Table of Contents

Advertisement

Quick Links

CS-1530/2030
SERVICE
MANUAL
Published in Feb.'01
2AV70951
Revision 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CS-2030 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Copystar CS-2030

Summary of Contents for Copystar CS-2030

  • Page 1: Service Manual

    CS-1530/2030 SERVICE MANUAL Published in Feb.’01 2AV70951 Revision 1...
  • Page 2 CAUTION DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY REPLACED. REPLACE ONLY WITH THE SAME OR EQUIVALENT TYPE RECOMMENDED BY THE MANUFACTURER. DISPOSE OF USED BATTERIES ACCORDING TO THE MANUFACTURER’S INSTRUCTIONS. ATTENTION IL Y A DANGER D’EXPLOSION S’IL Y A REMPLACEMENT INCORRECT DE LA BATTERIE. REMPLACER UNIQUEMENT AVEC UNE BATTERIE DU MÊME TYPE OU D’UN TYPE REC- OMMANDÉ...

  • Page 3: Safety Precautions

    Safety precautions This booklet provides safety warnings and precautions for our service personnel to ensure the safety of their customers, their machines as well as themselves during maintenance activities. Service personnel are advised to read this booklet carefully to familiarize themselves with the warnings and precautions described here before engaging in maintenance activities.
  • Page 4 Safety warnings and precautions Various symbols are used to protect our service personnel and customers from physical danger and to prevent damage to their property. These symbols are described below: DANGER: High risk of serious bodily injury or death may result from insufficient attention to or incorrect compliance with warning messages using this symbol.

  • Page 5: Installation Precautions

    1. Installation Precautions WARNING • Do not use a power supply with a voltage other than that specified. Avoid multiple connections to one outlet: they may cause fire or electric shock. When using an extension cable, always check that it is adequate for the rated current..................... •...

  • Page 6: Specifications 1

    2. Precautions for Maintenance WARNING • Always remove the power plug from the wall outlet before starting machine disassembly....• Always follow the procedures for maintenance described in the service manual and other related brochures............................• Under no circumstances attempt to bypass or disable safety features including safety mechanisms and protective circuits.
  • Page 7 • Do not pull on the AC power cord or connector wires on high-voltage components when removing them; always hold the plug itself....................... • Do not route the power cable where it may be stood on or trapped. If necessary, protect it with a cable cover or other appropriate item.

  • Page 8: Table Of Contents

    2AV/X CONTENTS 1-1 Specifications 1-1-1 Specifications ............................1-1-1 1-1-2 Parts names and their functions ......................1-1-5 (1) Copier ............................. 1-1-5 (2) Operation panel ..........................1-1-6 1-1-3 Machine cross section .......................... 1-1-8 1-1-4 Drive system ............................1-1-9 (1) Drive system 1 (optical section) ...................... 1-1-9 (2) Drive system 2 (drive motor drive train) ..................
  • Page 9 2AV/X (6) A black line appears longitudinally....................1-5-20 (7) A black line appears laterally......................1-5-20 (8) One side of the copy image is darker than the other..............1-5-20 (9) Black dots appear on the image....................1-5-21 (10) Image is blurred.
  • Page 10 2AV/X (4) The scanner does not travel......................1-5-30 (5) Multiple sheets of paper are fed at one time.................. 1-5-30 (6) Paper jams........................... 1-5-30 (7) Toner drops on the paper conveying path..................1-5-30 (8) Abnormal noise is heard....................... 1-5-30 1-6 Assembly and Disassembly 1-6-1 Precautions for assembly and disassembly ..................
  • Page 11 2AV/X 1-7 Requirements on PCB Replacement 1-7-1 Replacing the main PCB ........................1-7-1 1-7-2 Upgrading the firmware on the main PCB .................... 1-7-3 1-7-3 Upgrading the firmware on the operation unit PCB (20 cpm copier only) ..........1-7-5 1-7-4 Adjustment-free variable resistors (VR) ....................1-7-6 2-1 Mechanical construction 2-1-1 Paper feed section ..........................

  • Page 12: Specifications

    2AV/X 1-1-1 Specifications 15 cpm copier Type ..........Desktop Copying system ......Indirect electrostatic system Originals ......... Sheets and books Maximum size: A3/11" × 17" Original feed system ...... Fixed Copy paper ........Drawer: Plain paper (64 – 80 g/m Bypass table: Plain paper (60 –...
  • Page 13 2AV/X Transfer system ......Transfer roller Fixing system ......... Heat roller Heat source: halogen heaters (850 W for 120 V specifications/910 W for 220-240 V specifications) Control temperature: 180°C/356°F (at normal ambient temperature) Abnormally high temperature protection device: 140°C/284°F thermostat Fixing pressure: 49 N Charge erasing system ....
  • Page 14 2AV/X 20 cpm copier Type ..........Desktop Copying system ......Indirect electrostatic system Originals ......... Sheets and books Maximum size: A3/11" × 17" Original feed system ...... Fixed Copy paper ........Drawer: Plain paper (64 – 80 g/m Bypass table: Plain paper (60 – 160 g/m Special paper: Transparencies, tracing paper, colored paper, letterhead and envelopes (when using the printer function only) Note: Use the bypass table for special paper.
  • Page 15 2AV/X Cleaning system ......Cleaning blade Scanning system ......Flat bed scanning by CCD image sensor Bit map memory ......17.1 MB (standard) Image storage memory ....46.9 MB (standard) Resolution ........600 × 600 dpi Light source ........Inert gas lamp Dimensions ........

  • Page 16: Parts Names And Their Functions

    2AV/X 1-1-2 Parts names and their functions (1) Copier ‹ ¤ ‹ › ⁄ & Figure 1-1-1 1 Original cover (optional)* 2 Operation panel 3 Paper conveying unit 4 Multi-Bypass 5 Insert guides 6 Support tray 7 Toner cartridge 8 Toner cartridge release lever 9 Waste toner tank 0 Waste toner tank release lever ! Cleaning shaft...

  • Page 17: Operation Panel

    2AV/X (2) Operation panel 15 cpm copier Metric Á ´ Œ · ‹ 6 54 ¤⁄ )( % ˇ „ ‚ › ‰ ° ‡ fi fl * & $# !0 Inch Á ´ Œ · ‹ ¤ ⁄ )( % 6 54 ˇ...
  • Page 18 2AV/X 20 cpm copier Metric ‹ ⁄ fl › ¤ ‡fi ^ & Inch ‹ ⁄ fl › ¤ ‡fi ^ & Figure 1-1-3 1 Start key (Indicator) * On-line/Printer key (Indicator) 2 Reset key ( Layout key (Indicator) 3 Interrupt key (Indicator) ) Copy exposure adjustment keys/Copy 4 Energy Saver (preheat) key (Indicator) exposure indicators...

  • Page 19: Machine Cross Section

    2AV/X 1-1-3 Machine cross section Light path Paper path Figure 1-1-4 Machine cross section 1 Paper feed section 2 Main charging section 3 Optical section 4 Developing section 5 Transfer and paper conveying section 6 Cleaning section 7 Charge erasing section 8 Fixing section 1-1-8...

  • Page 20: Drive System

    2AV/X 1-1-4 Drive system (1) Drive system 1 (optical section) As viewed from machine front Figure 1-1-5 1 Scanner motor gear 5 Scanner wire 2 Gear 44/16 6 Scanner wire pulley 3 Gear 26 7 Scanner wire pulley 4 Scanner wire drum 8 Scanner wire pulley 1-1-9...

  • Page 21: Drive System 2 (Drive Motor Drive Train)

    2AV/X (2) Drive system 2 (drive motor drive train) ˆ ¨ Á — ‰ ‡ ˇ fi fl › & Œ · ‹ „ ´ ¤ ⁄ ‚ Å Î Í ” Ø As viewed from machine rear Figure 1-1-6 1 Drive motor gear ^ Upper paper feed clutch gear Œ...

  • Page 22: Drum

    2AV/X 1-2-1 Drum Note the following when handling or storing the drum. • When removing the image formation unit, never expose the drum surface to strong direct light. • Keep the drum at an ambient temperature between –20°C/–4°F and 40°C/104°F and at a relative humidity not higher than 85% RH.
  • Page 23 2AV/X • 20 cpm copier a: 675 mm/26 " b: 873 mm/34 " c: 555 mm/21" d: 718 mm/28 " e: 603 mm/23 " f: 1218 mm/46 " g: 418 mm/16 " h: 951 mm/37 " Figure 1-2-1b Installation dimensions 1-2-2...

  • Page 24: Unpacking And Installation

    2AV/X 1-3-1 Unpacking and installation (1) Installation procedure Start Unpack. Remove the tapes. Adjust the fixing pressure. Remove the pins holding light source units 1 and 2. Connect the power cord. Install the optional devices. Carry out initial developer setting (maintenance item U130).
  • Page 25 2AV/X Light source unit 1 pins Light source unit 2 pin *The diagram shows the 20 cpm copier. *The original cover is standard for Asia and Oceania specifications for the 15 cpm copier only. Figure 1-3-1 1-3-2...
  • Page 26 2AV/X Unpack • 15 cpm copier %& Figure 1-3-2a Unpacking 1 Copier # Bar code labels 2 Outer case $ Hinge joint 3 Inner frame % Instruction handbook 4 Upper pads ^ Plastic bag 5 Bottom pads & Business reply mail* 6 Bottom case * Drawer spacers 7 Skid...
  • Page 27 2AV/X • 20 cpm copier & Figure 1-3-2b Unpacking 1 Copier @ Instruction handbook 2 Outer case # Plastic bag 3 Inner frame $ Business reply mail* 4 Upper pads % Drawer spacers 5 Bottom pads ^ Drawer claw spacers 6 Bottom case &...
  • Page 28 2AV/X Remove the tapes. 1. Remove the tape holding the front cover and the power cord, and remove the tape binding the power cord. 2. Remove the tape holding the drawer. 3. Remove the two tapes holding the paper conveying unit and bypass tray. 4.
  • Page 29 2AV/X 7. Pull the drawer out and remove the tape holding each of the drawer spacers and then the spacers. 8. Remove the tape holding the fulcrum of the drawer lift inside the drawer. Fulcrum of the drawer lift Drawer spacers Figure 1-3-5 Rear cursor 9.
  • Page 30 2AV/X Remove the pins holding light source units 1 and 2. 1. Remove the two pins for light source unit 1 and the pin for light source unit 2. Light source unit 1 pins Light source unit 2 pin Figure 1-3-8 Install optional devices.
  • Page 31 2AV/X Load developer. 1. Remove the developing unit upper cover by pushing and lifting it in the direction of the arrow Developing unit upper cover in the diagram. Caution: Be sure to place the image formation unit on a level surface when loading developer. Figure 1-3-10 2.
  • Page 32 2AV/X 2. Check that the cleaning shaft is inserted as far as 12-pin connector it will go. 3. Refit the image formation unit using the two screws. 4. Connect the 12-pin connector. Figure 1-3-13 Waste toner tank Install a waste toner tank. release lever 1.While holding the waste toner tank release lever up, fit the waste toner tank in the copier.
  • Page 33 2AV/X Connect the power cord. 1. Connect the power cord to the connector on the copier. 2. Insert the power plug into the wall outlet. Carry out initial developer setting (maintenance item U130). 1. Turn the main switch on and enter the maintenance mode by entering “10871087” using the numeric keys. 2.
  • Page 34 2AV/X Install a toner cartridge. 1. Open the front cover. 2. Shift the toner cartridge release lever to the right until it stops. Toner cartridge release lever Figure 1-3-16 3. Tap the toner cartridge on the top five or six times and shake it horizontally eight to ten times to agitate the toner.
  • Page 35 2AV/X Make test copies. 1. Place an original and make test copies. Check if the center lines of the bypass tray and drawer are correct. If not, adjust the center lines. Completion of machine installation. 1-3-12...

  • Page 36: Setting Initial Copy Modes

    2AV/X 1-3-2 Setting initial copy modes Factory settings are as follows: Factory setting Maintenance item Contents Metric Inch U253 Switching between double and single counts Double count Double count U254 Turning auto start function on/off U255 Setting auto clear time 90 s 90 s U256...

  • Page 37: Copier Management

    2AV/X 1-3-3 Copier management In addition to a maintenance function for service, the copier is equipped with a management function which can be operated by users (mainly by the copier administrator). In this copier management mode, settings such as default settings can be changed.

  • Page 38: Setting Department Management Items

    2AV/X (2) Setting department management items Turning department management on/off Clearing copy counts 1. Select “d01” and press the enter key. 1. Select “d04” and press the enter key. 2. Select “copy management on” or “copy 2. Select “clear” or “do not clear” and press the management off”...
  • Page 39 2AV/X Default drawer Copy limit Sets the drawer to be selected in cases such as Sets the number of copies limit for multiple copy- after the reset key is pressed. ing. 1. Select “F10” and press the enter key. 1. Select “F16” and press the enter key. 2.
  • Page 40 2AV/X Silent mode Auto preheat time Selects whether or not to enter silent mode after Sets the auto preheat time. copying. 1. Select “F25” and press the enter key. 1. Select “F22” and press the enter key. 2. Select the setting and press the enter key. 2.

  • Page 41: Using The Copier Management Mode (20 Cpm Copier)

    2AV/X (4) Using the copier management mode (20 cpm copier) Start Press the */language key. Select “Management” and press the enter key. Enter the Execute department manage- management code. ment items (page 1-3-19). Select “End” and press the enter key. Select “Copy default”...

  • Page 42: Setting Department Management Items

    2AV/X (5) Setting department management items Registering a new department code Clearing copy counts Sets a department code and the limit of the 1. Select “Management Setting” (“COPY MGMT number of copies for that department. SETTING”) and press the enter key. 1.

  • Page 43: Machine Default

    2AV/X Photo original density Border erase width Adjusts the exposure to be used when photo Sets the default setting of the border erase width original is selected for the image mode. for the border erase mode. 1. Select “Photo original density set” and press 1.

  • Page 44: Language

    2AV/X APS for special paper Auto shutoff time Sets whether to use the paper source with the Sets the auto shutoff time. special paper for auto paper selection and auto 1. Select “Auto shut-off time” and press the enter drawer switching. key.

  • Page 45: Installing The Key Counter (Option)

    2AV/X 1-3-4 Installing the key counter (option) Key counter installation requires the following parts: Key counter set (P/N 2A369702) Contents of the set: • Key counter cover (P/N 2A360010) • Key counter retainer (P/N 66060030) • Key counter cover retainer (P/N 66060022) •...
  • Page 46 2AV/X 8. Refit the right cover. 9. Pass the 4-pin connector of the key counter through the aperture in the key counter cover retainer, and insert into the 4-pin connector of the copier. 10. Seat the projection of the key counter cover retainer in the aperture in the right cover, and Key counter cover retainer fasten them both to the copier using three...

  • Page 47: Installing The Original Size Detection Sensor (Option For The Metric Specifications Of The 15 Cpm Copier Only)

    2AV/X 1-3-5 Installing the original size detection sensor (option for the metric specifications of the 15 cpm copier only) Original size detection sensor installation requires the following parts: • Original size detection sensor (P/N 35927290) • One (1) M3 × 8 bronze binding screw (P/N B1303080) Procedure 1.

  • Page 48: Installing The Drawer Heater (Option)

    2AV/X 1-3-6 Installing the drawer heater (option) Drawer heater installation requires the following parts: For 120 V specifications Drawer heater set (P/N 3A569710) Contents of the set • One (1) BVM4 × 4 bronze binding screw (P/N B1304040) • Two (2) BVM4 × 6 bronze binding screws (P/N B1304060) •...
  • Page 49 2AV/X 7. Insert one of the 2-pin receptacles on the heater wire into the opening in the frame and connect the other 2-pin receptacle to the drawer heater cable. 2-pin receptacle Opening 2-pin receptacle Figure 1-3-27 8. Refit the drawer. 9.

  • Page 50: Maintenance Mode

    2AV/X 1-4-1 Maintenance mode The copier is equipped with a maintenance function which can be used to maintain and service the machine. (1) Executing a maintenance item Start Enter 10871087. · · · · · · · Entering the maintenance mode Enter the number of the maintenance item to be executed using the cursor ·...

  • Page 51: Maintenance Mode Item List (For 20 Cpm Copier)

    2AV/X (2) Maintenance mode item list (for 20 cpm copier) Item Initial Section Maintenance item contents setting* — General U000 Outputting an own-status report — U001 Exiting the maintenance mode U003 Setting the service telephone number *************** U004 Setting the machine number —...
  • Page 52 2AV/X Item Initial Section Maintenance item contents setting* — High voltage U111 Checking/clearing the drum drive time Developing U130 Initial setting for the developer — U131 Setting the toner sensor control voltage U132 Replenishing toner forcibly — U135 Checking toner feed motor operation —...
  • Page 53 2AV/X Item Initial Section Maintenance item contents setting* — Image U404 Adjusting margins for scanning an original from the DF — processing U407 Adjusting the leading edge registration for memory image printing Others U901 Checking/clearing copy counts by paper feed locations —...

  • Page 54: Contents Of Maintenance Mode Items (For 20 Cpm Copier)

    2AV/X (3) Contents of maintenance mode items (for 20 cpm copier) Maintenance Description item No. U000 Outputting an own-status report Description Outputs lists of the current settings of the maintenance items, and paper jam and service call occurrences. Purpose To check the current setting of the maintenance items, or paper jam or service call occurrences. Before initializing or replacing the backup RAM, output a list of the current settings of the maintenance items to reenter the settings after initialization or replacement.
  • Page 55 2AV/X Maintenance Description item No. U003 Setting the service telephone number Description Sets the telephone number to be displayed when a service call code is detected. Purpose To set the telephone number to call service when installing the machine. Method Press the start key.
  • Page 56 2AV/X Maintenance Description item No. U005 Copying without paper Description Simulates the copy operation without paper feed. Purpose To check the overall operation of the machine. Method 1. Press the start key. The screen for selecting an item is displayed. 2.
  • Page 57 2AV/X Maintenance Description item No. U020 Initializing all data Description Initializes all the backup RAM on the main PCB to return to the original settings. Purpose Used when replacing the backup RAM on the main PCB. Method 1. Press the start key. The screen for executing is displayed. 2.
  • Page 58 2AV/X Maintenance Description item No. U030 Checking motor operation Description Drives each motor. Purpose To check the operation of each motor. Method 1. Press the start key. The screen for selecting an item is displayed. 2. Select the motor to be operated using the cursor up/down keys. 3.
  • Page 59 2AV/X Maintenance Description item No. U032 Checking clutch operation Description Turns each clutch on. Purpose To check the operation of each clutch. Method 1. Press the start key. The screen for selecting an item is displayed. 2. Select the clutch to be operated using the cursor up/down keys. 3.
  • Page 60 2AV/X Maintenance Description item No. U035 Setting folio size Description Changes the image area for copying onto folio size paper. Purpose To prevent the image at the trailing edge, or right or left side of the paper from not being copied by setting the actual size of the folio paper used.
  • Page 61 2AV/X Maintenance Description item No. U053 Interrupt copy mode While this maintenance item is being performed, a VTC pattern shown below is output in interrupt copy mode. Correct values for an A3/11" × 17" output are: A = 300 ± 0.75 mm B = 260 ±...
  • Page 62 2AV/X Maintenance Description item No. U061 Turning the exposure lamp on Description Turns the exposure lamp on. Purpose To check the exposure lamp. Method 1. Press the start key. The screen for executing is displayed. 2. Press the start key. The exposure lamp lights. 3.
  • Page 63 2AV/X Maintenance Description item No. U070 Adjusting the DF magnification Description Adjusts the DF original scanning speed. Purpose To be executed if the correct magnification is not obtained in the auxiliary scanning direction when the optional DF is used. Caution Before making this adjustment, ensure that the following adjustments have been made in maintenance mode.
  • Page 64 2AV/X Maintenance Description item No. U071 Adjustment 1. In interrupt copy mode, make a copy using the DF. 2. Check the copy image and adjust the registration as follows. For copy example 1, increase the setting of LEAD EDGE ADJ. For copy example 2, decrease the setting of LEAD EDGE ADJ.
  • Page 65 2AV/X Maintenance Description item No. U072 Adjustment 1. In interrupt copy mode, make a copy using the DF. 2. Check the copy image and adjust the center line as follows. For copy example 1, increase the setting. For copy example 2, decrease the setting. Reference Original Copy...
  • Page 66 2AV/X Maintenance Description item No. U074 Adjusting the DF input light luminosity Description Adjusts the luminosity of the exposure lamp for scanning originals from the optional DF. Purpose Used if the exposure amount differs significantly between when scanning an original on the contact glass and when scanning an original from the DF.
  • Page 67 2AV/X Maintenance Description item No. U087 Setting the reference data for identifying dust Available only when the mode is turned on. 1. Select the item to be set using the cursor up/down keys. The selected item is displayed in reverse. 2.
  • Page 68 2AV/X Maintenance Description item No. U091 Checking shading Description Performs scanning under the same conditions as before and after shading is performed, displaying the original scanning values at nine points of the contact glass. Purpose To check the change in original scanning values before and after shading. The results may be used to decide the causes for fixing unevenness (uneven density) of the gray area of an image: either due to optical (shading or CCD) or other problems.
  • Page 69 2AV/X Maintenance Description item No. U092 Adjusting the scanner automatically Description Makes auto scanner adjustments in the order below using the specified original. • Adjusting the scanner center line (U067) • Adjusting the scanner leading edge registration (U066) • Adjusting scanner magnification in the auxiliary direction (U065) When this maintenance item is performed, the settings in U065, U066 and U067 are also changed.
  • Page 70 2AV/X Maintenance Description item No. U093 Setting the exposure density gradient Description Changes the exposure density gradient in manual density mode, depending on respective image modes (text, text and photo, photo). Purpose To set how the image density is altered by a change of one step in the manual density adjustment. Also used to make copy image darker or lighter.
  • Page 71 2AV/X Maintenance Description item No. U099 Checking the original size detection Description Displays the original width detection data and sets the original width detection threshold. Purpose To check the original width detection. Also to change the original size detection threshold if the size of the original on the contact glass is detected incorrectly.
  • Page 72 2AV/X Maintenance Description item No. U100 Setting the surface potential Description Changes the surface potential by changing the grid control voltage. Also performs main charging. Purpose To set the surface potential or check main charging. Also used when reentering data after replacing the backup RAM or initializing the set data.
  • Page 73 2AV/X Maintenance Description item No. U101 Setting high voltages Description Changes the developing bias voltage and transfer voltage by changing the developing bias control voltage and transfer control voltage. Also checks the transfer output voltage. Purpose To check and change high voltages other than the main charger voltage. Start 1.
  • Page 74 2AV/X Maintenance Description item No. U109 Setting the drum type Description Sets or checks the drum type. Purpose To prevent variations in halftones due to differences in drum sensitivity. Method 1. Press the start key. The screen for selecting an item is displayed. 2.
  • Page 75 2AV/X Maintenance Description item No. U130 Initial setting for the developer Description Automatically sets the toner sensor control voltage and toner feed start level for the installed developer. Purpose To set the initial settings for the developer when installing the machine or replacing the developer. Caution Before performing the initial setting for the developer, remove the transfer roller (see page 1-6-45).
  • Page 76 2AV/X Maintenance Description item No. U132 Replenishing toner forcibly Description Replenishes toner forcibly until the toner sensor output value reaches the toner feed start level. Purpose Used when the toner empty is detected frequently. Method 1. Press the start key. The screen for executing is displayed. 2.
  • Page 77 2AV/X Maintenance Description item No. U156 Changing the toner control level Description Changes the toner feed start level set in maintenance item U130 or the toner empty level to be determined by the difference from the toner feed start level. Purpose To check the toner feed start level and toner empty level.
  • Page 78 2AV/X Maintenance Description item No. U158 Checking/clearing the developing count Description Displays the developing count for checking, clearing or changing a figure, which is used as a reference when correcting the toner control. It is automatically cleared when U130 is executed. Purpose To check the developing count after replacing the developer.
  • Page 79 2AV/X Maintenance Description item No. U162 Stabilizing fixing forcibly Description Stops the stabilization fixing drive forcibly, regardless of fixing temperature. Purpose To forcibly stabilize the machine before the fixing section reaches stabilization temperature. Method 1. Press the start key. The screen for executing is displayed. 2.
  • Page 80 2AV/X Maintenance Description item No. U200 Turning all LEDs on Description Turns all the LEDs on the operation panel on. Purpose To check if all the LEDs on the operation panel light. Method Press the start key. All the LEDs on the operation panel light. Press the stop/clear key or wait for 10 s.
  • Page 81 2AV/X Maintenance Description item No. U207 Checking the operation panel keys Description Checks operation of the operation panel keys. Purpose To check operation of all the keys and LEDs on the operation panel. Method 1. Press the start key. The screen for executing is displayed. 2.
  • Page 82 2AV/X Maintenance Description item No. U211 Completion Press the stop/clear key at the screen for selectiong an item. The screen for selectiong a maintenance item No. is displayed. U240 Checking the operation of finisher motors and solenoids Description Turns the motors and solenoids in the optional finisher on. Purpose To check the operation of the finisher motors and solenoids.
  • Page 83 2AV/X Maintenance Description item No. U243 Checking the operation of the DF motors, solenoids and clutch Description Turns the motors, solenoids or clutch in the optional SRDF on (when SRDF is installed). Turns the motors in the optional STDF on (when STDF is installed). Purpose To check the operation of the SRDF motors, solenoids and clutch (when SRDF is installed).
  • Page 84 2AV/X Maintenance Description item No. U244 Numerical Original width to be detected value × " " 49.664 50.176 61.440 61.952 × 103.936 " 14"/ × " 11" 104.448 Folio/A4R 139.264 139.776 146.432 B4/B5 146.994 197.120 × 197.632 11" 17"/ × ×...
  • Page 85 2AV/X Maintenance Description item No. U244 Checking the DF switches (when installing the optional STDF) Description Displays the status of the respective switches in the optional STDF. Purpose To check if respective switches in the optional STDF operate correctly. Start 1.
  • Page 86 2AV/X Maintenance Description item No. U250 Setting the maintenance cycle Description Displays and changes the maintenance cycle. Purpose To check and change the maintenance cycle. Method Press the start key. The current setting is displayed as follows: Maintenance cycle (number of copies) = setting × 1000 Setting 1.
  • Page 87 2AV/X Maintenance Description item No. U252 Setting the destination Description Switches the operations and screens of the machine according to the destination. Purpose To be executed after replacing the backup RAM on the main PCB or initializing the backup RAM by running maintenance item U020, in order to return the setting to the value before replacement or initialization.
  • Page 88 2AV/X Maintenance Description item No. U254 Turning auto start function on/off Description Selects if the auto start function is turned on. Purpose Normally no change is necessary. If incorrect operation occurs, turn the function off: this may solve the problem. Method Press the start key.
  • Page 89 2AV/X Maintenance Description item No. U256 Turning auto preheat/energy saver function on/off Description Selects if the auto preheat/energy saver function is turned on. When set to ON, the time to enter preheat/ energy saver mode can be changed in copy management mode. Purpose According to user request, to set the preheat time to save energy, or enable copying promptly without the recovery time from preheat mode.
  • Page 90 2AV/X Maintenance Description item No. U260 Changing the copy count timing Description Changes the copy count timing for the total counter and other counters. Purpose To be set according to user (copy service provider) request. If a paper jam occurs frequently in the finisher when the number of copies is counted at the time of paper ejection, copies are provided without copy counts.
  • Page 91 2AV/X Maintenance Description item No. U330 Setting the number of sheets to enter stacking mode during sort operation Description When sort copying is set to perform automatically in the output form setting of the user simulation, sets the number of sheets at which the eject location is switched to the optional finisher (only when the finisher is installed).
  • Page 92 2AV/X Maintenance Description item No. U342 Setting the ejection restriction Description Sets or cancels the restriction on the number of sheets to be ejected continuously when the internal eject tray is selected as the eject location. Purpose According to user request, sets or cancels restriction on the number of sheets. Method 1.
  • Page 93 2AV/X Maintenance Description item No. U344 Setting preheat/energy saver mode Description Changes the control for preheat/energy saver mode. Purpose According to user request, selects which has priority, the recovery time from preheat or energy saver. Method Press the start key. The screen for selecting an item is displayed. Setting 1.
  • Page 94 2AV/X Maintenance Description item No. U348 Setting the copy density adjustment range Description Selects the adjustment range for copy density from NORMAL and SPECIAL AREA (for wider range). Purpose To change the setting according to user request. When especially dark or light density is requested, set to SPECIAL AREA. Method Press the start key.
  • Page 95 2AV/X Maintenance Description item No. U404 Adjusting margins for scanning an original from the DF Description Adjusts margins for scanning the original from the DF. Purpose Used if margins are not correct when the optional DF is used. Caution Before making this adjustment, ensure that the following adjustments have been made in maintenance mode.
  • Page 96 2AV/X Maintenance Description item No. U407 Adjusting the leading edge registration for memory image printing Adjustment See page 1-6-12. U901 Checking/clearing copy counts by paper feed locations Description Displays or clears copy counts by paper feed locations. Purpose To check the time to replace consumable parts. Also to clear the counts after replacing the consumable parts.
  • Page 97 2AV/X Maintenance Description item No. U904 Checking/clearing the service call counts Description Displays or clears the service call code counts by types. Purpose To check the service call code status by types. Also to clear the service call code counts after replacing consumable parts.
  • Page 98 2AV/X Maintenance Description item No. U906 Resetting partial operation control Description Resets the service call code for partial operation control. Purpose To be reset after partial operation is performed due to problems in the drawers or other sections, and the related parts are serviced.
  • Page 99 2AV/X Maintenance Description item No. U914 Switching between fax and copier modes Description Selects whether the fax or copier mode is given priority when the optional facsimile kit is installed to use the copier as a fax. Purpose To select the mode that is used more frequently by the user. Method Press the start key.
  • Page 100 2AV/X Maintenance Description item No. U992 Checking or clearing the printer/fax count Description Displays, clears or changes the print count of the printer or fax when the optional printer board or fax unit is installed. Purpose To check the frequency of use of the printer or fax. Method Press the start key.
  • Page 101 2AV/X Maintenance Description item No. U998 Outptting the memory list Description Outputs the list of memory. Purpose To output the list as required. Method 1. Press the start key. The screen for selecting an item is displayed. 2. Enter the six digits of address using the numeric keys. To enter alphabets, press the keys shown below as required.

  • Page 102: Maintenance Mode Item List (For 15 Cpm Copier)

    2AV/X (4) Maintenance mode item list (for 15 cpm copier) Item Initial Section Maintenance item contents setting* General U000 Outputting an own-status report — U001 Exiting the maintenance mode — U004 Setting the machine number — U005 Copying without paper —...
  • Page 103 2AV/X Item Initial Section Maintenance item contents setting* High voltage U100 Setting the surface potential U101 Setting high voltages • Developing bias 193/38 • Transfer voltage • Transfer voltage output timing –176 U109 Setting the drum type U110 Checking/clearing the drum count —...
  • Page 104 2AV/X Item Initial Section Maintenance item contents setting* Image U402 Adjusting margins of image printing — processing U403 Adjusting margins for scanning an original on the contact glass — U404 Adjusting margins for scanning an original from the DF — U407 Adjusting the leading edge registration for memory image printing —...

  • Page 105: Contents Of Maintenance Mode Items (For 15 Cpm Copier)

    2AV/X (5) Contents of maintenance mode items (for 15 cpm copier) Maintenance Description item No. U000 Outputting an own-status report Description Outputs lists of the current settings of the maintenance items, and paper jam and service call occurrences. Purpose To check the current setting of the maintenance items, or paper jam or service call occurrences. Before initializing the backup RAM, output a list of the current settings of the maintenance items to reenter the settings after initialization or replacement.
  • Page 106 2AV/X Maintenance Description item No. U005 Copying without paper Description Simulates the copy operation without paper feed. Purpose To check the overall operation of the machine. Method 1. Press the start key. A selection item appears. 2. Select the item to be operated using the copy exposure adjustment keys. Display Operation Only the copier operates.
  • Page 107 2AV/X Maintenance Description item No. U021 Initializing memories Description Initializes the setting data other than that for adjustments due to variations between respective machines, i.e., settings for counters, service call history and mode settings. As a result, initializes the backup RAM according to the specifications depending on the destination selected in U252.
  • Page 108 2AV/X Maintenance Description item No. U031 Checking switches for paper conveying Description Displays the on-off status of each paper detection switch on the paper path. Purpose To check if the switches for paper conveying operate correctly. Method 1. Press the start key. 2.
  • Page 109 2AV/X Maintenance Description item No. U033 Checking solenoid operation Description Turns each solenoid on. Purpose To check the operation of each solenoid. Method 1. Press the start key. A selection item appears. 2. Select the desired operation using the copy exposure adjustment keys. 3.
  • Page 110 2AV/X Maintenance Description item No. U053 Performing fine adjustment of the motor speed Description Performs fine adjustment of the speeds of the motors. Purpose Used to adjust the speed of the respective motors when the magnification is not correct. Method Press the start key.
  • Page 111 2AV/X Maintenance Description item No. U060 Adjusting the scanner input properties Description Adjusts the image scanning density. Purpose Used when the entire image appears too dark or light. Method Press the start key. Setting 1. Change the setting using the zoom +/– keys. Description Setting range Initial setting...
  • Page 112 2AV/X Maintenance Description item No. U065 Adjusting the scanner magnification Adjustment See pages 1-6-32 and 34. U066 Adjusting the leading edge registration for scanning an original on the contact glass Adjustment See page 1-6-36. U067 Adjusting the center line for scanning an original on the contact glass Adjustment See page 1-6-37.
  • Page 113 2AV/X Maintenance Description item No. U071 Adjusting the DF scanning timing Description Adjusts the DF original scanning timing. Purpose To be executed if there is a regular error between the leading or trailing edges of the original and the copy image when the optional DF is used.
  • Page 114 2AV/X Maintenance Description item No. U072 Adjusting the DF center line Description Adjusts the scanning start position for the DF original. Purpose To be executed if there is a regular error between the centers of the original and the copy image when the optional DF is used.
  • Page 115 2AV/X Maintenance Description item No. U073 Checking scanner operation Description Simulates the scanner operation under arbitrary conditions. Purpose To check scanner operation. Method 1. Press the start key. 2. Select the item to be changed by lighting a copy exposure indicator using the copy exposure adjustment keys.
  • Page 116 2AV/X Maintenance Description item No. U075 Setting the original size detection Description Sets whether or not to detect the original size automatically using the original size detection sensor (OSDS). Purpose On the metric specifications of the European models, set to “on” when an optional original size detection sensor is installed.
  • Page 117 2AV/X Maintenance Description item No. U087 Turning the DF scanning position adjust mode on/off Description Turns on or off the DF scanning position adjust mode, in which the DF original scanning position is adjusted automatically by determining the presence or absence of dust on the slit glass. Also changes the reference data for identifying dust.
  • Page 118 2AV/X Maintenance Description item No. U088 Setting the input filter (moiré reduction mode) Description Turns moiré reduction mode on and off by switching the input filter on and off. Purpose Used to prevent regular density unevenness (moiré) on halftone image areas of the copy image in text mode and text and photo mode.
  • Page 119 2AV/X Maintenance Description item No. U091 3. Press the start key. Scanning is performed under the selected conditions and the result is displayed. (cont.) 4. Change the measurement point by lighting a copy exposure indicator or making one flash using the copy exposure adjustment keys.
  • Page 120 2AV/X Maintenance Description item No. U092 Adjusting the scanner automatically Description Makes auto scanner adjustments in the order below using the specified original. • Adjusting the scanner center line (U067) • Adjusting the scanner leading edge registration (U066) • Adjusting scanner magnification in the auxiliary direction (U065) When this maintenance item is performed, the settings in U065, U066 and U067 are also changed.
  • Page 121 2AV/X Maintenance Description item No. U093 Setting the exposure density gradient Description Changes the exposure density gradient in manual density mode, depending on respective image modes (text, text and photo, photo). Purpose To set how the image density is altered by a change of one step in the manual density adjustment. Also used to make copy image darker or lighter.
  • Page 122 2AV/X Maintenance Description item No. U093 Setting (cont.) 1. Select the item to be adjusted by lighting a copy exposure indicator using the copy exposure adjustment keys. 2. Adjust the setting using the zoom +/– keys. Copy exposure Description Setting range Initial setting indicator Exp.
  • Page 123 2AV/X Maintenance Description item No. U099 Checking the original size detection Description Displays the original width detection data and sets the original width detection threshold. Purpose To check the original width detection. Also to change the original size detection threshold if the size of the original on the contact glass is detected incorrectly.
  • Page 124 2AV/X Maintenance Description item No. U099 Method to set or check the original size detection threshold (cont.) 1. Place an original on the contact glass and turn the original detection switch on. The original size detection starts and detection data is displayed. 2.
  • Page 125 2AV/X Maintenance Description item No. U100 Setting the surface potential Description Changes the surface potential by changing the grid control voltage. Also performs main charging. Purpose To set the surface potential or check main charging. Also used when reentering data after initializing the set data.
  • Page 126 2AV/X Maintenance Description item No. U101 Setting high voltages Description Changes the developing bias voltage and transfer voltage by changing the developing bias control voltage and transfer control voltage. Also checks the transfer output voltage. Purpose To check and change high voltages other than the main charger voltage. Start 1.
  • Page 127 2AV/X Maintenance Description item No. U109 Setting the drum type Description Sets the type of the drum installed in the copier. Purpose To prevent variations in halftone due to differences in drum sensitivity. Method Press the start key. Setting 1. Select the drum type using the zoom +/– keys. Display Description Type G...
  • Page 128 2AV/X Maintenance Description item No. U111 Checking/clearing the drum drive time Description Displays the drum drive time for checking, clearing or changing a figure, which is used as a reference when correcting the high voltage based on time. Purpose To check the drum status. Also used to clear the drive time after replacing the drum. Method 1.
  • Page 129 2AV/X Maintenance Description item No. U131 Setting the toner sensor control voltage Description Displays or changes the toner sensor control voltage automatically set in maintenance item U130. Purpose To check the automatically set toner sensor control voltage. Also to change the toner density if an image is too dark or light.
  • Page 130 2AV/X Maintenance Description item No. U155 Displaying the toner sensor output Description Displays the toner sensor output value, and related data. Purpose To check the toner sensor output value. Method 1. Press the start key. 2. Press the start key. Sampling starts. 3.
  • Page 131 2AV/X Maintenance Description item No. U157 Checking/clearing the developing drive time Description Displays the developing drive time for checking, clearing or changing a figure, which is used as a reference when correcting the toner control. It is automatically cleared when U130 is executed. Purpose To check the developing drive time after replacing the developer.
  • Page 132 2AV/X Maintenance Description item No. U161 Setting the fixing control temperature Description Changes the fixing control temperature. Purpose Normally no change is necessary. However, can be used to prevent curling or creasing of paper, or solve a fixing problem on thick paper. Method Press the start key.
  • Page 133 2AV/X Maintenance Description item No. U196 Turning the fixing heater on Description Turns the fixing heater on. Purpose To check fixing heater. Method 1. Press the start key. “on” appears. 2. Press the start key. The fixing heater turns on for 1 s and then turns off. Completion Press the stop/clear key when fixing heater is off.
  • Page 134 2AV/X Maintenance Description item No. U204 Setting the presence or absence of a key card or key counter Description Sets the presence or absence of the optional key card or key counter. Purpose It is not necessary to run this maintenance item if a key card is installed on a 120 V specification machine. A key card is not available for 220 –...
  • Page 135 2AV/X Maintenance Description item No. U244 Checking the DF switches Description Displays the status of the switches in the optional DF. Purpose To check if switches in the optional DF operate correctly. Method 1. Press the start key. 2. Manually turn on and off each switch to check the status. When the on-status of a switch is detected, the original size indicator or other LED corresponding to the operated switch on the operation panel lights.
  • Page 136 2AV/X Maintenance Description item No. U251 Checking/clearing the maintenance count Description Displays, clears and changes the maintenance count. Purpose To check the maintenance count. Also to clear the count during maintenance service. Method 1. Press the start key. 2. Select the item by lighting a copy exposure indicator using the copy exposure adjustment keys. Copy exposure indicator Description Setting range Initial setting...
  • Page 137 2AV/X Maintenance Description item No. U253 Switching between double and single counts Description Switches the count system for the total counter and other counters. Purpose According to user (copy service provider) request, select if A3/11" × 17" paper is to be counted as one sheet (single count) or two sheets (double count).
  • Page 138 2AV/X Maintenance Description item No. U255 Setting auto clear time Description Sets the time to return to initial settings after copying is complete. Purpose To be set according to frequency of use. Set to a comparatively long time for continuous copying at the same settings, and a comparatively short time for frequent copying at various settings.
  • Page 139 2AV/X Maintenance Description item No. U258 Switching copy operation at toner empty detection Description Selects if continuous copying is enabled after toner empty is detected, and sets the number of copies that can be made after the detection. Method Press the start key. The current setting is displayed. Start 1.
  • Page 140 2AV/X Maintenance Description item No. U260 Changing the copy count timing Description Changes the copy count timing for the total counter and other counters. Purpose To be set according to user (copy service provider) request. If a paper jam occurs frequently in the eject section when the number of copies is counted at the time of paper ejection, copies are provided without copy counts.
  • Page 141 2AV/X Maintenance Description item No. U332 Setting the size conversion factor Description Sets the factor for converting each paper size into A4/11" × 8 ". The black ratio is converted for the A4/ 11" × 8 " size using the factor set in this maintenance item. Values set are displayed in the user simulation. Purpose To set the factor to convert the black ratio of each paper size for A4/11"...
  • Page 142 2AV/X Maintenance Description item No. U342 Setting the ejection restriction Description Sets or cancels the restriction on the number of sheets to be ejected continuously when the internal eject tray is selected as the eject location. When the restriction is set, the number of sheets that can be ejected continuously to the internal eject tray will be limited as shown below.
  • Page 143 2AV/X Maintenance Description item No. U344 Setting preheat/energy saver mode Description Changes the control for preheat/energy saver mode. Purpose According to user request, selects which has priority, the recovery time from preheat or energy saver. Method Press the start key. Setting 1.
  • Page 144 2AV/X Maintenance Description item No. U348 Setting the copy density adjustment range Description Selects the adjustment range for copy density from NORMAL and SPECIAL AREA (for wider range). Purpose To change the setting according to user request. When especially dark or light density is requested, set to SPECIAL AREA. Method Press the start key.
  • Page 145 2AV/X Maintenance Description item No. U404 DF leading edge margin (3 ± 2.5 mm) (cont.) Ejection direction (reference) DF left margin DF right margin +1.5 (2.5 +1.5 (2.5 –2.0 –2.0 DF trailing edge margin (3 ± 2.5 mm) Figure 1-4-14 Correct margin amount 3.
  • Page 146 2AV/X Maintenance Description item No. U901 Checking/clearing copy counts by paper feed locations Description Displays or clears copy counts by paper feed locations. Purpose To check the time to replace consumable parts. Also to clear the counts after replacing the consumable parts. Method 1.
  • Page 147 2AV/X Maintenance Description item No. U903 Checking/clearing the paper jam counts Description Displays or clears the jam counts by jam locations. Purpose To check the paper jam status. Also to clear the jam counts after replacing consumable parts. Method 1. Press the start key. 2.
  • Page 148 2AV/X Maintenance Description item No. U905 Checking/clearing counts by optional devices Description Displays or clears the counts of the optional DF. Purpose To check the use of the DF. Also to clear the counts after replacing consumable parts. Method 1. Press the start key. 2.
  • Page 149 2AV/X Maintenance Description item No. U910 Clearing the black ratio data Description Clears the accumulated black ratio data for A4/11" × 8 " sheets. Purpose To clear data as required at times such as during maintenance service. Method 1. Press the start key. 2.
  • Page 150 2AV/X Maintenance Description item No. U990 Checking/clearing the time for the exposure lamp to light Description Displays or clears the accumulated time for the exposure lamp to light. Purpose To check duration of use of the exposure lamp. Also to clear the accumulated time for the lamp after replacement.
  • Page 151 2AV/X Maintenance Description item No. U993 Outputting a VTC-PG pattern Description Selects and outputs a VTC-PG pattern created in the copier. Purpose When performing respective image printing adjustments, used to check the machine status apart from that of the scanner with a non-scanned output VTC-PG pattern. Method 1.
  • Page 152 2AV/X Maintenance Description item No. U998 Outputting the memory list Description Outputs the list of memory. Purpose To output the list as required. Method Press the start key. Entering the address 1. Select the item by lighting a copy exposure indicator using the copy exposure adjustment keys. Copy exposure indicator Description Setting range...

  • Page 153: Paper Misfeed Detection

    2AV/X 1-5-1 Paper misfeed detection (1) Paper misfeed indication When a paper misfeed occurs, the copier immediately stops copying and displays the jam location on the operation panel. Paper misfeed counts sorted by the detection condition can be checked in maintenance item U903. To remove paper jammed in the copier, open the front cover, paper conveying unit or drawer.
  • Page 154 2AV/X Jam code Contents See pape No paper feed from copier upper drawer P.1-5-4 No paper feed from copier lower drawer P.1-5-4 No paper feed from first optional drawer P.1-5-4 No paper feed from second optional drawer P.1-5-4 No paper feed from bypass P.1-5-4 Misfeed in copier vertical paper conveying section P.1-5-5...

  • Page 155: Paper Misfeed Detection Conditions

    2AV/X (2) Paper misfeed detection conditions DFSW DFSW (ST) 1 Figure 1-5-3 1-5-3...
  • Page 156 2AV/X 1. Jam at power-on • One or more of the switches in the paper feed conveying system is on when the main switch is turned on (jam code 00). 2. Paper feed section • No paper feed from copier upper drawer (jam code 10) The registration switch (RSW) does not turn on within 980 ms of the upper paper feed clutch (PFCL-U) turning on.
  • Page 157 2AV/X • Misfeed in copier vertical paper conveying section (jam code 15) The registration switch (RSW) does not turn on within 3200 ms of the drawer feed switch* (DFSW) turning on (when paper is fed from optional drawer 1). DFSW* 3200 ms Timing chart 1-5-6 •...
  • Page 158 2AV/X Drawer feed switch (ST) 1* (DFSW (ST) 1) does not turn off within the time required to convey the length of the used paper size plus 2000 ms of turning on (when paper is fed from optional drawer 2). DFSW (ST) 1* Paper size + 2000 ms Timing chart 1-5-11...
  • Page 159 2AV/X 5. Eject section • Misfeed in eject section The eject switch (ESW) does not turn off within 2475 ms of the registration switch (RSW) turning off. 2475 ms Timing chart 1-5-16 1-5-7...

  • Page 160: Paper Misfeeds

    2AV/X (3) Paper misfeeds Problem Causes/check procedures Corrective measures A piece of paper torn from Check visually and remove any found. A paper jam in the copy paper is caught paper feed, around the registration conveying, fixing or switch, the drawer feed eject section is switch* , drawer feed switch...
  • Page 161 2AV/X Problem Causes/check procedures Corrective measures Paper in optional drawer Change the paper. A paper jam in the is extremely curled. paper feed section Check if the paper feed Check visually and replace the pulleys if deformed. is indicated during pulleys of optional drawer copying (no paper are deformed.
  • Page 162 2AV/X Problem Causes/check procedures Corrective measures Broken drawer feed Check visually and replace the drawer feed switch* if its A paper jam in the switch* actuator. actuator is broken. paper feed section Defective drawer feed With 5 V DC present at CN8-21 on the main PCB, check if CN8- is indicated during switch* 23 on the main PCB remains low when the drawer feed switch*...
  • Page 163 2AV/X Problem Causes/check procedures Corrective measures (10) Broken drawer feed Check visually and replace the drawer feed switch* if its A paper jam in the switch* actuator. actuator is broken. paper feed section Defective drawer feed With 5 V DC present at CN8-21 on the main PCB, check if CN8- is indicated during switch* 23 on the main PCB remains low when the drawer feed switch*...

  • Page 164: Self-Diagnosis

    2AV/X 1-5-2 Self-diagnosis (1) Self-diagnostic function This unit is equipped with a self-diagnostic function. When a problem is detected, copying is disabled. On the 20 cpm copier, the problem is displayed as a code consisting of "C" followed by a number between 011 and 821, indicating the nature of the problem.

  • Page 165: Gear

    2AV/X Remarks Code Contents Causes Check procedures/corrective measures C100 Exposure lamp problem Poor contact of Check the connection of connectors CN24, • Check the CCD input value for the the connector CN23, CN22 and CN3 on the main PCB, lighting status of the exposure lamp terminals.
  • Page 166 2AV/X Remarks Code Contents Causes Check procedures/corrective measures C401 Polygon motor steady-state problem Poor contact of Reinsert the connector. Also check for • The polygon motor rotation is not the polygon motor continuity within the connector cable. If stable for 400 ms after the polygon connector none, repair or replace the cable.
  • Page 167 2AV/X Remarks Code Contents Causes Check procedures/corrective measures C620 Abnormally low fixing unit Fixing heater Check and reinstall if necessary. thermistor temperature installed • The fixing temperature remains below incorrectly. 100˚C/212˚F for 10 s during copying. Broken fixing Check for continuity. If none, replace fixing heater wire.
  • Page 168 2AV/X Remarks Code Contents Causes Check procedures/corrective measures C731 Short-circuited external temperature Poor contact of Reinsert the connector. Also check for thermistor the humidity continuity within the connector cable. If • The input voltage is below 0.5 V. sensor PCB none, repair or replace the cable.

  • Page 169: Image Formation Problems

    2AV/X 1-5-3 Image formation problems (1) No image appears (2) No image appears (3) Image is too light. (4) Background is visible. (entirely white). (entirely black). See page 1-5-18 See page 1-5-18 See page 1-5-19 See page 1-5-19 (5) A white line appears (8) One side of the copy (7) A black line appears (6) A black line appears...
  • Page 170 2AV/X (1) No image appears Causes (entirely white). 1. No transfer charging. Causes Check procedures/corrective measures 1. No transfer charging. A. Broken transfer wire. Replace or repair the wire. B. The connector terminals of the high-voltage Reinsert the connector. Also check for continuity within the transformer PCB make poor contact.
  • Page 171 2AV/X (3) Image is too Causes light. 1. Insufficient toner. 2. Deteriorated developer. 3. Dirty or deteriorated drum. Causes Check procedures/corrective measures 1. Insufficient toner. If the display shows the message requesting toner replenishment, replace the cartridge. 2. Deteriorated developer. Check the number of copies made with the current developer.
  • Page 172 2AV/X (6) A black line appears Causes longitudinally. 1. Dirty contact glass. 2. Dirty or flawed drum. 3. Deformed or worn cleaning blade. 4. Dirty scanner mirror. Causes Check procedures/corrective measures 1. Dirty contact glass. Clean the contact glass. 2. Dirty or flawed drum. Clean the drum or, if it is flawed, replace it (see page 1-6-43).

  • Page 173: Gear

    2AV/X (9) Black dots appear Causes on the image. 1. Dirty or flawed drum. 2. Dirty contact glass. 3. Deformed or worn cleaning blade. Causes Check procedures/corrective measures 1. Dirty or flawed drum. Clean the drum or, if it is flawed, replace it (see page 1-6-43). 2.
  • Page 174 2AV/X (12) The leading edge of Causes the image is sporadi- 1. Registration clutch, bypass paper feed clutch cally misaligned with or paper feed clutch installed or operating the original. incorrectly. Causes Check procedures/corrective measures 1. Registration clutch, bypass paper feed clutch Check the installation position and operation of the registration or paper feed clutch installed or operating clutch, bypass paper feed clutch and paper feed clutches.
  • Page 175 2AV/X Causes (15) Image is partly miss- 1. Paper damp. ing. 2. Paper creased. 3. Drum condensation. 4. Flawed drum. Causes Check procedures/corrective measures 1. Paper damp. Check the paper storage conditions. 2. Paper creased. Replace the paper. 3. Drum condensation. Clean the drum.
  • Page 176 2AV/X (19) Image is not Causes square. 1. Laser scanner unit positioned incorrectly. 2. Image scanning unit positioned incorrectly. Causes Check procedures/corrective measures 1. Laser scanner unit positioned incorrectly. Adjust the installation position of the laser scanner unit (see page 1-6-26). 2.

  • Page 177: Gear

    2AV/X 1-5-4 Electrical problems Problem Causes Check procedures/corrective measures No electricity at the power Measure the input voltage. The machine does outlet. not operate when The power cord is not Check the contact between the power plug and the outlet. the main switch is plugged in properly.
  • Page 178 2AV/X Problem Causes Check procedures/corrective measures Broken cooling fan motor 3 Check for continuity across the coil. If none, replace cooling fan Cooling fan motor 3 coil. motor 3. does not operate. Poor contact in the cooling Reinsert the connector. Also check for continuity within the fan motor 3 connector connector cable.
  • Page 179 2AV/X Problem Causes Check procedures/corrective measures (16) Poor contact in the Reinsert the connector. Also check for continuity within the The exposure lamp exposure lamp connector connector cable. If none, remedy or replace the cable. does not turn on. terminals. Defective inverter PCB.
  • Page 180 2AV/X Problem Causes Check procedures/corrective measures (24) Original is not placed Check the original and correct if necessary. The original size is correctly. not detected Poor contact in the original Reinsert the connector. Also check for continuity within the correctly. size detection sensor connector cable.
  • Page 181 2AV/X Problem Causes Check procedures/corrective measures (28) Poor contact in upper Reinsert the connector. Also check for continuity within the The size of paper in paper size switch 4 connector cable. If none, remedy or replace the cable. the upper drawer is connector terminals.

  • Page 182: The Scanner Does Not Travel

    2AV/X 1-5-5 Mechanical problems Problem Causes/check procedures Corrective measures Check if the surfaces of the following pulleys Clean with isopropyl alcohol. No primary paper feed. are dirty with paper powder: upper paper feed pulleys, lower paper feed pulleys* and bypass paper feed pulleys. Check if the paper feed pulleys are Check visually and replace any deformed deformed.

  • Page 183: Precautions For Assembly And Disassembly

    2AV/X 1-6-1 Precautions for assembly and disassembly (1) Precautions • Be sure to turn the main switch off and disconnect the power plug before starting disassembly. • When handling PCBs, do not touch connectors with bare hands or damage the board. •...

  • Page 184: Running A Maintenance Item

    2AV/X (2) Running a maintenance item Start Enter “10871087” using Maintenance mode is entered. the numeric keys. Enter the maintenance item number using the cursor up/down keys The maintenance item is (20 cpm), the zoom +/– keys (15 cpm) selected. or numeric keys.

  • Page 185: Paper Feed Section

    2AV/X 1-6-2 Paper feed section (1) Detaching and refitting the upper and lower paper feed pulleys Follow the procedure below to replace the paper feed pulleys. Procedure • Upper paper feed pulleys 1. Open the bypass tray and paper conveying unit and then remove the rear and rear left covers.
  • Page 186 2AV/X 6. Open the front cover and remove the image Stop ring formation unit (see page 1-6-40). 7. Remove the stop ring from the paper feed shaft unit (machine front). Figure 1-6-4 8. Push the paper feed shaft unit toward the machine rear (in the direction of 1) and remove the unit from the lower front side (in the direction of 2).
  • Page 187 2AV/X • Lower peper feed pulleys (optional for the 15 cpm copier) 1. Open the lower drawer left cover and pull the Drawer drive motor lower drawer out. 2. Remove the two screws holding the rear cover of the lower drawer and then the cover. 3.

  • Page 188: Detaching And Refitting The Bypass Paper Feed Pulley

    2AV/X (2) Detaching and refitting the bypass paper feed pulley Follow the procedure below to replace the bypass paper feed pulley. Procedure 1. Open the bypass tray, paper conveying unit and front cover and then remove the image formation unit (see page 1-6-40). 2.
  • Page 189 2AV/X 5. Remove the rear screw of the bypass paper feed pulley and then the pulley. Bypass paper feed pulley Figure 1-6-12 6. Replace the bypass paper feed pulley and refit all the removed parts. • When refitting, check that the cam on the rear of the shaft is correctly positioned (see figure 1-6-13).

  • Page 190: Detaching And Refitting The Left Registration Cleaner Assembly

    2AV/X (3) Detaching and refitting the left registration cleaner assembly Follow the procedure below to replace the left registration cleaner assembley. Procedure 1. Open the bypass tray and paper conveying Left registration roller unit. 2. Remove the transfer roller unit (see page 1-6- 47).

  • Page 191: Detaching And Refitting The Bypass Paper Width Switch

    2AV/X (5) Detaching and refitting the bypass paper width switch Follow the procedure below to replace the bypass paper width switch. Procedure 1. Remove the paper conveying unit and lower left cover (see page 1-6-6). 2. Remove the bypass tray assembly. 3.

  • Page 192: Adjustment After Roller And Clutch Replacement

    2AV/X (6) Adjustment after roller and clutch replacement Perform the following adjustment after refitting rollers and clutches. (6-1) Adjusting the leading edge registration of image printing Make the following adjustment if there is a regular error between the leading edges of the copy image and original. U066 U071 U034...
  • Page 193 2AV/X • 15 cpm Leading edge registration Start Correct image Output Output example 1 example 2 Enter maintenance mode. Figure 1-6-19b Photo G Image mode selection key Enter “034” using the numeric keys. Text Text indicator : Leading edge registration adjustment is on Press the start key.

  • Page 194: Adjusting The Leading Edge Registration For Memory Image Printing

    2AV/X (6-2) Adjusting the leading edge registration for memory image printing Make the following adjustment if there is a regular error between the leading edge of the copy image and the leading edge of the original during memory copying. U066 U053 U034 U065...

  • Page 195: Adjusting The Center Line Of Image Printing

    2AV/X (6-3) Adjusting the center line of image printing Make the following adjustment if there is a regular error between the center lines of the copy image and original when paper is fed from the drawer. U067 U072 U034 (P. 1-6-37) (P.
  • Page 196 2AV/X • 15 cpm Center line of printing Correct image Output Output example 1 example 2 Start Figure 1-6-21b Enter maintenance mode. Enter “034” using the numeric keys. Photo G Image mode selection key Text Photo and text indicators : Center line adjustment Press the start key.

  • Page 197: Adjusting The Margins For Printing

    2AV/X (6-4) Adjusting the margins for printing Make the following adjustment if the margins are not correct. U403 U404 U402 (P. 1-6-38) (P. 1-4-46) Caution: Check the copy image after the adjustment. If the margins are still incorrect, perform the above adjustments in maintenance mode.
  • Page 198 2AV/X • 15 cpm Start Enter maintenance mode. Enter “402” using the numeric keys. G Copy exposure adjustment keys Press the start key. Setting 1 : printer leading edge margin 2 : printer left/right margins 3 : printer trailing edge margin (standard size) Select the item to be adjusted using 4 : printer trailing edge margin...

  • Page 199: Adjusting The Amount Of Slack In The Paper

    2AV/X (6-5) Adjusting the amount of slack in the paper Make the following adjustment if the leading edge of the copy image is missing or varies randomly, or if the copy paper is Z-folded. Procedure • 20 cpm Start Original Copy Copy example 1...
  • Page 200 2AV/X • 15 cpm Original Copy Copy example 1 example 2 Figure 1-6-22b Start Enter maintenance mode. G Image mode G Image mode Photo Photo selection key selection key Text Text Enter “051” using the numeric keys. Text indicator : Amount of slack at the Photo and Text : Amount of slack at is on...

  • Page 201: Optical Section

    2AV/X 1-6-3 Optical section (1) Detaching and refitting the exposure lamp Replace the exposure lamp as follows. Procedure 1. Remove the original cover or the DF. Contact glass 2. Remove the five screws holding the right cover. While sliding the right cover in the direction of the arrow in the diagram, remove the contact glass.

  • Page 202: Detaching And Refitting The Scanner Wires

    2AV/X (2) Detaching and refitting the scanner wires Take the following procedure when the scanner wires are broken or to be replaced. Caution: After replacing the scanner wires, proceed to (4-1) Adjusting the skew of the laser scanner unit (see page 1-6-26) and (6) Adjusting the position of the ISU (see page 1-6-30).

  • Page 203: Fitting The Scanner Wires

    2AV/X (2-2) Fitting the scanner wires Caution: When fitting the wires, be sure to use those specified below. Machine front: P/N 2AV1219 (black) Machine rear: P/N 2AV1220 (gray) Fitting requires the following tools: Two frame securing tools (P/N 2AV6808) Two scanner wire stoppers (P/N 3596811) Procedure Scanner motor unit 1.
  • Page 204 2AV/X 4. Insert the locating ball on each of the scanner wires into the hole in the respective scanner wire drum and wind the scanner wire three turns inward and four turns outward. • With the locating ball as the reference point, Scanner wire stoppers wind the shorter end of each of the wires inward.
  • Page 205 2AV/X 8. Loop the inner ends of the scanner wires around the grooves in the pulleys at the right of the scanner unit, winding from below to above.......................... 1 9. Loop the scanner wires around the inner grooves in the pulleys on the mirror 2 frame, winding from above to below.

  • Page 206: Detaching And Refitting The Laser Scanner Unit

    2AV/X (3) Detaching and refitting the laser scanner unit Take the following procedure when the laser scanner unit is to be checked or replaced. Procedure 1. Open the front cover. 2. Remove the two screws holding the eject tray and then the tray. Eject tray Figure 1-6-35 3.
  • Page 207 2AV/X 5. Check or replace the laser scanner unit and LSU front spacer refit all the removed parts. Caution: Before fitting the new laser scanner unit, fit the LSU front spacer and LSU right spacer by orienting the markings correctly and using the correct layer as specified on the label on the laser scanner unit cover.

  • Page 208: Adjusting The Skew And Vertical Shifting Of The Laser Scanner Unit

    2AV/X (4) Adjusting the skew and vertical shifting of the laser scanner unit (4-1) Adjusting the skew of the laser scanner unit Perform the following adjustment if the leading and trailing edges of the copy image are laterally skewed (lateral squareness not obtained).

  • Page 209: Adjusting The Vertical Shifting Of The Laser Scanner Unit

    2AV/X (4-2) Adjusting the vertical shifting of the laser scanner unit Perform the following adjustment if the copy image shifts vertically due to vertical shifting of the position of the laser scanner unit. Vertical shifting : X (mm) Start Enter maintenance mode. Copy Copy Correct image...

  • Page 210: Detaching And Refitting The Isu (Reference)

    2AV/X (5) Detaching and refitting the ISU (reference) Take the following procedure when the ISU is to be checked or replaced. Caution: After fitting the ISU, proceed to (6) Adjusting the position of the ISU (see page 1-6-30). ISU installation requires the following tools: Two positioning pins (P/N 1856812) Procedure •...
  • Page 211 2AV/X • Refitting the ISU 1. Fit the ISU using the two positioning pins. Positioning pins 2. Secure the ISU using the four screws. 3. Remove the two positioning pins and refit all the removed parts. Figure 1-6-44 1-6-29...

  • Page 212: Adjusting The Position Of The Isu (Reference)

    2AV/X (6) Adjusting the position of the ISU (reference) Perform the following adjustment if the leading and trailing edges of the copy image are laterally skewed (lateral squareness not obtained). Caution: • Be sure to perform “(4-1) Adjusting the skew of the laser scanner unit” (page 1-6-26) first. •...

  • Page 213: Adjusting The Longitudinal Squareness (Reference)

    2AV/X (7) Adjusting the longitudinal squareness (reference) Perform the following adjustment if the copy image is longitudinally skewed (longitudinal squareness not obtained). Caution: • Adjust the amount of slack in the paper (page 1-6-17) first. Check for the longitudinal squareness of the copy image, and if it is not obtained, perform the longitudinal squareness adjustment.

  • Page 214: Adjusting Magnification Of The Scanner In The Main Scanning Direction

    2AV/X (8) Adjusting magnification of the scanner in the main scanning direction Perform the following adjustment if the magnification in the main scanning direction is not correct. U065 U065 U053 U067 (auxiliary scanning (main scanning (P. 1-4-11) (P. 1-6-37) direction) (P. 1-6-34) direction) Caution: Before making the following adjustment, ensure that the above adjustments have been made in maintenance mode.
  • Page 215 2AV/X • 15 cpm Start Copy Original Copy Enter maintenance mode. example 2 example Figure 1-6-49b Enter “065” using the numeric keys. Press the start key. Select “1” (main scanning direction G Copy exposure adjustment keys using the copy exposure Setting 1 : Main scanning direction adjustment keys).

  • Page 216: Adjusting Magnification Of The Scanner In The Auxiliary Scanning Direction

    2AV/X (9) Adjusting magnification of the scanner in the auxiliary scanning direction Perform the following adjustment if the magnification in the auxiliary scanning direction is not correct. U065 U065 U053 U070 (main scanning (auxiliary scanning (P. 1-4-11) (P. 1-4-14) direction) (P. 1-6-32) direction) Caution: Before making the following adjustment, ensure that the above adjustments have been made in maintenance mode.
  • Page 217 2AV/X • 15 cpm Start Copy Original Copy example 2 Enter maintenance mode. example 1 Figure 1-6-50b Enter “065” using the numeric keys. Press the start key. G Copy exposure adjustment keys Select “2” (auxiliary scanning direction using the copy exposure Setting 1 : Main scanning direction adjustment keys).

  • Page 218: Adjusting The Scanner Leading Edge Registration

    2AV/X (10) Adjusting the scanner leading edge registration Perform the following adjustment if there is regular error between the leading edges of the copy image and original. U034 U071 U066 (P. 1-6-10) (P. 1-4-14) Caution: Before making the following adjustment, ensure that the above adjustments have been made in maintenance mode. Procedure Scanner leading edge registration Start...

  • Page 219: Adjusting The Scanner Center Line

    2AV/X (11)Adjusting the scanner center line Perform the following adjustment if there is a regular error between the center lines of the copy image and original. U034 U071 U067 (P. 1-6-10) (P. 1-4-14) Caution: Before making the following adjustment, ensure that the above adjustments have been made in maintenance mode. Procedure Scanner center line Start...

  • Page 220: Adjusting The Margins For Scanning An Original On The Contact Glass

    2AV/X (12) Adjusting the margins for scanning an original on the contact glass Perform the following adjustment if the margins are not correct. U402 U404 U403 (P. 1-6-15) (P. 1-4-46) Caution: Before making the following adjustment, ensure that the above adjustments have been made in maintenance mode. Procedure •...
  • Page 221 2AV/X • 15 cpm Start Enter maintenance mode. Enter “403” using the numeric keys. Press the start key. G Copy exposure adjustment keys Setting 1 : scanner left margin 2 : scanner leading edge margin Select the item to be adjusted using 3 : scanner right margin the copy exposure adjustment keys.

  • Page 222: Main Charging Section

    2AV/X 1-6-4 Main charging section (1) Detaching and refitting the charger assembly Follow the procedure below to replace the charger assembly. Prucedure 1. Open the bypass tray, paper conveying unit Connector and front cover, and then remove the toner cartridge and waste toner tank. Hook 2.

  • Page 223: Replacing The Tungsten Wire (Reference)

    2AV/X (2) Replacing the tungsten wire (reference) Take the following procedure when the tungsten wire is broken or to be replaced. Precautions • Use the specified tungsten wire (P/N: 2AR1016). • The part of the wire wrapped around the charger spring must not protrude over the L-shaped hook in the main charger rear housing.
  • Page 224 2AV/X 6. Wind the new tungsten wire six turns around one end of the charger spring and trim the end. • The width of the coiled tungsten wire and the cut end must be less than 2 mm. 7. Hook the other end of the charger spring onto the charger terminal of the main charger rear housing. 8.

  • Page 225: Drum Section

    2AV/X 1-6-5 Drum section (1) Detaching and refitting the drum Follow the procedure below to replace the drum. Cautions: • Avoid direct sunlight or strong light when detaching and fitting the drum. • Hold the drum at the ends and never touch the drum surface. •...

  • Page 226: Developing Section

    2AV/X 1-6-6 Developing section (1) Adjusting the position of the doctor blade (reference) Perform the following adjustment if carrier or background appears on the copy image. Procedure 1. Remove the image formation unit (see page MC rail 1-6-40). 2. Remove the charger assembly (see page 1- 6-40).

  • Page 227: Transfer Section

    2AV/X 1-6-7 Transfer section (1) Detaching and refitting the transfer roller assembly Follow the procedure below to replace the transfer roller assembly. Procedure 1. Open the bypass tray and paper conveying unit. 2. Remove the transfer roller assembly. Caution: Remove the transfer roller assembly carefully to prevent the residual toner in the transfer roller assembly from spilling.

  • Page 228: Cleaning Section

    2AV/X 1-6-8 Cleaning section (1) Detaching and refitting the cleaning blade Follow the procedure below to replace the cleaning blade. Procedure 1. Remove the image formation unit and the charger assembly (see page 1-6-40). Cleaning blade 2. Remove the MC rail (see page 1-6-44). 3.

  • Page 229: Detaching And Refitting The Drum Separation Claw Assemblies

    2AV/X (2) Detaching and refitting the drum separation claw assemblies Follow the procedure to replace the drum separation claw assemblies. Procedure 1. Remove the image formation unit (see page Drum separation claw assemblies 1-6-40). 2. Remove the screw holding each of the drum separation claw assemblies and then the assemblies.

  • Page 230: Detaching And Refitting The Fixing Unit

    2AV/X 1-6-9 Fixing section (1) Detaching and refitting the fixing unit Follow the procedure below to check or replace the fixing unit. Procedure 1. Open the bypass tray, paper conveying unit Connector (blue) and front cover, and then remove the rear cover, left front cover and left rear cover.

  • Page 231: Detaching And Refitting The Fixing Unit Thermistor

    2AV/X (2) Detaching and refitting the fixing unit thermistor Follow the procedure below to replace the fixing unit thermistor. Procedure 1. Remove the fixing unit (see page 1-6-48). Fixing unit thermister 2. Remove the screw and detach the connector, and then remove the fixing unit thermistor. 3.

  • Page 232: Detaching And Refitting The Fixing Heater

    2AV/X (4) Detaching and refitting the fixing heater Follow the procedure below to replace the fixing heater. Procedure 1. Remove the fixing unit (see page 1-6-48). 2. Detach the fixing heater connector. Connector Figure 1-6-72 3. Remove the screw holding each of the fixing heater front and rear retainers and then the retainers.

  • Page 233: Detaching And Refitting The Heat Roller

    2AV/X (5) Detaching and refitting the heat roller Follow the procedure below to replace the heat roller. Procedure 1. Remove the fixing unit (see page 1-6-48). 2. Remove the fixing unit thermistor, fixing heater and heat roller separation claw assemblies (see pages 1-6-49 and 50). 3.
  • Page 234 2AV/X 6. Remove the four screws holding the fixing housing and then the housing. Fixing housing Figure 1-6-78 7. Remove the pressure spring from each of the front and rear ends of the fixing unit. Press springs Figure 1-6-79 8. Remove the C ring, gear and bushing on the C ring rear and the C ring and bushing on the front of the heat roller, and then remove the heat...

  • Page 235: Detaching And Refitting The Press Roller

    2AV/X (6) Detaching and refitting the press roller Follow the procedure below to replace the press roller. Procedure 1. Remove the fixing unit (see page 1-6-48). 2. Remove the heat roller (see page 1-6-51). 3. Remove the screw holding the fixing guide plate and then the plate.

  • Page 236: Replacing The Main Pcb

    2AV/X-1 1-7-1 Replacing the main PCB Main PCB replacement requires the following tools: Memory tool PCB (P/N 2AV68030) NVRAM (P/N NAS09010) Procedure • Before replacing the main PCB (backing up the machine data) 1. Turn the main switch off and disconnect the Upper shield power plug.
  • Page 237 2AV/X 6. Insert the power plug and turn the main switch on. LED1 (green) on the memory tool PCB flashes (on for 1 s → off for 1 s) for approximately 10 seconds and the machine data on the SRAM of the main PCB will be backed up on the NVRAM. 7.

  • Page 238: Upgrading The Firmware On The Main Pcb

    2AV/X 1-7-2 Upgrading the firmware on the main PCB Firmware upgrading requires the following tools: Flash tool assembly (P/N 35968010) Memory tool PCB (P/N 2AV68030) Master ROMs 15 cpm: Main ROM 1 IC (P/N 2AV68060) 20 cpm: Main ROM IC (P/N 2AX68010) Procedure 1.
  • Page 239 2AV/X 7. Insert the power plug and turn the main switch on. LED2 (green) on the flash tool assembly flashes and upgrading of the master ROM starts. 8. When flashing LED2 (green) remains lit after approximately 30 to 40 seconds, upgrading of the master ROM is complete.

  • Page 240: Upgrading The Firmware On The Operation Unit Pcb (20 Cpm Copier Only)

    2AV/X 1-7-3 Upgrading the firmware on the operation unit PCB (20 cpm copier only) Firmware upgrading requires the following tools: Flash tool assembly (P/N 35968010) Master ROMs Inch specifications Operation unit ROM 1 IC (P/N 2AX68020) Metric specifications Operation unit ROM 1 IC (P/N 2AX68040) Procedure 1.

  • Page 241: Adjustment-Free Variable Resistors (Vr)

    2AV/X 1-7-4 Adjustment-free variable resistors (VR) The variable resistors listed below are set at the factory prior to shipping and cannot be adjusted in the field. • High-voltage transformer PCB: VR101, VR102, VR201, VR301, VR302 • Inverter PCB: VR1, VR2 1-7-6...

  • Page 242: Paper Feed Section

    2AV/X 2-1-1 Paper feed section The paper feed section consists of the primary feed and secondary feed subsections. Primary feed conveys paper from the upper drawer, lower drawer or bypass tray to the left and right registration rollers, at which point secondary feed takes place and the paper travels to the transfer section in sync with the printing timing.
  • Page 243 2AV/X MPCB CN4-10 CN3-7 PFCL-U CN4-14 CN3-10 PSW-U BYPPFCL CN4-12 CN6-2 BYPPSW CN8-3 PFCL-L* CN8-15 PSW-L* *Optional for the 15 cpm copier. Figure 2-1-2 Paper feed section block diagram Start key 263 ms 300 ms 300 ms 263 ms 100 ms 100 ms PFCL-U 2927 ms (20 cpm)
  • Page 244 2AV/X Start key 263 ms 300 ms 100 ms BYPPFCL 3000 ms Original: A5R, copy paper: A3/11" × 17", magnification ratio 200% Timing chart 2-1-2 Paper feed from the bypass tray a: When the start key is pressed, the drive motor (DM) turns on. b: 3000 ms after the drive motor (DM) turns on, the bypass paper feed clutch (BYPPFCL) turns on and the bypass paper feed pulleys rotate to start primary paper feed.

  • Page 245: Main Charging Section

    2AV/X 2-1-2 Main charging section The main charging section consists of the drum and main charger assembly. The drum is electrically charged by means of a grid to form a latent image on the surface. The shield grid ensures that the charge is applied uniformly. Tungsten wire Main charger assembly Drum...
  • Page 246 2AV/X HVTPCB MPCB 24 V DC CN1-9 CN4-1 MC REM CN1-7 CN4-3 GRID GRID CONT CN1-4 CN4-6 MC ALM Drum CN1-1 CN4-9 Figure 2-1-5 Main charging section block diagram Start key 840 ms 500 ms MC REM Timing chart 2-1-3 Main charging a: 500 ms after the start key is pressed, main charging (MC REM) starts.

  • Page 247: Optical Section

    2AV/X 2-1-3 Optical section The optical section consists of the scanner, mirror frames and the image scanning unit for scanning and the laser scanner unit for printing. Figure 2-1-6 Optical section 1 Mirror 1 frame 2 Mirror 2 frame 3 Exposure lamp (EL) 4 Mirror 1 5 Mirror 2 6 Mirror 3...

  • Page 248: Original Scanning

    2AV/X (1) Original scanning The original image is illuminated by the exposure lamp (EL) and scanned by the CCD PCB (CCDPCB) in the image scanning unit via the three mirrors, the reflected light being converted to an electrical signal. The scanner and mirror frames travel to scan on the optical rails on the front and rear of the machine to scan from side to side.

  • Page 249: Image Printing

    2AV/X (2) Image printing The image data scanned by the CCD PCB (CCDPCB) is processed on the main PCB (MPCB) and transmitted as image printing data to the laser scanner unit (LSU). By repeatedly turning the laser on and off, the laser scanner unit forms a latent image on the drum surface.
  • Page 250 2AV/X Drum Figure 2-1-9 Laser scanner unit (2) 1 Laser diode: Generates the laser beam which forms a latent image on the drum. 2 Collimator lens: Collimates the diffused laser beam emitted from the laser diode to convert it into a cylindrical beam. 3 Cylindrical lens: Shapes the collimated laser beam to suit the printing resolution.

  • Page 251: Developing Section

    2AV/X 2-1-4 Developing section The developing section consists of the developing unit and the toner cartridge. The developing unit consists of the developing roller where a magnetic brush is formed, the doctor blade and the developing spirals that agitate the developer. Toner from the toner cartridge and residual toner collected in the cleaning section are conveyed to the waste toner tank.

  • Page 252: Formation Of Magnetic Brush

    2AV/X (1) Formation of magnetic brush The developing roller consists of a magnet roller with five poles and a sleeve roller. Rotation of the sleeve roller around the magnet roller entrains developer, which in turn forms a magnetic brush at pole N1 on the magnet roller. The height of the magnetic brush is regulated by the doctor blade;...

  • Page 253: Toner Density Detection By The Toner Sensor

    2AV/X (2) Toner density detection by the toner sensor The toner sensor (TNS) detects the toner density. As the developer passes by the sensor section of the toner sensor, the toner sensor detects the ratio of toner to carrier in the developer and converts it into a voltage. When more toner is used, the ratio of toner to carrier decreases and the toner sensor output voltage increases.

  • Page 254: Correcting The Toner Sensor Control Voltage

    2AV/X (4) Correcting the toner sensor control voltage The toner sensor control voltage is corrected based on the absolute humidity and the total drive motor time so that the toner density is kept constant regardless of the changes in humidity and the total drive motor time. Toner sensor control voltage after correction = A + B + C A: Toner sensor control voltage before correction (value set by maintenance item U131) B: Correction data based on the absolute humidity...

  • Page 255: Correcting Toner Output Voltage

    2AV/X • Correction based on the total drive motor time The toner sensor control voltage is also corrected based on the total time the drive motor (DM) has been on from execution of maintenance item U130, so that the toner sensor output voltage is regulated properly. Correction data X-10 X-20...

  • Page 256: Transfer And Separation Section

    2AV/X 2-1-5 Transfer and separation section The transfer and separation section consists mainly of the transfer roller and drum separation claws. A high voltage generated by the high-voltage transformer PCB (HVTPCB) is applied to the transfer roller for transfer charging. Toner adhered to the transfer roller is removed by the transfer cleaner. Separation claw pulleys Drum separation claws Transfer roller...
  • Page 257 2AV/X Start key 418 ms TC REM 474 ms Timing chart 2-1-5 Operation of transfer a: 418 ms after the registration clutch (RCL) turns on to start secondary paper feed, transfer charging (TC REM) starts. b: 474 ms after the trailing edge of the paper turns the registration switch (RSW) off, transfer charging (TC REM) ends. 2-1-16...

  • Page 258: Cleaning Section

    2AV/X 2-1-6 Cleaning section The cleaning section consists of the cleaning blade that removes residual toner from the drum surface after the transfer process, and the cleaning spiral that carries the residual toner back to the waste toner tank. Cleaning spiral Lower cleaning seal Cleaning blade Drum...

  • Page 259: Charge Erasing Section

    2AV/X 2-1-7 Charge erasing section The cleaning lamp (CL) consists of LEDs which remove residual charge from the drum surface. Cleaning lamp (CL) Light-blocking lumirror Figure 2-1-23 Charge erasing section MPCB CL REM CN12-2 Drum Figure 2-1-24 Charge erasing section block diagram Start key MC REM 1316 ms...

  • Page 260: Fixing Section

    2AV/X 2-1-8 Fixing section The fixing section consists of the parts shown in Figure 2-1-25. When paper reaches the fixing section after the transfer process, it passes between the press roller and heat roller, which is heated by the fixing heater (FH). Pressure is applied by the fixing unit pressure springs so that the toner on the paper is melted, fused and fixed onto the paper.
  • Page 261 2AV/X 1500 ms 1000 ms 20 s 30 s DB REM Half speed Full speed Half speed CFM1, 2, 3 Timing chart 2-1-7 Operation of fixing section a: 1500 ms after the main switch (MSW) is turned on, the fixing heater (FH) turns on to heat the heat roller. At the same time, cooling fan motors 1, 2 and 3 (CFM1, 2 and 3) rotate at half speed.

  • Page 262: Electrical Parts Layout

    2AV/X 2-2-1 Electrical parts layout (1) PCBs Machine front Machine inside Machine rear Figure 2-2-1 PCBs 1. Main PCB (MPCB) ........Controls the other PCBs, electrical components and optional devices. 2. Power source PCB (PSPCB) ....... Generates 24 V DC, +12 V DC, 5V DC and 3.3 V DC; controls the fixing heater.

  • Page 263: Switches And Sensors

    2AV/X (2) Switches and sensors 11 9 7 12 10 8 Machine front Machine inside Machine rear Figure 2-2-2 Switches and sensors 1. Main switch (MSW) ........Turns the AC power on and off. 2. Safety switch 1 (SSW1) ....... Breaks the safety circuit when the front cover is opened. 3.
  • Page 264 2AV/X 16. Bypass paper width switch (BYPPSW) ........... Detects the width of paper on the bypass tray. 17. Drawer feed switch* (DFSW) ....... Detects a paper misfeed in the lower drawer. 18. Scanner home position switch (SHPSW) ............. Detects the optical system in the home position. 19.

  • Page 265: Motors

    2AV/X (3) Motors Machine front Machine inside Machine rear Figure 2-2-3 Motors 1. Drive motor (DM) ......... Drives the machine. 2. Scanner motor (SM) ........Drives the optical system. 3. Toner feed motor (TFM) ....... Replenishes toner. 4. Cooling fan motor 1 (CFM1) ......Cools the fixing section. 5.

  • Page 266: Other Electrical Components

    2AV/X (4) Other electrical components Machine front Machine inside Machine rear Figure 2-2-4 Other electrical components 1. Upper paper feed clutch (PFCL-U) ....Primary paper feed from the upper drawer. 2. Lower paper feed clutch* (PFCL-L) ..... Primary paper feed from the lower drawer. 3.

  • Page 267: Power Source Pcb

    2AV/X 2-3-1 Power source PCB Power source PCB AC input Noise Rectifier circuit 24 V DC filter 24 V DC output C29,30 circuit circuit 12 V DC 12 V DC output circuit 5.1 V DC 5.1 V DC output C37,91 circuit IC4 Switching Zero-cross...
  • Page 268 2AV/X • 100V LUG1 L5 D13 LUG2 • 200V LUG1 L5 D13 LUG2 Figure 2-3-2 Power source PCB silk-screen diagram 2-3-2...
  • Page 269 2AV/X Terminals (CN) Voltage Remarks TB-1 TB-2 120 V AC 120 V AC supply, input TB-1 TB-2 220-240 V AC 220-240 V AC supply, input* TB-4 TB-5 120 V AC 120 V AC supply for MSW, output TB-4 TB-5 220-240 V AC 220-240 V AC supply for MSW, output* 120 V AC AC supply for FH, output...

  • Page 270: Main Pcb

    2AV/X 2-3-2 Main PCB • 15 cpm copier Main PCB Clock signal Analog image data CCD PCB Even Print data Printer data FEEPROM Printer controller* IC11 Memory image data Address bus Memory PCB* Data bus IC16 STDF* Control signal output Job separator* SRAM Driver...
  • Page 271 2AV/X CN25 CN23 CN22 CN24 CN20 CN21 IC5 1 2AV2801 REV:2 BAT1 IC10 IC11 IC12 IC15 IC18 IC19 IC29 IC30 Figure 2-3-4 Main PCB silk-screen diagram (15 cpm copier) 2-3-5...
  • Page 272 2AV/X • 20 cpm copier Main PCB Scan signal Driver Operation unit PCB Detection signal input LCD controller SRAM LCD display data IC12 IC19 Address bus Operation Flash tool Data bus unit CPU IC10 Clock signal Analog image data CCD PCB FEEPROM IC16 Even...
  • Page 273 2AV/X The main PCB (MPCB) consists of the main CPU and operation unit CPU. The main CPU IC23 communicates with other PCBs and controls memory copying, the image processing system and the engine drive system. The operation unit CPU IC10 controls the LCD display and the entire operation section. The main CPU IC23 operates on an 8-bit bus.
  • Page 274 2AV/X CN28 CN25 CN23 CN22 CN24 CN20 CN21 CN26 CN27 IC15 IC10 IC11 IC14 IC12 IC16 CN29 CN34 50 49 2AX2801 REV : 3 IC22 IC28 IC39 IC43 IC42 IC46 IC40 Figure 2-3-6 Main PCB silk-screen diagram (20 cpm copier) 2-3-8...
  • Page 275 2AV/X Terminals (CN) Voltage Remarks 3.3 V DC 3.3 V DC supply from PSPCB, input 1-5, 6 1-3, 4 5 V DC 5 V DC supply from PSPCB, input 1-9, 10 1-7, 8 24 V DC 24 V DC supply from PSPCB, input 12 V DC 12 V DC supply from PSPCB, input 0/5 V DC...
  • Page 276 2AV/X Terminals (CN) Voltage Remarks 8-15 8-22 0/5 V DC PSW-L* on/off, input 8-16 8-22 0/5 V DC PSW (ST) 1* on/off, input 8-17 8-22 0/5 V DC PSW (ST) 2* on/off, input 8-18 8-22 0/24 V DC DDM*2 on/off, output 8-19 8-22 0/24 V DC...
  • Page 277 2AV/X Terminals (CN) Voltage Remarks 14-2B 14-4A 0/5 V DC OSLED* (green) on/off, output 14-3B 14-4A 0/5 V DC SBPSOL* release signal, output 14-4B 14-4A 0/5 V DC SBPSOL* actuate signal, output 14-5B 14-4A 0/5 V DC OFCL* on/off, output 14-6B 14-4A 0/5 V DC...
  • Page 278 2AV/X Terminals (CN) Voltage Remarks 20-4 20-2 0/5 V DC PM READY signal, input 20-5 20-2 0/5 V DC (pulse) PM drive clock pulse, output 21-1 21-2 0/5 V DC LDPCB HSYNC signal, input 21-3 21-2 5 V DC 5 V DC supply for LDPCB, output 21-5 21-2 0/5 V DC...
  • Page 279 2AV/X Terminals (CN) Voltage Remarks 27-11 27-12 -12-0 V DC LCD Vo signal, output 28-1 24-5 0/24 V DC (pulse) SM coil energization pulse, output (_A) 28-2 24-5 24 V DC 24 V DC supply for SM, output 28-3 24-5 0/24 V DC (pulse) SM coil energization pulse, output (A) 28-4...

  • Page 280: Ccd Pcb

    2AV/X 2-3-3 CCD PCB CCD PCB Main PCB Logic IC1 Clock signal generator ASIC SHIFT SHIFT Transistor TR2 Analog signal processing circuit Even Even Transistor TR1 Figure 2-3-7 CCD PCB block diagram The CCD PCB (CCDPCB) is equipped with a CCD sensor IC2 for original scanning. The CCD sensor IC2 is controlled by the clock signals φ1, φ2, RS, CLP and SHIFT for CCD drive from the main PCB (MPCB) via logic IC1.

  • Page 281: Laser Diode Pcb

    2AV/X 2-3-4 Laser diode PCB Main PCB Laser diode PCB /ADJUST Laser driver Photo /ENABLE Driver sensor /VIDEO Figure 2-3-8 Laser diode PCB block diagram The laser diode PCB (LDPCB) consists of the laser diode LD1 and laser driver IC1. The laser driver IC1 on the laser diode PCB (LDPCB) turns the laser diode LD1 on and off according to the image data received from the main PCB (MPCB).
  • Page 282 2AV/X 2-4-1...
  • Page 283 2AV/X 2-4-2...
  • Page 284 2AV/X " × 8 " original onto a sheet of A3/11" × 17" copy paper from the bypass tray, magnification ratio 200% Timing chart No. 3 Copying an A5R/5 Start key Any key Fwd. rotation CN28-1,3,4,6 Rev. rotation 1078 P 34 P 472 P 2834 P...
  • Page 285 2AV/X Timing chart No. 4 Continuous copying of an A4/11" × 8 " original onto two sheets of A4/11" × 8 " copy paper from the upper drawer, magnification ratio 100% (20 cpm copier) Start key Any key Fwd. rotation CN28-1,3,4,6 Rev.

  • Page 286: Timing Chart No. 5

    2AV/X Timing chart No. 5 Continuous copying of an A4/11" × 8 " original onto two sheets of A4/11" × 8 " copy paper from the upper drawer, magnification ratio 100% (15 cpm copier) Start key Any key Fwd. rotation CN28-1,3,4,6 Rev.
  • Page 287 2AV/X Timing chart No. 6 Continuous copying of an A3/11" × 17" original onto two sheets of A5R/5 " × 8 " copy paper from the lower drawer, magnification ratio 50%, ejection to the job separator Start key Fwd. rotation CN28-1,3,4,6 Rev.

  • Page 288: Timing Chart No. 7

    2AV/X " × 11" original onto two sheets of A4R/8 " × 11" copy paper from optional drawer 1, magnification ratio 100% (15 cpm copier) Timing chart No. 7 Continuous copying of an A4R/8 Start key CN12-16 CN8-18 DDM (ST) 1 CN8-19 CN4-10 100 ms...
  • Page 289 2AV/X Timing chart No. 8 Continuous copying of an A4/11" × 8 " original onto two sheets of A4/11" × 8 " copy paper from optional drawer 1, magnification ratio 100%, ejection to the finisher (20 cpm copier) Start key CN12-16 CN8-18 DDM (ST) 1...

  • Page 290: Timing Chart No. 9

    2AV/X Timing chart No. 9 Continuous copying of an A4/11" × 8 " × 11" copy paper from optional drawer 1, magnification ratio 100%, ejection to the finisher (20 cpm copier) " original onto two sheets of A4R/8 Start key CN12-16 CN8-18 DDM (ST) 1...
  • Page 291 2AV/X " × 11" original onto a duplex A4R/8 " × 11" copy from optional drawer 2, magnification ratio 100%, ejection to the job separator Timing chart No. 10 Duplex copying of a single-sided A4R/8 (20 cpm copier) Start key CN12-16 CN8-18 DDM (ST) 1...
  • Page 292 2AV/X General wiring diagram (1) Output Output Output PSW-L PSW (ST) 1 PSW (ST) 2 DFSW DFSW (ST) 1 DFSW (ST) 2 Input Input Input Output DDMPCB Output DDMPCB (ST) 1 Output DDMPCB (ST) 2 PSW-L PSW (ST) 1 PSW (ST) 2 COM B COM B COM B...
  • Page 293 General wiring diagram (2) 2AV/X Duplex unit (Option) BIAS 24VT DRUM 24VT GRID LIVE Job separator 12-7 OCSW 24VT (Option) 12-6 MDPCB 12-5 WTDSW JOFSW FSOFSW SSW2 JBESW 220-240V INLET FSSOL FSSOL FSESW Duplex unit for finisher* (Option) LIVE CN2-1 Heater HVTPCB Noise filter...

  • Page 294: Maintenance Parts List

    2AV/X Maintenance parts list • Copier Maintenance part name Part No. Fig. No. Ref. No. Name used in service manual Name used in parts list Right registration roller RIGHT ROLLER, REGISTRATION 2AV06060 Left registration roller LEFT ROLLER, REGISTRATION 2AV06070 Upper paper feed pulley PULLEY, PAPER FEED 2AV06010 Lower paper feed pulley...

  • Page 295: Periodic Maintenance Procedures

    2AV/X Periodic maintenance procedures • Copier Maintenance Section Method Maintenance cycle Points and cautions Page part/location Test copy and Perform at the maximum Test copy Every service test print copy size Maintenance Section Method Maintenance cycle Points and cautions Page part/location Paper feed Right registration roller...
  • Page 296 2AV/X Maintenance Section Method Maintenance cycle Points and cautions Page part/location Optical section Original size detection Clean Every service Clean the sensor emitter and (con.) sensor receiver with alcohol and then a dry cloth only if there is a problem. Maintenance Section Method...
  • Page 297 2AV/X Maintenance Section Method Maintenance cycle Points and cautions Page part/location Fixing/Eject Heat roller Clean or replace Clean after 100,000 Clean with alcohol. 1-6-51 section counts; check and replace after 200,000 counts Press roller Clean or replace Clean after 100,000 Clean with alcohol.
  • Page 298 2AV/X General wiring diagram (1) Output Output Output PSW-L PSW (ST) 1 PSW (ST) 2 DFSW DFSW (ST) 1 DFSW (ST) 2 Input Input Input Output DDMPCB Output DDMPCB (ST) 1 Output DDMPCB (ST) 2 PSW-L PSW (ST) 1 PSW (ST) 2 COM B COM B COM B...
  • Page 299 General wiring diagram (2) 2AV/X Duplex unit (Option) BIAS 24VT DRUM 24VT GRID LIVE Job separator 12-7 OCSW 24VT (Option) 12-6 MDPCB 12-5 WTDSW JOFSW FSOFSW SSW2 JBESW 220-240V INLET FSSOL FSSOL FSESW Duplex unit for finisher* (Option) LIVE CN2-1 Heater HVTPCB Noise filter...
  • Page 300 STDF-3...
  • Page 301 CONTENTS 1-1 Specifications 1-1-1 Specifications ............................1-1-1 1-1-2 Part names and their functions ......................1-1-2 1-1-3 Machine cross section .......................... 1-1-3 1-1-4 Drive system ............................1-1-4 1-2 Installation 1-2-1 Unpacking ............................1-2-1 1-3 Troubleshooting 1-3-1 Original misfeed detection ........................1-3-1 (1) Original misfeed indication ......................
  • Page 302 2-3 Operation of the PCBs 2-3-1 DF driver PCB ............................2-3-1 2-3-2 Original size detection PCB ......................... 2-3-4 2-4 Appendixes Timing chart No. 1 ............................2-4-1 Timing chart No. 2 ............................2-4-2 Periodic maintenance procedures ........................2-4-3 Wiring diagram ............................... 2-4-4 1-1-2...

  • Page 303: Specifications

    1-1-1 Specifications Original feed system ...... Automatic feed Originals ......... Sheets Original weights ......35 – 160 g/m Original sizes ........A3 – A5R, folio/11" × 17" – 5 " × 8 " , or 11" × 8 Number of originals ......Up to 70 sheets (A4 or smaller paper of 80 g/m "...

  • Page 304: Part Names And Their Functions

    1-1-2 Part names and their functions Figure 1-1-1 1 Original table 2 Original insertion guides 3 DF open/close handle 4 Original eject cover 5 DF original cover 1-1-2...

  • Page 305: Machine Cross Section

    1-1-3 Machine cross section Original path Figure 1-1-2 Machine cross section 1-1-3...

  • Page 306: Drive System

    1-1-4 Drive system & Figure 1-1-3 1 Original feed motor gear 0 Idle gear Z45/B16 2 Gear 42/29 ! Original conveying belt 92 3 Lift gear 38 @ Tension pulley 4 Idle gear 20 # Registration pulley 19 5 Original feed gear 30 $ Original conveying pulley 24 6 Original feed pulley % Original conveying belt 190...

  • Page 307: Unpacking

    1-2-1 Unpacking Figure 1-2-1 Unpacking 1 Sheet through DF 2 Installation manual 3 Plastic bag 4 Bottom pads 5 Upper pad 6 Outer case 7 Plastic sheet 8 Bar-code labels 9 Plastic bag 1-2-1...

  • Page 308: Original Misfeed Detection

    1-3-1 Original misfeed detection (1) Original misfeed indication When an original jams, the machine immediately stops operation and the occurrence of an original jam is indicated on the copier operation panel. To remove the jammed original, open the DF or the DF original cover. To reset the original misfeed detection, open and close the DF or the DF original cover to turn DF safety switch 1 or 2 off and    DFTSW...

  • Page 309: Original Misfeed Detection Condition

    (2) Original misfeed detection condition • No original feed (jam code 70) During the primary feed of the second or later original, the DF timing switch (DFTSW) does not turn on within 1410 original feed motor (OFM) pulses of the start of forward rotation of the original feed motor (OFM). After up to five retries, the DF timing switch (DFTSW) still fails to turn on.

  • Page 310: Original Misfeeds

    (3) Original misfeeds Problem Causes Check procedures/corrective measures A piece of paper torn from Remove any found. An original jams an original is caught around when the main the actuator of the original switch is turned on. size detection PCB. Defective original size With 5 V DC present at CN5-8 on the DF driver PCB, check if detection PCB.
  • Page 311 1-3-2 Image formation problems (1) There is a regular error (2) There is a regular error between the centers of between the leading the original and copy edges of the original image when the DF is and copy image when used.
  • Page 312 (1) There is a regular error Causes between the centers of 1. Misadjusted DF center line. the original and copy image when the DF is used. Causes Check procedures/corrective measures 1. Misadjusted DF center line. Readjust the DF center line (see page 1-4-7). (2) There is a regular error Causes between the leading...

  • Page 313: Electrical Problems

    1-3-3 Electrical problems Problem Causes Check procedures/corrective measures Broken original feed motor Check for continuity across the coil. If none, replace the original The original feed coil. feed motor. motor does not The connector terminals of Reinsert the connector. Also check for continuity within the operate.

  • Page 314: Mechanical Problems

    1-3-4 Mechanical problems Problem Causes/check procedures Corrective measures The surfaces of the DF forwarding pulley, DF Check and clean them with isopropyl No primary original feed. original feed pulley or DF separation pulley alcohol if they are soiled. are soiled with paper powder. Check if the DF forwarding pulley, DF original Check visually and replace the deformed feed pulley or DF separation pulley is...

  • Page 315: Precautions For Assembly And Disassembly

    1-4-1 Precautions for assembly and disassembly (1) Precautions • Be sure to turn the main switch off and disconnect the power plug before starting disassembly. • When handling PCBs, do not touch connectors with bare hands or damage the board. •...

  • Page 316: Procedure For Assembly And Disassembly

    1-4-2 Procedure for assembly and disassembly (1) Detaching and refitting the DF forwarding pulley and DF original feed pulley Clean or replace the DF forwarding pulley and DF original feed pulley as follows. Procedure 1. Open the DF original cover. 2.

  • Page 317: Detaching And Refitting The Df Separation Pulley

    (2) Detaching and refitting the DF separation pulley Clean or replace the DF separation pulley as follows. Procedure 1. Open the DF original cover. Original feed guide 2. Remove the screw securing the original feed guide and then the guide. Figure 1-4-4 3.

  • Page 318: Adjusting The Lateral Squareness Of The Df

    (3) Adjusting the lateral squareness of the DF Perform the following adjustment if the leading edge or trailing edge of the copy image is laterally skewed (lateral squareness not obtained). Caution: Before adjusting the lateral squareness of the DF, adjust the amount of slack in the paper at the registration roller and scanner image lateral squareness at the copier first and check the lateral squareness of the copy image by copying using the DF.

  • Page 319: Adjusting The Df Magnification

    (4) Adjusting the DF magnification Adjust magnification in the auxiliary scanning direction if magnification is incorrect when the DF is used. U053 U034 U402 U065 U066 U071 U404 U403 U070 (P. 1-4-9) (P. 1-4-13) Caution: Before making the following adjustment, ensure that the above adjustments have been made in maintenance mode. Procedure Main scanning direction...
  • Page 320 • 15 cpm copier Main scanning direction Start Auxiliary Enter maintenance mode. scanning direction Enter “070” using the numeric keys. Original Copy Copy example 1 example 2 Press the start key. Figure 1-4-9 Press the interrupt key. Press the start key. The new setting is stored.

  • Page 321: Adjusting The Df Center Line

    (5) Adjusting the DF center line Perform the following adjustment if there is a regular error between the centers of the original and the copy image when the DF is used. U404 U034 U402 U067 U403 U072 (P. 1-4-13) Caution: Before making the following adjustment, ensure that the above adjustments have been made in maintenance mode.
  • Page 322 • 15 cpm copier Start Reference Enter maintenance mode. Enter “072” using the numeric keys and press the start key. Original Copy Copy example 2 example 1 Press the interrupt key. Press the start key. Figure 1-4-11 The new setting is stored.

  • Page 323: Adjusting The Scanning Start Position When The Df Is Used

    (6) Adjusting the scanning start position when the DF is used Perform the following adjustment if there is a regular error between the leading or trailing edges of the original and the copy image. U404 U402 U034 U066 U403 U071 (P.
  • Page 324 • 15 cpm copier Start Enter maintenance mode. Enter “071” using the numeric Original Copy Copy keys and press the start key. example 1 example 2 Figure 1-4-13 Light the copy exposure indicator exp. 1 using the copy exposure adjustment keys. Press the interrupt key.

  • Page 325: Adjusting The Df Trailing Edge Registration

    (6-2) Adjusting the DF trailing edge registration Perform the following adjustment if the original scanning end position is not correct. Caution: If the copies look like copy example 2, clean the DF original scanning section. Procedure • 20 cpm copier Start Enter maintenance mode.
  • Page 326 • 15 cpm copier Start Enter maintenance mode. Enter “071” using the numeric keys and press the start key. Original Copy Copy example 1 example 2 Light the copy exposure indicator exp. 2 using the copy exposure Figure 1-4-15 adjustment keys. Press the start key.

  • Page 327: Adjusting The Margins For Scanning The Original From The Df

    (7) Adjusting the margins for scanning the original from the DF Perform the following adjustment if margins are not correct. U403 U402 U404 Caution: Before making the following adjustment, ensure that the above adjustments have been made in maintenance mode. Procedure •...
  • Page 328 • 15 cpm copier Start Enter maintenance mode. Enter “404” using the numeric keys. Press the start key. Adjustment items (copy exposure indicator) Exp. 1: DF left margin Select the item to be adjusted using Exp. 2: DF leading edge margin the copy exposure adjustment keys.

  • Page 329: Mechanical Construction

    2-1-1 Mechanical construction (1) Original feed mechanism The DF consists of the components shown in Figure 2-1-1. It conveys the original across the DF contact glass in synchro- nization with the copier scanning operation. During primary original feed, the original feed motor (OFM) turns on and the lift cam starts rotating, moving the lift guide up until the originals make contact with the DF forwarding pulley.
  • Page 330 DFTSW OSDPCB DFDPCB Figure 2-1-2 DF block diagram 2-1-2...

  • Page 331: Original Feed Timing

    (2) Original feed timing DF start signal DFTSW Fwd. rotation 300 P 450 P 192 P 192 P Rev. rotation 3606/3329 P 1260/1129 P Fwd. rotation 2300 P Rev. rotation Original: A4R/11" × 8 " : Burst of OFM pulses : Burst of OCM pulses * Metric/inch Timing chart 2-1-1...
  • Page 332     2-2-2 Electrical parts layout Machine front Machine inside Machine rear Figure 2-2-1 1. DF driver PCB (DFDPCB) ......Controls electrical components. 2. DF safety switch 1 (DFSSW1) ..... Breaks the safety circuit when the DF original cover is opened; resets original jam detection.
  • Page 333 2-3-1 DF driver PCB DF driver PCB 24 V DC 24 V DC OCM A Motor OCM B driver IC OCM A OCM B 24 V DC Copier 24 V DC OFM A Motor OFM B driver IC OFM A OFM B Switches Figure 2-3-1 DF driver PCB block diagram...
  • Page 334 Figure 2-3-2 DF driver PCB silk-screen diagram 2-3-2...
  • Page 335 Terminals (CN) Voltage Remarks 1-3, 4 24 V DC 24 V DC supply, input 1-3, 4 24 V DC 24 V DC supply, input 1-9, 10 5 V DC 5 V DC supply, input 1-9, 10 5 V DC 5 V DC supply, input 1-3, 4 24/0 V DC DFSSW2 off/on, output...
  • Page 336 2-3-2 Original size detection PCB CN2-1 CN1-1 CN1-2 CN1-3 CN1-4 CN1-5 CN1-6 CN2-3 CN1-7 DFTSW DFTSW CN2-2 CN1-8 Figure 2-3-3 Original size detection circuit The original size detection PCB (OSDPCB) consists of five transmission-type photointerrupters, the original set switch (PI5) and original size width switches B to E (PI4 to PI1).
  • Page 337 • Original size detection Original size width switches B to E (PI4 to PI1) are arranged from the inner side to the outer side of the PCB as shown in Figure 2-3-4. When an original is placed on the original table, the original size is determined by the turning on of the original size width switches and the on/off status of the original size length switch (OSLSW) on the original table.
  • Page 338 2-4-1...
  • Page 339 2-4-2...
  • Page 340 Periodic maintenance procedures Maintenance Section Method Maintenance cycle Points and cautions Page part/location Original feed DF original feed pulley Replace Every service 1-4-2, section and DF separation pulley DF forwarding pulley Replace Every service 1-4-2 Original size detection Clean Every service Airbrush.
  • Page 341 2-4-4...
  • Page 342 J-1302...

  • Page 343: Electrical Parts Layout

    CONTENTS 1-1 Specifications 1-1-1 Specifications ............................1-1-1 1-1-2 Part names and their functions ......................1-1-2 1-1-3 Machine cross section .......................... 1-1-3 1-1-4 Drive system ............................1-1-4 1-2 Installation 1-2-1 Unpacking ............................1-2-1 1-3 Troubleshooting 1-3-1 Paper misfeed detection ........................1-3-1 (1) Paper misfeed indication .......................

  • Page 344: Specifications

    1-1-1 Specifications Type ..........Enclosed Tray capacity ........100 sheets of 64 – 80 g/m paper Paper ..........Plain paper: 75 – 80 g/m Special paper: colored paper Paper sizes ........A3 – A5R, folio/11" × 17" – 5 " × 8 "...

  • Page 345: Part Names And Their Functions

    1-1-2 Part names and their functions Figure 1-1-1 1 Job separator tray 2 LED 1-1-2...

  • Page 346: Machine Cross Section

    1-1-3 Machine cross section Paper path Figure 1-1-2 1-1-3...

  • Page 347: Drive System

    1-1-4 Drive system Figure 1-1-3 1 Gear 20 2 Gear 14 3 Gear 21 4 Eject roller gear 1-1-4...

  • Page 348: Unpacking

    1-2-1 Unpacking 1 Job separator 2 Right eject cover 3 Job separator tray 4 Pin 5 Two (2) cross-head bronze binding screws BMV3 × 05 6 Jam correction label 7 Installation manual 8 Plastic bag 9 Upper pad & 0 Spacer ! Bottom pad &...

  • Page 349: Paper Misfeed Detection

    1-3-1 Paper misfeed detection (1) Paper misfeed indication When paper jams, the machine immediately stops operation and the occurrence of a paper jam is indicated on the copier operation panel. To remove the jammed paper, open the copier left cover. To reset the paper misfeed detection, open and close the copier left cover to turn safety switch 2 off and on.

  • Page 350: Paper Misfeed Detection Condition

    (2) Paper misfeed detection condition • Jam in job separator eject section (jam code 51) The job separator eject switch (JBESW) does not turn off within 1260 ms of the copier eject switch (ESW) turning off. ESW (copier) 1260 ms JBESW Timing chart 1-3-1 1-3-2...

  • Page 351: Paper Misfeeds

    (3) Paper misfeeds Problem Causes/check procedures Corrective measures A piece of paper torn from Remove any found. Paper jams when the copy paper is caught main switch is turned around the job separator eject switch. Defective job separator With 5 V DC present at CN16-6 on the copier main PCB, check if eject switch.

  • Page 352: Electrical Problems

    1-3-2 Electrical problems Problem Causes Check procedures/corrective measures Broken feedshift solenoid Check for continuity across the coil. If none, replace the feedshift The feedshift coil. solenoid. solenoid does not Poor contact of the Reinsert the connector. Also check for continuity within the operate.

  • Page 353: Mechanical Problems

    1-3-3 Mechanical problems Problem Causes/check procedures Corrective measures Check if the contact between the job eject Check and remedy. Paper jams. pulley and job eject roller is correct. Check if the job eject pulley, job eject roller Grease the bushings and gears. Abnormal noise is and gears operate smoothly.

  • Page 354: Construction Of Each Section

    2-1-1 Construction of each section The job separator consists of the components shown in Figure 2-1-1. It switches the paper path to eject copied paper to the job separator tray. Figure 2-1-1 Job separator 1 Job eject pulley 5 Lower left guide 2 Job eject roller 6 Job separator tray 3 Upper guide...

  • Page 355: Switching The Paper Path

    (1) Switching the paper path If the job separator is selected for the copy eject location, when a copy is made, the feedshift solenoid (FSSOL) turns on and the feedshift guide of the copier operates to switch the paper path to the job separator. The copied paper is conveyed to the job separator and then ejected to the job separator tray.

  • Page 356: Electrical Parts Layout

       2-2-1 Electrical parts layout    Machine front Machine inside Machine rear Figure 2-2-1 1. Job separator eject switch (JBESW) ... Detects a paper jam in the job separator. 2. Ejected paper detection switch (EPDSW) ... Detects the presence of paper on the job separator tray. 3.

  • Page 357: Periodic Maintenance Procedures

    Periodic maintenance procedures Maintenance Section Method Maintenance cycle Points and cautions Page part/location Paper Job eject roller Clean Every service Clean with alcohol or a dry cloth. conveying Job separator tray Clean Every service Spray air onto the black pad. section 2-3-1...
  • Page 358 AD-61...
  • Page 359 CONTENTS 1-1 Specifications 1-1-1 Specifications ............................1-1-1 1-1-2 Part names and their functions ......................1-1-2 1-1-3 Machine cross section .......................... 1-1-3 1-1-4 Drive system ............................1-1-4 (1) Feedshift section ........................... 1-1-4 (2) Duplex unit ............................ 1-1-5 1-2 Installation 1-2-1 Unpacking ............................1-2-1 1-3 Troubleshooting 1-3-1 Paper misfeed detection ........................
  • Page 360 1-1-1 Specifications Type ..........Outboard Paper ..........Plain paper: 75 – 80 g/m Special paper: colored paper Paper sizes ........A3 – A5R, folio/11" × 17" – 5 " × 8 " Power source ......... Electrically connected to the copier Dimensions ........

  • Page 361: Part Names And Their Functions

    1-1-2 Part names and their functions Figure 1-1-1 1 Duplex handle 2 Open/close guide 1-1-2...

  • Page 362: Machine Cross Section

    1-1-3 Machine cross section Paper path Figure 1-1-2 1 Feedshift section 2 Duplex unit 1-1-3...
  • Page 363 1-1-4 Drive system (1) Feedshift section Figure 1-1-3 1 Feedshift motor gear 5 Gear 30 2 Gear 19/38 6 Gear 19/21 3 Gear 23 7 Gear 25 4 Gear 19 1-1-4...
  • Page 364 (2) Duplex unit Figure 1-1-4 1 Gear 20 6 Gear 25 2 Gear 20 7 Pulley 20 3 Gear 16 8 Duplex belt 4 Gear 16 9 Pulley 20 5 Gear 25 1-1-5...

  • Page 365: Unpacking

    1-2-1 Unpacking &* „ )⁄ ˇ ¤ fi ´ ‚ ‹ › ° ∏ Á ¨ fl ‡ ‰ ˆ Œ ‡ ˆ Ø fl ‰ · Figure 1-2-1 Unpacking 1 Feedshift unit % Seven (7) cross head chrome binding fl...

  • Page 366: Paper Misfeed Detection

    1-3-1 Paper misfeed detection (1) Paper misfeed indication When paper jams, the machine immediately stops operation and the occurrence of a paper jam is indicated on the copier operation panel. To remove the jammed paper, open the duplex unit. To reset the paper misfeed detection, open and close the duplex unit to turn the duplex open/close switch off and on. DUPPCSW1 DUPPCSW2 Figure 1-3-1 Paper misfeed detection...

  • Page 367: Paper Misfeed Detection Conditions

    (2) Paper misfeed detection conditions • Jam in feedshift section (jam code 51) Duplex paper conveying switch 1 (DUPPCSW1) does not turn on within 1640 ms of the start of reverse rotation of the feedshift motor (FSM). Rev. rotation 1640 ms DUPPCSW1 Timing chart 1-3-1 •...

  • Page 368: Paper Misfeeds

    (3) Paper misfeeds Problem Causes Check procedures/corrective measures A piece of paper torn from Remove any found. Paper jams in the copy paper is caught duplex unit when the around duplex paper main switch is turned conveying switch 1 or 2. Defective duplex paper With 5 V DC present at CN5-11 on the copier main PCB, check if conveying switch 1.

  • Page 369: Electrical Problems

    1-3-2 Electrical problems Problem Causes Check procedures/corrective measures Broken feedshift solenoid Check for continuity across the coil. If none, replace the feedshift The feedshift coil. solenoid. solenoid does not Poor contact of the Reinsert the connector. Also check for continuity within the operate.

  • Page 370: Mechanical Problems

    1-3-3 Mechanical problems Problem Causes/check procedures Corrective measures Check if the contact between the right eject Check and remedy. Paper jams. pulley and right eject roller is correct. Check if the contact between the left eject Check and remedy. pulley and left eject roller is correct. Check if the duplex pulley, upper duplex roller Check visually and replace the pulley or or lower duplex roller is deformed.

  • Page 371: Precautions For Assembly And Disassembly

    1-4-1 Precautions for assembly and disassembly (1) Precautions • Be sure to turn the main switch off and disconnect the power plug before starting disassembly. • When handling PCBs, do not touch connectors with bare hands or damage the board. •...

  • Page 372: Procedure For Assembly And Disassembly

    1-4-2 Procedure for assembly and disassembly (1) Adjusting the margin for printing Perform the following adjustment if the printer leading edge margin for duplex copying (second face) is not correct. Procedure Printer leading edge margin Start for duplex copying (second face, 3 ± 2.5 mm) Enter maintenance mode.

  • Page 373: Adjusting The Amount Of Slack At The Registration Roller

    (2) Adjusting the amount of slack at the registration roller Perform the following adjustment if the leading edge of the copy image is missing or varies randomly, or if the copy paper is Z-folded during duplex copying. Procedure Start Enter maintenance mode. Original Copy Copy...

  • Page 374: Adjusting The Center Line Of Image Printing

    (3) Adjusting the center line of image printing Make the following adjustment if there is a regular error between the center lines of the copy image and original when copying using the duplex unit. Procedure Center line of printing Start Enter maintenance mode.

  • Page 375: Feedshift Section

    2-1-1 Feedshift section The feedshift section consists of the components shown in Figure 2-1-1. It switches the path for the paper conveyed from the copier during duplex copying. Figure 2-1-1 Feedshift section 1 Right eject pulley 6 Lower right guide 2 Right eject roller 7 Lower left guide 3 Left eject pulley...

  • Page 376: Paper Conveying Operation In The Feedshift Section

    (1) Paper conveying operation in the feedshift section In duplex mode, when the reverse face of the paper is copied, the feedshift solenoid (FSSOL) turns on and the feedshift guide of the copier operates to switch the paper path to the feedshift section. When the trailing edge of the paper passes the paper conveying switch (PCSW), the feedshift motor (FSM) reverses, rotating the right eject roller in the reverse direction to switch back the paper into the duplex unit.

  • Page 377: Duplex Unit

    2-1-2 Duplex unit The duplex unit consists of the components shown in Figure 2-1-4. In duplex mode, after copying on to the reverse face of the paper, the paper is reversed in the feedshift section and conveyed to the duplex unit. The paper is then conveyed to the copier paper feed section by the upper and lower duplex rollers.

  • Page 378: Electrical Parts Layout

    2-2-1 Electrical parts layout Machine front Machine inside Machine rear Figure 2-2-1 Feedshift unit 1. Motor driver PCB (MDPCB) ......Controls the feedshift motor. 2. Duplex open/close switch (DUPOCSW) ..Detects if the duplex unit is opened/closed. 3. Feedshift eject switch (FSESW) ....Detects a paper jam in the feedshift unit. 4.
  • Page 379    Machine front Machine inside Machine rear Figure 2-2-2 Duplex unit 1. Duplex paper conveying switch 1 (DUPPCSW1) ..........Detects a paper jam in the duplex unit. 2. Duplex paper conveying switch 2 (DUPPCSW2) ..........Detects a paper jam in the duplex unit. 2-2-2...

  • Page 380: Periodic Maintenance Procedures

    Periodic maintenance procedures Maintenance Section Method Maintenance cycle Points and cautions Page part/location Paper Upper duplex roller Clean Every service Clean with alcohol or a dry cloth. conveying Lower duplex roller Clean Every service Clean with alcohol or a dry cloth. section Job separator tray Clean...
  • Page 381 F-2205/AD-62...
  • Page 382 3BN/3A4 CONTENTS 1-1 Specifications 1-1-1 Specifications ............................1-1-1 1-1-2 Part names and their functions ......................1-1-2 (1) Finisher ............................1-1-2 (2) Duplex unit ............................ 1-1-3 1-1-3 Machine cross section .......................... 1-1-4 (1) Finisher ............................1-1-4 (2) Duplex unit ............................ 1-1-5 1-1-4 Drive system ............................
  • Page 383 3BN/3A4 1-4 Assembly and Disassembly 1-4-1 Precautions for assembly and disassembly ..................1-4-1 (1) Precautions ........................... 1-4-1 1-4-2 Finisher ..............................1-4-2 (1) Adjusting the positions of the front side registration cursor, rear side registration cursor and trailing edge registration cursor (reference) ................1-4-2 (2) Cleaning the stapler ........................

  • Page 384: Specifications

    3BN/3A4 1-1-1 Specifications Finisher Type ..........Built-in Number of trays ......1 (intermediate tray) Stapling limit ........A4/11" × 8 " or smaller: 30 sheets Other sizes than above: 20 sheets Power source ......... Electrically connected to the copier Dimensions ........696 (W) × 618 (D) × 281 (H) mm "...

  • Page 385: Part Names And Their Functions

    3BN/3A4 1-1-2 Part names and their functions (1) Finisher Figure 1-1-1 1 Intermediate tray 2 JAM release lever 3 Stapler 4 Eject tray 1-1-2...

  • Page 386: Duplex Unit

    3BN/3A4 (2) Duplex unit Figure 1-1-2 1 Duplex lever 2 Open/close guide 1-1-3...

  • Page 387: Machine Cross Section

    3BN/3A4 1-1-3 Machine cross section (1) Finisher Paper path Figure 1-1-3 Machine cross section (finisher) 1 Feedshift section 2 Intermediate tray section 3 Eject section 1-1-4...

  • Page 388: Duplex Unit

    3BN/3A4 (2) Duplex unit Paper path Figure 1-1-4 Machine cross section (duplex unit) 1-1-5...

  • Page 389: Drive System

    3BN/3A4 1-1-4 Drive system (1) Finisher % $ # & Figure 1-1-5 1 Paper conveying motor gear ! Gear 32 2 Gear 18/38 @ Stopper gear 26 3 Gear 18 # One-way gear 18 (rear) 4 Central gear $ Gear 21 (front) 5 Gear 15 % Central gear (middle) 6 Central gear (front)

  • Page 390: Duplex Unit

    3BN/3A4 (2) Duplex unit Figure 1-1-5 1 Gear 20 6 Gear 25 2 Gear 20 7 Pulley 20 3 Gear 16 8 Duplex belt 4 Gear 16 9 Pulley 20 5 Gear 25 1-1-7...

  • Page 391: Unpacking

    3BN/3A4 1-2-1 Unpacking ‹ ¤ „ fl fi ⁄ · Œ ‚ & ° ‡ › › Figure 1-2-1 Unpacking (finisher) 1 Intermediate tray unit & Outer case 2 Feedshift unit * Eject tray spacer 3 Eject unit ( Spacer B 4 Eject tray unit ) Spacer C 5 Stapler cover...
  • Page 392 3BN/3A4 ‹ ⁄ ¤ ¤ & Figure 1-2-2 Unpacking (duplex unit) 1 Duplex unit # One (1) cross-head tap-tight P chrome TP-A screw M4 × 12 2 Duplex joint 3 Front duplex fulcrum plate $ Bottom pads 4 Rear duplex fulcrum plate % Spacers 5 Front fulcrum hook ^ Upper pad...

  • Page 393: Paper Misfeed Detection

    3BN/3A4 1-3-1 Paper misfeed detection (1) Paper misfeed indication When paper jams, the machine immediately stops operation and the occurrence of a paper jam is indicated on the copier operation panel. To remove the jammed paper, lower the intermediate tray or open the duplex unit. To reset the paper misfeed detection, detach and refit the intermediate tray to turn the tray open/close switch off and on or open and close the duplex unit to turn the duplex open/close switch off and on.

  • Page 394: Paper Misfeed Detection Condition

    3BN/3A4 (2) Paper misfeed detection condition (2-1) Finisher • Jam between the finisher and copier (jam code 80) No signal indicating the completion of paper ejection is output from the finisher within 15 s of the paper conveying switch (PCSW) turning off. •...

  • Page 395: Duplex Unit

    3BN/3A4 (2-2) Duplex unit • Jam in feedshift section (jam code 51) Duplex paper conveying switch 1 (DUPPCSW1) does not turn on within 1640 ms of the start of reverse rotation of the paper conveying motor (PCM). Rev. rotation 1640 ms DUPPCSW1 Timing chart 1-3-5 •...

  • Page 396: Paper Misfeeds

    3BN/3A4 (3) Paper misfeeds (3-1) Finisher Problem Causes Check procedures/corrective measures A piece of paper torn from Remove any found. Paper jams in the copy paper is caught finisher when the around the paper main switch is turned conveying switch. Defective paper conveying With 5 V DC present at CN4-9 on the main PCB, check if CN4-10 switch.

  • Page 397: Duplex Unit

    3BN/3A4 (3-2) Duplex unit Problem Causes Check procedures/corrective measures A piece of paper torn from Remove any found. Paper jams in the copy paper is caught duplex unit when the around duplex paper main switch is turned conveying switch 1 or 2. Defective duplex paper With 5 V DC present at CN5-11 on the copier main PCB, check if conveying switch 1.

  • Page 398: Self-Diagnosis

    3BN/3A4 1-3-2 Self-diagnosis (1) Self-diagnostic function This unit is equipped with a self-diagnostic function. When a problem is detected, copying is disabled and the problem displayed as a code consisting of “C” followed by a number between 034 and 821, indicating the nature of the problem. A message is also displayed requesting the user to call for service.

  • Page 399: Self-Diagnostic Codes

    3BN/3A4 (2) Self-diagnostic codes Remarks Code Contents Causes Check procedure/corrective measures C034 Finisher communication problem The connector Check the connection of connector CN27 During the serial communication makes poor on the copier main PCB and CN1 on the between the copier and finisher, when contact.
  • Page 400 3BN/3A4 Remarks Code Contents Causes Check procedure/corrective measures C819 Trailing edge registration motor The trailing edge Reinsert the connector. Also check for problem registration motor continuity within the connector cable. If When the trailing edge registration connector makes none, repair or replace the cable. home position sensor is on during poor contact.

  • Page 401: Electrical Problems

    3BN/3A4 1-3-3 Electrical problems (1) Finisher Problem Causes Check procedures/corrective measures Broken paper conveying Check for continuity across the coil. If none, replace the paper The paper conveying motor coil. conveying motor. motor does not Poor contact of the paper Reinsert the connector.
  • Page 402 3BN/3A4 Problem Causes Check procedures/corrective measures Broken trailing edge Check for continuity across the coil. If none, replace the trailing Trailing edge registration motor coil. edge registration motor. registration motor Poor contact of the trailing Reinsert the connector. Also check for continuity within the does not operate.

  • Page 403: Duplex Unit

    3BN/3A4 (2) Duplex unit Problem Causes Check procedures/corrective measures Broken duplex feedshift Check for continuity across the coil. If none, replace the duplex The duplex feedshift solenoid coil. feedshift solenoid. solenoid does not Poor contact of the duplex Reinsert the connector. Also check for continuity within the operate.

  • Page 404: Mechanical Problems

    3BN/3A4 1-3-4 Mechanical problems (1) Finisher Problem Causes/check procedures Corrective measures Check if the contact between the feedshift Check and remedy. Paper jams. pulley and feedshift roller is correct. Check if the contact between the feedshift Check and remedy. roller and press roller is correct. Check if the rollers and gears operate Grease the bushings and gears.

  • Page 405: Abnormal Noise Is Heard

    3BN/3A4 (2) Duplex unit Problem Causes/check procedures Corrective measures Check if the duplex pulley, upper duplex roller Check visually and replace the pulley or Paper jams. or lower duplex roller is deformed. roller if deformed. Check if rollers and gears operate smoothly. Apply grease to the bushings and gears.

  • Page 406: Precautions For Assembly And Disassembly

    3BN/3A4 1-4-1 Precautions for assembly and disassembly (1) Precautions • Be sure to turn the main switch off and disconnect the power plug before starting disassembly. • When handling PCBs, do not touch connectors with bare hands or damage the board. •...

  • Page 407: Finisher

    3BN/3A4 1-4-2 Finisher (1) Adjusting the positions of the front side registration cursor, rear side registration cursor and trailing edge registration cursor (reference) Perform the following adjustment if paper registration is poor or stapling is made outside the specified area. Procedure Stapler Start...

  • Page 408: Cleaning The Stapler

    3BN/3A4 (2) Cleaning the stapler During periodic maintenance, remove all the staples remaining inside the machine due to failure of stapling. Procedure 1. Open the front cover of the copier. 2. Remove the staple cartridge. 3. Remove the screw securing the stapler cover and then the cover.

  • Page 409: Adjusting The Tension Of The Front And Rear Side Registration Belts

    3BN/3A4 (3) Adjusting the tension of the front and rear side registration belts Adjust the tension of each belt during periodic maintenance. Procedure 1. Remove the intermediate tray unit from the Intermediate tray unit copier. 2. Loosen the tension adjustment screws for the front and rear side registration belts.

  • Page 410: Duplex Unit

    3BN/3A4 1-4-3 Duplex unit (1) Adjusting the margin for printing Perform the following adjustment if the printer leading edge margin for duplex copying (second face) is not correct. Procedure Printer leading edge margin Start for duplex copying (second face, 3 ± 2.5 mm) Enter maintenance mode.

  • Page 411: Adjusting The Amount Of Slack At The Registration Roller

    3BN/3A4 (2) Adjusting the amount of slack at the registration roller Perform the following adjustment if the leading edge of the copy image is missing or varies randomly, or if the copy paper is Z-folded during duplex copying. Procedure Start Enter maintenance mode.

  • Page 412: Adjusting The Center Line Of Image Printing

    3BN/3A4 (3) Adjusting the center line of image printing Make the following adjustment if there is a regular error between the center lines of the copy image and original when copying using the duplex unit. Procedure Center line of printing Start Enter maintenance mode.

  • Page 413: Feedshift Section

    3BN/3A4 2-1-1 Feedshift section The feedshift section consists of the components shown in Figure 2-1-1. It switches the path for the paper conveyed from the copier in sort and duplex modes. Figure 2-1-1 Feedshift section 1 Feedshift pulley 5 Stopper 2 Feedshift roller 6 Feedshift claw 3 Press roller...

  • Page 414: Paper Conveying Operation In Sort Mode

    3BN/3A4 (1) Paper conveying operation in sort mode When a copy is made in the sort mode, the feedshift solenoid (FSSOL) turns on and the feedshift guide of the copier operates to switch the paper path to the feedshift section. The switchback solenoid (SBSOL) then turns on to lower the separation claw and the paper is conveyed to the intermediate tray by the feedshift roller.

  • Page 415: Switchback Operation In Duplex Mode

    3BN/3A4 (2) Switchback operation in duplex mode In duplex mode, when the rear face of the paper is copied, the paper is conveyed to the feedshift section in the same manner as in sort mode. When the trailing edge of the paper passes the paper conveying switch (PCSW), the paper conveying motor (PCM) reverses, rotating the feedshift roller in the reverse direction to switch back the paper into the duplex unit.

  • Page 416: Intermediate Tray Section

    3BN/3A4 2-1-2 Intermediate tray section The intermediate tray section consists of the components shown in Figure 2-1-5. It stores and evens up the paper conveyed from the feedshift section and returns the stack of paper to the feedshift section. Figure 2-1-5 Intermediate tray section 1 Intermediate tray 3 Rear side registration cursor 2 Front side registration cursor...

  • Page 417: Paper Registration On The Intermediate Tray

    3BN/3A4 (1) Paper registration on the intermediate tray In sort mode, the front and rear side registration cursors move to the size of the paper used to even up the sides of the stack of paper and the trailing edge registration cursor shifts the paper to the feedshift section. In staple-sort mode, the front and rear side registration cursors even up the sides of the stack of paper and shift the stack toward the machine front, and then the trailing edge registration cursor shifts the stack to the stapling position.

  • Page 418: Eject Section

    3BN/3A4 2-1-3 Eject section The eject section consists of the components shown in Figure 2-1-8. It ejects paper to the eject tray. Figure 2-1-8 Eject section 1 Eject tray 3 Eject roller 2 Eject pulley 4 Lower eject guide 2-1-6...

  • Page 419: Stapler Section

    3BN/3A4 2-1-4 Stapler section In staple-sort mode, paper stocked on the intermediate tray is stapled by the stapler. The stapler motor (STM) drives the stapler cam via the stapler drive gear to staple paper. Stapler drive gear Stapler motor Stapler self-priming Stapler cam Stapler cam sensor...

  • Page 420: Duplex Unit

    3BN/3A4 2-1-5 Duplex unit The duplex unit consists of the components shown in Figure 2-1-11. In duplex mode, it refeeds paper switched back in the feedshift section to the copier paper feed section. Figure 2-1-11 Duplex unit 1 Duplex feedshift guide 5 Open/close guide 2 Upper duplex roller 6 Entry guide...

  • Page 421: Switching The Paper Path In The Duplex Unit

    3BN/3A4 (1) Switching the paper path in the duplex unit In duplex mode, when the reverse face of the paper is copied, the paper is switched back in the feedshift section and conveyed to the duplex unit. The paper is then conveyed to the paper conveying section of the copier by the upper and lower duplex rollers.

  • Page 422: Electrical Parts Layout

    3BN/3A4 2-2-1 Electrical parts layout (1) Finisher Machine front Machine inside Machine rear Figure 2-2-1 Feedshift section 1. Left cover switch (LCSW) ......Detects if the copier left cover is opened or closed. 2. Paper conveying switch (PCSW) ....Detects a paper jam in the finisher. 3.
  • Page 423       3BN/3A4 Machine front Machine inside Machine rear Figure 2-2-2 Intermediate tray section 1. Main PCB (MPCB) ........Controls electrical components. 2. Tray open/close switch (TOCSW) ....Detects if the intermediate tray is opened or closed. 3.
  • Page 424 3BN/3A4          Machine front Machine inside Machine rear Figure 2-2-3 Stapler section 1. Stapler empty sensor (STES) ...... Detects the presence of staples. 2. Staple cartridge sensor (STCS) ....Detects the presence of the staple cartridge. 3.

  • Page 425: Duplex Unit

    3BN/3A4    (2) Duplex unit Machine front Machine inside Machine rear Figure 2-2-4 Duplex unit 1. Duplex feedshift solenoid (DUPFSSOL) ..Operates the duplex feedshift guide. 2. Duplex paper conveying switch 1 (DUPPCSW1) ..........Detects a paper jam in the duplex unit. 3.

  • Page 426: Main Pcb

    3BN/3A4 2-3-1 Main PCB Paper conveying motor, Solenoids feedshift solenoid, switchback solenoid Main PCB Driver drive Motors circuit CPU (IC5) Switches sensors Buffer IC12, IC13, IC14 Copier Figure 2-3-1 Main PCB block diagram The main PCB (MPCB) consists mainly of the CPU IC5 and driver drive circuit. The CPU IC5 detects the condition of the switches and sensors and controls the motors and solenoids by serially communicating with the copier.
  • Page 427 3BN/3A4 IC15 IC11 IC12 IC14 IC13 IC18 IC17 IC19 ZD1 D2 IC10 IC16 Figure 2-3-2 Main PCB silk-screen diagram 2-3-2...
  • Page 428 3BN/3A4 Terminals (CN) Voltage Remarks 0/5 V DC PCM control signal (MODE), input 5/0 V DC TOCSW on/off, output 0/5 V DC PCM on/off, input 0/5 V DC PCM control signal CWB, input 0/5 V DC (pulse) PCM clock signal, input 5 V DC 5 V DC supply, input 0/5 V DC...
  • Page 429 3BN/3A4 Terminals (CN) Voltage Remarks 0/24 V DC (pulse) TERM motor coil energization pulse, output (A) 24 V DC 24 V DC supply for TERM, output 24 V DC 24 V DC supply for PCM, output 24 V DC 24 V DC supply for PCM, output 0/24 V DC (pulse) PCM motor coil energization pulse, output (A) 6-10...
  • Page 430 3BN/3A4 2-4-1...
  • Page 431 3BN/3A4 2-4-2...
  • Page 432 3BN/3A4 2-4-3...
  • Page 433 3BN/3A4 2-4-4...

  • Page 434: Periodic Maintenance Procedure

    3BN/3A4 Periodic maintenance procedures • Finisher Maintenance Section Method Maintenance cycle Points and cautions Page part/location Stapler section Magnet Clean Every service Remove the staples attracted to 1-4-3 the magnet inside the stapler cover. • Duplex unit Maintenance Section Method Maintenance cycle Points and cautions Page...
  • Page 435 3BN/3A4 2-4-6...
  • Page 436 Fax System (B)
  • Page 437 CONTENTS 1-1 Specifications 1-1-1 Specifications ............................1-1-1 1-1-2 Parts names and their functions ......................1-1-2 (1) Copier ............................1-1-4 (2) Operation panel ..........................1-1-5 1-1-3 Machanical construction ........................1-1-8 1-2 Installation 1-2-1 Unpacking ............................1-2-1 1-2-2 Setting and registering data ......................... 1-2-2 (1) Settings ............................
  • Page 438 1-1-1 Specifications Line requirements ......Subscription telephone line Compatibility ........G3 Transmission ........Half-duplex system Modulation ........TCM, QAM and RhM Modem speed ........ 33600/31200/28800/26400/24000/21600/19200/16800/14400/12000/9600/7200/ 4800/2400 (bps) Encoding ........MMR, MR, MH Error correction ......ECM Scanning line density ..... Main × auxiliary Normal (8 dots/mm ×...
  • Page 439 Reception functions Manual reception Automatic reception Fax/telephone auto selection TAD reception D.R.D. reception* Remote switching Transmission functions Abbreviated dialing (up to 100 numbers can be stored) One-touch dialing* Program dialing* Group dialing* Chain dialing* Redialing (manual/automatic) Dial confirmation Communication functions Direct feed transmission Memory transmission Direct reception...
  • Page 440 Reports Activity report Transmission report Reception report Power failure report Delayed communication report Confirmation report User settings list Encryption key list Management report Department list Abbreviated dial list One-touch key list Telephone directory list Program dial list Group dial list Others Memory editing Remote diagnosis...

  • Page 441: Parts Names And Their Functions

    1-1-2 Parts names and their functions (1) Copier Figure 1-1-1 1 Operation panel .... Use the operation panel to operate the machine. 2 Cover plate ....Flipping up the cover plate will change the number assigned to each one-touch key. 3 Telephone jack ....

  • Page 442: Operation Panel

    (2) Operation panel Inch ⁄ 7 8# & ° ‡ Œ „ ´ ⁄ fl (Left portion) (Right portion, with cover plate raised) ‹ ¤ › fi ‚ · ‰ ˇ Á ¨ ˆ Metric ⁄ 78 # & ° ‡...
  • Page 443 1 Message display ....... The message display shows the date, time, operation procedures and operational errors. 2 Cursor keys ....... Press the cursor keys to select a function or item while making settings. 3 Enter key ........Press the enter key to proceed to the next item or to store the data registered or set for each function.
  • Page 444 · TAD/Auto Rx. key* 1 ......Press the TAD/auto Rx. key to change the reception mode. When the TAD indicator is lit, the fax is in the TAD reception mode. When the auto Rx. indicator is lit, the fax is in the auto fax reception mode. When both indicators are turned off, the fax is in the manual fax reception mode.
  • Page 445 1-1-3 Mechanical construction PSPCB RELAY IN APSPCB NEUTRAL IN MPCB SPEAKER A.GND BATT G(3.3V) LINE TEL/Handset (option*) *Optional for 120 V specifications only. Figure 1-1-3 The fax system consists of the fax control PCB (FCPCB), NCU PCB (NCUPCB), auxiliary power source PCB (APSPCB), fax operation unit PCB (FOPCB), speaker (SP), backup battery (BUBAT) and optional add-on memory.

  • Page 446: Unpacking

    1-2-1 Unpacking *()⁄ ¨ °·‚ Œ &¤‹› fifl‡ ˆ Á ´ ˇ ‰ „ Ø Figure 1-2-1 1 NCU PCB assembly ‹ FCC68 label* 2 Antistatic air-padded bags › FCC68C label* 3 Fax operation unit fi IC line label* 4 Fax control PCB assembly fl...

  • Page 447: Setting And Registering Data

    1-2-2 Setting and registering data After setting up the machine, set or register the following data. (1) Settings • Setting the type of telephone line* Select the setting (pulse or tone) according to the type of telephone line to be used. •...
  • Page 448 • Setting the destination code 1. Enter maintenance mode. 2. Execute maintenance item U601. Enter a destination code using the numeric keys (refer to the destination code list on page 1-3-5 for the destination code). INI. KEEP DATA COUNTRY CODE:XXX 3.

  • Page 449: Registration

    (2) Registration • Date and time Set the current date and time. • Self station information Register the self telephone number, self station name and self station ID. • One-touch dialing Register destination fax (telephone) numbers and names under one-touch keys. Up to 32 entries can be registered. •...

  • Page 450: Installing The Optional Add-On Memory

    1-2-3 Installing the optional add-on memory Add-on memory installation on the fax control PCB assembly requires the following parts: 8 MB add-on memory (P/N: 2AW6001) Fax control PCB <Procedure> 1. Turn the main switch off and disconnect the power plug from the wall outlet. 2.

  • Page 451: Installing The Handset (Optional For 120 V Specifications Only)

    1-2-4 Installing the handset (optional for 120 V specifications only) <Procedure> 1. Fit the handset retainer to the handset holder using the two M3 × 5 cross-head chrome binding screws. Handset holder Handset retainer Screws (M3 × 5 cross-head chrome binding screws) Figure 1-2-3 2.

  • Page 452: Maintenance Mode

    1-3-1 Maintenance mode (1) Maintenance mode item list Item Initial Section Maintenance item contents setting* U600 Initializing all data — U601 Initializing permanent data — U602 Setting factory defaults — U603 Setting the user registration data • Setting the self telephone number —...
  • Page 453 Item Initial Section Maintenance item contents setting U610 Setting the modem output level • Setting the modem output level — • Adjusting the modem output level — U611 G3 cable equalizer • Setting the G3 transmission cable equalizer — • Setting the G3 reception cable equalizer —...
  • Page 454 Item Initial Section Maintenance item contents setting U894 Performing board test • Performing tests on SRAM and DRAM — • Performing tests on optional memory — Others U914 Switching between fax/copier modes copier U992 Checking or clearing the printer/fax count —...

  • Page 455: Contents Of Maintenance Mode Items

    (2) Contents of maintenance mode items Maintenance Description item No. U600 Initializing all data Description Initializes software switches and all data in the SRAM on the fax control PCB, according to the destination and OEM. Purpose Used to initialize the fax control PCB. Method 1.
  • Page 456 Maintenance Description item No. U600 Destination code list (cont.) Code Destination Code Destination CTR21 (European nations) Japan Australia Italy Canada Germany Greece Spain Hong Kong U.K. Indonesia Netherlands Sweden Israel Malaysia France New Zealand Austria Peru Switzerland Philippines Belgium Middle East Denmark Singapore Finland...
  • Page 457 Maintenance Description item No. U602 Setting factory defaults Description Initializes software switches other than that for machine data and the SRAM on the fax control PCB, according to the destination and OEM. Purpose Used to initialize the fax control PCB to the factory default. Method 1.
  • Page 458 Maintenance Description item No. U603 Setting the user registration data Description Makes user settings to enable the use of the copier as a fax. Purpose To be run after installation of the facsimile kit if necessary. Start 1. Press the start key. The screen for selecting an item is displayed. 2.
  • Page 459 Maintenance Description item No. U604 Clearing data Description Initializes data related to the fax transmission such as transmission history and IDs. Purpose Used to clear the transmission history or if an ID has been forgotten. Method 1. Press the start key. The screen for selecting an item is displayed. 2.
  • Page 460 Maintenance Description item No. U605 Setting an alarm for when reception is completed (cont.) 1. Enter 1 or 2 using the numeric keys to change the setting. Display Description 1: ON An alarm rings. 2: OFF An alarm does not ring. 2.
  • Page 461 Maintenance Description item No. U605 Setting the continuous detection time for remote switching (cont.) Sets the detection time when continuous detection is selected for remote switching. (This setting item will be displayed, but the setting made is ineffective.) 1. Change the setting using the numeric keys. Description Setting range Continuous detection time for remote switching...
  • Page 462 Maintenance Description item No. U606 Setting if the image scanning quality in fax mode is initialized (cont.) Sets if the resolution is to be initialized when fax operation is complete. 1. Enter 1 or 2 using the numeric keys to change the setting. Display Description 1: ON...
  • Page 463 Maintenance Description item No. U607 Setting the system (communication 1) Description Makes settings for fax transmission regarding the communication. Start 1. Press the start key. The screen for selecting an item is displayed. 2. Select an item using the cursor up/down keys. 3.
  • Page 464 Maintenance Description item No. U607 Setting the mode for remote switching (cont.) Sets the signal detection method for remote switching. Be sure to change the setting according to the type of telephone connected to the machine. 1. Enter 1 or 2 using the numeric keys to change the setting. Display Description 1: ONE...
  • Page 465 Maintenance Description item No. U608 Setting transmission Description Makes settings regarding fax transmission. Start 1. Press the start key. The screen for selecting an item is displayed. 2. Select an item using the cursor up/down keys. 3. Press the start key. The screen for the selected item is displayed. Display Description ERROR...
  • Page 466 Maintenance Description item No. U608 Setting the waiting period to prevent echo problems at the sender (cont.) Sets the period before a DCS signal is sent after a DIS signal is received. Used when problems occur due to echoes at the sender. 1.
  • Page 467 Maintenance Description item No. U608 Setting the frequency of the CED signal (cont.) Sets the frequency of the CED signal. Used as one of the measures to improve transmission performance for international communications. 1. Enter 1 or 2 using the numeric keys to change the frequency. Display Frequency of the CED signal 1: 2100...
  • Page 468 Maintenance Description item No. U609 Setting the T2 time-out time (cont.) The T2 time-out time decides the following. • From CFR signal output to image data reception • From image data reception to the next signal reception • In ECM, from RNR signal detection to the next signal reception 1.
  • Page 469 Maintenance Description item No. U609 Setting the Tc time-out time (cont.) In the TAD mode, set the time to check if there are any triggers for shifting to fax reception after a connected telephone receives a call. Only the telephone function is available if shifting is not made within the set Tc time. In the TAD mode, change the setting when fax reception is unsuccessful or a telephone fails to receive a call.
  • Page 470 Maintenance Description item No. U610 Setting the modem output level Description Sets the modem output level. Start 1. Press the start key. The screen for selecting an item is displayed. 2. Select an item using the cursor up/down keys. 3. Press the start key. The screen for the selected item is displayed. Display Description SGL LEVEL MODEM...
  • Page 471 Maintenance Description item No. U611 G3 cable equalizer Description Sets the G3 cable equalizer. Start 1. Press the start key. The screen for selecting an item is displayed. 2. Select an item using the cursor up/down keys. 3. Press the start key. The screen for the selected item is displayed. Display Description REG.
  • Page 472 Maintenance Description item No. U612 Setting the modem detection level Description Sets the modem detection level. Purpose Used to improve the transmission performance when a low quality line is used. Method Press the start key. The current setting is displayed. Setting 1.
  • Page 473 Maintenance Description item No. U614 Adjusting the DTMF output level Description Adjusts the DTMF output level of a push-button dial telephone. Purpose No change is necessary from the factory default. Start 1. Press the start key. The screen for selecting an item is displayed. 2.
  • Page 474 Maintenance Description item No. U615 Setting the NCU Description Makes setting regarding the network control unit (NCU). Purpose To be set when installing the facsimile kit. Start 1. Press the start key. The screen for selecting an item is displayed. 2.
  • Page 475 Maintenance Description item No. U615 Setting for a PBX (cont.) Selects the mode to connect an outside call when connected to a PBX. According to the type of the PBX connected, select the mode to connect an outside call. 1. Change the setting using the numeric keys. Display Description 1: EARTH...
  • Page 476 Maintenance Description item No. U617 Outputting lists Description Outputs a list of data regarding fax transmissions. Purpose Used to check conditions of use, settings and transmission procedures of the fax. Method 1. Press the start key. The screen for selecting an item is displayed. 2.
  • Page 477 Maintenance Description item No. U650 Setting the system 1 Description Makes settings for fax reception regarding the sizes of the fax paper and received images and automatic printing of the protocol list. Start 1. Press the start key. The screen for selecting an item is displayed. 2.
  • Page 478 Maintenance Description item No. U650 Setting the number of lines to be ignored when receiving a fax (A4R, letter) in the auto reduction mode (cont.) Sets the maximum number of lines to be ignored if the received data volume exceeds the recording capacity when the data is recorded in the auto reduction mode onto A4R or letter-size paper under the conditions below.
  • Page 479 Maintenance Description item No. U651 Setting the system 2 Description Sets the variation range in rotation reception and the number of adjustment lines for automatic reduction. Start 1. Press the start key. The screen for selecting an item is displayed. 2.
  • Page 480 Maintenance Description item No. U660 Setting the system (communication 2) Description Makes settings for fax transmission regarding the communication. Purpose To reduce transmission errors when a low quality line is used. Start 1. Press the start key. The screen for selecting an item is displayed. 2.
  • Page 481 Maintenance Description item No. U660 3. To return to the screen for selecting an item, press the stop/clear key. (cont.) Setting the CNG detection times in the fax/telephone auto select mode Sets the CNG detection times in the fax/telephone auto select mode. 1.
  • Page 482 Maintenance Description item No. U670 Setting the system (communication 3) Description Makes settings for fax transmission regarding the communication. Purpose To reduce transmission errors when a low quality line is used. Start 1. Press the start key. The screen for selecting an item is displayed. 2.
  • Page 483 Maintenance Description item No. U670 Setting the V.34 symbol speed (2800 Hz) (cont.) Sets if the V.34 symbol speed 2800 Hz is used. 1. Enter 1 or 2 using the numeric keys to change the setting. Display Description 1: ON V.34 symbol speed 2800 Hz is used.
  • Page 484 Maintenance Description item No. U894 Performing board test Description Performs tests on the SRAM, DRAM (image memory, bitmap memory) and optional memory on the fax control PCB. Purpose Used to check if reading and writing are performed correctly in respective installed memories. Start 1.
  • Page 485 Maintenance Description item No. U914 Switching between fax/copier modes Description Switches between fax and copier modes when the facsimile kit is installed to use the copier as a fax. Purpose To be set according to frequency of use: set to the more frequently used mode. Method Press the start key.

  • Page 486: Error Code

    1-4-1 Error codes (1) Error code Error codes are listed on the communication reports, activity report, etc. The codes consist of an error code indication "U" followed by a 5-digit number. The upper three of the five digits indicate general classification of the error and its cause, while the lower two indicate the detailed classification.

  • Page 487: Error Code

    (2) Table of general classification Error code Description U00000 No response or busy after the set number of redials. U00100 Transmission was interrupted by a press of the stop/clear key. U00200 Reception was interrupted by a press of the stop/clear key. U00300 Recording paper on the destination unit has run out during transmission.
  • Page 488 Error code Description U04200 In encrypted transmission, the specified encryption box was not registered in the destination unit. U04300 Encrypted transmission failed because the destination unit had no encrypted communication capability. U044XX Communication was interrupted because of an encryption key error during encrypted transmission (refer to page 1-4-10 "U044XX error code table").

  • Page 489: U006Xx Error Code Table

    (2-1) U004XX error code table: interrupted phase B Error code Description U00420 A relay request was received from the host center but interrupted because of a mismatch in permit ID or telephone number. U00421 F-code based relay reception was interrupted because of a mismatch in the specified F-code relay box number.

  • Page 490: U008Xx Error Code Table

    (2-3) U008XX error code table: Page transmission error Error code Description U00800 A page transmission error occurred because of reception of a RTN or PIN signal. U00810 A page transmission error reoccurred after retry of transmission in the ECM mode. (2-4) U009XX error code table: Page reception error Error code Description...
  • Page 491 (2-5) U010XX errror code table: G3 transmission Error code Description U01000 An FTT signal was received for a set number of times after TCF signal transmission at 2400 bps. Or, an RTN signal was received in response to a Q signal (excluding EOP) after transmission at 2400 bps.
  • Page 492 Error code Description U01045 A DCN or other inappropriate signal was received after transmission of an MPS signal. U01046 A DCN or other inappropriate signal was received after transmission of an EOM signal. U01047 A DCN or other inappropriate signal was received after transmission of an EOP signal. U01048 A DCN signal was received after transmission of a PRI-EOP signal.

  • Page 493: U011Xx Error Code Table

    (2-6) U011XX error code table: G3 reception Error code Description U01100 Function of the unit differs from that indicated by a DCS signal. U01101 Function of the unit (excl. communication mode select) differs from that indicated by an NSS signal. U01102 A DTC (NSC) signal was received when no transmission data was in the unit.
  • Page 494 Error code Description U01191 Communication was interrupted because an error occurred during an image data reception sequence in the V.34 mode. U01199 A DIS signal with different FIF was received after transmission of a DIS signal. 1-4-9...

  • Page 495: U017Xx Error Code Table

    (2-7) U017XX error code table: V.34 transmission Error code Description U01700 A communication error occurred in phase 2 (line probing). U01720 A communication error occurred in phase 4 (modem parameter exchange). U01721 Operation was interrupted due to the absence of a common communication speed between units.

  • Page 496: Self Diagnosis

    1-5-1 Self-diagnosis (1) Self diagnostic codes Remarks Code Contents Causes Check procedures/corrective measures C003 Fax control PCB system problem Defective fax con- Replace the fax control PCB and check for • Processing with the fax software was trol PCB. correct operation. disabled due to a hardware or soft- ware problem.
  • Page 497 Remarks Code Contents Causes Check procedures/corrective measures C083 Flash ROM program area checksum Defective SRAM Replace the fax control PCB and check for error on the fax control correct operation. • A checksum error occurred with the PCB. program in the flash ROM on the fax control PCB.

  • Page 498: Updating The Firmware

    1-6-1 Updating the firmware (1) Updating the firmware on the fax control PCB Perform the steps below when updating the firmware in the Flash ROM on the fax control PCB. Firmware updating requires the following tools: Flash tool assembly (P/N 35968010) Control ROM IC1 (P/N 2AW29310) Control ROM IC2 (P/N 2AW29320) Caution:...

  • Page 499: Fax Control Pcb

    2-2-1 Fax control PCB PSPCB BUBAT Lithium Back up Back up battery circuit 1 circuit 2 BT101 ASIC 28.224MHz Crystal oscillator FLASH SRAM Clock driver Modem IC62 IC12 IC11 IC51,52 IC63 Analog circuit IC61 IC81 ASIC SDRAM IC71 IC21 32-bit Telephone 8-bit 16-bit...
  • Page 500 Figure 2-2-2 Fax control PCB silk-screen diagram 2-2-2...
  • Page 501 Terminals (CN) Voltage Remarks 3.3/0 V DC (pulse) 3.3 V DC supply detection signal, input 3.3/0 V DC (pulse) FPVCLK signal, input 3.3/0 V DC (pulse) FVCLK signal, output 3.3/0 V DC (pulse) FMRE signal, output 1-10 3.3/0 V DC (pulse) FPVD signal, output 1-11 1-12...
  • Page 502 Terminals (CN) Voltage Remarks 4-87 4-71, 73, 75 3.3/0 V DC (pulse) AB (2) signal, output 4-88 4-71, 73, 75 3.3/0 V DC (pulse) AB (14) signal, output 4-89 4-71, 73, 75 3.3/0 V DC (pulse) AB (13) signal, output 4-90 4-71, 73, 75 3.3/0 V DC (pulse) DB (25) signal, input/output...

  • Page 503: Ncu Pcb

    2-2-2 NCU PCB 120 V specifications Destination NCUTYPE identification circuit 1, 2, 3 JP20, JP21, JP22 /ONHOOK1 Loop current LINE2 /ONHOOK2 detection/tone signal reception RXIN circuit IC30 LINE1 FAXSEL MODRXD Line transformer MODTXD SHUNT Ring signal DC loop/dial pulse detection PLSDIL transmission circuit circuit...
  • Page 504 The NCU PCB (NCUPCB) mainly controls the connection to the telephone line. It consists of the circuits shown in the block diagram. The loop current detection/tone signal reception circuit IC30 detects the DC loop current formed at the DC loop/dial pulse transmission circuit PC80 to determine the status of the telephone line.
  • Page 505 120 V specifications C406 C202 JP21 R418 C412 C414 R416 C413 C203 JP20 R805 R405 JP22 TR43 R406 PC60 R404 E C B TR81 PC40 PC41 E C B PC42 TR42 R403 PC80 PC31 PC30 TR70 TR80 TR41 E C B TR11 R402 R400...
  • Page 506 Terminals (CN) Voltage Remarks 1-22 Analog RXIN signal, output 1-22 Analog MODRXD signal, output 1-20 3.3/0 V DC (pulse) RNGDET signal, output 1-22 Analog MODTXD signal, input 1-20 5/0 V DC (pulse) ONHOOK1 signal, output 1-20 5/0 V DC (pulse) ONHOOK2 signal, output 1-20 3.3/0 V DC (pulse)

  • Page 507: Fax Operation Unit Pcb

    2-2-3 Fax operation unit PCB FOPCB MPCB LED display matrix circuit LEDON0-4 SCAN4-7 Keyboard matrix circuit KEY SENS0-7 Figure 2-2-5 Fax operation unit PCB block diagram The fax operation unit PCB (FOPCB) consists of an LED display matrix circuit and a keyboard matrix circuit. The scan signals SCAN4 to SCAN7 are output to both matrix circuits from the main PCB (MPCB).
  • Page 508 2AW2401 JP11 Figure 2-2-6 Fax operation unit PCB silk-screen diagram Terminals (CN) Voltage Remarks 5/0 V DC (pulse) _LEDON4 signal, input 5/0 V DC (pulse) _LEDON3 signal, input 5/0 V DC (pulse) _LEDON2 signal, input 5/0 V DC (pulse) _LEDON1 signal, input 5/0 V DC (pulse) _LEDON0 signal, input 5/0 V DC (pulse)

  • Page 509: Auxiliary Power Source Pcb

    2-2-4 Auxiliary power source PCB 5.2 V DC 5.2 V DC AC input output Overvoltage C15,91 detection circuit circuit DC12V 12 V DC output circuit Switching control circuit Relay Relay REM PSPCB Figure 2-2-7 Auxiliary power source PCB block diagram The auxiliary power source PCB (APSPCB) is a switching regulator that converts an AC input to generate 5.2 V DC and 12 V DC.
  • Page 510 J1001 J7502 J1002 J1003 3B12802 Figure 2-2-8 Auxiliary power source PCB silk-screen diagram Terminals (CN) Voltage Remarks 12 V DC 12 V DC supply, output 5 V DC 5 V DC supply, output 2-2-12...
  • Page 511 2-1-1 Electrical parts layout Machine front Machine inside Machine rear Figure 2-1-1 1. Fax control PCB (FCPCB) ......Modulates, demodulates, compresses, decompresses and smoothes out image data, and converts resolution of image data. • Add-on memory* ........Expands memory capacity for image data and bitmap conversion. 2.NCU PCB (NCUPCB) ........
  • Page 512 KYOCERA MITA AMERICA, INC. Headquarters: Western Region: 225 Sand Road, P.O. Box 40008 14101 Alton Parkway, Fairfield, New Jersey 07004-0008 P.O.Box 57006, Irvine, TEL : (973) 808-8444 California 92618-7006 FAX : (973) 882-6000 TEL : (949) 457-9000 FAX : (949) 457-9119 New York Show Room: 149 West 51st street, Southeastern Region:...

This manual is also suitable for:

Cs-1530

Table of Contents
