Summary of Contents for Mercedes-Benz 2005 C 240

Page 1 Operator’s Manual C-Class Wagon...
Page 2 Ê4Ct]rgË 2035846182 Order No. 6515 0136 13 Part No. 203 584 61 82 USA Edition A 2005...
Page 3 C 240 C 240 4MATIC...
Page 4 Your Mercedes-Benz represents the ef- forts of many skilled engineers and crafts- men. To help assure your driving pleasure, and also the safety of you and your passen-...
Page 5: Table Of Contents
Operator’s Manual ... 10 Service and warranty information .. 10 Important notice for California retail buyers and lessees of Mercedes-Benz automobiles ... 11 Maintenance ... 12 Roadside Assistance ... 12 Change of address or ownership... 12 Operating your vehicle outside the USA or Canada...
Page 6 Contents Safety and Security ... 59 Occupant safety... 60 Air bags ... 61 Seat belts ... 66 Children in the vehicle... 69 Blocking of rear door window operation... 77 Panic alarm* ... 78 Activating ... 78 Deactivating ... 78 Driving safety systems... 79 ABS ...
Page 7 Automatic transmission... 152 One-touch gearshifting... 154 Gear ranges ... 155 Gear selector lever position ... 156 Automatic shift program ... 158 Driving tips... 159 Emergency operation (Limp Home Mode) ... 160 Good visibility ... 161 Headlamp cleaning system* ... 161 Rear view mirrors...
Page 8 Contents Operation ... 255 The first 1000 miles (1500 km)... 256 Driving instructions... 257 Drive sensibly – save fuel ... 257 Drinking and driving ... 257 Pedals ... 257 Power assistance ... 257 Brakes ... 258 Driving off... 259 Parking ... 259 Tires ...
Page 9 Practical hints ... 293 What to do if … ... 294 Lamps in instrument cluster ... 294 Lamp in center console... 300 Vehicle status messages in the multifunction display... 301 Where will I find ...? ... 321 First aid kit... 321 Vehicle tool kit ...
Page 10 Contents Technical data... 361 Parts service ... 362 Warranty coverage... 363 Loss of Service and Warranty Information Booklet... 363 Identification labels... 364 Layout of poly-V-belt drive ... 365 C 240 (all models) ... 365 Engine... 366 Rims and Tires ... 367 Same size tires ...
Page 11: Introduction
Product information Please observe the following in your own best interest: We recommend using genuine Mercedes-Benz parts as well as conversion parts and accessories explicitly approved by us for your vehicle model. We have tested these parts to determine their reliability, safety and special suitability for Mercedes-Benz vehicles.
Page 12: Operator's Manual
Therefore, you may find explanations for optional equipment not installed in your vehicle. If you have any questions about the operation of any equipment, your authorized Mercedes-Benz Center will be glad to demonstrate the proper proce- dures. We continuously strive to improve our...
Page 13: Mercedes-Benz Automobiles
30 calender days. Written notification should be sent to us, not a dealer, at Mercedes-Benz USA, LLC, Customer Assistance Center, One Mercedes Drive, Montvale, NJ 07645-0350.
Page 14: Maintenance
Calls to the toll-free Roadside Assistance number 1-800-FOR-MERCedes (in the USA) 1-800-387-0100 (in Canada) will be answered by Mercedes-Benz Customer Assistance Representatives 24 hours a day, 365 days a year. For additional information refer to the Mercedes-Benz Roadside Assistance Program Brochure in your glove box.
Page 15: Operating Your Vehicle Outside The Usa Or Canada
Certain Mercedes-Benz models are avail- able for delivery in Europe under our Euro- pean Delivery Program. For details, consult an authorized Mercedes-Benz Center or...
Page 16: Where To Find It
Here you will find all the information you need for your first drive. You should read this section first if this is your first Mercedes-Benz vehicle or if you are rent- ing or borrowing this vehicle. Safety and Security Here you will find descriptions of the safety features of your vehicle.
Page 17: Symbols
Symbols The following symbols are found in this Operator’s Manual: Optional equipment is identified with an asterisk. Since standard equipment varies between models, the descriptions and illustrations in this manual may differ slightly from the actual equipment of your vehi- cle.
Page 18: Operating Safety
Electronic malfunctions could seriously impair the operating safety of your vehicle. See an authorized Mercedes-Benz Center for repairs or modifications to electronic components. Other improper work or modifications on the vehicle could also have a negative impact on the operating safety of the vehicle.
Page 19: Problems With Your Vehicle
If you should experience a problem with your vehicle, particularly one that you believe may affect its safe operation, we urge you to immediately contact an authorized Mercedes-Benz Center to have the problem diagnosed and corrected if required. If the matter is...
Page 20: Reporting Safety Defects
If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying Mercedes-Benz USA, LLC. If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign.
Page 21: Vehicle Data Recording
Vehicle data recording Information regarding electronic recording devices (Including notice pursuant to California Code § 9951) Please note that your vehicle is equipped with devices that can record vehicle systems data and, if equipped with the Tele Aid system, may transmit some data in certain accidents. This information helps, for example, to diagnose vehicle systems after a collision and to continuously improve vehicle safety.
Page 23: At A Glance
At a glance Cockpit Instrument cluster Multifunction steering wheel Center console Overhead control panel Door control panel...
Page 24: Cockpit
At a glance Cockpit...
Page 25 Feature description is based on preliminary infor- mation at time of printing. At time of printing, no date for availability of voice control had been set. Contact an authorized Mercedes-Benz Center for details and availability for your vehicle model. Item...
Page 26: Instrument Cluster
At a glance Instrument cluster...
Page 27: Brake Warning
Item Page 1 Speedometer with: v Electronic Stability Program (ESP) warning lamp ; Brake warning lamp, USA only 3 Brake warning lamp, Canada only B Low beam head- lamp indicator lamp 2 L Left turn signal indicator lamp 3 Multifunction display with: Trip odometer Main odometer...
Page 28: Multifunction Steering Wheel
At a glance Multifunction steering wheel Item Page 1 Multifunction display Operating control system 2 Selecting the submenu or setting the volume: Press button æ up/to increase ç down/to decrease 3 Telephone*: Press button s to take a call t to end a call Item Page 4 Menu systems:...
Page 29: Important Notice For California Center Console
Center console Upper part Item Page 1 Seat heating*, driver’s side 2 ESP control switch 3 Hazard warning flasher switch – switching on/off 4 Central locking switch Central unlocking switch 5 Tow-away alarm switch* Anti-theft alarm system indicator lamp* 6 Seat heating*, passenger side At a glance Center console...
Page 30: Lower Part
At a glance Center console Lower Part Item Page 1 Ashtray Cigarette lighter 2 Gear selector lever for automatic transmission 3 Cup holders 4 Armrest 5 Program mode selector switch for automatic transmission...
Page 31: Overhead Control Panel
Overhead control panel 1 Rear interior lighting 2 Power tilt/sliding sunroof* 3 Right reading lamp on/off 4 Interior lighting control 5 Hands-free microphone for Item Page 6 Interior rear view mirror on/off 7 Garage door opener* 8 Left reading lamp on/off 9 Tele Aid* (emergency call 148, Tele Aid* (emergency call...
Page 32: Door Control Panel
At a glance Door control panel Item Page 1 Door handle 2 Memory function* (for storing seat, exterior mirror and steering wheel settings) 3 Switches for seat 35, 97 adjustment* 4 Switches for opening/closing front door windows 5 Switch for rear door window override 6 Switches for opening/closing rear door...
Page 33: Getting Started
Getting started Unlocking Adjusting Driving Parking and locking...
Page 34: Unlocking
Getting started Unlocking The “Getting started” section provides an overview of the vehicle’s most basic func- tions. First-time Mercedes-Benz owners should pay special attention to the infor- mation given here. If you are already familiar with the basic functions described here, the “Controls in detail”...
Page 35: Starter Switch Positions
Starter switch positions Warning! When leaving the vehicle, always remove the SmartKey from the starter switch and lock the vehicle. Do not leave children unattend- ed in the vehicle, or with access to an un- locked vehicle. Unsupervised use of vehicle equipment may cause an accident and/or serious personal injury.
Page 36 Getting started Unlocking When you switch on the ignition, the indicator and warning lamps in the instrument cluster come on. This indi- cates that the respective systems are operational. They should go out when the engine is running. The SmartKey can only be removed from the starter switch with the gear selector lever in position P.
Page 37: Adjusting
Adjusting Warning! Children 12 years old and under must never ride in the front seat, except in a Mercedes-Benz authorized BabySmart compatible child seat, which operates with the BabySmart system installed in the ve- hicle to deactivate the passenger front air bag when it is properly installed.
Page 38 Getting started Adjusting A child’s risk of serious or fatal injuries is significantly increased if the child restraints are not properly secured in the vehicle and the child is not properly secured in the child restraint. Manual seat adjustment 1 Seat fore and aft adjustment 2 Seat cushion tilt 3 Seat backrest tilt 4 Seat height...
Page 39 Head restraint height 1 Release button Raising: Manually adjust the height of the head restraint by pulling it upward. Lowering: To lower head the restraint, push release button 1 and push down on the head restraint. Warning! For your protection, drive only with properly positioned head restraints.
Page 40 Getting started Adjusting Power seat* adjustment The seat adjustment switches are located in each front door. 1 Head restraint height 2 Seat height 3 Seat cushion tilt 4 Seat fore and aft adjustment 5 Seat backrest tilt Switch on ignition ( page 33). Open the respective door.
Page 41: Steering Wheel
Warning! For your protection, drive only with properly positioned head restraints. Adjust head restraint so that the center of the head restraint supports the back of the head at eye level. This will reduce the poten- tial for injury to the head and neck in the event of an accident or similar situation.
Page 42: Steering Wheel Adjustment
Getting started Adjusting Steering wheel adjustment, manual 1 Handle To unlock the steering column, pull handle 1 out to its stop limit. Move steering wheel to the desired position. To lock the steering column, push handle 1 all the way in until it engages.
Page 43: Mirrors
Adjusting steering column in or out Move stalk forward or back in the direction of arrow 1 until a comfort- able steering wheel position is reached with your arms slightly bent at the elbow. Adjusting steering column up or down Move stalk up or down in the direction of arrow 2.
Page 44 Getting started Adjusting The buttons are located above the exterior lamp switch. 1 Adjustment button 2 Passenger-side exterior rear view mirror button 3 Driver’s side exterior rear view mirror button Switch on ignition ( page 33). Press button 3 for the driver’s side exterior rear view mirror or button 2 for the passenger-side exterior rear view mirror.
Page 45: Driving
Driving Warning! Children 12 years old and under must never ride in the front seat, except in a Mercedes-Benz authorized BabySmart compatible child seat, which operates with the BabySmart system installed in the ve- hicle to deactivate the passenger front air bag when it is properly installed.
Page 46 Getting started Driving A child’s risk of serious or fatal injuries is significantly increased if the child restraints are not properly secured in the vehicle and the child is not properly secured in the child restraint. Warning! Never ride in a moving vehicle with the seat backrest in an excessively reclined position as this can be dangerous.
Page 47 If necessary, tighten the lap portion to a snug fit by pulling shoulder portion Seat belt height adjustment Adjust seat belt so that shoulder portion is located as close as possible to the middle of your shoulder (it should not touch the neck or pass under the arm).
Page 48: Starting The Engine
In a crash, they may not be able to provide adequate protection. Damaged seat belts or belts that were highly stressed in an accident must be replaced. Contact an authorized Mercedes-Benz Center. Starting the engine Warning! Inhalation of exhaust gas is hazardous to your health.
Page 49: Parking Brake Pedal
Get a jump start ( page 350). If the engine does not start after several starting attempts, there could be a mal- function in the engine electronics or in the fuel supply system. Notify an authorized Mercedes-Benz Center. Getting started Driving Parking brake...
Page 50 Getting started Driving Release parking brake by pulling on handle 1. The warning lamp ; (USA only) or 3 (Canada only) in the instrument cluster goes out. Driving Depress the brake pedal. Move gear selector lever to position D or R. Wait for the gear selection process to complete before setting the vehicle in motion.
Page 51: Switching On Headlamps
Warning! It is dangerous to shift the gear selector lever out of P or N if the engine speed is higher than idle speed. If your foot is not firmly on the brake pedal, the vehicle could accelerate quickly forward or in reverse. You could lose control of the vehicle and hit someone or something.
Page 52: Turn Signals
Getting started Driving Push combination switch in direction of arrow 1. The high beam headlamp indicator lamp A in the instrument cluster comes on ( page 24). Turn signals The combination switch is located on the left of the steering column. Combination switch 1 Turn signals, right 2 Turn signals, left...
Page 53 Switching on windshield wipers Turn the combination switch to the desired position depending on the intensity of the rain. 0 Windshield wipers off Intermittent wiping II Normal wiper speed III Fast wiper speed Vehicles without rain sensor: When the vehicle is standing still, the wiper speed returns to next lower setting.
Page 54 Remove blockage. Turn the windshield wipers on again. If windshield wipers fail to function at all in switch position I, set the combination switch to the next highest wiper speed have the windshield wipers checked at the nearest authorized Mercedes-Benz Center...
Page 55: Rear Window Wiper
Rear window wiper The combination switch is located on the left of the steering column. Combination switch 1 Rear window wiper switch 2 Wiping rear window with washer fluid 3 Intermittent wiping 4 Rear window wiper off 5 Wiping rear window with washer fluid Switch on ignition ( page 33).
Page 56: Problems While Driving
Unburned gasoline may have entered the catalytic converter and damaged it. Give very little gas. Have the problem repaired by an au- thorized Mercedes-Benz Center as soon as possible. The coolant temperature is above 248°F (120°C) The coolant is too hot and is no longer cooling the engine.
Page 57: Parking And Locking
Parking and locking You have now completed your first drive. You have properly stopped and parked your vehicle. End your drive as follows. Warning! Wait until the vehicle is stationary before removing the SmartKey from the starter switch. The vehicle cannot be steered when the SmartKey is removed.
Page 58: Switching Off Headlamps
Getting started Parking and locking Warning! When leaving the vehicle, always remove the SmartKey from the starter switch, and lock the vehicle. Do not leave children unattend- ed in the vehicle, or with access to an un- locked vehicle. Children could release the parking brake and/or move the gear selec- tor lever from position P, either of which could result in an accident and/or serious...
Page 59: Turning Off Engine
Turning off engine Place the gear selector lever in position P. Always set the parking brake in addition to shifting to position P. On steep slopes, turn the front wheels towards the road curb. Turn the SmartKey in the starter switch to position 0 and remove the SmartKey from the starter switch.
Page 61: Safety And Security
Safety and Security Occupant safety Panic alarm* Driving safety systems Anti-theft systems...
Page 62: Occupant Safety
For safety reasons, we strongly recom- mend that you visit an authorized Mercedes-Benz Center immediately to have the system checked. For more information, see “Practical hints”( page 299).
Page 63: Air Bags
SRS self-check has detected a malfunction. For your safety, we strongly recommend that you visit an authorized Mercedes-Benz Center immediately to have the system checked; otherwise the SRS may not be activated when needed in an acci-...
Page 64 If you have any prob- lems, please see an authorized Mercedes-Benz Center. Do not lean with your head or chest close to the steering wheel or dash- board.
Page 65 Mercedes-Benz Center at an additional cost. Safety and Security Occupant safety...
Page 66 Only use belts in- stalled or supplied by an authorized Mercedes-Benz Center. Air bags and emergency tensioning devices (ETDs) are designed to function on a one-time only basis. An air bag or ETD that was activated must be replaced.
Page 67 These instructions are available 1 Driver’s air bag from your authorized Mercedes-Benz 2 Passenger front air bag Center. Driver and front passenger air bags are Given the considerable deployment...
Page 68: Seat Belts
Safety and Security Occupant safety Do not place objects heavier than 20 lbs (9 kg) on the front passenger seat. This could cause the front or side impact air bag on the front passenger side to deploy in a crash which exceeds the system's deployment threshold.
Page 69 Only use seat belts which have been ap- proved by Mercedes-Benz. Do not make any modifications to the seat belts. This can lead to unintended activation or to failure.
Page 70 Safety and Security Occupant safety Warning! USE SEAT BELTS PROPERLY Seat belts can only work when used properly. Never wear seat belts in any other way than as described in this sec- tion, as that could result in serious inju- ries in case of an accident.
Page 71: Children In The Vehicle
When scrapping the emergency tensioning device, our safety instructions must be followed. These are available at your authorized Mercedes-Benz Center. Do not place objects heavier than 20 lbs (9 kg) on the front passenger seat. This could cause the front or side...
Page 72 Safety and Security Occupant safety We recommend all infants and children be properly restrained at all times while the vehicle is in motion. All lap-shoulder belts except the driver’s seat belt have special seat belt retractors for secure fastening of child restraints. To fasten a child restraint, follow child re- straint instructions for mounting.
Page 73 Children 12 years old and under must never label on the restraint and in the ride in the front seat, except in a instruction manual provided with the Mercedes-Benz authorized BabySmart restraint. compatible child seat, which operates with When using any infant or child restraint...
Page 74 Automotive Corp. Special BabySmart compatible child seats, designed for use with the Mercedes-Benz system and available at any authorized Mercedes-Benz Center are required for use with the BabySmart air bag deactivation system. With the spe- cial child seat properly installed, the pas- senger front air bag will not deploy.
Page 75 Warning! The BabySmart air bag deactivation sys- tem will ONLY work with a special child seat designed to operate with it. It will not work with child seats which are not BabySmart compatible. Never place anything between seat cushion and child seat (e.g. pillow), since it reduces the effectiveness of the deactivation sys- tem.
Page 76 Safety and Security Occupant safety Installation of infant and child restraint systems Prior to installing a tether strap, note the following steps: Roll up retractable luggage cover and partition net. If you place a child seat in the left or center rear seat position, remove twin roller blind ( page 229) and return seat to its original position.
Page 77 Fold up anchorage ring 1. Securely fasten hook 2, which is part of the tether strap, to anchorage ring 1. For safety, make sure the hook has attached to the ring beyond the safety catch, as illustrated. 1 Anchorage ring 2 Hook Once the top tether anchorage hook is attached, the child restraint itself can be...
Page 78 Safety and Security Occupant safety The child seat must be firmly attached in the right and left side anchors 1. With a child seat installed in the left rear seat, the seat belt for the center seat occupied by a passenger must op- erate freely.
Page 79: Blocking Of Rear Door Window Operation
Blocking of rear door window operation You can block the rear door window operation (for instance when you have children riding in the rear passenger compartment). The override switch is located on the door control panel of the driver’s door. 1 Enable 2 Disable 3 Override switch...
Page 80: Panic Alarm
Safety and Security Panic alarm* An audible alarm and flashing exterior lamps will operate for approximately minutes. 1 Â button Canada only: Only vehicles equipped with an anti-theft alarm system* have SmartKeys with integrated panic button 1. Activating Press and hold button 1 for at least one second.
Page 81: Driving Safety Systems
Driving safety systems In this section you will find information on the following driving safety systems: ABS (Antilock Brake System) BAS (Brake Assist System) ESP (Electronic Stability Program) 4MATIC (Four Wheel Electronic Traction System) In winter operation, the maximum effectiveness of the ABS, ESP, and 4MATIC (if so equipped) is only achieved with winter tires (M+S tires), or snow chains as required.
Page 82: Bas
Safety and Security Driving safety systems Braking At the instant one of the wheels is about to lock up, a slight pulsation can be felt in the brake pedal, indicating that the ABS is in the regulating mode. Keep firm and steady pressure on the brake pedal while experiencing the pulsation.
Page 83: Esp
Warning! The BAS cannot prevent the natural laws of physics from acting on the vehicle, nor can it increase braking efficiency beyond that afforded by the condition of the vehicle brakes and tires or the traction afforded. The BAS cannot prevent accidents, includ- ing those resulting from excessive speed in turns, following another vehicle too closely, or hydroplaning.
Page 84 Safety and Security Driving safety systems Warning! The ESP cannot prevent the natural laws of physics from acting on the vehicle, nor can it increase the traction afforded. The ESP cannot prevent accidents, including those resulting from excessive speed in turns or hydroplaning.
Page 85 Avoid spinning of a drive wheel for an extended period with the ESP switched off. This may cause serious damage to the drivetrain which is not covered by the Mercedes-Benz Limited Warranty. Switching on the ESP Press switch 1 again. The ESP warning lamp v in the speedometer goes out.
Page 86: Four Wheel Electronic Traction System (4Matic) With The Esp
Do not tow with one axle raised. Otherwise the transfer case can be damaged, which is not covered by the Mercedes-Benz Limited Warranty. Performance testing must only be con- ducted on a two-axle dynamometer. Otherwise the transfer case can be damaged, which is not covered by the Mercedes-Benz Limited Warranty.
Page 87: Anti-Theft Systems
In case the engine cannot be started (yet the vehicle’s battery is charged), the system is not operational. Contact an authorized Mercedes-Benz Center or call 1-800-FOR-MERCedes (in the USA), or 1-800-387-0100 (in Canada). Anti-theft alarm system* Once the alarm system has been armed, a...
Page 88 Safety and Security Anti-theft systems Arming the alarm system The indicator lamp is in the switch for the tow-away alarm* in the center console. 1 Indicator lamp Lock the vehicle with the SmartKey. The turn signal lamps flash three times to indicate that the alarm system is activated.
Page 89: Tow-Away Alarm
Tow-away alarm* Once the tow-away alarm is armed, a visual and audible alarm will be triggered when someone attempts to raise the vehicle. The tow-away protection alarm is triggered, for example, if the vehicle is lifted on one side. If the alarm stays on for more than 30 seconds, a call to the Response Center is initiated automatically by the Tele Aid system* ( page 242) provid-...
Page 90 Safety and Security Anti-theft systems Press switch 1. Indicator lamp 2 in switch comes on briefly. Exit and lock your vehicle with the SmartKey. The tow-away alarm remains disarmed until you lock your vehicle again. Canceling the alarm To cancel the alarm: Press the Œ...
Page 91: Controls In Detail
Controls in detail Locking and unlocking Seats Memory function* Lighting Instrument cluster Control system Automatic transmission Good visibility Climate control Audio system Power windows Power tilt/sliding sunroof* Driving systems Loading Useful features...
Page 92: Locking And Unlocking
Controls in detail Locking and unlocking In the “Controls in detail” section you will find detailed information on how to oper- ate the equipment installed on your vehi- cle. If you are already familiar with the basic functions of your vehicle, this section will be of particular interest to you.
Page 93 Warning! When leaving the vehicle, always remove the SmartKey from the starter switch and lock the vehicle. Do not leave children unattend- ed in the vehicle, or with access to an un- locked vehicle. It is possible for children to open a locked door from the inside, which could result in an accident and/or serious injury.
Page 94 ( page 326). Use the mechanical key to lock the driver’s door ( page 327). Have the vehicle battery and the battery connections checked ( page 347). If the SmartKey is malfunctioning, contact an authorized Mercedes-Benz Center.
Page 95: Opening The Doors From The Inside
SmartKey batteries are discharged. Replace the batteries ( page 331). You can obtain the required batteries at any authorized Mercedes-Benz Center. If the batteries are checked within signal range of the vehicle, pressing the ‹...
Page 96: Opening The Tailgate
Controls in detail Locking and unlocking Rear doors Pull up locking knob 1 on the respective rear door to unlock door. Pull on door handle 2 on the respective rear door to open door. If the vehicle has previously been locked from the outside with the SmartKey, opening a door from the inside will trigger the anti-theft alarm...
Page 97: Automatic Central Locking
Warning! To prevent possible personal injury, always keep hands and fingers away from the tail- gate opening when closing the tailgate. Be especially careful when small children are around. When leaving the vehicle, always remove the SmartKey from the starter switch, take it with you and lock your vehicle.
Page 98: Locking And Unlocking From The Inside
Controls in detail Locking and unlocking Locking and unlocking from the inside You can lock or unlock the doors and the tailgate from inside using the central lock- ing or unlocking switch. This can be useful, for example, if you want to lock the vehicle before starting to drive.
Page 99: Seats
Seats For information on seat adjustment, see “Adjusting” ( page 35). Easy-entry/exit feature* This feature allows for easier entry into and exit from the vehicle. The easy-entry/exit feature can be activated or deactivated in the Convenience submenu of the control system ( page 144).
Page 100 Controls in detail Seats If the current position for the steering wheel is in the uppermost tilt position, the steering wheel will no longer be able to move upward when the easy-entry/exit feature is activated. If the current seat position falls into a factory-set position range and the system recognizes the current seat position to be rearward enough for...
Page 101: Removing And Installing Front Seat Head Restraints
Removing and installing front seat head restraints For information on head restraint adjustment, see “Seats” ( page 35). Adjust the head restraint in such a way that it is as close to the head as possible. Warning! For your protection, drive only with properly positioned head restraints.
Page 102: Rear Seat Head Restraints
Controls in detail Seats Front seat head restraints, power seat* 1 Head restraint switch Switch on ignition ( page 33). Removing front seat head restraints Press switch 1 upwards and hold until head restraint is fully extended. Pull out head restraint. Installing front seat head restraints Press switch 1 upwards and hold for about five seconds.
Page 103 Adjust the head restraint in such a way that it is as close to the head as possible. Warning! For your protection, drive only with properly positioned head restraints. Adjust head restraint so that the center of the head restraint supports the back of the head at eye level.
Page 104 Controls in detail Seats Head restraint tilt (rear outer seats) Two different head restraint angle positions are available. Press the release button ( page 101) and tilt the head restraint to the desired position. Removing and installing rear seat head restraints (rear outer seats) Adjust the head restraint in such a way that it is as close to the head as...
Page 105: Multicontour Seats
Multicontour seats* This multicontour seat has a movable seat cushion and inflatable air cushions built into the backrest to provide additional lumbar and side support. The seat cushion movement, backrest cushion height and curvature can be continuously varied with switches on the side of the seat after switching on ignition.
Page 106: Seat Heating
Controls in detail Seats Seat heating* The switches for the front seats are located in the center console. 1 Seat heating switch 2 Indicator lamps The red indicator lamps 2 in the switch show the heating level selected. Level Three indicator lamps on. After approximately five minutes, seat heating is automatically switched to level 2.
Page 107: Memory Function
Memory function* You can store up to three different settings per SmartKey. Prior to operating the vehicle, the driver should check and adjust the seat The following settings are stored when height, seat position fore and aft, and using the buttons on the driver’s door: seat backrest angle if necessary, to ensure adequate control, reach and comfort.
Page 108: Storing Positions Into Memory
Controls in detail Memory function* The memory button and memory position switch are located on the door. 1 Memory button 2 Memory position switch Switch on ignition ( page 33). Open the respective door. Storing positions into memory Adjust the seat, steering wheel and exterior rear view mirrors to the desired position ( page 35).
Page 109: Storing Exterior Rear View Mirror Parking Position
Storing exterior rear view mirror parking position For easier parking, you can adjust the passenger-side exterior rear view mirror so that you can see the right rear wheel as soon as you engage reverse gear R. For information on activating the parking position, see “Activating exterior rear view mirror parking position*”...
Page 110: Lighting
Relevant information can be obtained at your authorized Mercedes-Benz Center. Exterior lamp switch The exterior lamp switch is located on the dashboard to the left of the steering wheel.
Page 111 With the SmartKey removed from the starter switch and the driver’s door open, a warning sounds if the parking lamps or low beam headlamps are switched on. The message Switch off lights. appears in the multifunction display Manual headlamp mode The low beam headlamps and the parking lamps can be switched on and off with the exterior lamp switch.
Page 112 Controls in detail Lighting Daytime running lamp mode Turn the exterior lamp switch to position M or U. When the engine is running, the low beam headlamps are switched on. In low ambient light conditions, the following lamps will switch on additionally: Tail and parking lamps License plate lamps Side marker lamps...
Page 113 Locator lighting and night security illumination The locator lighting and the night security illumination are described in the “Control system” section, see “Setting locator light- ing” ( page 141) and “Setting night secu- rity illumination” ( page 141). Fog lamps Warning! In low ambient lighting or foggy conditions, only switch from position U to B with...
Page 114: Combination Switch
Controls in detail Lighting Rear fog lamp (driver’s side only) Switch on the front fog lamps ( page 111). Pull out the exterior lamp switch to second stop. The rear fog lamp switches on. The yellow indicator lamp † in the exterior lamp switch comes on ( page 108).
Page 115: Hazard Warning Flasher
Hazard warning flasher The hazard warning flasher can be switched on at all times, even with the SmartKey removed from the starter switch. The hazard warning flasher switches on automatically when an air bag deploys. The hazard warning flasher switch is located on the upper part of the center console.
Page 116: Interior Lighting
Controls in detail Lighting Interior lighting The controls are located in the overhead control panel. 1 Rear interior lights 2 Right front reading lamp 3 Rocker switch for automatic control system 4 Left front reading lamp Activating automatic control Press rocker switch 3 to center position.
Page 117: Door Entry Lamps
The setting selected for the interior lighting is used for the cargo compart- ment lighting as well. If you leave the tailgate open for an extended period of time, the cargo compartment lighting will switch off automatically after approximately ten minutes Switching rear interior lights on and off Press button V.
Page 118: Instrument Cluster
Controls in detail Instrument cluster For a full view illustration of the instrument cluster, see “At a glance” ( page 24). 1 Reset button The instrument cluster is activated when open a door switch on ignition press reset button 1 switch on the exterior lamps You can change the instrument cluster settings in the Instrument cluster submenu...
Page 119: Coolant Temperature Gauge
The engine should not be operated with the coolant temperature above 248°F (120°C). Doing so may cause serious en- gine damage which is not covered by the Mercedes-Benz Limited Warranty. Controls in detail Instrument cluster Trip odometer Make sure you are viewing the trip odometer and main odometer in the multifunction display ( page 119).
Page 120: Tachometer
Avoid driving at excessive engine speeds, as it may result in serious engine damage that is not covered by the Mercedes-Benz Limited Warranty. To help protect the engine, the fuel supply is interrupted if the engine is operated within the red marking.
Page 121: Control System
Control system The control system is activated as soon as the SmartKey in the starter switch is turned to position 1. The control system enables you to call up information about your vehicle change vehicle settings For example, you can use the control system to find out when your vehicle is next due for service, to set the language for messages in the instrument cluster...
Page 122: Multifunction Steering Wheel
Controls in detail Control system Multifunction steering wheel The displays in the multifunction display and the settings in the control system are controlled by the buttons on the multifunc- tion steering wheel. 1 Multifunction display Operating the control system 2 Selecting the submenu or setting the volume: Press button æ...
Page 123 It is helpful to think of the menus, and the functions within each menu, as being arranged in a circular pattern. If you press button è or ÿ repeatedly, you will pass through each menu one after the other. If you press button k or j repeatedly, you will pass through each function display, one after the other, in the current menu.
Page 124: Menus
Controls in detail Control system Menus This is what you will see when you scroll through the menus. The table on the next page provides an overview of the individual menus.
Page 125 Menus, submenus and functions Menu 1 Menu 2 Standard display AUDIO ( page 124) ( page 125) Digital speedometer Select radio or outside tempera- station ture Call up maintenance Select satellite service display radio station* (USA only) Check engine oil Operate the level CD player*...
Page 126: Standard Display Menu
Controls in detail Control system The headings used in the menus table are designed to facilitate navigation within the system and are not neces- sarily identical to those shown in the control system displays. The first function displayed in each menu will automatically show you which part of the system you are in.
Page 127: Press Button J Or K Repeatedly
Display digital speedometer or outside temperature Press button j or k repeatedly until the digital speedometer appears in the multifunction display. The current vehicle speed is shown in the multifunction display. 1 Digital speedometer AUDIO menu You can have the outside temperature The functions in the displayed instead of the digital the audio equipment which you currently...
Page 128 Controls in detail Control system Select radio station Turn on the radio ( page 178). Vehicles with COMAND*: Refer to separate operating instructions. Press button è or ÿ repeatedly until the currently tuned station appears in the multifunction display. 1 Waveband setting 2 Station frequency Press button k or j repeatedly Select satellite radio station*...
Page 129 Press button k or j repeatedly Operate the CD player* until the desired channel is found. Feature description is based on preliminary information available at time of printing. For more information on satellite radio operation, see “Introduction to satellite radio* (USA only)” ( page 188). Vehicles with COMAND*: Refer to separate operating instructions.
Page 130: Nav* Menu
Mercedes-Benz Center to address the malfunction and warning messages ( page 301). Press button è or ÿ repeatedly...
Page 131 No vehicle status messages If no conditions are recorded in memory, the message in the multifunction display No message Vehicle status messages have been recorded If conditions have occured causing status messages to be recorded, the number of messages appears in the multifunction display: 1 Number of messages Press button k or j.
Page 132: Settings Menu
Controls in detail Control system Settings menu In the Settings menu there are two functions: The function Reset to factory , with which you can reset all settings the settings to the original factory settings. A collection of submenus with which you can make individual settings for your vehicle.
Page 133 Submenus in the Settings menu Press button k or j. The collection of the submenus appears in the multifunction display. Press button ç. The selection marker moves to the next submenu. The submenus are arranged by hierarchy. Scroll down with button ç, scroll up with button æ.
Page 134 Controls in detail Control system The table below shows what settings can be changed within the various menus. Instrument cluster Time/Date Selecting temperature Time synchronization with head display mode unit* Selecting speedometer Setting the time (hours) display mode Selecting language Setting the time (minutes) Selecting display (speed Selecting time display mode...
Page 135 Instrument cluster submenu Access the Instr.Cl. submenu via the Settings menu. Use the Instr.Cl. submenu to change the instrument cluster display settings. The following functions are available: Function Page Selecting temperature display mode Selecting speedometer display mode Selecting language Selecting display (speed display or outside temperature) for status indicator Selecting temperature display mode...
Page 136 Controls in detail Control system Selecting language Move the selection marker with button æ or ç to the Instr.Cl. submenu. Press button j or k repeatedly until the message appears in Language the multifunction display. The selection marker is on the current setting.
Page 137 Time/Date submenu Access the Time/Date submenu via the Settings menu. Use the Time/Date submenu to change the instrument cluster display settings. The following functions are available: Function Page Time synchronization with head unit* Setting the time (hours) Setting the time (minutes) Selecting time display mode Selecting automatic time change (Daylight Saving Time (DST)
Page 138 Controls in detail Control system The selection marker is on the hour setting. Press button æ or ç to set the hour. Press the reset button in the instru- ment cluster ( page 116) to confirm. The hour is set and stored. Setting the time (minutes) This function can only be seen with audio system.
Page 139 Selecting time display mode Move the selection marker with button æ or ç to the Time/Date submenu. Press button j or k repeatedly until the message Clock display appears in the multifunction display. The selection marker is on the current setting.
Page 140 Controls in detail Control system The selection marker is on the month setting. Press button æ or ç to set the month. Setting the date (day) This function can only be seen with audio system. Vehicles with COMAND*: For information on setting the date, refer to the separate COMAND operating instructions.
Page 141 Setting the date (year) This function can only be seen with audio system. Vehicles with COMAND*: For information on setting the date, refer to the separate COMAND operating instructions. Move the selection marker with button æ or ç to the Time/Date submenu.
Page 142 Controls in detail Control system Setting daytime running lamp mode (USA only) This function is not available in countries where the daytime running lamp mode is mandatory and therefore in a constant mode. Move the selection marker with button æ or ç to the Lighting submenu.
Page 143 Setting locator lighting With the locator lighting feature activated and the exterior lamp switch in position U, the following lamps will switch on when the vehicle is unlocked with the SmartKey during darkness: Parking lamps Tail lamps License plate lamps Side marker lamps Front fog lamps The locator lighting switches off when the...
Page 144 Controls in detail Control system You can reactivate this function within ten minutes by opening a door. Move the selection marker with button æ or ç to the Lighting submenu. Press button j or k repeatedly until the message Hdlamp delay off appears in the multifunction display.
Page 145 Setting interior lighting delayed shut-off Use this function to set whether and how long you would like the interior lighting to remain lit during darkness after you have removed the SmartKey from the starter switch. Move the selection marker with button æ...
Page 146 Controls in detail Control system The selection marker is on the current setting. Press button æ or ç to switch the automatic central locking Convenience submenu Access the Convenience submenu via the Settings menu. Use the Convenience submenu to change the settings for a number of convenience features.
Page 147 Do not leave children unattended in the ve- hicle, or with access to an unlocked vehicle. Children could open the driver’s door and unintentionally activate the easy-entry/exit feature, which could result in an accident and/or serious personal injury. Move the selection marker with button æ...
Page 148: Trip Computer Menu
Controls in detail Control system Press button æ or ç to set key-dependency Setting parking position* for exterior rear view mirror Use the function Mirror set. parking aid to select whether the passenger-side exterior rear view mirror should be turned downward during parking maneuvers when reverse gear R is engaged.
Page 149 Fuel consumption statistics after start Press button ÿ or è repeatedly until the first function of the Trip computer menu appears in the multifunction display. Press button j or k repeatedly until the message appears After start in the multifunction display. 1 Distance driven since start 2 Time elapsed since start 3 Average speed since start...
Page 150: Tel Menu
Controls in detail Control system Resetting fuel consumption statistics Press button ÿ or è repeatedly until the first function of the Trip computer menu appears in the multifunction display. Press button j or k repeatedly until the reading that you want to reset appears in the multifunction display.
Page 151 Never operate radio transmitters equipped with a built-in or attached antenna (i.e. with- out being connected to an external antenna) from inside the vehicle while the engine is running. Doing so could lead to a malfunc- tion of the vehicle’s electronic system, pos- sibly resulting in an accident and/or personal injury.
Page 152 Controls in detail Control system Ending a call Press button t. You have ended the call. The standby message appears in the multifunction display. Dialing a number from the phone book If your telephone is ready to receive calls, you may select and dial a number from the phone book at any time.
Page 153 If you press and hold j or k for longer than one second, the system scrolls rapidly through the list of names until you release the button again. Cancel the quick search mode by pressing button t. Press button s. The system dials the selected phone number.
Page 154: Automatic Transmission
Controls in detail Automatic transmission For more information on driving with an automatic transmission, see “Automatic transmission” ( page 46). Your vehicle’s transmission adapts its gear shifting process to your individual driving style by continually adjusting the shift points up or down. These shift point adjust- ments are performed based on current operating and driving conditions.
Page 155 1 Current gear range/gear selector lever position 2 Current program mode The current gear range/gear selector lever position and program mode ( ) appear in the multifunction display. An additional indication of the current gear selector lever position can be found on the cover of the shifting-gate.
Page 156: One-Touch Gearshifting
Controls in detail Automatic transmission One-touch gearshifting Even with an automatic transmission you can change the gears manually when the gear selector lever is in position D. Downshifting Briefly press the gear selector lever to the left in the D- direction. The transmission will shift from the current gear to the next lower gear.
Page 157: Gear Ranges
Gear ranges With the gear selector lever in position D, you can limit the transmission’s gear range by pressing the gear selector lever to the left (D-), and reverse the gear range limit by pressing the gear selector lever to the right (D+).
Page 158: Gear Selector Lever Position
Controls in detail Automatic transmission Gear selector lever position Effect ì Park position Gear selector lever position when the vehicle is parked. Place gear selector lever in position P only when vehicle is stopped. The park position is not intended to serve as a brake when the vehicle is parked.
Page 159 P that is not covered by the is dangerous. Also, position P alone is not Mercedes-Benz Limited Warranty. intended to or capable of preventing your vehicle from moving, possibly hitting people or objects.
Page 160: Automatic Shift Program
Controls in detail Automatic transmission Automatic shift program The program mode selector switch is located on the lower part of the center console. 1 Program mode selector switch C Comfort For comfort driving S Sport For standard driving Never change the program mode when the gear selector lever is out of position P.
Page 161: Driving Tips
Driving tips Accelerator position Your driving style influences the transmission’s shifting behavior: Less throttle Earlier upshifting More throttle Later upshifting Kickdown Use kickdown when you want maximum acceleration. Press the accelerator past the point of resistance. The transmission shifts into a lower gear.
Page 162: (Limp Home Mode)
Move gear selector lever to P. Turn off the engine. Wait at least ten seconds before restarting. Restart the engine. Move gear selector lever to position D (for second gear) or R. Have the transmission checked at an authorized Mercedes-Benz Center as soon as possible.
Page 163: Good Visibility
Good visibility For information on the windshield wipers, see “Windshield wipers” ( page 50). Headlamp cleaning system* The switch is located on the left side of the dashboard. 1 Headlamp washer switch Switch on ignition ( page 33). Press switch 1. The headlamps are cleaned with a high-pressure water jet.
Page 164: Good Visibility
Controls in detail Good visibility Automatic antiglare rear view mirrors* The reflection brightness of the exterior rear view mirror on the driver’s side and the interior rear view mirror will respond automatically to glare when the ignition is switched on incoming light from headlamps falls on the sensor in the interior rear view mirror.
Page 165 Activating exterior rear view mirror parking position* Follow these steps to activate the mirror parking position so that the passenger-side exterior rear view mirror will be turned downward to the stored position. The buttons are located above the exterior lamp switch. 1 Driver’s side exterior rear view mirror button 2 Passenger-side exterior rear view...
Page 166: Sun Visors
Controls in detail Good visibility Sun visors The sun visors protect you from sun glare while driving. Warning! Do not use the vanity mirror while driving. Keep the mirrors in the sun visors closed while vehicle is in motion. Reflected glare can endanger you and others.
Page 167: Rear Window Defroster
Rear window defroster The rear window defroster uses a large amount of power. To keep the battery drain to a minimum, switch off the defroster as soon as the rear window is clear. The defroster is automatically deactivated after approximately 6 to 17 minutes of operation depending on the outside temperature.
Page 168 Controls in detail Climate control...
Page 169: Climate Control
Item 1 Left side defroster vent, fixed 2 Left side air vent, adjustable 3 Thumbwheel for air volume control for left side air vent 4 Thumbwheel for air volume control for left center air vent 5 Left center air vent, adjustable 6 Right center air vent, adjustable 7 Thumbwheel for air volume control for right center air vent...
Page 170 Controls in detail Climate control The climate control is operational when- ever the engine is running. You can oper- ate the climate control system in either the automatic or manual mode. The system cools or heats the interior depending on the selected interior temperature and the current outside temperature.
Page 171: Deactivating The Climate Control System
Deactivating the climate control system Deactivating Set air volume control 1 ( page 167) to position 0. When the air conditioning is switched off, the outside air supply and circula- tion are also switched off. Only choose this setting for a short time. Otherwise the windows could fog up.
Page 172: Volume
Controls in detail Climate control Adjusting air distribution and volume Use air distribution control 4 ( page 167) to adjust the air distribution. The following symbols are found on the controls: Symbol Function Directs air to the windshield and the side defroster vents Directs air into the entire vehicle interior Directs air to the footwells...
Page 173: Defrosting
Defrosting These settings should only be selected for a short time. Activating Press button P ( page 167). The indicator lamp on the button comes on. The air conditioning switches automatically to the following functions: maximum blowing and heating power air flows onto the windshield and the front side windows the air recirculation mode is...
Page 174 Controls in detail Climate control The closing of the side windows and tilt/sliding sunroof* can be reversed by again pressing and holding the , button. The air recirculation mode is activated automatically at high outside tempera- tures. The indicator lamp on the , button is not lit when the air recirculation mode is automatically switched on.
Page 175: Air Conditioning
CFCs which are harmful to the ozone layer. If the air conditioning cannot be turned on again, this indicates that the air conditioning is losing refrigerant. The compressor has turned itself off. Have the air conditioning checked at the nearest authorized Mercedes-Benz Center.
Page 176: Rear Passenger Compartment Adjustable Air Vents
Controls in detail Climate control Rear passenger compartment adjustable air vents The air conditioning for the rear passenger compartment is controlled via the climate control panel ( page 167). The temperature at the center air vents for the rear passenger compartment 1 and 3 is the same as at the dashboard center air vents.
Page 177: Audio System
Audio system Audio and telephone, operation These instructions are intended to help you become familiar with your Mercedes-Benz audio system. They con- tain useful tips and a detailed description of the user functions. Warning! In order to avoid distraction which could...
Page 178: Operating And Display Elements
Controls in detail Audio system Operating and display elements...
Page 179 Item Page 1 CD changer mode selector AUX mode selector 2 Single CD mode selector 3 Radio mode selector 4 Mute function (radio) Pause (CD) 5 Volume distribution 6 Sound settings 7 Display 8 Alphanumeric keypad Item Page 9 Speed dialing memory (telephone) in descending order a Accepting a call...
Page 180: Button And Soft Key Operation
Controls in detail Audio system Button and soft key operation In these instructions, the alphanumeric keypad (right side of radio panel) and the function buttons (left side of radio panel) are referred to as “buttons”. The four keys below the display panel are referred to as “soft keys”.
Page 181 Turn rotary control of N button. The volume will increase or decrease depending on the direction turned. If your vehicle equipment includes a Mercedes-Benz specified mobile telephone*, you can adjust its volume separately from the volume of the audio system while the telephone is being used.
Page 182 Controls in detail Audio system Adjusting treble Press O button repeatedly until TREBLE appears in the display. Press soft key to increase or – decrease tone level accordingly. Press soft key briefly to reset treble tones to their center level. The radio switches back to the standard radio menu eight seconds after the last soft key is pressed.
Page 183 Returning sound functions to factory settings Press O button to call up settings menu in the display. Press soft key briefly; the respec- tive sound function is reset to its center level. Press and hold soft key until RESET appears in the display. The sound settings for bass and treble are returned to their center level and the volume is set to a predefined level.
Page 184 Telephone* muting If your vehicle equipment includes a Mercedes-Benz specified mobile telephone*, you can adjust its volume separately from the volume of the audio system while the telephone is being used.
Page 185: Radio Operation
Feature description is based on preliminary information at time of printing. Contact an authorized Mercedes-Benz Center for availability. You can adjust the volume ( page 179), the sound settings ( page 179) and the volume distribution ( page 181) for the AUX input.
Page 186: Press * Button
Controls in detail Audio system Calling up wavebands for radios with SAT Press soft key repeatedly until desired waveband has been selected. The FM, AM and WB wavebands are called up one after another. The waveband currently selected appears in the upper left-hand corner of the display.
Page 187 You can only enter frequencies within the respective waveband. If a button is not pressed within four seconds, the radio will return to the last station tuned. Manual tuning Select desired waveband. Press S or T button for approx. three seconds. Press button repeatedly until desired frequency has been reached.
Page 188 Controls in detail Audio system Ending scan search soft key or S or T. Press The station last played will be selected and disappears from the display. Station memory You can store ten AM and ten FM stations in the memory. Storing stations Tune in desired station.
Page 189 Calling up stations Press desired station button 1 to R. Leaving the Autostore memory level Press soft key briefly. Interrupting radio mode The radio mode is interrupted by an incoming call on the telephone* ( page 205). Mute on Press U button. The radio mode is interrupted and MUTED appears in the display.
Page 190: Introduction To Satellite Radio* (Usa Only)
At time of printing, no date for the avail- ability of optional equipment required for satellite radio operation had been set. Contact an authorized Mercedes-Benz Center for details and availability for your vehicle. Note that categories and channels shown in illustrations are dependent on programming content delivered by the service provider.
Page 191 Satellite radio service may be unavail- able or interrupted from time to time for a variety of reasons, such as envi- ronmental or topographic conditions and other things beyond the service provider’s or our control. Service might also not be available in certain places (e.g., in tunnels, parking garages, or within or next to buildings) or near other technologies.
Page 192 Controls in detail Audio system The system will tune to a default station if no station had been selected previously. The first channel 001 is called up and the PTY system changes to All categories. If no station can be received, ACQUIRING appears in the display.
Page 193 Press *. Input line appears in the main radio menu. Use number keys to enter desired channel within eight seconds, e.g. 1 6. The system tunes to channel 16. The station you have selected begins to play. You can only enter available channel numbers.
Page 194 Controls in detail Audio system Tuning via scan search Scan search is characterized as follows: Scan search plays a channel for approx. eight seconds and then skips to the next channel within the current category. Scan search can be terminated manually.
Page 195: Cd Mode
Calling up the ESN information menu Press soft key. Press soft key. The twelve-digit electronic serial number (ESN) of the SAT tuner* installed in your vehicle is displayed. Press soft key to exit the menu. CD mode Safety precautions Warning! The single CD player and the CD changer* are Class 1 laser products.
Page 196 In certain situations, the CDs can then no longer be ejected and cause damage to the drive. Such damage is not covered by the Mercedes-Benz Limited Warranty. Your CD drive or CD changer has been designed to play CDs which correspond to the EN 60908 standard.
Page 197 Inserting a second CD in the slot with another CD still loaded will cause dam- age to the CD drive not covered by the Mercedes-Benz Limited Warranty. If a CD has been inserted incorrectly or cannot be read, will appear WRONG CD0 in the display.
Page 198 Controls in detail Audio system 1 CD 2 CD changer 3 CD tray 4 CD magazine Remove magazine 4 and pull CD tray 3 fully out. Place CD 1 in recess of tray, label side Push tray into magazine in direction of arrow.
Page 199 Playing tracks You have the following options: Audio system with CD changer*: selecting CDs Direct track entry Track skip forward/reverse Fast forward/reverse Scan Random tracks Repeat track Selecting CDs in the audio unit with CD changer* You can select from among the inserted CDs with buttons R to 6.
Page 200 Controls in detail Audio system The number of the track being played appears next to in the display. TRACK You can only enter available track numbers. Skipping tracks forward/backward Skipping tracks forward Press S button briefly. The next track will be played. Skipping tracks backward Press T button briefly.
Page 201 Switching on random Press soft key. appears in the display. A randomly selected track is played. Switching off random Press soft key again. Repeat The track being played is repeated until the repeat function is switched off. When you start the RPT function, the RDM function is automatically switched off.
Page 202: Gsm Network Phones
If your audio system is set up for telephone operation, the t symbol will appear in the display. When you insert your Mercedes-Benz specified mobile telephone* into the telephone cradle, you will be prompted to enter your PIN for 30 seconds ( page 201).
Page 203 PIN entry Enter PIN number using buttons 1 to R. If necessary, correct number entered with the soft key. Press soft key briefly to delete the last digit entered; press soft key and hold to delete the complete number. Press soft key after entering correct PIN.
Page 204 Controls in detail Audio system If necessary, correct number entered with the soft key. Press soft key briefly to delete the last digit entered; press soft key and hold to delete the complete number. After correct telephone number has been entered, press s button. If the telephone number has been saved together with a name in the telephone book, the name will appear...
Page 205 Press button ‚ or ƒ repeatedly until desired entry has been reached. The stored entries are selected in alphabetical order with the sub-entries. Several sub-entries can be stored for each main entry (name). These entries are marked by a corresponding abbreviation that appears in the upper left-hand corner of the display.
Page 206 Controls in detail Audio system Speed dial If you have stored telephone numbers as speed dial numbers in your telephone, you can also enter these with buttons 1 to R on the radio head unit. Press desired button 1 to R briefly.
Page 207 Accepting an incoming call If the telephone is active in the background (reception symbol is visible in the display), the audio source is muted when an incom- ing call is received. A ringing tone can be heard and the caller’s telephone number, or the name under which the telephone number has been saved in the phone book, appears in the display.
Page 208: Tdma Or Cdma Network Phones
Terminating a combined call operation, the t symbol will appear in Press t button. the display. When you insert your Mercedes-Benz The connection to both callers is specified mobile telephone* into the terminated. telephone cradle, you will be prompted to enter your PIN for 30 seconds ( page 207).
Page 209 Switching on the telephone Switching on the telephone Press h button. If you have programmed an unlock code for the telephone, you must now enter the code. Enter code using buttons 1 to R. If necessary, correct number entered with the soft key.
Page 210 Controls in detail Audio system If necessary, correct number entered with the soft key. Press soft key briefly to delete the last digit entered; press soft key and hold to delete the complete number. After correct telephone number has been entered, press s button. If the telephone number has been saved together with a name in the phone book, the name will appear in...
Page 211 Press button ‚ or ƒ repeatedly until desired entry has been reached. The stored entries are selected in alphabetical order with the sub-entries. Several sub-entries can be stored for each main entry (name). These entries are marked by a corresponding abbreviation that appears in the upper left-hand corner of the display.
Page 212 Controls in detail Audio system Speed dial If you have stored telephone numbers as speed dial numbers in your telephone, you can also enter these with buttons 1 to R on the radio unit. Press desired button 1 to R briefly.
Page 213 Accepting an incoming call If the telephone is active in the background (reception symbol is visible in the display), the audio source is muted when an incom- ing call is received. A ringing tone can be heard and the caller’s telephone number, or the name under which the telephone number has been saved in the telephone book, appears in the display.
Page 214 Controls in detail Audio system Switching between calls Press s button. This switches between the calls. The non-active call is kept on hold. Terminating a call Press t button. The current call is terminated. The connection to the caller previously kept on hold is also interrupted;...
Page 215: Emergency Calls "911
Emergency calls “911” The following describes how to dial a “911” emergency call using the audio system head unit when a Mercedes-Benz specified mobile phone* is inserted in the phone cradle*. Unless otherwise specified, the descriptions refer to the audio system head unit.
Page 216 Controls in detail Audio system Placing a “911” emergency call using audio head unit with the phone unlocked Press h button to switch to telephone operation. Enter 911 using the number keypad on the audio head unit. Press s button for dialing to begin. DIALING appears in the audio display while the telephone establishes the...
Page 217: Power Windows
Power windows Opening and closing the windows The side windows can be opened and closed electrically. The switches for all the side windows are on the driver’s door. The switches for the respective windows are on the front passenger door and the rear doors.
Page 218 Controls in detail Power windows You can also open or close the windows using the SmartKey (summer opening/convenience closing feature) ( page 217). You can close and reopen the windows using the air recirculation button , in the climate control panel ( page 167).
Page 219 Warning! If the upward movement of the window is blocked during the closing Driver’s door only: procedure, the window will stop and If within five seconds you again pull the open slightly. switch past the resistance point and Remove the obstruction, pull the release, the automatic reversal will not switch again past the resistance point function.
Page 220: Synchronizing Power Windows
Controls in detail Power windows Aim transmitter eye at the driver’s door handle. Opening (Summer opening feature) Press and hold button Œ after unlocking the vehicle. The windows and tilt/sliding sunroof* begin to open after approximately one second. Release the Œ button to stop procedure.
Page 221: Adjusting Air Distribution And Power Tilt/Sliding Sunroof
Power tilt/sliding sunroof* Opening and closing the power tilt/sliding sunroof The tilt/sliding sunroof can be opened and closed electrically. The switch for the tilt/sliding sunroof is on the overhead control panel. Sunroof switch 1 Push up to raise sunroof at rear 2 Pull down to lower sunroof at rear 3 Push forward to slide sunroof closed 4 Push back to slide sunroof open...
Page 222 Controls in detail Power tilt/sliding sunroof* When leaving the vehicle, always remove the SmartKey from starter switch, and lock your vehicle. Do not leave children unattended in the vehicle, or with access to an unlocked vehicle. Unsupervised use of vehicle equip- ment can cause an accident and/or serious personal injury.
Page 223 Stopping the power tilt/sliding sunroof during Express-operation Move the sunroof switch in any direction. If the movement of the tilt/sliding sunroof is blocked during the closing procedure, the tilt/sliding sunroof will stop and reopen slightly. Opening and closing the tilt/sliding sunroof with the SmartKey The power windows ( page 217) will also be opened or closed when you operate the...
Page 224: Synchronizing The Power Tilt/Sliding Sunroof
Controls in detail Power tilt/sliding sunroof* Closing (Convenience feature) Press and hold button ‹ after locking the vehicle. The windows and the tilt/sliding sunroof begin to close after approximately one second. Release the ‹ button to stop procedure. Make sure all side windows and the tilt/sliding sunroof are properly closed before leaving the vehicle.
Page 225: Rear Passenger Compartment Driving Systems
Driving systems The driving system of your vehicle is described on the following pages: Cruise control, with which the vehicle can maintain a preset speed For information on the BAS, ABS and ESP driving systems, see “Driving safety sys- tems” ( page 79). Cruise control Cruise control automatically maintains the speed you set for your vehicle.
Page 226 Controls in detail Driving systems 1 Sets current or higher speed 2 Sets current or lower speed 3 Cancels cruise control 4 Resumes at last set speed Setting current speed Accelerate or decelerate to the desired speed. Briefly lift 1 or depress 2 the cruise control lever.
Page 227 Setting a higher speed Lift cruise control lever to position 1 and hold it up until the desired speed is reached. Release cruise control lever. The new speed is set. Depressing the accelerator pedal does not deactivate cruise control. After brief acceleration (e.g.
Page 228: Loading
Controls in detail Loading Roof rack* Warning! Only use roof racks approved by Mercedes-Benz for your vehicle model to avoid damage to the vehicle. Follow manu- facturer’s installation instructions. Attach the roof rack only to the roof rails. Secure the roof rack according to manufacturer’s instructions for...
Page 229: Storage Compartment Under Cargo Compartment Floor
1 Rail 2 Mounting lug Removal of parcel net Slide rails 1 upward and remove. Installation of parcel net Place mounting lugs 2 in opening. Slide rails 1 down as far as they can Storage compartment under cargo compartment floor To open cargo compartment floor Press handle 1 on the recess.
Page 230: Retractable Luggage Cover And Partition Net
Controls in detail Loading Retractable luggage cover and partition net The twin-reel roller blind comprises a lug- gage cover and a partition net. It is mount- ed on the backrest of the rear seat and can also be used with backrest folded down. Partition net Warning! To help avoid personal injury during a colli-...
Page 231 Luggage cover Closing Pull luggage cover back by handle 1 until it locks into position. Opening Press handle 1 down and release. The luggage cover retracts automati- cally. With the luggage cover rolled up, fold the lip down. Twin-reel roller blind 1 Twin-reel roller blind 2 Guide rail Retract the partition net and luggage...
Page 232: Split Rear Bench Seat
Controls in detail Loading Split rear bench seat To expand the cargo compartment, you can fold down the left and right rear seat backrests. The two sections can be folded down separately. Warning! When expanding the luggage compartment, always fold the seat cushions fully forward and always use the partition net when trans- porting cargo.
Page 233 Returning the backrest to original position Pull release lever 4. Fold backrest 5 forward. With the twin-reel roller blind installed: When folding the backrest forward, fold the right section first and then the left section. If only the left section is to be folded, first remove the twin-reel roller blind ( page 229).
Page 234: Loading Instructions
Controls in detail Loading Warning! If a red indicator is visible with the backrest up, then the backrest is not properly locked into position. Always lock backrest in its upright position when rear seat bench is occupied, or the extended cargo compartment is not in use. Check for secure locking by pushing and pulling on the backrest.
Page 235: Cargo Tie-Down Rings
Warning! Always fasten items being carried as secure- ly as possible. In an accident, during hard braking or sud- den maneuvers, loose items will be thrown around inside the vehicle and can cause in- jury to vehicle occupants unless the items are securely fastened in the vehicle.
Page 236: Useful Features
Controls in detail Useful features Storage compartments Warning! To help avoid personal injury during a colli- sion or sudden maneuver, exercise care when stowing objects in the vehicle. Put lug- gage or cargo in the cargo compartment if possible. Do not pile luggage or cargo higher than the seat backs.
Page 237 Armrest storage compartments 1 Handle 2 Button, passenger side 3 Button, driver’s side Do not store any items between the telephone holder and the cover for the blower. Otherwise these items could be damaged when the holder is closed. Use the space in the front door pocket for stowing.
Page 238 Controls in detail Useful features Armrest in the rear passenger compartment Pull the top of the armrest out and fold it down. Cup holders in front of seat armrest Warning! When not in use, keep the cup holder closed. Place only containers that fit into the cup holder to prevent spills.
Page 239 Turning the swiveling cup holder outward Turn the cup holder in the direction of arrow 2 until it engages. You can now use both cup holders. Turning the swiveling cup holder inward and sliding it in Turn the cup holder in the direction of arrow 3 until it engages.
Page 240: Ashtrays
Controls in detail Useful features Opening cup holder Briefly press the front of cup holder 1. The cup holder slides out slightly. Pull out the cup holder until it stops. Closing cup holder Slide cup holder 1 in until it engages. Parcel net in front passenger footwell A small convenience parcel net is located in the front passenger footwell.
Page 241: Cigarette Lighter
Reinstalling the ashtray insert Push the ashtray insert 3 down into the retainer until it engages. Push down cover plate 1 to close ashtray. The cover plate engages. Rear seat ashtray 1 Button 2 Ashtray insert 3 Cover Pull at top of cover 3. Removing ashtray insert Push button 1 to disengage ashtray insert 2 and remove it.
Page 242: Electrical Outlet
Controls in detail Useful features Warning! Never touch the heating element or sides of the lighter; they are extremely hot. Hold the knob only. When leaving the vehicle, always remove the SmartKey from the starter switch, and lock your vehicle. Do not leave children unat- tended in the vehicle, or with access to an unlocked vehicle.
Page 243: Telephone
The external antenna must be approved by Mercedes-Benz. Please contact an autho- rized Mercedes-Benz Center for informa- tion on the installation of an approved external antenna. Refer to the radio trans- mitter operation instructions regarding use of an external antenna.
Page 244: Tele Aid
Controls in detail Useful features Tele Aid* The initial activation of the Tele Aid system may only be performed by completing the subscriber agreement and placing an acquaintance call using the ¡ button. Failure to complete either of these steps will result in a system that is not activated.
Page 245 If a malfunction is indicated as outlined above, the system may not operate as expected. Have the system checked at the nearest Mercedes-Benz Center as soon as possible. Controls in detail Useful features...
Page 246 Controls in detail Useful features A voice connection between the Response Center and the occupants of the vehicle will be established automatically soon af- ter the emergency call has been initiated. The Response Center will attempt to determine more precisely the nature of the emergency provided they can speak to an occupant of the vehicle.
Page 247 Located below the center armrest cover is the Roadside Assistance button •. Press and hold button (for longer than two seconds). A call to a Mercedes-Benz Roadside Assistance dispatcher will be initiated. The button will flash while the call is in progress. The message...
Page 248: Information Button
Assistance Center representative and the occupants of the vehicle will be established. Information regarding the operation of your vehicle, the nearest Mercedes-Benz Center or Mercedes-Benz USA products and services is available to you. For more details concerning the Tele Aid system, please visit www.mbusa.com and...
Page 249 Tele Aid system has detected a malfunction or the service is not currently active, and may not initiate a call. Visit your Mercedes-Benz Center and have the system checked or contact the Response Center at 1-800-756-9018 (in the USA) or 1-888-923-8367 (in Canada) as soon as possible.
Page 250 The Response Center will then unlock your vehicle with the remote door unlocking feature. Contact the Mercedes-Benz Response Center at 1-800-756-9018 (in the USA) or 1-888-923-8367 (in Canada). You will be asked to provide your pass- word which you provided when you completed the subscriber agreement.
Page 251: Garage Door Opener
HomeLink Pass this number on to the You can program the signal transmitter Mercedes-Benz Response Center along buttons. with your password issued to you when you subscribed to the service. The Response Center will then attempt to covertly contact the vehicle’s...
Page 252 Certain types of garage door openers are incompatible with the integrated opener. If you should experience difficulties with programming the transmitter, contact an authorized Mercedes-Benz Center, or call Mercedes-Benz Customer Assistance Center (in the USA only) at 1-800-FOR-MERCedes, or Customer Service (in Canada) at...
Page 253 Programming or reprogramming the integrated remote control For operation in the USA only: This device complies with Part 15 of Step 1: the FCC Rules. Operation is subject to the following two conditions: Step 2: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including...
Page 254 Controls in detail Useful features The indicator lamp 1 flashes the first time the signal transmitter button is programmed. If this button has already been programmed, the indicator lamp will only start flashing after 20 seconds. Step 5: When the indicator lamp 1 flashes rapidly, release both buttons.
Page 255 Step 9: Press “training” button on the garage door opener motor head unit. The “training light” is activated. You have 30 seconds to initiate the following step. Step 10: Firmly press, hold for two seconds and release the programmed integrated signal transmitter button (2, 3 or 4).
Page 256 Controls in detail Useful features Operation of integrated remote control Switch on ignition ( page 33). Select and press the appropriate integrated signal transmitter button (2, 3 or 4) to activate the remote controlled device. The integrated remote control trans- mitter continues to send the signal as long as the button is pressed –...
Page 257: Operation
Operation The first 1000 miles (1500 km) Driving instructions At the gas station Engine compartment Tires and wheels Winter driving Maintenance Vehicle care...
Page 258: The First 1000 Miles (1500 Km)
Operation The first 1000 miles (1500 km) In the “Operation” section you will find detailed information on operating, main- taining and caring for your vehicle. The more cautiously you treat your vehicle during the break-in period, the more satis- fied you will be with its performance later Drive your vehicle during the first 1000 miles (1500 km) at varying but moderate vehicle and engine speeds.
Page 259: Driving Instructions
Have all maintenance work performed at the intervals specified in the Maintenance Booklet and as required by the maintenance service display. Contact an authorized Mercedes-Benz Center. Fuel consumption is also increased by driving in cold weather, in stop-and-go traffic, on short trips and in hilly country.
Page 260: Brakes
Contact an authorized Mercedes-Benz Center. Only install brake pads and brake fluid rec- ommended by Mercedes-Benz. Warning! If other than recommended brake pads are installed, or other than recommended brake fluid is used, the braking properties of the vehicle can be degraded to an extent that safe braking is substantially impaired.
Page 261: Driving Off
ESP switched off. Doing so may cause serious damage to the drivetrain which is not covered by the Mercedes-Benz Limited Warranty. Simultaneously depressing the accelerator pedal and applying the brake reduces engine performance and causes premature brake and drivetrain wear.
Page 262: Tires
Inspect the tires and the vehicle underbody for possible damage. If the vehicle or tires appear unsafe, have it towed to the nearest Mercedes-Benz Center or tire dealer for repairs. Treadwear indicators (TWI) are required by law. These indicators are located in six...
Page 263: Tire Traction
If ice has formed on the road, tire traction will be substantially reduced. Under such weather conditions, drive, steer and brake with extreme caution. Mercedes-Benz recommends M+S rated radial-ply tires with a minimum tread depth of approximately in (4 mm) on all four wheels for the winter season to ensure normal balanced handling characteristics.
Page 264: Winter Driving Instructions
Operation Driving instructions Winter driving instructions The most important rule for slippery or icy roads is to drive sensibly and to avoid abrupt acceleration, braking and steering maneuvers. Do not use the cruise control system under such conditions. When the vehicle is in danger of skidding, move gear selector lever to position N.
Page 265: Standing Water
Operation Driving instructions Driving abroad Abroad, there is an extensive Mercedes-Benz service network at your disposal. If you plan to drive into areas which are not listed in the index of your Mercedes-Benz Center directory, you should request pertinent information from...
Page 266: Control And Operation Of Radio Transmitter
Refer to the radio transmitter operation instructions regarding use of an external antenna. Catalytic converter Your Mercedes-Benz is equipped with monolithic-type catalytic converters, an important element in conjunction with the oxygen sensors to achieve substantial control of the pollutants in the exhaust emissions.
Page 267: Emission Control
Any adjustments on the engine should, therefore, be carried out only by qualified Mercedes-Benz Center authorized techni- cians. Engine adjustments should not be altered in any way. Moreover, the specified service jobs must be carried out regularly according to Mercedes-Benz servicing requirements.
Page 268: Coolant Temperature
The engine should not be operated with the coolant temperature above 248°F (120°C). Doing so may cause serious engine damage which is not covered by the Mercedes-Benz Limited Warranty. Warning! Driving when your engine is badly overheated can cause some fluids, which may have leaked into the engine compartment, to catch fire.
Page 269: At The Gas Station
At the gas station Refueling Warning! Gasoline is highly flammable and poisonous. It burns violently and can cause serious injury. Whenever you are around gasoline, avoid inhaling fumes and skin contact, extinguish all smoking materials. Never allow sparks, flame or smoking materials near gasoline! Warning! Flexible Fuel Vehicles only (identified by a...
Page 270 Operation At the gas station Open the fuel filler flap by pushing at the point indicated by arrow 1. The fuel filler flap springs open. Turn fuel cap counterclockwise and hold on to it until possible pressure is released. Take off cap and set it in direction of arrow 2 in the recess on fuel filler flap.
Page 271: Check Regularly And Before A Long Trip
Notify an authorized Mercedes-Benz Center immediately. Do not add brake fluid as this will not solve the problem. For more information, see “Practical hints”...
Page 272: Engine Compartment
Operation Engine compartment Hood Warning! Do not pull the release lever while the vehicle is in motion. Otherwise the hood could be forced open by passing air flow. Opening The hood lock release lever is located to the left of the steering wheel under the dashboard.
Page 273 Warning! If you see flames or smoke coming from the engine compartment, or if the coolant tem- perature display indicates that the engine is overheated, do not open the hood. Move away from vehicle and do not open the hood until the engine has cooled.
Page 274: Engine Oil
Do not use any special lubricant addi- tives, as these may damage the drive assemblies. Using special additives not approved by Mercedes-Benz will restrict your warranty entitlement. More information on this subject is available at any Mercedes-Benz Center.
Page 275 Mercedes-Benz Center. Excess oil must be siphoned or drained off. It could cause damage to the engine and catalytic converter not covered by the Mercedes-Benz Limited Warranty. More information on messages in the display concerning engine oil can be found in the “Practical hints”...
Page 276: Transmission Fluid Level
Maintenance System (U.S. vehicles) or FSS (Canada Vehicles) will result in engine damage not covered by the Mercedes-Benz Limited Warranty. 1 Filler cap Unscrew filler cap 1 from filler neck.
Page 277: Coolant Level
Coolant level The engine coolant is a mixture of water and anticorrosion/antifreeze. To check the coolant level, the vehicle must be parked on level ground and the engine must be cool. The coolant expansion tank is located on the passenger side of the engine compart- ment.
Page 278: Battery
When replacing the battery, always use batteries approved by Mercedes-Benz. If you do not intend to operate your vehicle for an extended period of time, consult an authorized Mercedes-Benz Center about steps you need to observe.
Page 279: Windshield Washer System And Headlamp Cleaning System
Windshield washer system and headlamp cleaning system* The windshield washer reservoir is located in the engine compartment. 1 Washer fluid reservoir cap Fluid for the windshield washer system and the headlamp cleaning system* is supplied from the windshield washer reservoir. It has a capacity of: 3.2 US qt (3.0 l) in vehicles without headlamp cleaning system*...
Page 280: Tires And Wheels
When replacing rims, only use genuine Mercedes-Benz wheel bolts specified for the particular rim type. Failure to do so can result in the bolts loosening and possibly an accident.
Page 281: Life Of Tire
Life of tire The service life of a tire is dependent upon varying factors including but not limited to: Driving style Tire pressure Distance driven Warning! Tires and spare tire should be replaced after six years, regardless of the remaining tread. Keep unmounted tires in a cool, dry place with as little exposure to light as possible.
Page 282 Operation Tires and wheels The pressures listed for light loads are minimum values offering high driving comfort. Increased inflation pressures listed for heavier loads may also be used for light loads. These higher pressures produce favorable handling characteristics. The ride of the vehicle, however, will be somewhat harder.
Page 283: Rotating Tires
Wheels could become loose if not tightened with a torque of 80 lb-ft (110 Nm). Only use genuine Mercedes-Benz wheel bolts specified for your vehicle's rims. For information on wheel change, see the “Practical hints” section ( page 321) and...
Page 284: Winter Driving
Operation Winter driving Before the onset of winter, have your vehicle winterized at an authorized Mercedes-Benz Center. This service includes: Check of anticorrosion and antifreeze concentration. Addition of cleaning concentrate to the water of the windshield and headlamp cleaning system. Add MB Concentrate “S”...
Page 285: Block Heater (Canada Only)
Snow chains should only be used on the rear wheels. Follow the manufac- turer's mounting instructions. Only use snow chains that are approved by Mercedes-Benz. Your authorized Mercedes-Benz Center will be glad to advise you on this subject. Use of snow chains may be prohibited depending on location.
Page 286: Maintenance
We strongly recommend that you have your vehicle serviced by an authorized Mercedes-Benz Center, in accordance with the Maintenance Booklet at the times called for by the maintenance service indicator display.
Page 287: Clearing The Maintenance Service Indicator
Service A exceeded by XX Days Service A exceeded by XX Miles In addition, a signal sounds when the message appears. Any authorized Mercedes-Benz Center will reset the maintenance service indicator following a completed maintenance service. Operation Maintenance...
Page 288: Resetting The Maintenance Service Indicator
Resetting the maintenance service indicator In the event that the maintenance service on your vehicle is not carried out by an authorized Mercedes-Benz Center, you can have the maintenance service indicator reset. The automotive maintenance facility carrying out the maintenance service will...
Page 289: Vehicle Care
Post-production treatment is neither necessary nor recommended by Mercedes-Benz because of the possibility of incompatibility between materials used in the production process and others applied later.
Page 290 We have selected car-care products and compiled recommendations which are specially matched to our vehicles and which always reflect the latest technology. You can obtain Mercedes-Benz approved car-care products at an authorized Mercedes-Benz Center. Scratches, corrosive deposits, corrosion or damage due to negligent or incorrect care cannot always be removed or repaired with the car-care products recommended here.
Page 291 Vehicle washing Do not use hot water or wash your vehicle in direct sunlight. Only use a mild car wash detergent, such as Mercedes-Benz approved Car Shampoo. Thoroughly spray the vehicle with a dif- fused jet of water. Direct only a very weak spray towards the ventilation intake.
Page 292 If released, the force of the impact from the tensioning spring could crack the windshield. Light alloy wheels Mercedes-Benz approved Wheel Care should be used for regular cleaning of the light alloy wheels. If possible, clean wheels once a week with...
Page 293 Steering wheel and gear selector lever Wipe with a damp cloth and dry thoroughly or clean with Mercedes-Benz approved Leather Care. Cup holders Use a gentle dishwashing detergent or mild detergent for delicate fabrics as a washing solution. Wipe with a cloth moist- ened in lukewarm solution.
Page 294 Clean with soft bristle brush, or use a dry-shampoo cleaner in case of excessive dirt. MB Tex upholstery Pour Mercedes-Benz approved Interior Care onto soft lint-free cloth and apply with light pressure. Plastic and rubber parts Do not use oil or wax on these parts.
Page 295: Practical Hints
Practical hints What to do if … Where will I find ...? Unlocking/locking in an emergency Opening/closing in an emergency Replacing SmartKey batteries Replacing bulbs Replacing wiper blades Flat tire Battery Jump starting Towing the vehicle Fuses...
Page 296: What To Do If
Read and observe messages in the display ( page 301). Have the system checked at an autho- rized Mercedes-Benz Center as soon as possible. Failure to follow these instructions increases the risk of an accident. Switch off electrical consumers that are currently not needed, e.g.
Page 297 Practical hints What to do if … Release the parking brake ( page 47). Risk of accident! Carefully stop the vehicle and notify an authorized Mercedes-Benz Center. Do not add brake fluid! This will not solve the problem.
Page 298 Suggested solution There is a malfunction in: Have the vehicle checked as soon as possible by an authorized The fuel management Mercedes-Benz Center. system An on-board diagnostic connector is The ignition system used by the service station to link the...
Page 299 If it is closed properly: Have the fuel system checked by an authorized Mercedes-Benz Center. Your fuel tank is empty. After refuelling start, turn off and restart the engine three or four times in succession.
Page 300 Suggested solution Switch the ESP back on ( page 81). If the ESP cannot be switched back on, have the system checked at an autho- rized Mercedes-Benz Center as soon as possible. When driving off, apply as little throttle as possible.
Page 301 SRS may not be operational. For your safety, we strongly recommend that you visit an autho- rized Mercedes-Benz Center immediately to have the system checked; otherwise the SRS may not be activated when needed in...
Page 302: Lamp In Center Console
The system is malfunctioning. Have the system checked as soon as possible by an authorized Mercedes-Benz Center. Make sure there is nothing between seat cushion and child seat and check installation of the child seat.
Page 303: Vehicle Status Messages In The Multifunction Display
Mercedes-Benz Center. Failure to repair condition noted may cause damage not covered by the Mercedes-Benz Limited Warranty, or result in property damage or personal injury. Practical hints What to do if …...
Page 304 Continue driving with added caution. Wheels may lock during hard braking, reducing steering capability. Have the system checked at an authorized Mercedes-Benz Center as soon as possible. Continue driving with added caution. Wheels may lock during hard braking, reducing steering capability.
Page 305 If necessary, have the generator and battery checked. Continue driving with added caution. Have the system checked at an authorized Mercedes-Benz Center as soon as possible. Continue driving with added caution. Have the system checked at an authorized Mercedes-Benz Center as...
Page 306 When the voltage is above this value again, the ESP is operational again. Continue driving with added caution. Visit an authorized Mercedes-Benz Center as soon as possible. Continue driving with added caution. If necessary, have the generator and battery checked.
Page 307 Failure to follow these instructions increases the risk of an accident. The system is malfunctioning. Mercedes-Benz Center immediately to have the system checked; otherwise the SRS may not be activated when needed in an accident, which could result in serious or...
Page 308 Do not continue to drive. Otherwise the engine will overheat due to an inoperative water pump which may result in damage to the engine. Notify an authorized Mercedes-Benz Center. Drive immediately to the nearest authorized Mercedes-Benz Center. Start the engine ( page 46).
Page 309 ( page 47). Have the brake pads replaced as soon as possible. Risk of accident! Stop the vehicle and notify an authorized Mercedes-Benz Center. Do not add brake fluid! This will not solve the problem. Brake pad thickness must be visually...
Page 310 Do not ignore the low engine coolant level warning. Extended driving with the message and symbol displayed may cause serious engine damage not covered by the Mercedes-Benz Limited Warranty. Do not drive without sufficient amount of coolant in the cooling system. The engine will overheat causing major engine damage.
Page 311 Only start the engine again after the message disappears. You could otherwise damage the engine. The engine should not be operated with the coolant temperature above 248°F (120°C). Doing so may cause serious engine damage which is not covered by the Mercedes-Benz Limited Warranty.
Page 312 Do not continue to drive the vehicle with this message displayed. Doing so could result in serious engine damage that is not covered by the Mercedes-Benz Limited Warranty. Observe the coolant temperature gauge in the instrument cluster ( page 24).
Page 313 Cruise control display You are attempting to drive with one or more doors open. Practical hints What to do if … Visit an authorized Mercedes-Benz Center. Continue driving with added caution. Visit an authorized Mercedes-Benz Center as soon as possible.
Page 314 Practical hints What to do if … Display symbol Display messages USA only: At next gas station add 1.0 qt engine oil Canada only: At next gas station add 1.0 l engine oil Engine oil level Stop, engine off! Engine oil level Reduce oil level Change engine oil Visit workshop.
Page 315 Have the measuring system checked by an authorized Mercedes-Benz Center. The engine oil level warnings should not be ignored. Extended driving with the symbol displayed could result in serious engine damage that is not covered by the Mercedes-Benz Limited Warranty.
Page 316 No additional code available for SmartKey. Check the fuel cap ( page 267). Close the fuel cap. Have the fuel system checked by an authorized Mercedes-Benz Center. Close the hood ( page 270). Remove the SmartKey from the starter switch. Change the SmartKey.
Page 317 The right front side marker lamp is malfunctioning. Practical hints What to do if … Visit an authorized Mercedes-Benz Center as soon as possible. Replace the bulb as soon as possible. Replace the bulb as soon as possible. Visit an authorized Mercedes-Benz Center as soon as possible.
Page 318 In the control system, set lamp operation to manual ( page 140). Switch on the headlamps using the exterior lamp switch ( page 108). Visit an authorized Mercedes-Benz Center as soon as possible. Replace the bulb as soon as possible. Visit an authorized Mercedes-Benz...
Page 319 A substitute bulb is being used. Practical hints What to do if … Replace the bulb as soon as possible. Visit an authorized Mercedes-Benz Center as soon as possible. Replace the bulb as soon as possible. Replace the bulb as soon as possible.
Page 320 A substitute bulb is being used. Replace the bulb as soon as possible. Replace the bulb as soon as possible. Visit an authorized Mercedes-Benz Center as soon as possible. Visit an authorized Mercedes-Benz Center as soon as possible. Replace the bulb as soon as possible.
Page 321 Do not add steering oil without checking the steering system. Do not drive the vehicle. Have the system checked at an authorized Mercedes-Benz Center as soon as possible. Possible cause Possible solution The seat belt system is malfunctioning.
Page 322 The fluid level has dropped to about of total reservoir capacity. Close the tilt/sliding sunroof ( page 219). Close the tilt/sliding sunroof ( page 219). Have the Tele Aid system* checked by an authorized Mercedes-Benz Center. Close the tailgate. Add washer fluid ( page 277).
Page 323: Where Will I Find
Where will I find ...? First aid kit The first aid kit is located in the storage compartment behind the left trim panel. Press button 1. Fold down panel 2. Vehicle tool kit The vehicle tool kit is located in the storage compartment behind the left trim panel.
Page 324 Practical hints Where will I find ...? 3 Vehicle tool kit The following is included: Towing eye bolt Wheel wrench Alignment bolt Vehicle jack Spare wheel bolts Fuse extractor Spare fuses Collapsible wheel chock A pair of gloves Vehicle jack Warning! The jack is designed exclusively for jacking up the vehicle at the jack take-up brackets...
Page 325 Operational position Turn crank handle clockwise until it engages (operational position). Before storing the vehicle jack in its compartment: It should be fully collapsed. The handle must be folded in (storage position). Setting up the collapsible wheel chock The collapsible wheel chock serves to additionally secure the vehicle, e.g.
Page 326: Minispare Wheel
Practical hints Where will I find ...? Minispare wheel The Minispare wheel is located in the storage compartment underneath the cargo compartment floor. Removing the Minispare wheel Lift up cargo compartment floor cover. 1 Storage box Remove storage box 1. 2 Retaining screw 3 Minispare wheel Loosen retaining screw 2 by turning it...
Page 327 In the case of a flat tire, you may temporarily use the Minispare wheel when observing the following restrictions: Do not exceed a vehicle speed of 50 mph (80 km/h). Drive to the nearest tire repair facility to have the flat tire repaired or replaced as appropriate.
Page 328: Unlocking/Locking In An Emergency
Practical hints Unlocking/locking in an emergency Unlocking the vehicle If you are unable to unlock the vehicle with the SmartKey, open the driver’s door using the mechanical key and the tailgate using the emergency release. Removing the mechanical key 1 Mechanical key locking tab 2 Mechanical key Move locking tab 1 in direction of arrow.
Page 329: Locking The Vehicle
Remove cover 2 from the trim on the Locking the vehicle tailgate. If you are unable to lock the vehicle with Push release lever 1 all the way to the the SmartKey, do the following: right. Lift the tailgate. Always make sure there is sufficient overhead clearance.
Page 330: Fuel Filler Flap
Practical hints Unlocking/locking in an emergency Fuel filler flap In case the central locking system does not release the fuel filler flap, you can open it manually. Warning! If you operate the emergency release button, be careful of the sharp edges so that you do not injure yourself.
Page 331: Opening/Closing In An Emergency
Opening/closing in an emergency Power tilt/sliding sunroof* You can open or close the tilt/sliding sunroof manually should an electrical malfunction occur. The tilt/sliding sunroof drive is located behind the lens 1 of the interior overhead light. Remove SmartKey from the starter switch.
Page 332: Replacing Smartkey Batteries
Many states require sellers of batteries to accept old batteries for recycling. When inserting the batteries, make sure they are clean and free of lint. When replacing batteries, always replace both batteries. The required replacement batteries are available at any Mercedes-Benz Center.
Page 333: Smartkey
SmartKey Replacement batteries: Lithium, type CR 2025 or equivalent. Remove the mechanical key ( page 326). 1 Mechanical key 2 Battery compartment Insert mechanical key 1 in side opening and push grey slide. Battery compartment 2 is unlatched. Pull battery compartment 2 out of the housing in direction of arrow.
Page 334: Replacing Bulbs
Correct headlamp adjustment is extremely important. Have headlamps checked and readjusted at regular intervals and when a bulb has been replaced. See an authorized Mercedes-Benz Center for headlamp adjustment. Bulbs If the headlamps or front fog lamps are fogged up on the inside as a result of...
Page 335 Low and high beam D2S-35 W Vehicles with Bi-Xenon* headlamps: Low beam and high beam use the same D2S-35W lamp. Do not replace the Xenon bulbs yourself. See an authorized Mercedes-Benz Center. Lamp Type 4 Halogen headlamp: High beam/high beam...
Page 336: Replacing Bulbs
Your hands should be dry and free of oil and grease. If the newly installed bulb does not come on, visit an authorized Mercedes-Benz Center. Have the LEDs and bulbs for the following lamps replaced by an authorized Mercedes-Benz Center:...
Page 337: Replacing Bulbs For Front Lamps
Replacing bulbs for front lamps Before you start to replace a bulb for a front lamp, do the following first: Turn the exterior lamp switch to position M ( page 108). Open the hood ( page 270) (except for side marker lamps). Halogen headlamp 1 Housing cover for low beam headlamp 2 Housing cover for high beam head-...
Page 338 Practical hints Replacing bulbs High beam bulb Press the clamp on housing cover 2 and remove it. Pull the electrical connector off. Turn bulb socket 5 counterclockwise and take out the bulb. Insert the new bulb so that its socket locates in the recess of the lamp housing.
Page 339 Bi-Xenon* headlamp Warning! Do not remove the cover 1 for the Bi-Xenon headlamp. Because of high voltage in Bi-Xenon lamps, it is dangerous to replace the bulb or repair the lamp and its compo- nents. We recommend that you have such work done by a qualified technician.
Page 340 Practical hints Replacing bulbs Front turn signal lamp bulb Turn bulb socket 3 with the bulb counterclockwise and remove it. Press gently onto the bulb and turn it counterclockwise out of bulb socket 3. Press new bulb gently into bulb socket 3 and turn clockwise until it engages.
Page 341: Replacing Bulbs For Rear Lamps
Replacing bulbs for rear lamps Before you start to replace a bulb for a rear lamp, do the following first: Turn the exterior lamp switch to position M ( page 108). Open the tailgate ( page 94). Tail lamp unit 1 Latch 2 Trim panel Press latch 1 on the corresponding...
Page 342 Practical hints Replacing bulbs Bulb carrier 4 Brake lamp bulb 5 Turn signal lamp bulb 6 Backup lamp bulb 7 Rear fog lamp (driver’s side only), tail, parking, standing and side marker lamp bulb Press gently onto the respective bulb License plate lamp and turn counterclockwise out of its bulb socket.
Page 343: Replacing Wiper Blades
Make certain that the wiper blades are properly installed. Improperly installed wiper blades may cause windshield damage. For your convenience, we recommend that you have this work carried out by an authorized Mercedes-Benz Center.
Page 344: Flat Tire
50 mph (80 km/h). Drive to the nearest Mercedes-Benz Center as soon as possible to have the Minispare wheel replaced with a regular road wheel. Never operate the vehicle with more than one Minispare wheel mounted.
Page 345 Lifting the vehicle Prevent the vehicle from rolling away by blocking wheels with wheel chocks or other sizable objects. One wheel chock is included with the vehicle tool kit ( page 322). When changing wheel on a level surface: Place the wheel chock in front of and another sizable object behind the wheel that is diagonally opposite to the wheel being changed.
Page 346 Practical hints Flat tire The jack take-up brackets are located directly behind the front wheel housings and in front of the rear wheel housings. 1 Take-up bracket 2 Jack Place jack 2 on firm ground. Position jack 2 under take-up bracket 1 so that it is always vertical (plumb-line) as seen from the side, even if the vehicle is parked on an...
Page 347 Never apply oil or grease to wheel bolts. Damaged wheel hub threads should be repaired immediately. Do not continue to drive under these circumstances! Contact an authorized Mercedes-Benz Center or call Roadside Assistance. Incorrect wheel bolts or improperly tight- ened wheel bolts can cause the wheel to come off.
Page 348 Unscrew the alignment bolt, install last wheel bolt and tighten slightly. Warning! Only use genuine equipment Mercedes-Benz wheel bolts. Other wheel bolts may come loose. Do not tighten the wheel bolts when the vehicle is raised. Otherwise the vehicle could fall of the jack.
Page 349: Battery
Have the battery checked regularly by an authorized Mercedes-Benz Center. Refer to Maintenance Booklet for main- tenance intervals or contact an autho- rized Mercedes-Benz Center for further information. Warning! Do not place metal objects on the battery as this could result in a short circuit.
Page 350: Disconnecting The Battery
Practical hints Battery Warning! With a disconnected battery you will no longer be able to turn the SmartKey in the starter switch the gear selector lever will remain locked in position P 1 Negative terminal 2 Positive terminal cover Disconnecting the battery Turn off the engine ( page 57).
Page 351: Reconnecting The Battery
Reconnecting the battery Turn off all electrical consumers. Remove SmartKey from starter switch. Connect the battery positive lead and fasten its cover 2. Connect the battery negative lead. NEVER invert the terminal connections. Reinstall the filter box ( page 347). The battery, its filler caps and the vent tube must always be securely installed when the vehicle is in operation.
Page 352: Jump Starting
(12 V). Jump starting with a more powerful battery could damage the vehicle’s electrical system, which will not be covered by the Mercedes-Benz Limited Warranty. Only use jumper cables with sufficient cross-section and insulated terminal clamps. Always make sure the jumper cables...
Page 353 Remove the jumper cables first from negative terminals 4 and 3 and then from positive terminals 1 and 2. You can now turn on the lights. Have the battery checked at the near- est authorized Mercedes-Benz Center. Do not tow-start the vehicle.
Page 354: Towing The Vehicle
Practical hints Towing the vehicle Mercedes-Benz recommends that the vehicle be transported with all wheels off the ground using flatbed or appropriate wheel lift/dolly equipment. This method is preferable to other types of towing. Use flatbed or wheel lift/dolly equip- ment with the SmartKey in the starter switch turned to position 0.
Page 355: Towing The Vehicle
Warning! To be certain to avoid a possibility of damage to the drivetrain, however, we If circumstances require towing the vehicle recommend the drive shaft be discon- with all wheels on the ground, always tow nected at the rear axle drive flange with a tow bar if: (vehicles with 4MATIC: disconnected at the front and rear axle drive flanges) for...
Page 356 Practical hints Towing the vehicle Warning! With the engine not running, there is no power assistance for the brake and steering systems. In this case, it is important to keep in mind that a considerably higher degree of effort is necessary to brake and steer the ve- hicle.
Page 357: Installing Towing Eye Bolt
Installing towing eye bolt 1 Cover on right side of front bumper. 2 Cover on right side of rear bumper. Practical hints Towing the vehicle Removing cover Press mark on cover 1 or 2 in direction of arrows. Lift cover off to reveal threaded hole for towing eye bolt.
Page 358: Fuses
( page 357): Fuse chart Spare fuses Fuse extractor Warning! Only use fuses approved for Mercedes-Benz with the specified amperage for the system in question. Otherwise, a short circuit could result and cause a fire. Only install fuses that have been tested...
Page 359: Aids For Changing Fuses
Aids for changing fuses Fuse chart The fuse chart is found in the main fuse box in the passenger compartment ( page 357). The amperages of the fuses are also given there. Spare fuses Spare fuses are found in the vehicle tool kit in the cargo compartment ( page 359).
Page 360: Fuse Box In Engine Compartment
Practical hints Fuses Fuse box in engine compartment The fuse box is located in the engine compartment on the driver’s side. 1 Cover 2 Screws 3 Retainer Removing cover Twist screws 2 90° counterclockwise. Lift the rear of cover 1. Slide out retainer 3 and remove cover 1 by pulling towards front.
Page 361: Fuse Box In Cargo Compartment
Fuse box in cargo compartment The fuse box is located in the cargo compartment behind the left hand trim panel. 1 Button for unlocking trim panel 2 Trim panel Opening trim panel Press button 1. Fold down trim panel 2. 3 Fuse extractor 4 Fuse box 5 Spare fuses...
Page 363: Technical Data
Technical data Parts service Warranty coverage Identification labels Layout of poly-V-belt drive Engine Rims and Tires Electrical system Main Dimensions Weights Fuels, coolants, lubricants, etc. Consumer information...
Page 364: Parts Service
Mercedes-Benz vehicles. Therefore, genuine Mercedes-Benz parts should be installed. The use of non-genuine Mercedes-Benz parts and accessories not authorized by Mercedes-Benz could damage the vehicle, which is not covered by the Mercedes-Benz Limited Warranty, or could compromise the vehicle’s...
Page 365: Warranty Coverage
Emission System Warranty Emission Performance Warranty California, Maine, Massachusetts, and Vermont Emission Control Systems Warranty Replacement parts and accessories are covered by the Mercedes-Benz Parts and Accessories warranties, copies of which are available at any Mercedes-Benz Center. Technical data Warranty coverage...
Page 366: Identification Labels
Technical data Identification labels 1 Certification label 2 Vehicle Identification Number (VIN) 3 Emission control information label, includes both federal and California certification exhaust emission standards 4 Engine number (engraved on engine) 5 VIN, visible (lower edge of windshield) 6 Vacuum line routing diagram label When ordering parts, please specify vehicle identification and engine numbers.
Page 367: Layout Of Poly-V-Belt Drive
Technical data Layout of poly-V-belt drive Layout of poly-V-belt drive C 240 (all models) 1 Automatic belt tensioner 2 Power steering pump 3 Air conditioning compressor 4 Crankshaft 5 Coolant pump 6 Generator (alternator) 7 Idler pulley...
Page 368: Engine
Maximum engine speed Firing order Poly-V-belt The quoted data apply only to the standard vehicle. See an authorized Mercedes-Benz Center for the corresponding data of all special bodies and special equipment. Premium fuel required. Performance may vary with fuel octane rating.
Page 369: Rims And Tires
Rims and Tires Only use tires and rims which have been specifically developed for your vehicle and tested and approved by Mercedes-Benz. Other tires and rims can have detrimental effects, such as poor handling characteristics increased noise increased fuel consumption...
Page 370: Same Size Tires
Technical data Rims and Tires Same size tires Model C 240 (all models) Rims (light alloy) 7 J x16 H2 Wheel offset 1.22 in (31 mm) All-season tires (radial-ply tires) 205/55 R16 91H Summer tires (radial-ply tires) Winter tires (radial-ply tires) 205/55 R16 91H M+S...
Page 371: Minispare Wheel
Minispare wheel Model C 240 (all models) Rim (steel) 3.5 B x16 H2 Wheel offset 0.67 in (17 mm) Tire T 125/90 R16 98M Must not be used with snow chains. Technical data Rims and Tires...
Page 372: Electrical System
Technical data Electrical system Model C 240 (all models) Generator (alternator) 14 V/120 A Starter motor 12 V/1.7 kW Battery 12 V/100 Ah Spark plugs Bosch F 8 DPP 332 NGK PFR 5 R-11 Electrode gap 0.039 in (1.0 mm) Tightening torque 15 –...
Page 373: Main Dimensions
Main Dimensions Model C 240 (all models) Overall vehicle length 179.0 in (4546 mm) Overall vehicle width 68.0 in (1728 mm) Overall vehicle height 57.8 in (1467 mm) Wheelbase 106.9 in (2715 mm) Track, front 59.3 in (1505 mm) Track, rear 58.1 in (1476 mm) Technical data Main Dimensions...
Page 374: Weights
Technical data Weights Roof load max. 220 lb (100 kg)
Page 375: Fuels, Coolants, Lubricants, Etc
0.5 US qt (0.5 l) MB Brake Fluid (DOT 4+) approx. 6.8 US qt (6.4 l) MB 325.0 Anticorrosion/Antifreeze Agent Technical data Fuels, coolants, lubricants, etc. Please refer to the Factory Approved Service Products pamphlet, or inquire at your Mercedes-Benz Center.
Page 376 Technical data Fuels, coolants, lubricants, etc. Model Fuel tank including a reserve of Air conditioning system Windshield washer Windshield washer and headlamp cleaning system* Use MB Windshield Washer Concentrate “S” and water for temperatures above freezing point or MB Windshield Washer Concentrate “S” and commercially available premixed windshield washer solvent/antifreeze for temperatures below freezing point.
Page 377: Engine Oils
System (U.S. vehicles) or FSS (Canada vehicles). For a listing of approved engine oils and oil filters, refer to the Factory Approved Service Products pamphlet, or contact an authorized Mercedes-Benz Center. Using engine oils and oil filters of specification other than those expressly required for the Maintenance System (U.S.
Page 378: Premium Unleaded Gasoline
Technical data Fuels, coolants, lubricants, etc. Premium unleaded gasoline To maintain the engine’s durability and performance, premium unleaded gaso- line must be used. If premium unleaded is not available and low octane fuel is used, follow these precautions: Have the fuel tank only partially filled with unleaded regular and fill up with premium unleaded as soon as possible.
Page 379: Gasoline Additives
In areas where carbon deposits may be encountered due to lack of availability of gasolines which contain these additives, Mercedes-Benz recommends the use of additives approved by us for use on Mercedes-Benz vehicles. Refer to Factory Approved Service Products pamphlet for a listing of approved product(s).
Page 380 E85 compared to gasoline operation. Use of E85 may reduce your driving range. Maintenance Please inform your Mercedes-Benz Center if you use or have used E85 fuel when your vehicle is delivered for maintenance or repairs.
Page 381: Coolants
The replacement interval published in the Maintenance Booklet is only applicable if MB 325.0 anticorrosion/antifreeze solution or other Mercedes-Benz approved products of equal specification (see Factory Approved Service Products pamphlet) are used to renew the coolant concentration or bring it back up to the proper level.
Page 382 Before the start of the winter season (or once a year in hot southern regions), you should have the anticorrosion/antifreeze concentration checked. The coolant is also regularly checked each time you bring your vehicle to an authorized Mercedes-Benz Center for service.
Page 383: Windshield Washer And Headlamp Cleaning System
Windshield washer and headlamp cleaning system* Both the windshield washer and headlamp cleaning system* are supplied from the windshield washer fluid reservoir. The washer fluid reservoir has a capacity of approx.: 3.2 US qt (3.0 l) in vehicles without headlamp cleaning system* 6.4 US qt (6.0 l) in vehicles with headlamp cleaning system* Refill the reservoir with MB Windshield...
Page 384: Consumer Information
Technical data Consumer information The following text is published as required of all manufacturers of passenger cars under Title 49, Code of U.S. Federal Regulations, Part 575 pursuant to the “National Traffic and Motor Vehicle Safety Act of 1966”. Uniform tire quality grading Quality grades can be found, where applicable, on the tire sidewall between tread shoulder and maximum section...
Page 385 Temperature The temperature grades are A (the highest), B, and C, representing the tire’s resistance to the generation of heat and its ability to dissipate heat when tested under controlled conditions on a specified indoor laboratory test wheel. Sustained high temperature can cause the material of the tire to degenerate and reduce tire life, and excessive temperature can lead to sudden...
Page 387: Technical Terms
The system will automatically deacti- vate the passenger front air bag when such a seat is properly installed (the 56 indicator lamp located in the center console comes on). See an authorized Mercedes-Benz Center for availability. BabySmart is a trademark of Siemens Automotive Corp.
Page 388 Technical terms COMAND* (Cockpit Management and Data System) Information and operating center for vehicle sound and communications systems, including the radio and the navigation system, as well as other optional equipment (CD changer*, telephone*, etc.). Control system The control system is used to call up vehicle information and to change component settings.
Page 389 Engine speeds within the red marking of the tachometer dial. Avoid this engine speed range, as it may result in serious engine damage that is not covered by the Mercedes-Benz Limited Warranty. Poly-V-belt drive Drives engine-components (alternator, AC compressor, etc.) from the engine.
Page 390 Technical terms Power train Collective term designating all components used to generate and transmit motive power to the drive axles, including engine clutch/torque converter transmission transfer case drive shaft differential axle shafts/axles Program mode selector switch Used to switch the automatic trans- mission between standard operation S and comfort operation C.
Page 391 (radio, CD, etc.). Feature description is based on preliminary infor- mation at time of printing. At time of printing, no date for availability of voice control had been set. Contact an authorized Mercedes-Benz Center for details and availability for your vehicle model.
Page 393: Index
ABS 79, 385 ABS control 79 Indicator lamp 25 Malfunction indicator lamp 294 Messages in display 302 Accelerator position, automatic transmission 159 Accident In case of 54 Activating Air conditioning (cooling) 173 Air recirculation mode 171 Anti-theft alarm system* 86 Central locking (control system) 143 Climate control 167 Climate control system 169...
Page 394 Index Mirrors 41 Multicontour seat* 103 Placing upright rear seat head restraints 101 Power seat* 38 Rear seat head restraints 100 Seat belt height 45 Seat cushion depth 103 Seat cushion tilt, manual seat 36 Seat cushion tilt, power seat* 38 Seat fore and aft adjustment, manual seat 36 Seat fore and aft adjustment,...
Page 395 Antilock Brake System see ABS Anti-theft alarm system* Arming 86 Canceling alarm 86 Disarming 86 Anti-theft systems 85 Anti-theft alarm system* 85 Immobilizer 85 Tow-away alarm* 87 Aquaplaning see Hydroplaning Armrest Changing inclination of 235 Storage spaces 235 Armrest in rear passenger compartment 236 Ashtrays 238 ATF 274...
Page 396 Index BabySmart Air bag deactivation system 72, 385 Compatible child seats 72, 385 Self-test 72 Backrest Folding forward 230 Folding rearward 231 Backrest contour Adjusting 103 Backrest side bolsters Adjusting 103 Backrest tilt Manual seat 36 Power seat* 38 Backup lamps Messages in display 315 Replacing bulbs 333 BAS 80, 385...
Page 397 Standing lamps, front 333, 336, 338 Standing lamps, rear 333, 340 Tail lamp unit 339 Tail lamps 333, 340 Turn signal lamps, front 333, 336, 338 Turn signal lamps, rear 333, 340 Button Audio system 178 CAC 385 California Important notice 11 Calling up Maintenance service indicator 285 Range (distance to empty) 148...
Page 398 Index Checking Brake fluid 269 Coolant level 269, 275 Engine oil level 269, 272 Tire inflation pressure 269 Vehicle lighting 269 Washer reservoir level 269 Child safety 69 Air bags 62 Infant and child restraint systems 66, 69 LATCH-type child seat anchors 75 Child safety switch see Blocking of rear door window operation Child seat anchors see...
Page 399 Control system 119, 386 AUDIO menu 125 Convenience submenu 144 Display digital speedometer 125 Display outside temperature 125 Functions 120, 123 Instrument cluster submenu 133, 135 Lighting submenu 139 Menus 122, 123 Multifunction display 119 Multifunction steering wheel 120 NAV* menu 128 Selecting radio system 126 Selecting satellite radio* system 126 Settings menu 130...
Page 400 Index Deactivating Air conditioning (cooling) 173 Air recirculation mode 172 Alarm 86 Anti-theft alarm system* 86 Central locking (control system) 143 Climate control 167 Climate control system 169 Cruise control 224 Defrosting 171 Engine with the SmartKey 57 ESP 82 Exterior lamps 109 Exterior lamps delayed shut-off 141 Hazard warning flasher 113...
Page 401 Doors Message in display 311 Opening from inside vehicle 93 Opening from the outside 91 Downhill driving Cruise control 224 Downshifting 154 Drink holder see Cup holders Drinking and driving 257 Driving Driving abroad 263 General instructions 43, 257 Hydroplaning 260 In winter 262 Problems 54 Safety systems 79...
Page 402 Index Engine Compartment 270 Starting with automatic transmission 47 Starting with the SmartKey 47 Technical data 366 Turning off with the SmartKey 57 Engine cleaning 289 Engine compartment 270 Fuse box in 358 Hood 270 Engine malfunction indicator lamp 25, 296 Engine number 364, 386 Engine oil 272 Adding 274...
Page 403 Fog lamps, front Messages in display 315 Replacing bulbs 333 Switching on 111 Four wheel electronic traction system (4MATIC) with ESP 84 4MATIC 84 Front air bags 65 Front fog lamps Indicator lamp 108 Switching on 111 Front lamps Bi-Xenon* type 337 Halogen-type 335 Messages in display 315–318 Replacing bulbs 333, 335...
Page 404 Index Fuse chart 357 Fuse extractor 357 Fuses 356 Aids for changing fuses 357 Fuse box in cargo compartment 359 Fuse box in engine compartment 358 Fuse chart 357 Fuse extractor 357 Main fuse box in passenger compartment 357 Spare fuses 357 Garage door opener* 249 Gasoline additives 377 Gasoline see Fuel...
Page 405 Headlamps Automatic control 109 Bi-Xenon* 385 Bi-Xenon* type Replacing bulbs 337 Cleaning 289 Cleaning system* 161, 277, 381 Halogen-type, replacing bulbs 335 Refilling washer fluid 277 Switching off 56 Switching on 49 Washer fluid 381 Headliner and shelf below rear window Cleaning 291 Heated seats* 104 Height adjustment...
Page 406 Index Installing Infant and child restraint systems 74 Parcel net in cargo compartment 227 Towing eye bolt 355 Twin-reel roller blind 229 Wiper blades 341 Instrument cluster 24, 116, 387 Cleaning 290 Coolant temperature gauge 117 Illumination 116 Lamps in 294–299 Multifunction display 119 Outside temperature indicator 118 Selecting language 134...
Page 407 Labels, identification 364 Lamp bulbs, exterior 332 Lamp sensor Message in display 316 Lamps, exterior Front 333 Light sensor 316 Messages in display 315–318 Rear 333 Lamps, indicator and warning ABS 25, 294 Battery (SmartKey) 91 Brakes 25, 295 Engine diagnostics 296, 299 Engine malfunction 25, 296–297 ESP 25, 298 Front fog lamps 108...
Page 408 Index Loading 226 Cargo tie-down rings 233 Instructions 232 Roof rack* 226 Split rear bench seat 230 Locator lighting 111 Setting 141 Lock button 387 Locking 55, 90 Automatic while driving 95 Centrally from inside 96 Fuel filler flap 267 Global, SmartKey 91 Glove box 234 Vehicle in an emergency 327...
Page 409 MB Tex upholstery Cleaning 292 Mechanical key 326 Memory TV station 192 Memory function* 105, 387 Recalling positions from memory 106 Storing exterior rear view mirror parking position 107 Storing key dependent settings 106 Menus 120 AUDIO 125 In control system 122, 123 NAV* 128 Settings menu 130 Standard display 124...
Page 410 Index ESP 304–305 Fuel cap 297, 314 Hood 314 Key, SmartKey 314 Lamps, exterior 315–318 Oil 312–313 Parking brake 307 Restraint system 305 Seat belt system 319 SRS 305 Steering gear oil level 319 Tailgate 320 Tele Aid* 320 Telephone* 320 Tilt/sliding sunroof* 320 Windshield washer fluid 320 Multifunction steering...
Page 411 Operating Audio system 175 CD player* 127 COMAND* see separate operating instructions Navigation system* 128 Radio 126 Radio transmitters 264 Satellite radio* 126 Telephone* 148, 175, 200 Vehicle outside the USA and Canada 13 Operating safety Audio system 175 Operator’s Manual 10 Ornamental moldings 289 Outer seats Rear seat head restraints 100, 102...
Page 412 Index Playing CDs 196 Poly-V-belt drive 387 Layout 365 Positions (Memory function*) Recalling from memory 106 Storing into memory 106 Power assistance 257 Power seat* Adjusting backrest tilt 38 Adjusting head restraint height 38 Adjusting head restraint tilt 39 Adjusting seat cushion tilt 38 Adjusting seat height 38 Memory function* 105 Removing/installing front...
Page 413 Rear fog lamp 333 Bulb 333 Indicator lamp 108 Switching on 112 Rear lamp bulbs Replacing 339 Rear lamps Messages in display 315–318 Rear lamps see Tail lamps Rear outer seats Adjusting head restraint height 100 Rear passenger compartment, adjustable air vents 174 Rear seat ashtray 239 Rear seat head restraints 100 Adjusting 100...
Page 414 Index Side marker lamp bulbs, front 338 Side marker lamp bulbs, rear 340 Standing lamp bulbs, front 336, 338 Standing lamp bulbs, rear 340 Tail lamp bulbs 340 Turn signal lamp bulbs, front 336, 338 Turn signal lamp bulbs, rear 340 Wiper blades 341 Reporting Safety defects 18...
Page 415 Seats 97 Adjusting 35 Easy entry/exit feature* 97 Heating* 104 Manual seat 36 Multicontour seat* 103 Power seat* 38 Split rear bench seat 230 Securing cargo Cargo tie-down rings 233 Selecting Automatic time change (Daylight Saving Time (DST) summer/winter) 137 Display for status indicator 134 station (satellite radio) 190 Selecting radio mode 183...
Page 416 Index Setting current speed 224 Setting the temperature 169 Settings Convenience functions 144 Factory, SmartKey 91 Individual, SmartKey 145 Lighting (control system) 139 Menus and submenus 121 Resetting all (control system) 130 Resetting in the submenu 131 Selective, SmartKey 91 Settings menu Functions in 130 Individual vehicle settings 130...
Page 417 Spare wheel bolts For Minispare wheel 325 Speed Setting current 224 Speed settings Cruise control 225 Speedometer 25 Settings units 133 Speedometer display mode Selecting 133 Split rear bench seat 230 SRS 68, 388 Indicator lamp 25, 299 Message in display 305 Standing lamps, front Replacing bulbs 333 Standing lamps, rear...
Page 418 Index Lighting 139 Resetting functions in Control system 131 Selecting 131 Settings menu 131 Time/Date 135 Vehicle 143 Substitute lamps Bulbs 332 Sun visors 164 Supplemental Restraint System see SRS Switching Fuel (Flexible fuel vehicle) 378 Switching off Audio system 178 Automatic central locking (control system) 143 Delayed (exterior lamps) 141...
Page 419 Fuel requirements 376 Fuels 373, 374 Gasoline additives 377 Lubricants 373 Main dimensions 371 Premium unleaded gasoline 376 Rims and tires 367 Weights 372 Windshield washer 374 Windshield washer and headlamp cleaning* system 374, 381 Tele Aid* 242 Emergency calls 243 Hands-free microphone 29 Information 246 Initiating an emergency...
Page 420 Index Tire inflation pressure Checking 269, 279 Tire speed rating 261, 389 Tire traction 261 Tires 278, 367 Consumer information 382 Direction of rotation 279 Driving instructions 260 Retreads 278 Rims and tires 367 Rotating 281 Service life 279 Temperature 280 Temperature grades 383 Traction 382 Tread depth 282...
