Front Suspension; Special Tool Cross Reference Chart; Specifications - Torque Chart; Special Tools Front Suspension - Mercedes-Benz 2005 Sprinter Service Manual

2 - 2 FRONT
FRONT

SPECIFICATIONS - TORQUE CHART

DESCRIPTION
Lower Ball Joint To
Steering Knuckle
Strut To Steering Knuckle
Strut To Body
Bottom Spring Clamp
Plate To Front Axle
M12 X 1.5 Bolt
Bottom Spring Clamp
Plate To Front Axle
M10 Bolt
Sway Bar Clamp To The
Front Axle
Hexagon Socket Bolt For
Clamping Nut To Adjust
Wheel Bearing Play
Lower Control Arm To
Front Axle Beam
Stop Plate For Lower
Control Arm
Outer Tie Rod End Nut
Outer Tie Rod End Nut
Jam Nut
SPECIAL TOOLS

FRONT SUSPENSION

SPECIAL TOOL CROSS REFERENCE CHART

MB MILLER
TOOL # TOOL #
N/A 9288
N/A 9294
N/A 9302
N/A C-3894-A
730 589 9282
02 33 00
N/A C-4212F
TORQUE SPECIFICATIONS
N·m
280
185
100
130
65
30
12
150
60
130
50
DESCRIPTION
LEAF SPRING WEDGE
BLOCK
LOWER BALL JOINT
REMOVE/INSTALLER
BUSHING REMOVER
/INSTALLER
PULLER TIE ROD
BALL JOINT SEPARATOR
BALL JOINT PRESS
Ft. Lbs.
206
136
74
96
48
22
9
110
44
96
37
Puller Tie Rod C-3894-A
BALL JOINT PRESS - C-4212F
VA
In. Lbs.
—
—
—
—
—
—
106
—
—
—
—
