  • Page 1 Quick Install Guide...
  • Page 2 MOTHERBOARD MOTHERBOARD 1. CPU Socket 8. Serial-ATA connectors 15. PCI slots 2. NVIDIA SPP with passive heat sink 9. Front panel connector 16. Front Panel Audio connector 3. CPU fan connector 10. Floppy drive connector 17. PCI Express x1 slot 4.

  • Page 3: Memory Configuration

    DIMM Slot 0 DIMM Slot 2 DIMM Slot 1 DIMM SLOTS DIMM SLOTS DIMM Slot 3 Memory Configuration Configuration DIMM0 DIMM1 DIMM2 DIMM3 Single Channel Populated Populated Populated Populated Dual Channel Populated Populated Populated Populated Populated Populated Populated Populated Front Panel Header Pins LABEL DESCRIPTION HD_LED...
  • Page 4 INSTALLING MEMORY INSTALLING MEMORY Refer to page 13 of the manual in the motherboard installation CD for additional details. DIMM Slot Unlock a DIMM slot by pressing the module clips outward. Match the notch on the memory with the notch on the DIMM slot. Align the memory module to the DIMM slot, and insert the module vertically into the DIMM slot.
