AIR CONDITIONER
Wall Mounted type
DESIGN & TECHNICAL MANUAL
INDOOR
OUTDOOR
AS A09LEC
AS A12LEC
AO R09LECN
AO R12LECN

Advertisement

Table Of Contents

   Also See for Fujitsu ASYA09LEC

   Related Manuals for Fujitsu ASYA09LEC

   Summary of Contents for Fujitsu ASYA09LEC

  • Page 1: Wall Mounted Type

    AIR CONDITIONER Wall Mounted type DESIGN & TECHNICAL MANUAL INDOOR AS A09LEC AS A12LEC OUTDOOR AO R09LECN AO R12LECN...

  • Page 2: Indoor Unit

    1.INDOOR UNIT WALL MOUNTED TYPE : AS A09LEC AS A12LEC DTR_AS047E_01 2010.10.05...

  • Page 3: Table Of Contents

    CONTENTS 1. INDOOR UNIT 1. FEATURE ........................01 - 01 2. WIRELESS REMOTE CONTROLLER ..........01 - 04 3. SPECIFICATIONS ....................01 - 06 4. DIMENSIONS ......................01 - 07 5. WIRING DIAGRAMS ..................01 - 09 6. CAPACITY TABLE ....................

  • Page 4: Feature

    FEATURE MODEL AS A09LEC / AO R09LECN AS A12LEC / AO R12LECN FEATURES Low outdoor air temperature correspondence Corresponds to heating operation at -25°C outdoor air temperature Heating °C Specification improvement that can be operated under extreme low outdoor temperature (-25°C) without trouble Improvement of cold- proof specifications New model...

  • Page 5: Super Quiet

    Energy-Efficiency classification A Europe Energy-Efficiency classification A achieved ALL DC fan motor PAM control When operation starts, the machine operates at high voltage and high power and when operation stabilizes, the set temperature is maintained at low voltage. compressor Front view Super quiet Air flow mode can be set in 4 steps and more detailed air flow setting is possible.

  • Page 6

    Air conditioner filter features Dirty Air Ion Deodorization Filter Apple-catechin Filter Clean Air Long-life Ion Apple- Deodorization Filter catechin Filter - (01 - 03) -...

  • Page 7: Wireless Remote Controller

    WIRELESS REMOTE CONTROLLER FEATURES Four kinds of timer setup (On / Off / Program / Sleep) are possible. Four kinds of timers. Easy operation. Easy to change transmission code (4 patterns) by button operation. Simple function setting Setting of the air conditioner selection function is performed by remote controller. Built-in timers Select from four different timer programs (On/Off/Program/Sleep).

  • Page 8

    FUNCTIONS START/STOP button MODE button 10°C HEAT button SET TEMP. button ( COIL DRY button Signal transmitter TIMER MODE button TIMER SET ( ) button FAN button ECONOMY button START/STOP button SET button SWING button RESET button TEST RUN button This button is used when installing the air conditioner, and should not be used under normal conditions, as it will cause the indoor unit's thermostat function to operate incorrectly.

  • Page 9: Specifications

    SPECIFICATIONS WALL MOUNTED Type INVERTER HEAT PUMP Model name AS A09LEC AS A12LEC Power source 230V~ 50Hz Available voltage range 198-264V ~ 50Hz Cooling European energy label Heating 2.50 3.40 Rated BTU/h 8,500 11,600 Cooling 0.5 - 3.2 0.9 - 3.9 Min-Max BTU/h 1,700 - 10,900...

  • Page 10: Dimensions

    DIMENSIONS MODEL : AS A09LE, AS A12LE (Unit : mm) - (01 - 07) -...

  • Page 11

    INSTALLATION PLACE (Unit : mm) Outline of indoor unit 52 or more 48 or more 100 or more 70 or more 1500 or more - (01 - 08) -...

  • Page 12: Wiring Diagrams

    WIRING DIAGRAMS MODEL : AS A09LE, AS A12LE TO OUTDOOR UNIT - (01 - 09) -...

  • Page 13: Capacity Table

    CAPACITY TABLE 6-1. COOLING CAPACITY MODEL : AS A09LE 12.5 Indoor temperature °CDB °CWB °CDB 2.22 1.52 0.24 2.48 1.53 0.25 2.56 1.66 0.25 2.73 1.67 0.25 2.81 1.80 0.25 2.98 1.79 0.25 3.15 1.91 0.26 2.22 1.52 0.21 2.47 1.53 0.22 2.56...

  • Page 14: Heating Capacity

    6-2. HEATING CAPACITY This table is created using the maximum capacity. MODEL : AS A09LE 12.5 Indoor temperature °CDB °CDB °CWB 2.88 1.07 2.81 1.09 2.74 1.11 2.68 1.14 2.61 1.16 3.21 1.28 3.13 1.31 3.05 1.34 2.98 1.36 2.90 1.39 3.48 1.50...

  • Page 15: Fan Performance And Capacity

    FAN PERFORMANCE AND CAPACITY 7-1. AIR VELOCITY DISTRIBUTION MODEL : AS A09LE, AS A12LE Unit : m/s TOP VIEW Note: Vertical flap : Up Horizontal flap : Center Fan speed:High Operation mode:FAN Voltage:230V Unit : m/s TOP VIEW Vertical flap : Up Horizontal flap : Right &...

  • Page 16: Air Flow

    7-2. AIR FLOW MODEL : AS A09LE, AS A12LE COOLING Number of Fan speed rotations Air flow (r.p.m) m³/h HIGH 1440 m³/h 1200 m³/h m³/h QUIET HEATING Number of Fan speed rotations Air flow (r.p.m) m³/h HIGH 1440 m³/h 1200 m³/h m³/h QUIET...

  • Page 17: Operation Noise

    OPERATION NOISE 8-1. NOISE LEVEL CURVE MODEL : AS A09LE COOLING HEATING NC-65 NC-65 NC-60 NC-60 NC-55 NC-55 NC-50 NC-50 NC-45 NC-45 High High NC-40 NC-40 NC-35 NC-35 NC-30 NC-30 NC-25 NC-25 NC-20 NC-20 Quiet Quiet NC-15 NC-15 1,000 2,000 4,000 8,000 1,000...

  • Page 18: Sound Level Check Point

    8-2. SOUND LEVEL CHECK POINT - (01 - 15) -...

  • Page 19: Electric Characteristics

    ELECTRIC CHARACTERISTICS Model Name AS A09LE AS A12LE Voltage 230 ~ Power Supply Frequency Max Operating Current 11.0 Circuit breaker *)Wiring Spec Connection Cable Limited wiring length *) Wiring Spec Selected Sample (Selected based on Japan Electrotechnical Standard and Codes Committee E0005) - (01 - 16) -...

  • Page 20: Safety Devices

    SAFETY DEVICES Model Protection form AS A09LE AS A12LE Circuit protection Current fuse (PCB) 3.15A 250V Terminal protection Current (thermal) fuse 3A 250V 102°C Fan motor protection Terminal protection program MAX. 120±15°C - (01 - 17) -...

  • Page 21: External Input

    EXTERNAL INPUT & OUTPUT Connector INPUT OUTPUT REMARKS CN303 Control input See external input/ output settings for Operation status details. CN304 output 11-1. EXTERNAL INPUT CONTROL INPUT (Operation/Stop) The air conditioner can be remotely operated by means of the following on-site work. Operation is started at the following contents by adding the contact input of a commercial ON/OFF switch to a connector on the external control PC board and turning it ON.

  • Page 22: External Output

    11-2. EXTERNAL OUTPUT OPERATION STATUS OUTPUT An air conditioner operation status signal can be output. Circuit diagram example Indoor control PC board Communication kit Connected unit Connector 24V DC Ex.)Relay unit Ex.)Display Relay power supply *10 m Signal Optional parts Field supply Operation Indoor unit...

  • Page 23: Function Setting

    FUNCTION SETTING 12-1. INDOOR UNIT (Setting by remote controller) • This procedure changes to the function settings used to control the indoor unit according to the installation conditions. Incor settings can cause the indoor unit malfunction. • After the power is turned on, perform the “FUNCTION SETTING” according to the installation conditions using the remote controller.

  • Page 24

    CONTENTS OF FUNCTION SETTING • Follow the instructions in the Local Setup Procedure, which is supplied with the remote control, in accordance with the installed condition. After the power is turned on, perform the Function Setting on the remote control. •...

  • Page 25

    The following settings are also possible, depending on the operating conditions. 1-3. Auto Restart ( . . .Factory setting) Setting Description Function Number Setting Value 1-4. Indoor Room Temperature Sensor Switching Function (Only for Wired remote controller) The following settings are needed when use the control by Wired remote controller temperature sensor.

  • Page 26: Optional Parts

    OPTIONAL PARTS Exterior Parts name Model No. Summary Fine dust, invisible mold spores, and harmful microorganisms are absorbed Apple-catechin onto the filter by static UTR-FA16 filter electricity, and further growth is inhibited and deactivated by the polyphenol ingredient extracted from apples. The filter deodorizes by powerfully decomposing absorbed odors using the...

  • Page 27: Outdoor Unit

    2.OUTDOOR UNIT SINGLE TYPE : AO R09LECN AO R12LECN DTR_AO069E_01 2010.10.05...

  • Page 28

    CONTENTS 2. OUTDOOR UNIT 1. SPECIFICATIONS ....................02 - 01 2. DIMENSIONS ......................02 - 02 3. REFRIGERANT CIRCUIT ................02 - 03 4. WIRING DIAGRAMS ..................02 - 04 5. CAPACITY COMPENSATION RATE FOR PIPE LENGTH AND HEIGHT DIFERENCE ..................

  • Page 29: Specifications

    SPECIFICATIONS Type INVERTER HEAT PUMP Model name AO R09LECN AO R12LECN Power source 230V~ 50Hz Available voltage range 198-264V ~ 50Hz Starting current Cooling 2,020 1,950 Airflow rate Heating 1,760 1,700 Type × Q'ty Propeller fan×1 Motor output Cooling Sound pressure level dB(A) Heating Dimensions...

  • Page 30: Dimensions

    DIMENSIONS MODEL : AO R09LE, AO R12LE (Unit : mm) Drain port Ø20 Pitch of bolts for installation INSTALLATION PLACE 100 mm or more 100 mm or more 200 mm or more If the space is larger that is stated, the condition will be the same as that are no obstacles. - (02 - 02) -...

  • Page 31: Refrigerant Circuit

    REFRIGERANT CIRCUIT MODEL : AO R09LE, AO R12LE Heat exchanger 3-Way ( INDOOR ) valve 2-Way valve Muffler 4-Way valve Strainer Expansion valve Heat exchanger Strainer ( OUTDOOR ) Cooling Heating Refrigerant pipe diameter Liquid : 1/4" (6.35 mm) Gas : 3/8" (9.52 mm) - (02 - 03) -...

  • Page 32: Wiring Diagrams

    WIRING DIAGRAMS MODEL : AO R09LE, AO R12LE - (02 - 04) -...

  • Page 33: Capacity Compensation Rate For Pipe Length And Height Diference

    CAPACITY COMPENSATION RATE FOR PIPE LENGTH AND HEIGHT DIFERENCE MODEL : AO R09LE Pipe length (m) COOLING 0.913 0.922 0.963 0.928 0.937 Indoor unit is upper 0.980 0.967 0.932 0.941 than outdoor unit. 0.992 0.984 0.971 0.936 0.945 Height difference H 1.000 0.992 0.979...

  • Page 34

    MODEL : AO R12LE Pipe length (m) COOLING 0.882 0.880 0.943 0.896 0.894 Indoor unit is upper 0.968 0.947 0.900 0.898 than outdoor unit. 0.992 0.972 0.951 0.903 0.901 Height difference H 1.000 0.980 0.958 0.911 0.909 1.000 0.980 0.958 0.911 0.909 -7.5...

  • Page 35: Additional Charge Calculation

    ADDITIONAL CHARGE CALCULATION MODEL : AO R09LE Refrigerant type R410A Refrigerant amount REFRIGERANT CHARGE Pipe length 20g/m Additional charge 0 (Charge less) +100 MODEL : AO R12LE Refrigerant type R410A Refrigerant amount 1000 REFRIGERANT CHARGE Pipe length 20g/m Additional charge 0 (Charge less) +100 - (02 - 07) -...

  • Page 36: Air Flow

    AIR FLOW MODEL : AO R09LE COOLING Number of rotations Air flow (r.p.m) 2020 1189 HEATING Number of rotations Air flow (r.p.m) 1760 1036 MODEL : AO R12LE COOLING Number of rotations Air flow (r.p.m) 1950 1148 HEATING Number of rotations Air flow (r.p.m) 1700...

  • Page 37: Operation Noise

    OPERATION NOISE 8-1. NOISE LEVEL CURVE MODEL : AO R09LE COOLING HEATING NC-65 NC-65 NC-60 NC-60 NC-55 NC-55 NC-50 NC-50 NC-45 NC-45 NC-40 NC-40 NC-35 NC-35 NC-30 NC-30 NC-25 NC-25 NC-20 NC-20 NC-15 NC-15 1,000 2,000 4,000 8,000 1,000 2,000 4,000 8,000 Octave band center frequency,Hz...

  • Page 38: Sound Level Check Point

    8-2. SOUND LEVEL CHECK POINT - (02 - 10) -...

  • Page 39: Electric Characteristics

    ELECTRIC CHARACTERISTICS Model Name AO R09LE AO R12LE Voltage 230 ~ Power Supply Frequency Starting Current *) Wiring Spec Selected Sample (Selected based on Japan Electrotechnical Standard and Codes Committee E0005) - (02 - 11) -...

  • Page 40: Safety Devices

    SAFETY DEVICES Model Protection form AO R09LE AO R12LE Current fuse (NEAR THE TERMINAL) 20A 250V Circuit protection Current fuse 3.15A 250V (MAIN PRINTED CIRCUIT BOARD) OFF:100 °C Fan motor protection Thermal protection program ON:95 °C Thermal protection program OFF:110°C Compressor protection (DISCHARGE TEMP.) ON: After 7 minutes...
