  • Page 1 Modelle der MaK Typ DE 1002 HGK 37630...
  • Page 2: Table Of Contents

    Inhaltsverzeichnis: Sommaire : Seite Page Informationen zum Vorbild Informations concernant la locomotive réelle Hinweise zur Inbetriebnahme Indications relatives à la mise en service Sicherheitshinweise Remarques importantes sur la sécurité Allgemeine Hinweise Informations générales Funktionen Fonction Schaltbare Funktionen Fonctions commutables Parameter / Register Paramètre / Registre Ergänzendes Zubehör Accessoires complémentaires...
  • Page 3 Indice de contenido: Innehållsförteckning: Página Sida Notas para la puesta en servicio Bruksanvisningar för körning Aviso de seguridad Säkerhetsanvisningar Informaciones generales Allmänna informationer Función Funktion Funciones conmutables Ställbarer funktioner Parámetro / Registro Parameter / Register Accesorios complementarios Ytterligare tillbehör El mantenimiento Underhåll och reparation Recambios Reservdelar...
  • Page 4: Informationen Zum Vorbild

    Informationen zum Vorbild: Informations concernant la locomotive réelle : Diese dieselhydraulische Lokfamilie der MaK umfasst Mit- Cette famille de locomotives diesels-hydrauliques de la firme telführerhaus-Lokomotiven, die für den Streckenbetrieb bis MaK est composée de machines à cabine centrale pouvant zum schweren Rangierbetrieb eingesetzt werden können. être utilisées tant comme locomotives de ligne que comme Sie fahren für viele europäische Eisenbahngesellschaften machines de manoeuvre lourdes.
  • Page 5: Hinweise Zur Inbetriebnahme

    DE84 DE71 DE84 DE71...
  • Page 6: Sicherheitshinweise

    Sicherheitshinweise Funktionen • Die Lok darf nur mit einem dafür bestimmten Betriebssy- • Erkennung der Betriebsart: automatisch. stem (Märklin Wechselstrom, Märklin Delta, Märklin Digital • Einstellbare Adressen: 01 – 255 / Control Unit 01 – 80 oder Märklin Systems) eingesetzt werden. • Adresse ab Werk: 65 • Nur Schaltnetzteile/Transformatoren verwenden, die Ihrer • Mfx-Technologie für Mobile Station / Central Station. örtlichen Netzspannung entsprechen. Name ab Werk: DE 1002 HGK • Die Lok darf nur aus einer Leistungsquelle versorgt werden. • Veränderbare Anfahrverzögerung (ABV). • Beachten Sie unbedingt die Sicherheitshinweise in der • Veränderbare Bremsverzögerung (ABV). Bedienungsanleitung zu Ihrem Betriebssystem. • Veränderbare Höchstgeschwindigkeit.
  • Page 7: Schaltbare Funktionen

    f0 f8 Schaltbare Funktionen systems STOP mobile station Digital/Systems Stirnbeleuchtung function/off Funktion f0 Funktion f0 Betriebsgeräusch Funktion 2 Funktion 2 Funktion f2 Funktion f2 Geräusch: Horn Funktion 3 Funktion 6 Funktion f3 Funktion f3 Funktion 4 Funktion 4 Funktion f4 Funktion f4 Geräusch: Bremsenquietschen aus —...
  • Page 8: Safety Notes

    Safety Notes Functions • This locomotive is to be used only with an operating system • Recognition of the mode of operation: automatic. designed for it (Märklin AC, Märklin Delta, Märklin Digital or • Addresses that can be set: 01 – 255 / Control Unit 01 – 80 Märklin Systems). • Address set at the factory: 65 • Use only switched mode power supply units and transfor- • Mfx technology for the Mobile Station / Central Station. mers that are designed for your local power system. Name set at the factory: DE 1002 HGK • This locomotive must never be supplied with power from • Adjustable acceleration (ABV).
  • Page 9: Controllable Functions

    f0 f8 Controllable Functions systems STOP mobile station Digital/Systems Headlights function/off Function f0 Function f0 Operating sounds Function 2 Function 2 Function f2 Function f2 Sound effect: Horn Function 3 Function 6 Function f3 Function f3 Function 4 Function 4 Function f4 Function f4 Sound effect: Squealing brakes off —...
  • Page 10: Remarques Importantes Sur La Sécurité

    Remarques importantes sur la sécurité Fonctionnement • La locomotive ne peut être mise en service qu’avec un • Détection du mode d’exploitation : automatique. système d’exploitation adéquat (Märklin AC, Märklin Delta, • Adresses disponibles : 01 – 255 / Control Unit 01 – 80 Märklin Digital ou Märklin Systems). • Adresse encodée en usine : 65 • Utiliser uniquement des convertisseurs et transformateurs • Technologie mfx pour Mobile Station / Central Station. correspondant à la tension du secteur local. Nom encodée en usine : DE 1002 HGK • La locomotive ne peut être alimentée en courant que par • Temporisation d’accélération réglable (ABV).
  • Page 11: Fonctions Commutables

    f0 f8 Fonctions commutables systems STOP mobile station Digital/Systems Fanal function/off Fonction f0 Fonction f0 Bruit d’exploitation Fonction 2 Fonction 2 Fonction f2 Fonction f2 Bruitage : Trompe Fonction 3 Fonction 6 Fonction f3 Fonction f3 Fonction 4 Fonction 4 Fonction f4 Fonction f4 Bruitage : Grincement de freins désactivé...
  • Page 12: Veiligheidsvoorschriften

    Veiligheidsvoorschriften Functies • De loc mag alleen met een daarvoor bestemd bedrijfssy- • Herkenning van het bedrijfssysteem: automatisch. steem (Märklin AC, Märklin Delta, Märklin digitaal of • Instelbare adressen: 01 – 255 / Control Unit 01 – 80 Märklin Systems) gebruikt worden. • Vanaf de fabriek ingesteld: 65 • Alleen net-adapters en transformatoren gebruiken • Mfx-technologie voor het Mobile Station/Central Station. waarvan de aangegeven netspanning overeenkomt met Naam af de fabriek: DE 1002 HGK de netspanning ter plaatse. • Instelbare optrekvertraging (ABV).
  • Page 13: Schakelbare Functies

    f0 f8 Schakelbare functies systems STOP mobile station Digital/Systems Frontverlichting function/off Functie f0 Functie f0 Bedrijfsgeluiden Functie 2 Functie 2 Functie f2 Functie f2 Geluid: signaalhoorn Functie 3 Functie 6 Functie f3 Functie f3 Functie 4 Functie 4 Functie f4 Functie f4 Geluid: piepende remmen uit —...
  • Page 14: Aviso De Seguridad

    Aviso de seguridad Funciones • La locomotora solamente debe funcionar en un sistema de • Reconocimiento del sistema: automático. corriente propio (Märklin AC – Märklin Delta – • Códigos disponibles: 01 – 255 / Control Unit 01 – 80 Märklin Digital o Märklin Systems). • Código de fábrica: 65 • Emplear únicamente fuentes de alimentación conmutadas • Tecnología mfx para la Mobile Station/Central Station. y transformadores que sean de la tensión de red local. Nombre de fábrica: DE 1002 HGK • La locomotora no deberá recibir corriente eléctrica mas • Arranque lento variable (ABV). que de un solo punto de abasto. • Frenado lento variable (ABV).
  • Page 15: Funciones Conmutables

    f0 f8 Funciones posibles systems STOP mobile station Digital/Systems Faros frontales function/off Función f0 Función f0 Ruido: Ruido de explotación Función 2 Función 2 Función f2 Función f2 Ruido: Bocina Función 3 Función 6 Función f3 Función f3 Función 4 Función 4 Función f4 Función f4 Ruido: Desconectar chirrido de los frenos —...
  • Page 16: Avvertenze Per La Sicurezza

    Avvertenze per la sicurezza Funzioni • Tale locomotiva deve essere impiegata soltanto con un • Riconoscimento del tipo di funzionamento: automatico. sistema di funzionamento adeguato per questa (Märklin AC, • Indirizzi impostabili: 01 – 255 / Control Unit 01 – 80 Märklin Delta, Märklin Digital oppure Märklin Systems). • Indirizzo di fabbrica: 65 • Impiegare soltanto alimentatori “switching“ e trasforma- • Tecnologia Mfx per Mobile Station / Central Station. tori che corrispondono alla Vostra tensione di rete locale. Nome di fabbrica: DE 1002 HGK • La locomotiva non deve venire alimentata nello stesso • Ritardo di avviamento modificabile (ABV).
  • Page 17: Funzioni Commutabili

    f0 f8 Funzioni commutabili systems STOP mobile station Digital/Systems Illuminazione di testa function/off Funzione f0 Funzione f0 Rumori di esercizio Funzione 2 Funzione 2 Funzione f2 Funzione f2 Rumore: tromba Funzione 3 Funzione 6 Funzione f3 Funzione f3 Funzione 4 Funzione 4 Funzione f4 Funzione f4 Rumore: stridore dei freni escluso...
  • Page 18: Säkerhetsanvisningar

    Säkerhetsanvisningar Funktioner • Loket får endast köras med ett därtill avsett driftsystem • Driftsättet igenkänns automatiskt. (Märklin AC, Märklin Delta, Märklin Digital eller • Inställbara adresser: 01 – 255 / Control Unit 01 – 80 Märklin Systems). • Adress från tillverkaren: 65 • Använd endast nätadaptrar och transformatorer anpassa- • Mfx-teknologi för Mobile Station / Central Station. de för det lokala elnätet. Namn från tillverkaren: DE 1002 HGK • Loket får inte samtidigt försörjas av mer än en kraftkälla. • Accelerationsfördröjning kan ändras (ABV). • Beakta alltid säkerhetsanvisningarna i bruksanvisningen • Bromsfördröjning kan ändras (ABV).
  • Page 19: Ställbarer Funktioner

    f0 f8 Kopplingsbara funktioner systems STOP mobile station Digital/Systems Frontstrålkastare function/off Funktion f0 Funktion f0 Trafi kljud Funktion 2 Funktion 2 Funktion f2 Funktion f2 Ljud: Signalhorn Funktion 3 Funktion 6 Funktion f3 Funktion f3 Funktion 4 Funktion 4 Funktion f4 Funktion f4 Ljud: Bromsgnissel, från —...
  • Page 20: Vink Om Sikkerhed

    Vink om sikkerhed Funktioner • Lokomotivet må kun bruges med et driftssystem (Märklin AC, • Registrering af driftsarten: automatisk. Märklin Delta, Märklin Digital eller Märklin Systems), der er • Indstillelige adresser: 01 – 255 / Control Unit 01 – 80 beregnet dertil. • Adresse ab fabrik: 65 • Anvend kun DC-DC-omformere og transformatorer, der passer til den lokale netspænding. • Mfx-teknologi til Mobile Station / Central Station. • Lokomotivet må ikke forsynes fra mere end én strømkilde Navn ab fabrik: DE 1002 HGK ad gangen. • Indstillelig kørselsforsinkelse (ABV).
  • Page 21: Styrbare Funktioner

    f0 f8 Styrbare funktioner systems STOP mobile station Digital/Systems Frontbelysning function/off Funktion f0 Funktion f0 Driftslyd Funktion 2 Funktion 2 Funktion f2 Funktion f2 Lyd: Horn Funktion 3 Funktion 6 Funktion f3 Funktion f3 Funktion 4 Funktion 4 Funktion f4 Funktion f4 Lyd: Pibende bremser fra —...
  • Page 22: Parameter / Register

    Wert • Value • CV (Parameter) • CV (Parameter) • CV (Paramètre) • Valeur • Waarde • CV (Parameter) • CV (Parámetro) • CV (Parametro) • CV-Nr. Valor • Valore • CV (Parameter) • CV (Parameter) Värde • Værdi Adresse • Address • Adresse • Adres • 01 - (80) 255 Código • Indrizzo • Adress • Adresse Anfahrverzögerung • Acceleration delay • Temporisation accélération •...
  • Page 25 7154...
  • Page 31 motorisiert Dummy 1 Zylinderschraube 785 090 785 090 2 Decoder — 167 042 3 Beleuchtungseinheit 162 626 162 626 4 Motor 212 185 — 5 Antriebswelle 209 218 — 6 Senkschraube 786 790 — 7 Puffer 206 596 206 596 8 Kupplung 701 630 701 630...
  • Page 32 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Gebr. Märklin & Cie. GmbH Stuttgarter Str.
