  • Page 1: System Board

    System Board User’s Manual 935-X38T21-004G 03210751A...

  • Page 2: Fcc And Doc Statement On Class B

    Copyright This publication contains information that is protected by copyright. No par t of it may be reproduced in any form or by any means or used to make any transfor- mation/adaptation without the prior written permission from the copyright holders.

  • Page 3: Table Of Contents

    Table of Contents About this Manual................Warranty....................Static Electricity Precaution..............Safety Measures..................About the Package................Before Using the System Board............System Board Layout................English.................................................................................

  • Page 4: About This Manual

    (Main Board Utility CD) will appear. Click the “TOOLS” icon then click “Manual” on the main menu. For additional information on the system board, please download the complete version of the manual from DFI’s website. Visit www. dfi.com. Warranty 1.

  • Page 5: Static Electricity Precaution

    Introduction Static Electricity Precautions It is quite easy to inadver tently damage your PC, system board, components or devices even before installing them in your system unit. Static electrical discharge can damage computer components without causing any signs of physical damage. You must take extra care in handling them to ensure against electrostatic build-up.

  • Page 6: About The Package

    Introduction About the Package The system board package contains the following items. If any of these items are missing or damaged, please contact your dealer or sales representative for assistance. One system board One Bernstein audio module with cable One Transpiper kit (LP UT X38-T2R/T3R only) - One Transpiper - One metal pipe...

  • Page 7: System Board Layout

    Introduction System Board Layout LP UT X38-T2R/T3R...
  • Page 8 Introduction LP LT X38-T2R/T3R Note: The illustrations on the following pages are based on the LP UT X38- T2R/T3R system board.

  • Page 9: English

    English Chapter 1 - Specifications Processor • LGA 775 socket for: - Intel Core 2 Quad and Intel Core 2 Duo ® ® • Suppor ts Intel Enhanced Memory 64 Technology (EMT64T) • Supports Enhanced Intel SpeedStep Technology (EIST) • Suppor ts Intel Hyper-Threading Technology •...
  • Page 10 English • Mar vell 88E8052 and Mar vell 88E8053 PCIE Gigabit LAN controllers • Fully compliant to IEEE 802.3 (10BASE-T), 802.3u (100BASE- TX) and 802.3ab (1000BASE-T) standards Storage • Intel ICH9R chip - Intel Matrix Storage technology - Suppor ts up to 6 SATA devices - SATA speed up to 3Gb/s - RAID 0, RAID 1, RAID 0+1 and RAID 5 •...

  • Page 11: Jumper Settings

    English Chapter 2 - Hardware Installation Jumper Settings Clear CMOS Data Clearing CMOS Data using JP2 1-2 On: Normal 2-3 On: (default) Clear CMOS Data If you encounter the following, a) CMOS data becomes corrupted. b) You forgot the supervisor or user password. c) The overclocked settings in the BIOS resulted to the system’s in- stability or caused system boot up problems.
  • Page 12 English ® Clearing CMOS Data using the EZ Clear Function ® EZ Clear bypasses the manual process of using a jumper to clear the CMOS by simply using the reset and power buttons. Important: ® EZ Clear is supported only if standby power is present in the system.

  • Page 13: Usb Power Select

    English PS/2 Power Select 1-2 On: 5V 2-3 On: (default) 5VSB Important: The 5VSB power source of your p o w e r s u p p l y m u s t s u p p o r t ≥720mA.
  • Page 14 English Speaker On/Off Select 1-2 On: 2-3 On: Buzzer Speaker Off Speaker On (default) The system board is equipped with a buzzer which serves as the PC’s speaker. By default the buzzer is “on” allowing you to hear the system’s beep messages and warnings. If you intend to use an exter- nal speaker, turn this function off by setting JP8 pins 1 and 2 to On.
  • Page 15 English Safe Boot 1-2 On: 2-3 On: Default Safe boot This jumper is used to safely reboot the system whenever the sys- tem hangs and you are unable to restart the system. 1. Power-off the system then unplug the power cord. 2.

  • Page 16: Secondary Rtc Reset

    English Secondary RTC Reset JP12 1-2 On: Normal 2-3 On: (default) RTC reset When the RTC batter y is removed, this jumper resets the manageability register bits in the RTC. Note: 1. The SRTCRST# input must always be high when all other RTC power planes are on.
  • Page 17 English CPU FSB Select JP14 JP15 JP13 By default, JP13 to JP15 are set to pins 1 and 2 On. This setting will allow the system to automatically run according to the CPU’s FSB. If you want to change the setting, please refer to the table below. By CPU FSB 800 FSB 1066...
  • Page 18 English Rear Panel I/O Ports PS/2 LAN 1 LAN 2 Mouse 1394-0 USB 10-11 USB 6-7 PS/2 USB 8-9 PS/2 Ports and IEEE 1394 Ports PS/2 Mouse PS/2 KB 1394-0 1394-1 PS/2 Mouse and PS/2 Keyboard Ports These por ts are used to connect a PS/2 mouse and a PS/2 keyboard.
  • Page 19 English USB Ports and LAN Ports USB 11 USB 10 LAN 1 USB 9 USB 8 LAN 2 USB 7 USB 6 USB 4-5 USB 0-1 USB 2-3 USB Ports The USB ports are used to connect USB 2.0/1.1 devices. The 10-pin connectors allow you to connect 6 additional USB 2.0/1.1 por ts.

  • Page 20: Bernstein Audio Module

    English Bernstein Audio Module Left audio channel Line-in Ground Ground Line-out Right audio channel Mic-in Center/ CD-in Subwoofer Rear R/L Side R/L 1 0 9 Line out Jet Detect Line out_Left S/PDIF-out Sense N. C. Line out_Right Mic Jet Detect S/PDIF-in Mic_Right Mic_Left...
  • Page 21 English CD-in Connector The CD-in connector is used to receive audio from a CD-ROM drive, TV tuner or MPEG card. Front Audio Connector The front audio connector is used to connect to the line-out and mic-in jacks that are at the front panel of your system. Optical S/PDIF Connector The optical S/PDIF connector is used to connect an external audio output device using an optical S/PDIF cable.

  • Page 22: Serial Ata Connectors

    English 3. The length of the audio cable provides the option and flexibil- ity of installing the module on any available expansion bracket slot at the rear of the system chassis. Remove the screw of the bracket where you want the audio module installed then re- move the bracket.
  • Page 23 English Floppy Disk Drive Connector and IDE Connector Floppy Disk Drive Connector The floppy disk drive connector is used to connect a floppy drive. Insert one end of the floppy cable into this connector and the other end-most connector to the floppy drive. The colored edge of the cable should align with pin 1 of this connector.
  • Page 24 English IrDA, CIR and Serial (COM) Connectors IRRX Ground N. C. IRTX IrDA CIRTX 5VSB N. C. Ground CIRRX IrDA and CIR Connectors These connectors are used to connect an IrDA module and/or CIR module. Note: The sequence of the pin functions on some IrDA/CIR cable may be reversed from the pin function defined on the system board.

  • Page 25: Cooling Fan Connectors

    English Cooling Fan Connectors N. C. Ground Power Power Ground Sense Speed NB fan Control CPU fan Power Power Ground N. C. Ground N. C. 3rd fan 1st fan Power Power Ground N. C. Ground N. C. System fan 2nd fan These fan connectors are used to connect cooling fans.
  • Page 26 English LEDs DRAM Power LED Standby Diagnostic Power LED DRAM Power LED This LED will light when the system’s power is on. Standby Power LED This LED will light when the system is in the standby mode. Diagnostic LED The Diagnostic LED displays POST codes. POST (Power-On Self Tests) which is controlled by the BIOS is performed whenever you power-on the system.

  • Page 27: Power Connectors

    English Power Connectors Use a power supply that complies with the ATX12V Power Supply Design Guide Version 1.1. An ATX12V power supply unit has a standard 24-pin ATX main power connector that must be inserted into this connector. 1 2 2 4 +3.3VDC +12VDC +5VDC...
  • Page 28 English The power connectors from the power supply unit are designed to fit the 24-pin and 8-pin connectors in only one orientation. Make sure to find the proper orientation before plugging the connectors. The FDD-type power connectors are additional power connector.s If you are using more than one graphics cards, we recommend that you plug power cables from your power supply unit to the 5V/12V power connectors.
  • Page 29 English Restarting the PC Normally, you can power-off the PC by: 1. Pressing the power button at the front panel of the chassis. 2. Pressing the power switch that is on the system board (note: not all system boards come with this switch). If for some reasons you need to totally cut off the power supplied to the PC, switch off the power supply or unplug the power cord.

  • Page 30: Front Panel Connectors

    English Front Panel Connectors RESET SPEAKER HD-LED PWR-LED ATX-SW HD-LED: Primary/Secondary IDE LED This LED will light when the hard drive is being accessed. RESET: Reset Switch This switch allows you to reboot without having to power off the system thus prolonging the life of the power supply or system. SPEAKER: Speaker Connector This connects to the speaker installed in the system chassis.
  • Page 31 English PWR-LED: Power/Standby LED When the system’s power is on, this LED will light. When the system is in the S1 (POS - Power On Suspend) or S3 (STR - Suspend To RAM) state, it will blink every second. Note: If a system did not boot-up and the Power/Standby LED did not light after it was powered-on, it may indicate that the CPU or memor y module was not installed properly.

  • Page 32: Pci Express Slots

    English PCI Express Slots PCI Express x16 (PCIE 1) PCI Express x1 PCI Express x16 (PCIE 3) PCI Express x16 (PCIE 4) PCI Express x16 Install PCI Express x16 graphics card, that comply to the PCI Ex- press specifications, into the PCI Express x16 slot. To install a graph- ics card into the x16 slot, align the graphics card above the slot then press it down firmly until it is completely seated in the slot.

  • Page 33: Raid Levels

    English Chapter 3 - RAID The Intel ICH9R chip alows configuring RAID on Serial ATA drives connected to SATA 1 to SATA 6. It suppor ts RAID 0, RAID 1, RAID 0+1 and RAID 5. The JMicron JMB363 chip allows configuring RAID on another 2 Se- rial ATA drives connected to SATA 7 and SATA 8.
  • Page 34 English Settings To enable the RAID function, the following settings are required. 1. Connect the Serial ATA drives. 2. Configure Serial ATA in the Award BIOS. 3. Configure RAID in the RAID BIOS. 4. Install the RAID driver during OS installation. 5.
  • Page 35 Windows setup can reboot as needed. Step 5: Install the Intel Matrix Storage Manager Step 6: Install the JMB36X Driver Refer to the complete version of the manual for steps on installing the utlity and driver. Please download the manual from DFI’s website. Visit www.dfi.com.
  • Page 36 ® ® ® ®...
  • Page 40 Reset Power...
  • Page 41 2-3 On: 1-2 On: 5V 5VSB USB 6-11 (JP5) 2-3 On: 5VSB USB 0-5 2-3 On: (JP6) 5VSB...
  • Page 44 JP12...
  • Page 45 JP14 JP15 JP13 By CPU FSB 1333 FSB 800 FSB 1066 JP14 1-2 On 3-4 On 2-3 On 2-3 On JP13 1-2 On 2-3 On 2-3 On 2-3 On JP15 1-2 On 2-3 On 2-3 On 3-4 On...
  • Page 46 LAN 1 LAN 2 1394-0 USB 10-11 USB 6-7 USB 8-9 1394-0 1394-1...
  • Page 47 USB 11 USB 10 LAN 1 USB 9 USB 8 LAN 2 USB 7 USB 6 USB 4-5 USB 0-1 USB 2-3...
  • Page 48 CD-in Line-in Front Line-out audio Mic-in Optical Center/ S/PDIF Subwoofer Rear R/L Side R/L S/PDIF-out S/PDIF-in...
  • Page 49 Left audio channel Ground Ground Right audio channel CD-in 10 9 Line out Jet Detect Line out_Left Sense N. C. Line out_Right Mic Jet Detect Mic_Right Mic_Left Front audio SPDIF in SPDIF out Optical S/PDIF...
  • Page 51 SATA 7-8 SATA 1-2 SATA 3-4 SATA 5-6...
  • Page 53 IRRX Ground N. C. IRTX IrDA CIRTX 5VSB N. C. Ground CIRRX...
  • Page 54 N. C. Ground Power Power Ground Sense Speed NB fan Control CPU fan Power Power Ground N. C. Ground N. C. 3rd fan 1st fan Power Power Ground N. C. Ground N. C. System fan 2nd fan Reset Power...
  • Page 55 DRAM Power LED Standby Diagnostic Power LED...
  • Page 56 1 2 2 4 +3.3VDC +12VDC +5VDC +12VDC +5VDC +5VDC +5VSB PWR_OK +5VDC PS_ON# +5VDC -12VDC +3.3VDC +3.3VDC +3.3VDC +12V Ground...
  • Page 57 +12V Ground Ground...
  • Page 59 RESET SPEAKER HD-LED PWR-LED ATX-SW...
  • Page 61 PCI Express x16 (PCIE 1) PCI Express x1 PCI Express x16 (PCIE 3) PCI Express x16 (PCIE 4) PCIE 3 PCIE 4 PCIE 1 3 CrossFire N.C. CrossFire +...
  • Page 64 ® ®...
  • Page 65 ® ® ® ® ®...
  • Page 69 Reset Power...
  • Page 70 2-3 On: 5VSB USB 6-11 (JP5) 2-3 On: 5VSB USB 0-5 2-3 On: (JP6) 5VSB...
  • Page 73 JP12...
  • Page 74 JP14 JP15 JP13 By CPU FSB 1333 FSB 800 FSB 1066 JP14 1-2 On 3-4 On 2-3 On 2-3 On JP13 1-2 On 2-3 On 2-3 On 2-3 On JP15 1-2 On 3-4 On 2-3 On 2-3 On...
  • Page 75 LAN 1 LAN 2 1394-0 USB 10-11 USB 6-7 USB 8-9 1394-0 1394-1...
  • Page 76 USB 11 USB 10 LAN 1 USB 9 USB 8 LAN 2 USB 7 USB 6 USB 4-5 USB 0-1 USB 2-3...
  • Page 77 CD-in Line-in Front Line-out audio Mic-in Optical S/PDIF Rear R/L Side R/L S/PDIF-out S/PDIF-in...
  • Page 78 Left audio channel Ground Ground Right audio channel CD-in 10 9 Line out Jet Detect Line out_Left Sense N. C. Line out_Right Mic Jet Detect Mic_Right Mic_Left Front audio SPDIF in SPDIF out Optical S/PDIF...
  • Page 80 SATA 7-8 SATA 1-2 SATA 3-4 SATA 5-6...
  • Page 82 IRRX Ground N. C. IRTX IrDA CIRTX 5VSB Ground N. C. CIRRX...
  • Page 83 N. C. Ground Power Power Ground Sense Speed NB fan Control CPU fan Power Power Ground N. C. Ground N. C. 3rd fan 1st fan Power Power Ground N. C. Ground N. C. System fan 2nd fan Reset Power...
  • Page 84 DRAM Power LED Standby Diagnostic Power LED...
  • Page 85 1 2 2 4 +3.3VDC +12VDC +5VDC +12VDC +5VDC +5VSB +5VDC PWR_OK +5VDC PS_ON# +5VDC -12VDC +3.3VDC +3.3VDC +3.3VDC +12V Ground...
  • Page 86 +12V Ground Ground...
  • Page 88 RESET SPEAKER HD-LED PWR-LED ATX-SW...
  • Page 90 PCI Express x16 (PCIE 1) PCI Express x1 PCI Express x16 (PCIE 3) PCI Express x16 (PCIE 4) PCIE 3 PCIE 4 PCIE 1 2-way CrossFire N.C. 2-way CrossFire + Physics...
  • Page 93 ® ®...
  • Page 94 ® ® ® ® ® ®...
  • Page 95 • • • • •...
  • Page 97 Reset Power...
  • Page 98 1-2 On: 5V 2-3 On: 5VSB...
  • Page 99 USB 6-11 (JP5) 1-2 On: 5V 2-3 On: 5VSB USB 0-5 2-3 On: 1-2 On: 5V (JP6) 5VSB...
  • Page 102 JP12...
  • Page 103 JP14 JP15 JP13 FSB 1333 FSB 800 FSB 1066 1-2 On JP14 2-3 On 3-4 On 2-3 On 1-2 On JP13 2-3 On 2-3 On 2-3 On 1-2 On JP15 3-4 On 2-3 On 2-3 On...
  • Page 104 PS/2 LAN 1 LAN 2 1394-0 PS/2 USB 10-11 USB 6-7 USB 8-9 PS/2 PS/2 1394-0 1394-1...
  • Page 105 USB 11 USB 10 LAN 1 USB 9 USB 8 LAN 2 USB 7 USB 6 USB 4-5 USB 0-1 USB 2-3...
  • Page 106 CD-in Line-in Front Line-out audio Mic-in Optical S/PDIF Rear R/L Side R/L S/PDIF-out S/PDIF-in...
  • Page 107 Left audio channel Ground Ground Right audio channel CD-in 10 9 Line out Jet Detect Line out_Left Sense N. C. Line out_Right Mic Jet Detect Mic_Right Mic_Left Front audio SPDIF in SPDIF out Optical S/PDIF...
  • Page 109 SATA 7-8 SATA 1-2 SATA 3-4 SATA 5-6...
  • Page 111 IRRX Ground N. C. IRTX IrDA CIRTX 5VSB N. C. Ground CIRRX...
  • Page 112 N. C. Ground Power Power Ground Sense Speed NB fan Control CPU fan Power Power Ground N. C. Ground N. C. 3rd fan 1st fan Power Power Ground N. C. Ground N. C. System fan 2nd fan...
  • Page 113 Reset Power...
  • Page 115 12 24 +3.3VDC +12VDC +5VDC +12VDC +5VDC +5VDC +5VSB PWR_OK +5VDC PS_ON# +5VDC -12VDC +3.3VDC +3.3VDC +3.3VDC +12V Ground...
  • Page 116 +12V Ground Ground...
  • Page 118 RESET SPEAKER HD-LED PWR-LED ATX-SW...
  • Page 119 HDD LED Power HD-LED N. C. N. C. PWRBT+ ATX-SW PWRBT- N. C. N. C. RESET Ground H/W Reset Speaker Data N. C. SPEAKER Ground Speaker Power LED Power (+) LED Power (+) PWR-LED LED Power (-) or Standby Signal...
  • Page 120 PCI Express x16 (PCIE 1) PCI Express x1 PCI Express x16 (PCIE 3) PCI Express x16 (PCIE 4) PCIE 3 PCIE 1 PCIE 4 N.C.
