6.1 Create a private encrypted network

Step 1: Create a secure network.
First clear the public network and create a private network on
HomePlug A by pressing the GROUP button for 10 seconds On
release, all LED lights simultaneously turn off and on once. Do the
same on HomePlug B. At this moment, the network names have
changed to a random name and are ready to be joined together.
Step 2: Join the secure network.
Press the GROUP button of both HomePlugs for 2 to 3 sec (make
sure the POWER LED starts blinking). It doesn't matter which
device's button is pushed earlier than the other, but please push
the second device's Group button within two minutes after pushing
the first device's Group button. This way, HomePlug B joins the
same encrypted network as HomePlug A.
Please note: If you want to connect with any of the below Sitecom
Homeplugs, press the NMK button on these for 5~8 seconds to join a
secure network.
LN-506/LN-516
-
LN-507/LN-517
-
LN-508/LN-518
-
LN-509/LN-519
-
