Operation and Maintenance Instructions
Pressure resistant electric water heater
with control panel of the series
EKA
Wall-mounted storage tank with 3 connecting pieces
EKR
Wall-mounted storage tank with heat exchanger
EWH
Wall-mounted storage tank with one heating element
EKL
Wall-mounted storage tank horizontal
Please pass to the user
Id.Nr.: 228843-13
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for AE EKR
Summary of Contents for AE EKR
- Page 1 Operation and Maintenance Instructions Pressure resistant electric water heater with control panel of the series Wall-mounted storage tank with 3 connecting pieces Wall-mounted storage tank with heat exchanger Wall-mounted storage tank with one heating element Wall-mounted storage tank horizontal Please pass to the user Id.Nr.: 228843-13...
- Page 2 Electric water heater EKA, EKR, EWH, EKL Dear client! You have decided to purchase a water heating product with electric storage tank manu- factured by Austria Email. Thank you for your trust. You have purchased an elegantly shaped device that represents the state of the art, that is in conformity with the applicable rules and regulations and that has been safety tested by ÖVE (Austrian Electrotechnical Association).
-
Page 3: Table Of Contents
Electric water heater EKA, EKR, EWH, EKL Table of contents ..........Page Function .......................4 Hot water requirement ................4 Energy saving ....................5 Standby energy consumption of the individual series ......5 4.1 Series EWH, EKA, EKR ..............5 4.2 Series EKL ..................5 Operation .....................5 Temperature setting ..................6... -
Page 4: Function
CFC-free PU foam insulation), the heating will switch on until the preset storage water temperature is reached again. If the storage tank is equipped with a heater battery (EKR), the water may be heated with the system’s water heater as an alternative to electrical heating. -
Page 5: Energy Saving
All operating elements required for the operation of the electric storage tanks (EWH, EKA, EKR) (button to adjust the temperature controller) and monitoring elements (operation indi- cator lamp and thermometer) are included in a control panel on the front wall of the device. -
Page 6: Temperature Setting
Electric water heater EKA, EKR, EWH, EKL 6. Temperature setting For easier adjustment, the button to adjust the temperature controller of the electric heater has 4 main settings. These are: Setting: Protects the storage tank against freezing (up to 30 °C) ... -
Page 7: Thermometer
Austria Email AG or to observe a maximum operating temperature of approximately 65°C (setting “Pos. ”). The bare-tube heat exchanger of the EKR series must be flushed properly before the initial installation is performed. If the bare-tube heat exchanger is not used, the outer tube ends must be sealed to prevent back-cooling. -
Page 8: Installation And Safety Advice
(only 50 - 150 litres). Caution: Do not use any other hook than the hook provided by AE! d) With regard to the installation of the device, it is necessary to observe the dimensioned dra- wings of the device and the enclosed indicating labels, if any. -
Page 9: Dimensioned Drawing
Electric water heater EKA, EKR, EWH, EKL 11. Dimensioned drawing 11.1 Series EWH, EKA, EKR Dimensions in mm Nominal Weight Type content Variety A changeable in kg in litres from Wall-mounted storage tank 400 - 550 400 - 550 Wall-mounted storage tank... - Page 10 Electric water heater EKA, EKR, EWH, EKL Installation on a ceiling Wall-mounted storage tank with reater battery Heating ow Thin wall suspension Cable entry Heating return Id.Nr.: 228843-13...
-
Page 11: Series Ekl
Electric water heater EKA, EKR, EWH, EKL 11.2 Series EKL Dimensions in mm Nominal content Weight Type Variety in litres in kg Horizontal storage tank Horizontal storage tank Horizontal storage tank 1056 Horizontal storage tank 1256 Horizontal storage tank 1000... -
Page 12: Schematic Drawing Of The Device
Electric water heater EKA, EKR, EWH, EKL 12. Schematic drawing of the device PU insulation Outer jacket Height-adjustable hook Enamelled interior tank Hot water pipe Sensor tube Heater Heater battery (only EKR) Magnesium anode Control panel with thermometer Lower wall bracket... -
Page 13: Water Connection
Electric water heater EKA, EKR, EWH, EKL 13. Water connection 13.1 Pressure resistant connection Any warranty for our water heaters is rendered null and void if unsuitable or non-func- tioning storage tank connection fittings are used and if the stated operating pressure is exceeded. - Page 14 Electric water heater EKA, EKR, EWH, EKL a) To avoid limescale deposits from obstructing the air introduction system of the safety valve, operate the air introduction system of the safety valve from time to time during the operation of the facility. Check whether the valve closes once the air introduction system is released and whether the water drains completely through the funnel or the bleeding line.
-
Page 15: Pressureless Connection
Electric water heater EKA, EKR, EWH, EKL 13.2 Pressureless connection By using fittings for pressureless connection (overflow mixer taps), it is also possible to make a pressureless connection for a pressure resistant storage tank. In the cold water supply line, no safety valve is required. However, a non-return valve, a stop valve and a drain valve are required! This type of connection is advantageous if only one hot water tapping point is needed. -
Page 16: Connection Storage Tank With 3 Connecting Pieces
The bare-tube heat exchanger of the EKR series must be flushed properly before the initial installation is performed. If the bare-tube heat exchanger is not used, the outer tube ends must be sealed to prevent back-cooling. -
Page 17: Electrical Connection
Electric water heater EKA, EKR, EWH, EKL However, under no circumstances is it permissible to shut off the inflow line and the re- turn line because this would make it impossible for the water inside the heat exchanger to expand, which could damage the heat exchanger. -
Page 18: Reconnection Possibilities
Electric water heater EKA, EKR, EWH, EKL 15.2 Reconnection possibilities For storage tanks with choice of heating time, the heating elements must be recon- nected according to the wiring diagram glued inside the unit. The factory connection corresponds to a heating time of 6 hours in ~ 230 V supply voltage. The three-phase current circuits 3 ~ 400 V, respectively 3 N ~ 400 V, available as an option for 100 litres and above, must also be reconnected according to the following table. -
Page 19: Connection Diagram Ewh
Electric water heater EKA, EKR, EWH, EKL Bold figures represent the factory connection (6 hrs 230V) Heating times at mains voltage ~230V 3~400V 3N~400V Heater clamping* Heating time hrs S+M+S wye conn. S+M+S 3 1/3 3 1/3 3 1/3 1,65... -
Page 20: Connection Diagram Eka, Ekr, Ekl
Electric water heater EKA, EKR, EWH, EKL 15.4 Connection diagram EKA, EKR, EKL Tubular heater Reconnectable heating ratings in kW ~230V 3~400V 3N~400V Type 3 1/3 3 1/3 3 1/3 hrs. hrs. hrs. hrs. hrs. hrs. hrs. hrs. 1,65 EKL 080 U... -
Page 21: Commissioning
Electric water heater EKA, EKR, EWH, EKL 16. Commissioning Before the device is switched on electrically, the storage tank must be filled with water. The expansion water produced in the interior tank during heating must drip from the safety valve (pressure resistant connection), respectively from the overflow mixer tap (pressureless connection). -
Page 22: Checking, Maintenance, Care
Finally, flush the device thoroughly (according to ÖNORM H5195-1) and observe the heating procedure as if the device was first-time commissioned. c) To make a justified claim under the warranty granted by AE-AG, the fitted protective anode must be checked by a professional at max. 2-year intervals. Do not damage or remove the protective current discharge resistor underneath the heater fastening screw during maintenance work. -
Page 23: Warranty
(e.g. doors and passages too narrow) are not governed by the guarantee and warranty declaration and therefore shall be rejected on the part of AE AG. If the water boiler is set up and operated in uncommon locations (e.g. attics, living rooms with water-sensitive floors, store rooms, etc.), the possibility of water leakage must be taken into account and provisions made for collecting and discharging the water leakage in order to prevent secondary damage within the meaning of product liability. - Page 24 8. Neither the performance of works under warranty or guarantee, nor the performance of service and mainte- nance works shall renew or extend the term of warranty. 9. Transport damage shall be investigated and possibly accepted only if it is reported to AE AG in writing on the next following workday after delivery at the latest.
- Page 28 Austria Email AG Austriastraße 6 A-8720 Knittelfeld Telefon: (03512) 700-0 Fax: (03512) 700-239 Internet: www.austria-email.at E-Mail: office@austria-email.at Austria Email in your area? For addresses and telephone numbers of our subsidiaries, visit our homepage at www.austria-email.at Print errors and changes of all kinds are reserved. Reproduction prohibited.
