Deltran Battery Tender Junior Instructions Manual

BATTERY TENDER® JUNIOR
Single Voltage Output Battery Chargers
DC Output Current: 0.750 Amp
The best way to eliminate sulfation is to prevent it!
®
The Battery Tender Junior will fully charge a battery and maintain it at
the proper storage voltage without the damaging effects caused by most
trickle chargers (especially sulfation). This trickle charger has a brain!
S S ™ Charging Technology
UPER MART
4-STEP CHARGING (Initialization, Bulk, Absorption, Float)
SPARK PROOF
SHORT CIRCUIT PROTECTED
REVERSE POLARITY PROTECTED
5 YEAR WARRANTY !! (Material & Workmanship Only)
ORDERING INFORMATION
Deltran PART NO. DESCRIPTION
021-0123 12 Volt 0.750 Amp Output
021-0127 6 Volt 0.750 Amp Output
081-0148-25 Optional 25 ft. 2-pin Output Extension Leads
MSRP $39.95 U.S.D.
12 Volt or 6 Volt
Note: The economical Battery Tender
Junior is designed to accommodate the
demanding charging requirements of high
quality lead-acid batteries and should
safely charge all lead acid battery types.
Always check with the battery
manufacturer to get the most complete
charging recommendations that are
consistent with your application.
TECHNICAL SPECIFICATIONS SUMMARY
Input Voltage & Frequency
DC OUTPUT (Nominal voltage & current values)
Output Current
Output Voltage
Charger Output Voltage Amplitudes throughout the entire charge
algorithm, including absorption and float maintenance, are
consistent with the optimum charging recommendations of the
major lead-acid battery manufacturers.
Maximum Operating Temperature
Charger Case Dimensions 3.3 in (85 mm) L x 2.3 in (59 mm) W x 1.9 in (48 mm) H
Shipping Weight with Cable Accessories
Declaration of Conformity: These battery charger products are
designed to meet or exceed the specific requirements for the
following safety compliance standards: UL-1236 & CSA 22.2
These products are UL Listed in File E206016, Volume 2.
Design Conformance & Revision: All Deltran charger products are 100%
inspected and electrically tested prior to shipment. All Deltran battery
charger designs are proprietary and subject to change without notice.
Deltran makes no specific claims nor does it either make or imply any
specific guarantee or warranty with respect to either the physical
configuration or performance of any of the battery charger products listed
herein, including suitability for purpose or merchantability.
801 International Speedway Blvd.
DeLand, Florida 32724
Phone: 386-736-7900 FAX 386-736-0379
www.batterytender.com
120 VAC, 60 Hz
0.750 Amps
12 Volts or 6 Volts
50 °C Typical
2.0 lbs (0.9 kg)
CORPORATION
