3. Rainfall alert indicator
4. : remote rain gauge sensor battery low
5. : rain gauge RF reception status
6. TOTAL: rainfall indicator
7. : outdoor thermo RF reception status
8. : outdoor remote sensor battery low
9. AM/PM
0. : main unit battery low
. mm/in: millimeter/inch (rain rate unit)
2. Today's rainfall
3. mm/in: millimeter/inch (rain rate unit)
4. Total rainfall
5. Outdoor temperature
6. SINCE: start date of the accumulated rainfall yr: year
7. Time display; M:D (month: day); D:M (day: month);
calendar
P/N: 300103670-00004-10 REV1.0

REMOTE SENSOR (THN802)

1
. LED status indicator
2. Wall mount hole
3. RESET hole
4. CHANNEL switch (1,2,3)
5. Battery compartment
4
2
3
4
5
