Gas dryer

Advertisement

Quick Links

GAS DRYER INSTALLATION INSTRUCTIONS
CANADIAN ELECTRIC DRYER INSTRUCTIONS
INSTRUCTIONS POUR L'INSTALLATION DE LA SÉCHEUSE
ÉLECTRIQUE (CANADA UNIQUEMENT)

Table of Contents

DRYER SAFETY .......................................................................... 2
INSTALLATION REQUIREMENTS .............................................. 4
Tools and Parts ...................................................................... 4
LOCATION REQUIREMENTS ..................................................... 5
GAS DRYER POWER HOOKUP ................................................. 7
INSTALL LEVELING LEGS .......................................................... 9
MAKE GAS CONNECTION ......................................................... 9
VENTING .................................................................................... 10
Venting Requirements ......................................................... 10
Plan Vent System ................................................................. 11
Install Vent System .............................................................. 12
CONNECT VENT ....................................................................... 14
LEVEL DRYER ........................................................................... 14
COMPLETE INSTALLATION CHECKLIST ............................... 15
DOOR REVERSAL (OPTIONAL) ............................................... 15
INSTALLATION NOTES
_________________________________
Date of purchase:
_______________________________
Date of installation:
________________________________________
Installer:
___________________________________
Model number:
___________________________________
Serial number:
W10573707B
W10573708B-SP
À GAZ (É.-U. ET CANADA)
Para una version de estas instrucciones en español, visite www.Whirlpool.com
Table des matières
SÉCURITÉ DE LA SÉCHEUSE ..................................................23
EXIGENCES D'INSTALLATION .................................................25
Outillage et pièces .............................................................25
EXIGENCES D'EMPLACEMENT ...............................................26
SÉCHEUSE ÉLECTRIQUE RACCORDEMENT À
L'ALIMENTATION ÉLECTRIQUE - CANADA SEULEMENT .....27
RACCORDEMENT D'UNE SÉCHEUSE À GAZ ........................28
INSTALLATION DES PIEDS DE NIVELLEMENT ......................30
RACCORDEMENT AU GAZ .......................................................30
ÉVACUATION .............................................................................31
Exigences concernant l'évacuation .................................31
Planification du système d'évacuation ............................32
Installation du système d'évacuation ...............................34
RACCORDEMENT DU TUYAU D'ALIMENTATION
(MODÈLE À VAPEUR UNIQUEMENT) ......................................34
RACCORDEMENT DU CONDUIT D'ÉVACUATION .................36
RÉGLAGE DE L'APLOMB DE LA SÉCHEUSE..........................36
ACHEVER L'INSTALLATION LISTE DE VÉRIFICATION ...........37
INVERSION DE LA PORTE (FACULTATIF) ................................37
NOTES CONCERNANT L'INSTALLATION
______________________________________
Date d'achat:
__________________________________
Date d'installation:
_______________________________________
Installateur:
_________________________________
Numéro de modéle:
___________________________________
Numéro de série:

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the YWED94HEAC and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Whirlpool YWED94HEAC

  • Page 1: Table Of Contents

    RÉGLAGE DE L’APLOMB DE LA SÉCHEUSE......36 DOOR REVERSAL (OPTIONAL) ..........15 ACHEVER L’INSTALLATION LISTE DE VÉRIFICATION ...37 INVERSION DE LA PORTE (FACULTATIF) ........37 Para una version de estas instrucciones en español, visite www.Whirlpool.com INSTALLATION NOTES NOTES CONCERNANT L’INSTALLATION _________________________________ ______________________________________ Date of purchase: Date d’achat:...
  • Page 2: Dryer Safety

    DRYER SAFETY...
  • Page 3 IMPORTANT: When discarding or storing your old clothes dryer, remove the door.
  • Page 4: Installation Requirements

    INSTALLATION REQUIREMENTS Parts supplied (all models): TOOLS AND PARTS Gather the required tools and parts before starting installation. Tools needed for all installations: Leveling legs (4) Parts supplied (steam models): Flat-blade screwdriver #2 Phillips screwdriver “Y” connector 1/4" and 5/16" nut driver Level (recommended) Parts package is located in dryer drum.
  • Page 5: Location Requirements

    LOCATION REQUIREMENTS DRYER DIMENSIONS Front view: 27" (686 mm) " Min. (984 mm) 39" Max. (990 mm) Side view: You will need: A location allowing for proper exhaust installation. ■ See “Venting Requirements.” A separate 15 or 20 amp circuit for a gas dryer or 30 amp ■...
  • Page 6: Electric Dryer Power Hookup-Canada Only

    Installation Clearances Mobile home installations require: For each arrangement, consider allowing more space for ease Metal exhaust system hardware, available for purchase from ■ of installation and servicing; spacing for companion appliances your dealer. For further information, see “Assistance or and clearances for walls, doors, and floor moldings.
  • Page 7: Gas Dryer Power Hookup

    If using a replacement power supply cord, it is recommended that GROUNDING INSTRUCTIONS you use Power Supply Cord Replacement Part Number 8529008. For further information, please reference service numbers located For a grounded, cord-connected dryer: in “Assistance or Service” section of your Use and Care Guide. This dryer must be grounded.
  • Page 8 GAS SUPPLY LINE GAS SUPPLY CONNECTION REQUIREMENTS Option 1 (Recommended Method) Use an elbow and a 3/8" flare x 3/8" NPT adapter fitting ■ between the flexible gas connector and the dryer gas pipe, Flexible stainless steel gas connector: as needed to avoid kinking. If local codes permit, use a new flexible stainless steel gas ■...
  • Page 9: Install Leveling Legs

    INSTALL LEVELING LEGS MAKE GAS CONNECTION (gas models only) Connect gas supply to dryer Prepare dryer for leveling legs A. Flared male fitting B. Non-flared male fitting Remove red cap from gas pipe. Using a wrench to tighten, connect gas supply to dryer. Use pipe-joint compound on threads of all non-flared male fittings.
  • Page 10: Venting

    VENTING Exhaust hoods: An exhaust hood should cap the vent to keep rodents and ■ Venting Requirements insects from entering the home. Must be at least 12" (305 mm) from ground or any object ■ that may obstruct exhaust (such as flowers, rocks, bushes, or snow).
  • Page 11: Plan Vent System

    Plan Vent System Special provisions for mobile homes: Exhaust vent must be securely fastened to a noncombustible Choose your exhaust installation type portion of mobile home and must not terminate beneath the mobile home. Terminate exhaust vent outside. Recommended exhaust installation: Dryer Rigid metal or flexible metal vent...
  • Page 12: Install Vent System

    Install Vent System The “Vent System Charts” provide venting requirements that will help achieve best drying performance. Standard Vent System Chart Install exhaust hood Number of Type Angled 12" min. (305 mm) 90° elbows of vent hoods Rigid metal 64 ft. (20 m) Rigid metal 54 ft.
  • Page 13 Attach short hose and Attach long hose to dryer fill valve “Y” connector and tighten coupling Attach 2 ft (0.6 m) inlet hose to cold water faucet. Screw on coupling by hand until it is seated on faucet. Then attach “Y” connector to male end of the 2 ft (0.6 m) inlet hose.
  • Page 14: Connect Vent

    CONNECT VENT LEVEL DRYER Level dryer Connect vent to exhaust outlet Place level here Using a 4" (102 mm) clamp, connect vent to exhaust outlet Check levelness of dryer from in dryer. If connecting to existing vent, make sure vent is side to side.
  • Page 15: Complete Installation Checklist

    COMPLETE INSTALLATION DOOR REVERSAL (OPTIONAL) CHECKLIST The following instructions are for models with a round and square-shaped doors. Check that all parts are now installed. If there is an extra part, go back through steps to see what was skipped. Tools needed: Check that you have all of your tools.
  • Page 16 Move the door strike Remove outer window assembly from trim ring Using a TORX screwdriver, remove the 2 screws Fig. A ® ® securing the door strike to the door frame of the dryer. Rotate the strike 180° and attach to the opposite side of dryer door frame, as shown.
  • Page 17 Reverse outer window assembly Rotate and reassemble outer window assembly to trim ring Handle Bottom of door Notches Fig. A Fig. A Fig. B With the edge with 2 notches at the top, align the notches on the outer window assembly with the tabs on the trim ring and lower into place as shown in figure A.
  • Page 18 Remove hinge and latch Reinstall inner door assembly Latch Bottom of door Hinge Using a TORX screwdriver, remove the 3 TORX screws ® ® ® Position the door with the inside of the door facing up. securing the latch plate and latch backing plate and the Reinstall the 10 screws securing the inner door to the 5 screws holding the hinge assembly in place.
  • Page 19 Reverse door swing round-shaped door – double handle Remove inner door from outer door Remove door from dryer IMPORTANT: If the protective film has not yet been removed from the dryer, peel the film from the dryer door before proceeding. Position the door with the inside of the door facing up.
  • Page 20 Reinstall hinge and latch on Reinstall door on dryer opposite sides Using a TORX screwdriver, remove the 4 screws on the ® ® dryer. Insert the tabs on the hinge into the mounting slot and slide down to engage the top tab. Secure in place with Using a TORX screwdriver, reinstall the latch plate and ®...
  • Page 21 Move the door strike Remove hinge and latch from inner door Latch Hinge Using a TORX screwdriver, remove the 2 screws ® ® Using a TORX screwdriver, remove the 3 TORX screws ® ® ® securing the door strike to the door frame of the dryer. securing the latch plate and the 5 screws holding the hinge Remove the 4 screws above and below the door strike and assembly in place.
  • Page 22 Reattach inner door to Reattach door to dryer outer door Position the inner door on the outer door assembly. Using Using a TORX screwdriver, reinstall the 4 screws ® ® a Phillips screwdriver, secure with the 13 screws removed securing the door hinge to the dryer. earlier.
