DIGITAL MEDIA PLAYER
USER MANUAL
SMPV-4GBUA
PLEASE READ THIS OPERATING MANUAL COMPLETELY
BEFORE OPERATING THIS UNIT AND RETAIN THIS
BOOKLET FOR FUTURE REFERENCE.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SMPV-4GBUA and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Jensen SMPV-4GBUA

Summary of Contents for Jensen SMPV-4GBUA

  • Page 1 DIGITAL MEDIA PLAYER USER MANUAL SMPV-4GBUA PLEASE READ THIS OPERATING MANUAL COMPLETELY BEFORE OPERATING THIS UNIT AND RETAIN THIS BOOKLET FOR FUTURE REFERENCE.

  • Page 2: Dear Jensen ® Customer

    ® DEAR JENSEN CUSTOMER Selecting fine audio equipment such as the unit you've just purchased is only the start of your musical enjoyment. Now it's time to consider how you can maximize the fun and excitement your equipment offers. This manufacturer and the Electronic Industries Association's Consumer Electronics Group want you to get the most out of your equipment by playing it at a safe level.
  • Page 3 The serial number of this product is found on the unit. You should note the serial number of this unit in the space provided as a permanent record of your purchase to aid in identification in the event of theft of loss. Model Number: SMPV-4GBUA Serial Number:...
  • Page 4 WARNING Do not throw the product into fire to avoid danger of explosion. Do not immerse into water or get soaked since the battery charging function will be lost. Place the product far away from heat sources, and protect the product from direct sunlight.
  • Page 5 Do not attempt to disassemble or alter any part of the unit that is not expressly described in this guide. Internal inspections, alternations and repairs should be conducted by qualified service personnel. Save the data in the memory of the product to other storage device before repair.
  • Page 6 COMPLIANCE WITH FCC REGULATIONS This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: this device may not cause harmful interference, and this device must accept any interference received, including interference that may cause undesired operation. NOTE : This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.

  • Page 7: Battery Information

    CAUTION: Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. BATTERY INFORMATION For the first use of the product, you are recommended to fully charge your unit. Connect the unit with the provided USB cable to the personal computer correctly.
  • Page 8 Features Support MP3,WMA,WAV music format Support MTV video format(MTV video conversion software included in the CD-Rom) Support JPEG, BMP photo format 6 pre-set plus 1 user custom EQ Built-in microphone for voice recording Multi-language support USB2.0 interface E- book Games USB mass storage device Micro SD card (TF card) support ( the maximal memory for the Micro SD card (TF card) is 2GB)

  • Page 9: Locations Of Controls

    LOCATIONS OF CONTROLS LCD Display USB Port Power ON/OFF switch Play/Pause/ON/standy button Earphone Jack VOLUME (VOL) button Menu button Previous button ( Micro SD(TF) Card Slot Strap eyelet Next button ( Built-in Microphone...

  • Page 10: Buttons And Switch

    Buttons and Switch Power ON/Power OFF switch: Turn the unit power ON/OFF. Play/Pause button: play and pause; Power on/standby; enter/confirm button Menu button: menu or working mode selection. Next button: Fast forward / skip to track. Volume up; Menu Scroll down selection, Previous: Fast backward / skip to previous tack.
  • Page 11 Operation Manual I. Turn unit on/off - To turn on the unit, slide the Power Switch to the ON position, press the Play/Pause button ►|| once to turn on the player. - To turn off the unit, press and hold the Play/Pause button for few seconds will turn the unit to standby mode.
  • Page 12 2. Tap the ►|| button to access music mode. 3. In the music mode, Tap the M button to access the sub-menu of Music, Tap the M button again to return the music player screen. Repeat mode In the sub-menu of the music, press the button to select Repeat and short press the ►|| button to confirm.
  • Page 13 Equalizer(EQ) mode 1. In the sub-menu of the music, press the button to select Equalizer. 2. Tap the ►|| button to enter EQ selection menu. 3. There are 6 pre-set EQ modes - Normal/Pop/Rock/Classic/Jazz/Bass can be selected. 4. Press the to select the equalizer mode you desired, and then tap the ►|| to confirm.
  • Page 14 Play rate You can set the playback speed in this mode. File In this mode, you can browse all the music files, and press the ►|| to play the track selected. Classified Select the file according to the genre, artist, Album &Title. Play List Browse the file according to the list set by the user.

  • Page 15: Important Note

    After conversion, connect the unit to the PC. Create a new folder and rename it as SLS.DIR in the either the internal storage or external storage (microSD – not included). Use your PC to Copy the﹡. SLS file into SLS.DIR folder you just created in the unit’s storage location.

  • Page 16: Operation

    timer, the slideshow and will play, but the screen will remain off while playing. OPERATION： 1. Enter Music mode, locate a music file you want to play, press Play/Pause button to start playback. 2. Volume control In music mode, press and hold VOL button to enter the volume adjust mode, the volume icon will become pink .

  • Page 17: Video Mode

    III. VIDEO MODE IMPORTANT NOTE 1. The video conversion software only works on Windows operating systems. 2. The video file format for this player is MTV. The file formats that can be converted directly into MTV are MPG, ASF, AVI, WMV using the convert tooling located on the provided CD.
  • Page 18 SETTINGS 1. In the main menu, press the buttons to select VIDEO and then press the ►|| button to access. 2. In movie list, press the button to select a movie you want to play and then tap the ►|| button to start playback. 3.
  • Page 19 OPERATIONS： 1. Select a movie from the list, tap the ►|| button to playback / pause the movie. 2. Fast Forward / Fast Reverse During normal play, press and hold the button to fast forward or reverse 3. Volume control In video play/pause mode, tap the VOL button to enter the volume adjust mode.

  • Page 20: Auto Search

    Manual Search In FM mode, tap the ►|| button to toggle select between Normal and Preset mode. In the “Normal” model, tap the button to tune radio frequency up/down manually. Auto Search 1. In the FM Normal mode, tap the M button, the “Save Preset / Auto Scan” menu will pop up on the screen.
  • Page 21 4. Select Yes in pop up menu and tap the ►|| button to confirm. Delete pre-set channels 1. In the FM mode, tap the ►|| to select Preset mode, 2. Tap the M button and select “Delete” to enter the delete mode, 3.
  • Page 22 IV. Photo Viewer View Photo In the main menu, select “Photo” and press the ►|| button to enter into Photo viewer mode, a sub-menu showing all the photo files will appear. Select the file you want to view. Press the button to navigate and select a file.
  • Page 23 V. E-Book In the main menu, select “EBOOK” and then tap ►|| button to enter into the E-book mode. Press the M button to go to the E-book list. Press the button to navigate and select file Tap the ►|| button to open selected file Press the button to scroll the pages.
  • Page 24 VI. Voice Mode Voice Recording In the main menu select Voice and tap the ►|| button to enter the voice mode. 1. In the voice pause mode, tap the VOL button to start the voice record mode, 2. Press the ►|| button to pause recording, press it again to continue. 3.
  • Page 25 Tap the ►|| button to start playback. 3. Press the button to skip to the next or previous file. 4. Press and hold the VOL button to enter the volume adjust mode, the volume icon will turn pink 5. Press the button to increase &...
  • Page 26 Delete the file 1. To delete a file, use the button to navigate and select a folder or a file to be deleted. 2. Press the ►|| button to enter the delete mode, 3. Press the button to select Yes or No. 4.
  • Page 27 In the game mode, press the button to select the game you want to play and press the ►|| button to confirm. Game Play Go bang 1. Start: Start playing the game. 2. Introduction: Introduce the game. 3. Basic control - Use the button to move toward Right or Left - Use the M / VOL button to move toward Up or Down...
  • Page 28 IX. System Setup In the main menu select “SETUP”，tap the ►|| button to enter into sub-menu. Press the button to navigate and select setting option, press the ►|| button to enter into selected setting。 Power mode 1. Sleep Timer - This function allows user to set a sleep timer for the device to automatically power-off.
  • Page 29 2. Battery Saving - ON mode, to activate sleep timer. - OFF mode, unit will only turn off if no music is played for more than 120 minutes. Language To select language of the menu. Display 1. Brightness - To set display backlight dimmer. - 4 different settings: Low, Medium, High and Maximum 2.
  • Page 30 2. Format Set the record format in this mode, 2 selections available: ADPCM and 3. VAD Record according to the voice, If no voice is heard then recording will stop automatically. In this setting, you can turn on VAD function or turn off this function by selecting Yes or NO.
  • Page 31 4. System information - Display the system information of the player. 5. Refresh - Refresh the player 6. File Sort - Force Sort: Sort the files manually. - Auto Sort: Sort the files automatically. Storages - 2 options: Internal or SD/MMC Card (card not included) - If Internal is selected, the unit will play the files using the built-in memory, if you select SD/MMC Card, it will play files from an inserted micro SD (TF card) - (card not included)
  • Page 32 Frequently Asked Questions 1. Device does not power on - Check battery power - Charge battery and try again - After charging and if problem still persists, call for customer service 2. Cannot hear with your earphones - Check volume level - Check if earphones are connected properly 3.

  • Page 33: Technical Specifications

    Technical Specifications Music format MP3. WMA. WAV Record format Video format Picture format JPG, BMP Internal Memory External Memory Micro SD (TF card) up to 2GB Display 2.4” , 256K color, TFT, 320 X 240 pixels Battery specification Built in rechargeable lithium battery PC slot USB2.0 Windows ME, Win2000 and Win XP,...
  • Page 34 SERVICE Please refer to the instructions on the enclosed warranty card for returning your unit for service. When returning the unit. Distributed by: SPECTRA Merchandising International, Inc. Chicago Industry Tech Park 4230 North Normandy Avenue Chicago, IL 60634, U.S.A. Please have model number...
