle lever to the STOP position. -
Page 12: Parts List
PARTS BREAKDOWN FOR MODEL LS401105/LS401105H LOG SPLITTERS O/L- Obtain locally. Common fasteners available through hardware and farm stores. Page 10... - Page 13 O/L- Obtain locally. Common fasteners available through hardware and farm stores. Beam Assembly Page 11...
-
Page 14: Parts Breakdown Illustration
MODEL NO LS401105/LS401105H0 LOG SPLITTERS Refer to parts List on Pages 10 and 11 Refer to Parts List Below Ref. No Part Number Description Quantity 17020700 5/16”-18 UNC Nylock Nut 17030900 5/16” Regular Lock Washer 17053900 5/16” x 1-1/4” GR 5 Hex Cap Bolt 17054400 5/16”... -
Page 15: Notes
IMPORTANT NOTICE We, the manufacturer, reserve the right to change the product and/or specifications in this manual without notification. The manual is for information usage only and the pictures and drawings depicted herein are for reference only. NOTES Warranty Repair and Service Do not return this product to the store for warranty issues or repair. -
Page 16: Specifications
SPECIFICATIONS Engine SpeeCo 6.5 H.P. OHV or Honda GC190 Pump Two-Stage, 11 gpm Cylinder 3-1/2 in. Diameter x 18 in. Stroke Valve Auto-Return Maximum Splitting Force 15 Tons Maximum Log Length 19 in. Cycle Time 9 Seconds Wheels 4.80 x 8 in. Road Tires Wedge 6 in.
