Socket 7 processor motherboard

Advertisement

Quick Links

DECLARATION OF CONFORMITY
Per FCC Part 2 Section 2. 1077(a)
Responsible Party Name: G.B.T. INC.
Address: 18305 Valley Blvd., Suite#A
LA Puent, CA 91744
Phone/Fax No: (818) 854-9338/ (818) 854-9339
hereby declares that the product
Product Name:
Mother Board
GA-5VMM
Model Number:
Conforms to the following specifications:
FCC Part 15, Subpart B, Section 15.107(a) and Section 15.109(a),
Class B Digital Device
Supplementary Information:
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful
and
(2)
this device must accept any inference received, including
that may cause undesired operation.
Representative Person's Name:
ERIC LU
Eric Lu
Signature:
Date:
Jun. 26, 2000
determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
-Reorient or relocate the receiving antenna
-Move the equipment away from the receiver
-Plug the equipment into an outlet on a circuit different from that to which
the receiver is connected
-Consult the dealer or an experienced radio/television technician for
additional suggestions
You are cautioned that any change or modifications to the equipment not
expressly approve by the party responsible for compliance could void Your
authority to operate such equipment.
This device complies with Part 15 of the FCC Rules. Operation is subjected to
the following two conditions 1) this device may not cause harmful interference
and 2) this device must accept any interference received, including interference
that may cause undesired operation.
FCC Compliance Statement:
This equipment has been tested and found to
comply with limits for a Class B digital device,
pursuant to Part 15 of the FCC rules. These
limits are designed to provide reasonable
protection
against
residential
installations.
generates,
uses,
frequency energy, and if not installed and used
in accordance with the instructions, may cause
harmful interference to radio communications.
However, there is no guarantee that interference
will not occur in a particular installation. If this
equipment does cause interference to radio or
television equipment reception, which can be
harmful
interference
This
equipment
and
can
radiate
in
radio

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 5VMM and is the answer not in the manual?

Questions and answers

Summary of Contents for Gigabyte 5VMM

  • Page 1 Product Name: Mother Board generates, uses, radiate radio GA-5VMM Model Number: frequency energy, and if not installed and used Conforms to the following specifications: FCC Part 15, Subpart B, Section 15.107(a) and Section 15.109(a), in accordance with the instructions, may cause...
  • Page 2: Declaration Of Conformity

    Ausschlager Weg 41, 1F, 20537 Hamburg, Germany declare that the product ( description of the apparatus, system, installation to which it refers) Mother Board GA-5VMM is in conformity with (reference to the specification under which conformity is declared) in accordance with 89/336 EEC-EMC Directive...
  • Page 3 5VMM Socket 7 Processor Motherboard USER'S MANUAL Socket 7 Processor Motherboard REV. 2.1 First Edition R-21-01-000712...
  • Page 5 How This Manual Is Organized This manual is divided into the following sections: 1) Revision History Manual revision information 2) Item Checklist Product item list 3) Features Product information & specification 4) Hardware Setup Instructions on setting up the motherboard 5) Performance &...
  • Page 7: Table Of Contents

    Table Of Content Revision History Item Checklist Summary of Features 5VMM Motherboard Layout Page Index for CPU Speed Setup/Connectors/Panel and Jumper Definition Performance List P.37 Block Diagram P.38 Memory Installation P.39 Page Index for BIOS Setup P.40 Appendix P.73...
  • Page 8: Revision History

    Revision Revision Note Date Initial release of the 5VMM motherboard user’s manual. Jul.2000 The author assumes no responsibility for any errors or omissions that may appear in this document nor does the author make a commitment to update the information contained herein.
  • Page 9: Item Checklist

    Item Checklist Item Checklist þThe 5VMM motherboard þCable for IDE / floppy device þDiskettes or CD (TUCD) for motherboard driver & utility oInternal COM B Cable (Optional) oInternal USB Cable (Optional) oCable for SCSI device þ5VMM user’s manual...
  • Page 10: Summary Of Features

    5VMM Motherboard Summary Of Features Form Factor 24.6 cm x 18.6 cm Micro ATX size form factor, 4 layers PCB. Ÿ Socket 7 processor Ÿ 2nd cache in CPU (Depend on CPU) Ÿ Chipset VT8501 Ÿ VT82C686A Ÿ Clock Generator ICS 9248-127 Ÿ...
  • Page 11: 5Vmm Motherboard Layout

    5VMM Motherboard Layout 5VMM Motherboard Layout PS/2 BAT1 Socket 7 VT8501 5VMM AC97 PCI1 PCI2 VT82C686A Front USB PCI3...
  • Page 12 5VMM Motherboard Page Page Index for CPU Speed Setup/Connectors/Panel and Jumper Definition CPU Speed Setup Connectors P.24 Game & Audio Port P.24 COM A / VGA / LPT Port P.24 USB & LAN Connector P.25 PS/2 Keyboard & PS/2 Mouse Connector P.25...
  • Page 13: Cpu Speed Setup

    CPU Speed Setup CPU Speed Setup The system bus speed is selectable at 66,75,83,90,95,97MHz and 100MHz. CPU Voltage: O: ON/ X: OFF 1.3V 2.5V 1.4V 2.6V 1.5V 2.7V 1.6V 2.8V 1.7V 2.9V 1.8V 3.0V 1.9V 3.1V 2.0V 3.2V 2.1V 3.3V 2.2V 3.4V 2.3V...
  • Page 14 5VMM Motherboard O: ON / X: OFF SWITCH SW 2 S1 S2 S3 S4 S5 S6 S7 S8 1. Pentium 133 MHz 2. Pentium 166 MHz 3. Pentium 200 MHz 4. Intel MMX-166MHz 5. Intel MMX-200MHz 6. Intel MMX-233MHz 7. AMD-K6/166 (2.9V) 8.
  • Page 15 CPU Speed Setup SWITCH SW 2 S1 S2 S3 S4 S5 S6 S7 S8 31.AMD-K6-III/450 (100*4.5 2.2V) * 32.AMD-K6-III/450 (100*4.5 2.4V) * 33.AMD-K6-III/475 (95*5 2.2V) 34.AMD-K6-III/475 (95*5 2.4V) 35.AMD-K6-III/500 (100*5 2.2V) * 36.AMD-K6-III/500 (100*5 2.4V) * 37.AMD-K6-III/550 (100*5.5 2.2V) * 38.
  • Page 16 5VMM Motherboard SWITCH SW 2 S1 S2 S3 S4 S5 S6 S7 S8 53. Cyrix M ¢ º - PR366 (75*4 2.9V) 54. Cyrix M ¢ º - PR366 (83*3.5 2.9V) 55. Cyrix M ¢ º - PR366 (100*3 2.9V) 56.
  • Page 17 CPU Speed Setup Pentium Processor 133 MHz 6 5 4 3 2 1 Pentium Processor 166 MHz 6 5 4 3 2 1 Pentium Processor 200 MHz 6 5 4 3 2 1 Intel MMX-166 MHz 6 5 4 3 2 1...
  • Page 18 5VMM Motherboard Intel MMX-200 MHz 6 5 4 3 2 1 Intel MMX-233 MHz 6 5 4 3 2 1 AMD-K6/166 (2.9V) 6 5 4 3 2 1 AMD-K6/200 (2.9V) 6 5 4 3 2 1 AMD-K6/233 (3.2V) 6 5 4 3 2 1...
  • Page 19 CPU Speed Setup 10. AMD-K6/233 (66*3.5 2.2V) 6 5 4 3 2 1 11. AMD-K6/266 (66*4 2.2V); AMD-K6-2/266 (66*4 2.2V) 6 5 4 3 2 1 12. AMD-K6/300 (66*4.5 2.2V) 6 5 4 3 2 1 13. AMD-K6/300 (100*3 2.2V); AMD-K6-2/300 (100*3 2.2V) 6 5 4 3 2 1 14.
  • Page 20 5VMM Motherboard 15. AMD-K6-2/333 (95*3.5 2.2V) 6 5 4 3 2 1 16. AMD-K6-2/350 (100*3.5 2.2V) 6 5 4 3 2 1 17. AMD-K6-2/366 (66*5.5 2.2V) 6 5 4 3 2 1 18. AMD-K6-2/380 (95*4 2.2V) 6 5 4 3 2 1 19.
  • Page 21 CPU Speed Setup 20. AMD-K6-2/450 (100*4.5 2.2V) 6 5 4 3 2 1 21. AMD-K6-2/450 (100*4.5 2.4V) 6 5 4 3 2 1 22. AMD-K6-2/475 (95*5 2.2V) 6 5 4 3 2 1 23. AMD-K6-2/475 (95*5 2.4V) 6 5 4 3 2 1 24.
  • Page 22 5VMM Motherboard 25. AMD-K6-2/500 (100*5 2.3V) 6 5 4 3 2 1 26. AMD-K6-2/500 (100*5 2.4V) 6 5 4 3 2 1 27. AMD-K6-2/533 (97*5.5 2.2V) 6 5 4 3 2 1 28. AMD-K6-2/550 (100*5.5 2.2V) 6 5 4 3 2 1 29.
  • Page 23 CPU Speed Setup 30. AMD-K6-III/400 (100*4 2.4V) 6 5 4 3 2 1 31. AMD-K6-III/450 (100*4.5 2.2V) 6 5 4 3 2 1 32. AMD-K6-III/450 (100*4.5 2.4V) 6 5 4 3 2 1 33. AMD-K6-III/475 (95*5 2.2V) 6 5 4 3 2 1 34.
  • Page 24 5VMM Motherboard 35. AMD-K6-III/500 (100*5 2.2V) 6 5 4 3 2 1 36. AMD-K6-III/500 (100*5 2.4V) 6 5 4 3 2 1 37. AMD-K6-III/550 (100*5.5 2.2V) 6 5 4 3 2 1 38. Cyrix / IBM 6x86MX-PR166 (66*2 2.9V) 6 5 4 3 2 1 39.
  • Page 25 CPU Speed Setup 40. Cyrix / IBM 6x86MX-PR200 (75*2 2.9V) 6 5 4 3 2 1 41. Cyrix / IBM 6x86MX-PR233 (66*3 2.9V) 6 5 4 3 2 1 42. Cyrix / IBM 6x86MX-PR233 (75*2.5 2.9V) 6 5 4 3 2 1 43.
  • Page 26 5VMM Motherboard 45. Cyrix / IBM 6x86MX-PR266 (75*3 2.9V) 6 5 4 3 2 1 46. Cyrix / IBM 6x86MX-PR266 (83*2.5 2.9V) 6 5 4 3 2 1 47. Cyrix M¢ º - PR300 (66*3.5 2.9V) 6 5 4 3 2 1 48.
  • Page 27 CPU Speed Setup 50. Cyrix M¢ º - PR333 (75*3.5 2.9V) 6 5 4 3 2 1 51. Cyrix M¢ º - PR333 (100*2.5 2.9V) 6 5 4 3 2 1 52. Cyrix M¢ º - PR350 (90*3 2.9V) 6 5 4 3 2 1 53.
  • Page 28 5VMM Motherboard 55. Cyrix M¢ º - PR366 (100*3 2.9V) 6 5 4 3 2 1 56. Cyrix M¢ º - PR400 (90*4 2.9V) 6 5 4 3 2 1 57. Cyrix M¢ º - PR400 (100*3.5 2.9V) 6 5 4 3 2 1 58.
  • Page 29 CPU Speed Setup 60. IDT Winchip 2-225 (75*3 3.5V) 6 5 4 3 2 1 61. IDT Winchip 2-233 (66*3.5 3.5V) 6 5 4 3 2 1 62. IDT Winchip 2-266 (66*4 3.5V) 6 5 4 3 2 1 63. IDT Winchip 2-266 (100*2.33 3.5V) 6 5 4 3 2 1 64.
  • Page 30 5VMM Motherboard 65. IDT Winchip 3-266 (100*2.33 2.8V) 6 5 4 3 2 1 66. RISE MP6-266 (100*2 2.8V) 6 5 4 3 2 1...
  • Page 31: Connectors

    Connectors Connectors Game & Audio Port Game Port MIC In Line Out Line In COM A / VGA / LPT Port LPT Port COM A...
  • Page 32: Usb & Lan Connector

    5VMM Motherboard USB & LAN Connector (LAN is optional) Pin No. Definition USB V0 USB D0- USB D0+ USB V1 5 6 7 8 USB D1- USB D1+ 1 – Green LED (LAN Link LED) 2 – Yellow LED (LAN Active LED) PS/2 Keyboard &...
  • Page 33: J1: Cpu Fan

    Connectors J1: CPU Fan Pin No. Definition +12V SENSE J2: System Fan Pin No. Definition +12V SENSE...
  • Page 34: Atx Power

    5VMM Motherboard ATX Power Pin No. Definition 3,5,7,13,15-17 1,2,11 3.3V 4,6,19,20 +12V -12V Power Good 5V SB stand by+5V PS-ON(Soft On/Off) Front USB (Optional) Pin No. Definition 5V-SB USB D2- USB D2+ USB D3- USB D3+ 5V-SB...
  • Page 35: Floppy Port

    Connectors Floppy Port Red Line IDE1 (Primary), IDE2 (Secondary) Port IDE 1 IDE 2 Red Line...
  • Page 36: J15: Cd Audio Line In

    5VMM Motherboard J15: CD Audio Line In Pin No. Definition CD-L CD-R J12: AUX_IN (Optional) Pin No. Definition AUX-L AUX-R...
  • Page 37: J9 (Tel)[Optional]

    Connectors J9: TEL: The connector is for Modem with internal voice connector (Optional) Pin No. Definition Signal-In Signal-Out J5: Ring Power On (Internal Modem Card Wake Up) [Optional] Pin No. Definition Signal...
  • Page 38: J4: Wake On Lan (Optional)

    5VMM Motherboard J4: Wake On LAN (Optional) Pin No. Definition +5V SB Signal J3: IR Connector PIN No. Definition VCC (+5V) IR data input IR data output...
  • Page 39: Panel And Jumper Definition

    Panel and Jumper Definition Panel And Jumper Definition J7: For 2x11 Pins Jumper GN (Green Switch) Open: Normal Operation Close: Entering Green Mode GD (Green LED) Pin 1: LED anode(+) Pin 2: LED cathode( ) HD (IDE Hard Disk Active LED) Pin 1: LED anode(+) Pin 2: LED cathode( ) SPK (Speaker Connector)
  • Page 40: Jp1: Clear Cmos Function

    5VMM Motherboard JP1: Clear CMOS Function Pin No. Definition 1-2 close Normal (Default) 2-3 close Clear CMOS JP5/JP6/JP7: Onboard AC97 & AMR (Primary or Secondary) Select (AMRà Audio Modem Riser) Jumper Function Only AC97 1-2 Close Close Only AMR 3-4 Close...
  • Page 41: J6: Usb Device Wake Up Selection (Optional)

    Panel and Jumper Definition J6: USB Device Wake up Selection (Optional) Pin No. Definition 1-2 close Normal (Default) Enabled USB Device 2-3 close Wake up JP4: Onboard LAN Function (Optional) Pin No. Definition 1-2 close Onboard LAN Enabled (Default) 2-3 close Onboard LAN Disabled...
  • Page 42: Jp2: Bios Flash Rom Write Protection (Optional)

    5VMM Motherboard JP2: BIOS Flash ROM Write Protection (Optional) Pin No. Definition Close BIOS Write Protection Open Normal (Default) M Please set Jumper JP2 to “Open” to enabled BIOS write function when you update new BIOS or new device. JP3: Internal Buzzer Connector (Optional) Pin No.
  • Page 43: Bat1: Battery

    Panel and Jumper Definition BAT1: Battery Danger of explosion if battery is incorrectly replaced. + Replace only with the same or equivalent type recommended by the manufacturer. + Dispose of used batteries according to the manufacturer’s instructions.
  • Page 44: Performance List

    5VMM Motherboard Performance List The following performance data list is the testing results of some popular benchmark testing programs. These data are just referred by users, and there is no responsibility for different testing data values gotten by users. (The different Hardware & Software configuration will result in different benchmark testing results.)
  • Page 45: Block Diagram

    Block Diagram Block Diagram 14.318MHz Socket 7 CPU 3.3V DIMM DIMM Sockets Host Bus VT8501 Ultra DMA ICS 9248-127 33/ATA66 IDE Ports 33 MHz PCI Bus 33 MHz ISA Bus 24MHz 48MHz IDE Bus 14.318MHz VT82C686A COM Port AC’ 97-Link Port Floppy AC97...
  • Page 46: Memory Installation

    5VMM Motherboard Memory Installation The motherboard has 2 dual inline memory module (DIMM) sockets. The BIOS will automatically detects memory type and size. To install the memory module, just push it vertically into the DIMM Slot .The DIMM module can only fit in one direction due to the two notch. Memory size can vary between sockets.
  • Page 47: Page Index For Bios Setup

    BIOS Setup $ Page Index for BIOS Setup Page The Main Menu P.42 Standard CMOS Features P.45 Advanced BIOS Features P.49 Advanced Chipset Features P.53 Integrated Peripherals P.56 Power Management Setup P.61 PnP/ PCI Configurations P.65 Frequency / Voltage Control P.67 Load Fail-Safe Defaults P.68...
  • Page 48: Entering Setup

    5VMM Motherboard BIOS Setup BIOS Setup is an overview of the BIOS Setup Program. The program that allows users to modify the basic system configuration. This type of information is stored in battery-backed CMOS RAM so that it retains the Setup information when the power is turned off.
  • Page 49: Getting Help

    BIOS Setup GETTING HELP Main Menu The on-line description of the highlighted setup function is displayed at the bottom of the screen. Status Page Setup Menu / Option Page Setup Menu Press F1 to pop up a small help window that describes the appropriate keys to use and the possible selections for the highlighted item.
  • Page 50 5VMM Motherboard Standard CMOS Features This setup page includes all the items in standard compatible BIOS. Advanced BIOS Features This setup page includes all the items of Award special enhanced features. Advanced Chipset Features This setup page includes all the items of chipset special features.
  • Page 51 BIOS Setup Save & Exit Setup Save CMOS value settings to CMOS and exit setup. Exit Without Saving Abandon all CMOS value changes and exit setup.
  • Page 52: Standard Cmos Features

    5VMM Motherboard Standard CMOS Features The items in Standard CMOS Features Menu (Figure 2) are divided into 9 categories. Each category includes no, one or more than one setup items. Use the arrows to highlight the item and then use the <PgUp> or <PgDn> keys to select the value you want in each item.
  • Page 53 BIOS Setup Time The times format in <hour> <minute> <second>. The time is calculated base on the 24-hour military-time clock. For example, 1 p.m. is 13:00:00. IDE Primary Master, Slave / Secondary Master, Slave The category identifies the types of hard disk from drive C to F that has been installed in the computer.
  • Page 54 5VMM Motherboard Floppy 3 Mode Support (for Japan Area) Normal Floppy Drive. (Default value) Disabled Drive A Drive A is 3 mode Floppy Drive. Drive B Drive B is 3 mode Floppy Drive. Both Drive A & B are 3 mode Floppy Drives.
  • Page 55 BIOS Setup Memory The category is display-only which is determined by POST (Power On Self Test) of the BIOS. Base Memory The POST of the BIOS will determine the amount of base (or conventional) memory installed in the system. The value of the base memory is typically 512 K for systems with 512 K memory installed on the motherboard, or 640 K for systems with 640 K or more memory installed on the motherboard.
  • Page 56: Advanced Bios Features

    5VMM Motherboard Advanced BIOS Features CMOS Setup Utility-Copyright( C ) 1984-2000 Award Software Advanced BIOS Features Virus Warning Disabled Item Help CPU Internal Cache Enabled Menu Level 4 Quick Power On Self Test Enabled First Boot Device Floppy Allows you to...
  • Page 57: Boot Other Device

    BIOS Setup CPU Internal Cache These two categories speed up memory access. However, it depends on CPU / chipset design. Enabled cache. (Default value) Enabled Disabled Disabled cache. Quick Power On Self Test This category speeds up Power On Self Test (POST) after you power on the computer. If it is set to Enable, BIOS will shorten or skip some check items during POST.
  • Page 58: Security Option

    5VMM Motherboard Boot Up Floppy Seek During POST, BIOS will determine the floppy disk drive installed is 40 or 80 tracks. 360 K type is 40 tracks 720 K, 1.2 M and 1.44 M are all 80 tracks. Enabled BIOS searches for floppy disk drive to determine it is 40 or 80 tracks.
  • Page 59 BIOS Setup OS Select For DRAM>64MB Using non-OS2 operating system. (Default value) Non-OS2 Using OS2 operating system and DRAM>64MB. HDD S.M.A.R.T. Capability Enabled Enabled HDD S.M.A.R.T. Capability. Disabled Disabled HDD S.M.A.R.T. Capability. (Default value) Report No FDD For WIN 95 Assign IRQ6 For FDD.
  • Page 60: Advanced Chipset Features

    5VMM Motherboard Advanced Chipset Features CMOS Setup Utility-Copyright( C ) 1984-2000 Award Software Advanced Chipset Features Bank 0/1 DRAM Timing SDRAM 10ns Item Help Bank 2/3 DRAM Timing SDRAM 10ns Menu Level 4 SDRAM Cycle Length DRAM Read Pipeline Disabled...
  • Page 61 BIOS Setup Video BIOS Cacheable Enabled video BIOS Cacheable. (Default value) Enabled Disabled Disabled video BIOS Cacheable. System BIOS Cacheable Enable System BIOS Cacheable. (Default value) Enabled Disabled Disable System BIOS Cacheable. Memory Hole Disabled Normal Setting. (Default value) 15M-16M Set Address=15~16MB remap to ISA BUS.
  • Page 62 5VMM Motherboard OnChip Sound Enabled OnChip Sound. (Default Value) Enabled Disabled Disabled this function. OnChip Modem Enabled OnChip Modem. (Default Value) Enabled Disabled Disabled this function. Memory Parity/ECC Check Enabled Enabled Memory Parity/ECC Check Function. Disabled Memory Parity/ECC Check Function. (Default Value)
  • Page 63: Integrated Peripherals

    BIOS Setup Integrated Peripherals CMOS Setup Utility-Copyright( C ) 1984-1999 Award Software Integrated Peripherals OnChip IDE Channel 0 Enabled Item Help OnChip IDE Channel 1 Enabled Menu Level 4 IDE Prefetch Mode Enabled Primary Master PIO Auto Primary Slave PIO Auto Secondary Master PIO Auto...
  • Page 64 5VMM Motherboard OnChip IDE Channel 1 Enabled onboard 2nd channel IDE port. (Default value) Enabled Disabled Disabled onboard 2nd channel IDE port. IDE Prefetch Mode Enabled IDE Prefetch Mode. (Default value) Enabled Disabled Disabled IDE Prefetch Mode. Primary Master PIO (for onboard IDE 1st channel) Auto BIOS will automatically detect the IDE HDD Accessing mode.
  • Page 65 BIOS Setup Secondary Master UDMA Auto BIOS will automatically detect the IDE HDD Accessing mode. (Default value) Disabled Disable UDMA function. Secondary Slave UDMA Auto BIOS will automatically detect the IDE HDD Accessing mode. (Default value) Disabled Disable UDMA function. IDE HDD Block Mode Enabled IDE HDD Block Mode.
  • Page 66 5VMM Motherboard UART 2 Mode (This item allows you to determine which UART 2 Mode of onboard I/O chip) HPSIR Set onboard I/O chip UART 2 to HPSIR mode. (Default Value) ASKIR Set onboard I/O chip UART 2 to ASKIR Mode.
  • Page 67 BIOS Setup Onboard Legacy Audio Enabled Onboard Legacy Audio. (Default Value) Enabled Disabled Disabled Onboard Legacy Audio. Sound Blaster Enabled Enabled Sound Blaster. Disabled Sound Blaster. (Default Value) Disabled SB I/O Base Address SB I/O Base Address is 220h. (Default Value) 220H SB I/O Base Address 240H...
  • Page 68: Power Management Setup

    5VMM Motherboard Power Management Setup CMOS Setup Utility-Copyright( C ) 1984-2000 Award Software Power Management Setup „Power Management Press Enter Item Help PM Control by APM Menu Level 4 Video Off Option SuspendgOff Video Off Method DPMS Support MODEM Use IRQ...
  • Page 69 BIOS Setup PM Control by APM Enabled PM Control by APM. (Default value) Disabled this function. Video off Option SuspendgOff BIOS will turn off V/H-SYNC when gets into Green mode for Green monitor power saving. (Default value) All ModesgOff BIOS will turn off V/H-SYNC when all modes. Always On BIOS will turn always on when all modes.
  • Page 70 5VMM Motherboard CPU Fan In Suspend Disabled this function. (Default value) Stop CPU FAN when entering Suspend mode. Disabled monitor VGA activity. (Default value) Enabled monitor VGA activity. LPT & COM Enabled LPT/COM Ports Activity. (Default value) LPT/COM NONE Normal Operation.
  • Page 71 BIOS Setup RTC Alarm Resume You can set “RTC Alarm Resume” item to Enabled and key in date/time to power on system. Disabled this function. (Default value) Disabled Enabled Enabled alarm function to POWER ON system. If the “RTC Alarm Resume” is Enabled. Date ( of Month) Alarm : 0~31 Resume Time ( hh: mm: ss) Alarm :...
  • Page 72: Pnp/Pci Configurations

    5VMM Motherboard PnP/PCI Configurations CMOS Setup Utility-Copyright( C ) 1984-2000 Award Software PnP/PCI Configurations PNP OS Installed Item Help Reset Configuration Data Disabled Menu Level 4 Resources Controlled By Auto (ESCD) X IRQ Resources Press Enter When resources are X DMA Resources...
  • Page 73: Resources Controlled By

    BIOS Setup Resources Controlled by Manual User can set the PnP resource (I/O Address, IRQ & DMA channels) used by legacy ISA DEVICE. Auto(ESCD) BIOS automatically use these PnP rescuers. (Default value) IRQ ( 3,4,5,7,9, 10,11,12,14,15 ),DMA( 0,1,3,5,6,7 ) Legacy ISA The resource is used by Legacy ISA device.
  • Page 74: Frequency/Voltage Control

    5VMM Motherboard Frequency/Voltage Control CMOS Setup Utility-Copyright( C ) 1984-2000 Award Software Frequency/Voltage Control Auto Detect DIMM/PCI Clk Enabled Item Help Spread Spectrum Modulated Disabled Menu Level 4 Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help F5:Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults...
  • Page 75: Load Fail-Safe Defaults

    BIOS Setup Load Fail-Safe Defaults CMOS Setup Utility-Copyright( C ) 1984-2000 Award Software 4 Standard CMOS Features Load Fail - Safe Defaults 4Advanced BIOS Features Load Optimized Defaults 4Advanced Chipset Features Set Supervisor Password 4Integrated Peripherals Set User Password 4Power Management Setup Save &...
  • Page 76: Load Optimized Defaults

    5VMM Motherboard Load Optimized Defaults CMOS Setup Utility-Copyright( C ) 1984-2000 Award Software 4 Standard CMOS Features Load Fail-Safe Defaults 4Advanced BIOS Features Load Optimized Defaults 4Advanced Chipset Features Set Supervisor Password 4Integrated Peripherals Set User Password 4Power Management Setup Save &...
  • Page 77: Set Supervisor / User Password

    BIOS Setup Set Supervisor / User Password When you select this function, the following message will appear at the center of the screen to assist you in creating a password. CMOS Setup Utility-Copyright( C ) 1984-2000 Award Software 4 Standard CMOS Features Load Fail-Safe Defaults 4Advanced BIOS Features Load Optimized Defaults...
  • Page 78: Save & Exit Setup

    5VMM Motherboard Save & Exit Setup CMOS Setup Utility-Copyright( C ) 1984-2000 Award Software 4 Standard CMOS Features Load Fail-Safe Defaults 4Advanced BIOS Features Load Optimized Defaults 4Advanced Chipset Features Set Supervisor Password 4Integrated Peripherals Set User Password 4Power Management Setup Save &...
  • Page 79: Exit Without Saving

    BIOS Setup Exit Without Saving CMOS Setup Utility-Copyright( C ) 1984-2000 Award Software 4 Standard CMOS Features Load Fail-Safe Defaults 4Advanced BIOS Features Load Optimized Defaults 4Advanced Chipset Features Set Supervisor Password 4Integrated Peripherals Set User Password 4Power Management Setup Save &...
  • Page 80: Appendix

    5VMM Motherboard Appendix Appendix A: VIA Chipsets Driver A. VIA 4 in 1 Service Pack Utility: Insert the support CD that came with your motherboard into your CD-ROM driver or double –click the CD driver icon in My Computer to bring up the screen.
  • Page 81 Appendix 7.Click “Next”. 8.Click “Next”. 10.Click “Finish” to restart. 9.Click “Next”. (10)
  • Page 82 5VMM Motherboard B. VGA Driver: Insert the support CD that came with your motherboard into your CD-ROM driver or double –click the CD driver icon in My Computer to bring up the screen. 1.Click “Change” item. 2. Click “Next”. 4.You can select “Specify a location: D:\VIA\VGA\Trident\8400\Win9x then Click “Next”.
  • Page 83 Appendix 7.Click “Finish” to restart computer.
  • Page 84 5VMM Motherboard Appendix B: VIA Sound Driver A. AC’97 Audio Driver: Insert the support CD that came with your motherboard into your CD-ROM driver or double –click the CD driver icon in My Computer to bring up the screen. Audio 2.Click “Next”.
  • Page 85 C:\utility\ AWDFlash or AMIFlash <filename of the BIOS binary file intended for flashing>. ü Once the process is finished, reboot the system. MNote: Please download the newest BIOS from our website (www.gigabyte.com.tw) or contact your local dealer for the file.
  • Page 86 5VMM Motherboard Appendix D: Acronyms Acor. Meaning ACPI Advanced Configuration and Power Interface POST Power-On Self Test Local Area Network Extended Capabilities Port Advanced Power Management Direct Memory Access Megahertz ESCD Extended System Configuration Data Central Processing Unit Symmetric Multi-Processing...
  • Page 87 Appendix Acor. Meaning Peripheral Component Interconnect RIMM Rambus in-line Memory Module Dual Retention Mechanism Industry Standard Architecture Memory Translator Hub CRIMM Continuity RIMM...
