6.2 Programmable Digital Thermostat
A cooling only digital thermostat designed to provide accurate control, displays room temperature and
cooling on mode. The buttons on the front of the thermostat allow complete control of the equipment.
Cooling - Select the temperature by pressing the "Up" or "Down" button. The word "COOL" and the
temperature setting is displayed for five seconds.
Fahrenheit/Celsius - Simultaneously press the "Up" and "Down" buttons to switch between Fahrenheit
and Celsius temperature set point.
In addition, the thermostat can be programmed for two or four events per day. The events will allow
program of a day and night setting. Four events will allow programming of a morning, day, evening and
night settings. See the enclosed booklet (Uni-Line 110-809C) for programming details.
Follow the provided wiring diagram.
6.3

Optional Mini DAP II Microprocessor Control Panel

The Mini DAP II microprocessor control panel is an optional control panel available as an upgrade to
the thermostat. There is a separate manual that goes into extensive detail regarding functions, features,
programming and troubleshooting.
The Mini DAP II microprocessor control panel has an entire manual dedicated to its use
and operation. This manual must be referenced to complete a thorough unit installation.
Start-up is not complete until the Mini DAP II control panel settings are established.
6.4

Optional DAP II Microprocessor Control Panel

The DAP II microprocessor control panel is available as an upgrade to the Mini DAP II panel and offers
additional features including remote communications (with additional communication card options).
There is a separate manual that goes into extensive detail regarding functions, features, programming
and troubleshooting.
The DAP II microprocessor control panel has an entire manual dedicated to its use and
operation. This manual must be referenced to complete a thorough unit installation. Start-
up is not complete until the DAP II control panel settings are established.
6.5

Wiring Diagrams

Every Data Aire evaporator and condensing unit or fluid cooler comes with a wiring diagram. These
diagrams are 'ladder'- type schematics intended for service personnel. The intent is to allow the technician
to understand the wiring details associated with the electrical components and how they interface with
the controls as well as peripheral equipment, including secondary heat exchangers.
