Enabled Enabled NA#.
Disabled Disabled NA#.
•
SDRAM CAS Latency
The default value is 3T
2T Set SDRAM CAS Latency to 2T.
3T Set SDRAM CAS Latency to 3T.
•
SDRAM WR Retire Rate
The default value is X-2-2-2
X-1-1-1 Set SDRAM WR Retire Rate to X-1-1-1.
X-2-2-2 Set SDRAM WR Retire Rate to X-2-2-2.
•
SDRAM Wait State Control
The default value is 1WS
0WS Set SDRAM Wait State Control to 0WS.
1WS Set SDRAM Wait State Control to 1WS.
•
RAMW# Assertion Timing
The default value is 3T
2T Set RAMW# Assertion Timing to 2T.
3T Set RAMW# Assertion Timing to 3T.
•
CAS Precharge Time EDO
The default value is 2T
1T CAS Precharge Time (EDO) 1T.
2T CAS Precharge Time (EDO) 2T.
1T/2T CAS Precharge Time (EDO) 1T/2T.
•
CAS# Pulse Width for EDO
BIOS CONFIGURATION
4-18
