Wire feed arc welder

Advertisement

Soudeuse à dévidage de fil-électrode
Garantie de remplacement
Garantie de remplacement
Cet article Mastercraft comprend une garantie de réparation de trois (3) ans contre les
défauts de fabrication et de matériau(x). Mastercraft Canada consent, à sa discrétion, à
réparer ou à remplacer toute pièce défectueuse sans frais au cours de la période de garantie
convenue lorsque l'article, accompagné de la preuve d'achat, est retourné par l'acquéreur
initial. Exclusion : usure ou bris causés par un usage abusif ou inapproprié.
Cet article n'est pas garanti s'il est utilisé à des fins industrielles ou commerciales.
SERVICE D'ASSISTANCE TÉLÉPHONIQUE SANS FRAIS : 1 866 220-2097
28 Fr
Operating Instructions & Parts Manual
Please read and save these instructions. Read carefully before attempting to assemble, install, operate or maintain the product described.
Protect yourself and others by observing all safety information. Failure to comply with instructions could result in personal injury and/or
property damage! Retain instructions for future reference.
Unpacking
Description
Welding accessories are packed inside
This wire feed arc welder is designed to
the wire feed compartment on the
be used on standard 115 V household
side of the welder. When unpacking,
current. The welder is equipped with
inspect carefully for any damage that may
infinite wire speed control to accurately
have occurred during transit. Make sure
select the proper wire feed rate needed
any loose fittings and screws, etc., are
for various welding conditions. Internal
tightened before putting unit into service.
components are thermostatically
Report any missing or damaged
items by calling 1-866-220-2097.
protected.
This welding system is designed for use
CIRCUIT REQUIREMENTS
with flux-core or MIG wires. As delivered
CAUTION
!
from the factory, this welder can weld
115 V circuit. Refer to the following chart
with .024" (.6 mm) to .030" (.8 mm)
for correct circuit breaker or fuse rating.
diameter wire in MIG and .030" (.8 mm)
Do not run other appliances, lights or
to .035" (.9 mm) diameter wire in flux-
tools on this circuit while operating this
core. A starter spool of .035" (.9 mm)
equipment. Extension cords are not
flux-core wire is included.
recommended. Blown fuses and tripped
circuit breakers can result from failure to
comply with this recommendation.
8
9
Fig. 1 - Welder Components and Controls
REMINDER: Keep your dated proof of purchase for warranty purposes! Attach it to this manual or file it for safekeeping.
WG2063, 58-8027- 4

Wire Feed

Arc Welder
Heat
Circuit Breaker or
Selector
Slow Blow Fuse
1-2-3
15 A
4
20 A
See page 7 for supply cable
replacement instructions.
COMPONENTS AND CONTROLS
1. Work Clamp: connects to workpiece.
This equipment
requires a dedicated
2. Torch with .035" tip.
3. Power Cord: plugs into 115 V outlet.
4. Light: illuminates if thermostat has
automatically shut welder off.
5. Infinite Wire Speed Control: turn
clockwise to increase wire speed and
counter-clockwise to decrease wire
speed.
6. Heat Selection Dial: selects welding
power and turns welder on. Four
selections are possible: 1 – 2 – 3 – 4.
7. MIG/Flux-core Polarity Selection Dial:
4
for changing to electrode positive or
5
negative polarity.
8. MIG Gas Hook-up
6
9. Wire Feed Compartment
3
General Safety
1
Danger means a
DANGER
!
hazard that will
cause death or serious injury if the
warning is ignored.
Warning means a
WARNING
!
hazard that could
cause death or serious injury if the
7
warning is ignored.
Caution means a
CAUTION
!
hazard that may
cause minor or moderate injury if the
2
warning is ignored. It also may mean a
hazard that will only cause damage to
property.
IN972900AV 2/05
