Built-in cabinet instructions

This unit is designed for either built-in or free standing installation. If
you plan to use this unit in a built-in application please follow the
requirements shown to the right.
Installing Stainless Steel Handle
This wine chiller includes a stainless steel handle that is not required to operate this unit. To install the
handle please follow the below instructions:
1. Pull away the door gasket in the area where the handle is to be installed as shown below in
Illustration # 1. The gasket is easily displaced by hand, no tools are necessary.
2. Align the handle with the screws pre-installed on the backside of the door. Tighten the screws
using a Phillips head screwdriver until the handle sets both flush and secured tightly against
the door frame. (DO NOT overtighten as this will cause damage to the handle assembly).
3. Replace the door gasket to its original position.
Picture # 1
1 Gasket
2 Screwdriver

Cabinet Opening Dimensions

Inches
Width
Depth
Height 34 ½"
Centimetres
24" 61 cm
24" 61 cm
87.6 cm
Picture # 2
3 Stainless Steel Handle
