SERVICE MANUAL
LS2100P
TYPE: YS1074
WEB ACCESS: http://www.yorkville.com
WORLD HEADQUARTERS
CANADA
U.S.A.
Yorkville Sound
Yorkville Sound Inc.
550 Granite Court
4625 Witmer Industrial Estate
Pickering, Ontario
Niagara Falls, New York
L1W-3Y8 CANADA
14305 USA
Voice: (905) 837-8481
Voice: (716) 297-2920
Fax: (905) 837-8746
Fax: (716) 297-3689
Quality and Innovation Since 1963
Printed in Canada
Manual-Service-LS2100P-00-1v3 • Nov 17, 2015

Advertisement

loading
Need help?

Need help?

Do you have a question about the LS2100P and is the answer not in the manual?

Questions and answers

Related Manuals for YORKVILLE LS2100P

Summary of Contents for YORKVILLE LS2100P

  • Page 1 550 Granite Court 4625 Witmer Industrial Estate Pickering, Ontario Niagara Falls, New York L1W-3Y8 CANADA 14305 USA Voice: (905) 837-8481 Voice: (716) 297-2920 Fax: (905) 837-8746 Fax: (716) 297-3689 Quality and Innovation Since 1963 Printed in Canada Manual-Service-LS2100P-00-1v3 • Nov 17, 2015...

  • Page 2: Power Cord

    IM PORTA N T S A F E T Y IN ST RUC TI ON S This lightning flash with arrowhead symbol, within The exclamation point within an equilatereal triangle is intended to alert the an equilateral triangle, is intended to alert the user to the presence of user to the presence of important operating and maintenance (servicing) uninsulated “dangerous voltage”...
  • Page 3 SUCH AS TWO CHANNELS FROM A MIXER OR A STEREO SOURCE LS2100P #1 LS2100P #2 LS2100P #1 LS2100P #2 MIXER PUSH TO RESET MODEL TYPE: YS1074 A-Z1206 / 1v2 230V 120VAC 50Hz 6,0A 60Hz 12.0A DESIGNED & MANUFACTURED BY YORKVILLE SOUND • TORONTO, CANADA POWER...
  • Page 4 Specifications - LS2100P Rear Horn Loaded Subwoofer System Type Active Active or Passive 2400 Program Power (Watts) Max SPL (dB) 32 - 150 Frequency Response (Hz +/- 3db) Single 21 inch with 6 inch voicecoil LF Driver(s) 2400 LF Program Power(Watts)
  • Page 5 image-Block-Diag-LS2100P-00-1v0...
  • Page 6 LS2100P Parts List 11/16/2015 YS # Description Qty. YS # Description Qty. YS # Description Qty. 2019 W125 100R0 1%FLAME PROOF T&R RES 4949 W250 180K 5% .2INU T&R RES 8741 4-40X1/2 PAN PH MS JS500 2037 W250 10R FUSIBLE T&R RES...
  • Page 7 2W00 3R9 5% T&R RES C133 5212 100N 63V 5%CAP T&R RAD .2FLM 5606 __1N5 50V 10%CAP T&R RAD CER.2X7R M1375BLANK 2_OZ 2SD 189.1 SQIN 01PER LS2100P 4983 W250 10K 5%MINI T&R RES C134 5212 100N 63V 5%CAP T&R RAD .2FLM 5205 _15N 100V 10%CAP T&R RAD...
  • Page 8 M1375 pg2 Parts Reference List 11/16/2015 YS # Description YS # Description YS # Description R171 4832 W250 22K T&R RES 6136 W250 3K3 5%MINI T&R RES 6432 1N5248B 18V0 0W5 ZENER 5% T&R R172 6119 W250 47K 5%MINI T&R RES 6136 W250 3K3 5%MINI T&R RES...
  • Page 9 BLACK W5:D TO SPEAKER - W5:C W6:D 4 BLACK 4080 2.0UH W6:C 4 250V 6500 275V 2.7mH W6:B 4 250V 2.0UH 4080 W6:A 4 100V 400V W5:B TO SPEAKER + W5:A M1373PCB_DATABASE_HISTORY MODEL(S):- CROW BAR DATE VER# DESCRIPTION OF CHANGE 07-JAN-2009 1.00 FIRST DESIGN 14DEC09...
  • Page 10 M1373 V3.00 EMC FILTER 275V 5262 4080 2.0UH CLINCH 2ozCopper INSERT ORIGIN LONG AXIS ORIGIN BlankSize - 15500x7000 SEE LAYOUT DOCUMENTATION...
  • Page 11 SEE LAYOUT DIAGRAM M1373 PRODUCTION NOTES M1373PCB_DATABASE_HISTORY MODEL(S):- CROW BAR DATE VER# DESCRIPTION OF CHANGE 07-JAN-2009 1.00 FIRST DESIGN 14DEC09 2.00 PC#7925 CHANGE L4, L5 FROM YS#3769 TO YS#4080 09-FEB-2010 3.00 PC7993: Reduce panel to 3x5 boards...
  • Page 12 U27:C SPACER GROUND U7:C U19:C U25:C U1:C U18:C U6:C 3899 1N5248B (VCC) U40:C U5:C 100N HERE LM13600N Product LS2100P/NS21P 18V0 U15:D MINI 4148 6745 Dual VCA -15VIP {Function} LS2100P/NS21P PCB# M1375 Sheet -15VIP -15VIP -15V ADD MORE BYPASS CAPS 18uH...
  • Page 13 74HC14N PSGND SIG_GND U17:C U24:C U12:C 6603 -15V_U12 100N 200V 18uH R101 R124 3899 -15V_MOD 1/8W -15V_U12 1/8W Product -15V LS2100P/NS21P -15V U20:E 10R0 10R0 -15V -15V_U12 FLMP +15V_LS- 74HC14N FLMP -15V_MOD SIG_GND -15V -15V LS2100P/NS21P PCB# M1375 Sheet Date:...
  • Page 14 CIRCUIT -15V_U21 FLMP -15V_TRI FLMP 100N PSGND 6640 ON AMP PCB R160 -15V_TRI 100N 100N R174 -15V_U21 MINI MINI Product LS2100P/NS21P 200V -15V_U21 GND-TRI +15V_TRI GND-TRI GND-TRI LS2100P/NS21P PCB# M1375 Sheet GND-TRI Date: Wed Jun 17, 2015 Rev: Filename: M1375V07sch.sch2006...

  • Page 15: Power Supply

    POWER SUPPLY POWER AMP M1375 3/3 M1375 1/3 +15V_LS Thermal Breaker ACDETECT 96 DEG C +130V -130V PSGND +15V -15V Product LS2100P/NS21P LS2100P/NS21P PCB# M1375 Sheet Date: Wed Jun 17, 2015 Rev: Filename: M1375V07sch.sch2006...
  • Page 16 100N 100N 100N 100N 150P 681R0 150P R T V R165 R T V BAT85 R175 TIP-SW TIP-SW 470P C118 681R0 BAT85 LS2100P/NS21P R180 R117 BAT85 M1375 IRS2184 R195 IRS2184 250V 250V R193 R192 2.0W 5953 5953 180K C105 0.4"Fins...
  • Page 17 SEE LAYOUT DIAGRAM M1375 LS2100P PRODUCTION NOTES 1. LEDS LD1, LD2, AND LD3 ARE TO BE HAND INSERTED. 2. INSTALL YS#8937 TIE AROUND C104. SEE PIC. 3. RTV ALL ELECTROLYTIC CAPACITORS.
  • Page 18 LEADS & PINS REFERENCE POTENTIOMETERS AND KNOBS 2N5401 (YS#5108) M1375 2N5551 (YS#5107) MODEL(S):- LS2100P MPSA06 (YS#5103) FUNCTION PART# KNOB STYLE MPSA13 (YS#5105) LEVEL 2339 8653 SHAPE 2340 8653 ROLLOFF 2339 8653 TO-92 E B C IRS21844PBF (YS#6586) 74HC14N (YS#6603) LM13600N (YS#6745) "STYLE_P34"...
