Control unit
Control unit
Control unit
Control unit
aquaduct
User's manual
Firmware version 1.05
OS version 2.00
prior notice. All rights reserved
Current as of: May 2009
Aqua Computer GmbH & Co. KG
Gelliehäuser Str. 1, 37130 Gleichen, Germany
AQUADUCT CONTROL UNIT
- 1 -

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the aquaduct mark 3 and is the answer not in the manual?

Questions and answers

Summary of Contents for Aqua Computer aquaduct mark 3

  • Page 1 OS version 2.00 The information contained in this manual is subject to change without prior notice. All rights reserved Current as of: May 2009 © 2008-2009 Aqua Computer GmbH & Co. KG - 1 - Gelliehäuser Str. 1, 37130 Gleichen, Germany...
  • Page 2: Table Of Contents

    5.2.13. Return to display ................14 6. Menu „Temperature sensors“..........14 6.1. Sensor name ................15 6.2. Start-up temperature..............15 6.3. Maximum temperature..............15 6.4. Alarm temperature ..............15 - 2 - Aqua Computer GmbH & Co. KG © 2008-2009 Gelliehäuser Str. 1, 37130 Gleichen, Germany...
  • Page 3 10.3. Minimum brightness ..............22 10.4. Turn-off time................22 10.5. Switch time ................22 10.6. LCD switch-off ................23 10.7. USBLCD mode................23 10.8. USBLCD at bootup ..............23 © 2008-2009 Aqua Computer GmbH & Co. KG - 3 - Gelliehäuser Str. 1, 37130 Gleichen, Germany...
  • Page 4 14.9. Off Time 2 ................30 14.10. Back ..................30 15. Menu „Power measurement“ ........30 15.1. Measurement 1 Sensor 1 ............31 15.2. Measurement 1 Sensor 2 ............31 - 4 - Aqua Computer GmbH & Co. KG © 2008-2009 Gelliehäuser Str. 1, 37130 Gleichen, Germany...
  • Page 5 19.4. Restrictions of the emergency shutdown functions ......36 19.6. Configuring display contrast on start-up........36 20. Trouble shooting ............36 20.1. Loading factory defaults on start-up..........36 © 2008-2009 Aqua Computer GmbH & Co. KG - 5 - Gelliehäuser Str. 1, 37130 Gleichen, Germany...
  • Page 6: Preface

    2.3. “ 2.3. “flow“ flow“ flow“ flow“ This connector must not be used as the aquaduct 360/720 XT features an integrated flow sensor! - 6 - Aqua Computer GmbH & Co. KG © 2008-2009 Gelliehäuser Str. 1, 37130 Gleichen, Germany...
  • Page 7: Fan

    Factory setting is power supply connector. When using standby power, this jumper must imperatively be removed! Jumper setting: closed: standard power supply open: standby power supply © 2008-2009 Aqua Computer GmbH & Co. KG - 7 - Gelliehäuser Str. 1, 37130 Gleichen, Germany...
  • Page 8: Temp Sensor 1/2

    You should now familiarize yourself with the functions of the device be- fore you perform the setup of the basic settings. - 8 - Aqua Computer GmbH & Co. KG © 2008-2009 Gelliehäuser Str. 1, 37130 Gleichen, Germany...
  • Page 9: Display And Operation

    50% will effectively be powered by 70 %. Prerequisites: The respective fan is configured to manual power configu- ration or in fixed rpm mode and the override function is enabled. © 2008-2009 Aqua Computer GmbH & Co. KG - 9 - Gelliehäuser Str. 1, 37130 Gleichen, Germany...
  • Page 10: Display Mode

    Maximum freq.: 53 Hz Voltage: 12,00 V Current fill level full 20,0C 20,0C 20,0C 20,0C 20,0C 20,0C Water out : 20,0C Water in : 20,0C - 10 - Aqua Computer GmbH & Co. KG © 2008-2009 Gelliehäuser Str. 1, 37130 Gleichen, Germany...
  • Page 11 12,0V Middle fan 12,0V Bottom fan 12,0V Ext. fan 12,0V Power measurement 1 Power : Power measurement 2 Power : Flow 50,00 liter/hour © 2008-2009 Aqua Computer GmbH & Co. KG - 11 - Gelliehäuser Str. 1, 37130 Gleichen, Germany...
  • Page 12: Device Settings

    One or two temperature sensors can be assigned to each fan, alterna- tively each fan can also be manually controlled. - 12 - Aqua Computer GmbH & Co. KG © 2008-2009 Gelliehäuser Str. 1, 37130 Gleichen, Germany...
  • Page 13: Settings Menu

    ATX control line of the PSU or connection to the power switch header of the motherboard. For details, see 11. Menu „Relay“ © 2008-2009 Aqua Computer GmbH & Co. KG - 13 - Gelliehäuser Str. 1, 37130 Gleichen, Germany...
  • Page 14: Alarm Parameters

    To leave the menu "temperature sensors", choose the entry "back" and confirm the selection by pushing the knob. - 14 - Aqua Computer GmbH & Co. KG © 2008-2009 Gelliehäuser Str. 1, 37130 Gleichen, Germany...
  • Page 15: Sensor Name

    © 2008-2009 Aqua Computer GmbH & Co. KG - 15 - Gelliehäuser Str. 1, 37130 Gleichen, Germany...
  • Page 16: Target Temperature

    This value is only needed if the corresponding fan is in the target-value mode. The controller delay sets the minimum time in seconds after which the controller is recalculated. - 16 - Aqua Computer GmbH & Co. KG © 2008-2009 Gelliehäuser Str. 1, 37130 Gleichen, Germany...
  • Page 17: Controller Factor

    If the current flow rate drops below this value, an alarm will be raised. Additionally, alarm evaluation must be activated for this alarm, for de- tails see 12.1. Alarm. © 2008-2009 Aqua Computer GmbH & Co. KG - 17 - Gelliehäuser Str. 1, 37130 Gleichen, Germany...
  • Page 18: Calibration Factor

    The fan can either be turned off (0 revolutions) or regulated in the area from approximately ¼ of the maximum speed to the maxi- - 18 - Aqua Computer GmbH & Co. KG © 2008-2009 Gelliehäuser Str. 1, 37130 Gleichen, Germany...
  • Page 19: Manual Control

    Here, you can define the minimal output performance of the tempera- ture-controlled operation. This value is processed differently depending © 2008-2009 Aqua Computer GmbH & Co. KG - 19 - Gelliehäuser Str. 1, 37130 Gleichen, Germany...
  • Page 20: Control Options

    With some fans - 20 - Aqua Computer GmbH & Co. KG © 2008-2009 Gelliehäuser Str. 1, 37130 Gleichen, Germany...
  • Page 21: Override On/Off

    This value defines the minimum frequency equaling a minimum rotation speed for the pump. This value is only processed if “minimum frequency on/off” is enabled. © 2008-2009 Aqua Computer GmbH & Co. KG - 21 - Gelliehäuser Str. 1, 37130 Gleichen, Germany...
  • Page 22: Frequency Preset

    Enter the time span after which the display should automatically switch to the next screen. Adjustable in 1-30-second-steps from 1 to 240 sec- onds, alternatively no automatic switches (value> 240). - 22 - Aqua Computer GmbH & Co. KG © 2008-2009 Gelliehäuser Str. 1, 37130 Gleichen, Germany...
  • Page 23: Lcd Switch-Off

    - User screen 3 (configurable from the aquasuite software) - User screen 4 (configurable from the aquasuite software) - Override function - Aquaduct information page 1 © 2008-2009 Aqua Computer GmbH & Co. KG - 23 - Gelliehäuser Str. 1, 37130 Gleichen, Germany...
  • Page 24: Key Click

    This setting determines, whether the relay is controlled automatically or manually. If the relay is to be used for emergency shutdown functions (additional accessories required), automatic mode must be enabled. - 24 - Aqua Computer GmbH & Co. KG © 2008-2009 Gelliehäuser Str. 1, 37130 Gleichen, Germany...
  • Page 25: Relay On/Off

    If you select “Timer disabled”, all further settings for the timer functions are ignored. 11.6. 11.6. Back Back 11.6. 11.6. Back Back Leaves the submenu and returns to "Settings". © 2008-2009 Aqua Computer GmbH & Co. KG - 25 - Gelliehäuser Str. 1, 37130 Gleichen, Germany...
  • Page 26: Mena „Alarms

    (default setting is 8 seconds). 12.4. Alarm 12.4. Alarm 12.4. Alarm 12.4. Alarm beeper beeper beeper beeper This setting enables/disables the acoustic alarm function of the aquaduct - 26 - Aqua Computer GmbH & Co. KG © 2008-2009 Gelliehäuser Str. 1, 37130 Gleichen, Germany...
  • Page 27: Rpm Signal On/Off

    LED, the sensors are first analyzed individually and the highest result (i.e. the highest brightness) is used to control the LED. © 2008-2009 Aqua Computer GmbH & Co. KG - 27 - Gelliehäuser Str. 1, 37130 Gleichen, Germany...
  • Page 28: Sensor 2 (Auto)

    If the aquaduct is connected to the standby-power supply of the PSU, time stays current even when the PC is turned off (soft-off). - 28 - Aqua Computer GmbH & Co. KG © 2008-2009 Gelliehäuser Str. 1, 37130 Gleichen, Germany...
  • Page 29: Turn-On Time 1

    Turn- - - - Off Time Off Time Off Time Off Time 2 2 2 2 Enter a second time as described in 14.6. Turn-Off Time 1. © 2008-2009 Aqua Computer GmbH & Co. KG - 29 - Gelliehäuser Str. 1, 37130 Gleichen, Germany...
  • Page 30: Off Time 2

    You should therefore regard the calculated value only as interesting additional information. - 30 - Aqua Computer GmbH & Co. KG © 2008-2009 Gelliehäuser Str. 1, 37130 Gleichen, Germany...
  • Page 31: Measurement 1 Sensor 1

    A prerequisite for a reliable level analysis is a preceding calibration of the 100 % ref- erence value. © 2008-2009 Aqua Computer GmbH & Co. KG - 31 - Gelliehäuser Str. 1, 37130 Gleichen, Germany...
  • Page 32: Set 100 % Reference

    PSU prior to loading the default settings! 17.2. 17.2. 17.2. 17.2. Back Back Back Back Leaves the submenu and returns to "Settings". - 32 - Aqua Computer GmbH & Co. KG © 2008-2009 Gelliehäuser Str. 1, 37130 Gleichen, Germany...
  • Page 33: Example Configuration

    Set the following values for Sensor 1 (“Water out“): Start-up temperature: 30 °C Maximum temperature: 50 °C © 2008-2009 Aqua Computer GmbH & Co. KG - 33 - Gelliehäuser Str. 1, 37130 Gleichen, Germany...
  • Page 34: Emergency Shutdown Of The Pc On Temperature Alarm

    Relay Usage: ATX-Break-Line Enable alarm: enabled Set the following alarm parameters: Alarm events: Temperature alarm: on Alarm-Off timeout: 10 seconds Alarm time: Switch permanently Result: - 34 - Aqua Computer GmbH & Co. KG © 2008-2009 Gelliehäuser Str. 1, 37130 Gleichen, Germany...
  • Page 35: Special Notices

    Please note: If the PC starts up immediately after pressing the rotary knob when using the ATX break line, „Restart after AC power loss“ (or similar) is most likely activated in the computer BIOS. © 2008-2009 Aqua Computer GmbH & Co. KG - 35 - Gelliehäuser Str. 1, 37130 Gleichen, Germany...
  • Page 36: Restrictions Of The Emergency Shutdown Functions

    Now that you have completely read the instructions, we wish you much joy with our products. For further questions please do not hesitate to contact us via e-mail or also in our support forum. - 36 - Aqua Computer GmbH & Co. KG © 2008-2009 Gelliehäuser Str. 1, 37130 Gleichen, Germany...
