  • Page 1 CMS 3.0 Series In-Ceiling Loudspeakers Operation Manual...
  • Page 2 CMS 3.0 Series Operation Manual rev 3.0.0...

  • Page 3: Table Of Contents

    6.4. Installation Guide for Optional Pre-Installation Backcan (PI Models Only) ..........11 7. Wiring and Setting Up 8. CMS Series Model Dimensions 9. Technical Specifications 10. Painting 11. Warranty 12. Declaration of conformity CMS 3.0 Series Operation Manual rev 3.0.0...

  • Page 4: Introduction

    Recommended torque setting: 1.5 Nm Tannoy will not be held responsible for any damages caused by the improper installation of these loudspeakers. The CMS 603 ICT LS is UL-1480, category UUMW, for use with non-DC supervised systems.

  • Page 5: Product Feature Identification

    The blind-mount models are supplied with a pre-fitted backcan. Above applies to all models with a “BM” suffix as well any others that do NOT have a “PI” suffix. 4.2. Pre-install A pre-install (PI) unit is shown without the optional pre-install backcan. CMS 3.0 Series Operation Manual rev 3.0.0...

  • Page 6: Pre-Install Backcan

    Optional pre-install (PI) backcan for PI models. NOTE: The CMS 603DC/ICT and CMS 803DC models have the transformer pre-attached to the inside of the backcan. The CMS 503DC/ICT has the transformer pre-attached to the loudspeaker assembly. CMS 3.0 Series Operation Manual rev 3.0.0...

  • Page 7: Accessories

    Grille Cut-out template Paint Mask Optional Accessories Plaster (mud) 60 W Transformer ring Note: For use with CMS 803 PI in distributed lines without backcans. CMS 3.0 Series Operation Manual rev 3.0.0...

  • Page 8: Installation

    Tighten the screws until a firm grip is achieved. (NOTE: Screws have a PoziDriv head; use of a PoziDriv driver is recommended). If using a power driver, Tannoy recommends a torque setting of 1.5 Nm. (Fig.4) Fig.3...

  • Page 9: Installation Guide For Sheetrock Ceilings

    Tighten the screws until a firm Fig.2 grip is achieved. (NOTE: Screws have a PoziDriv head; use of a PoziDriv driver is recommended). If using a power driver, Tannoy recommends a torque setting of 1.5 Nm. (Fig.3) DO NOT OVERTIGHTEN! 5.

  • Page 10: Installation Guide For Optional Plaster Ring

    6. Installation 6.3. Installation Guide for Optional Plaster Ring An optional plaster (mud) ring bracket is available from Tannoy. This bracket is designed to be pre-installed into newly constructed, non-suspended ceilings. 1. Nail or screw the plaster ring to the joists. (Fig.1) 2.

  • Page 11: Installation Guide For Optional Pre-Installation Backcan (Pi Models Only)

    (Fig.3) Fig.3 b. Next, secure the wings of the pre-mount ring to a safe and secure fixing point by using suitable fixings. (Fig.4) Please turn over Fig.4 CMS 3.0 Series Operation Manual rev 3.0.0...

  • Page 12: Method

    PI backcan. 4. Cut hole in the proper location in the ceiling using a pad saw. Place the pre-install backcan over the hole. (Fig.7) Fig.7 CMS 3.0 Series Operation Manual rev 3.0.0...
  • Page 13 Tighten the screws until a firm grip is achieved. (NOTE: Screws have a PoziDriv head; use of a PoziDriv driver is recommended). If using a power driver, Tannoy recommends a torque setting of 1.5 Nm. (Fig.8) Fig.8...

  • Page 14: Wiring And Setting Up

    CMS 603DC/ICT and CMS 803DC models (all variants) use a 60 W transformer. In distributed line applications, the transformer can be tapped at 60 W, 30 W and 15 W, with an additional 7.5 W tap for 70 V line systems. (Fig.4) Fig.4 CMS 3.0 Series Operation Manual rev 3.0.0...

  • Page 15: Cms Series Model Dimensions

    8. CMS Series Model Dimensions CMS 403DCe Hole Cut-out Size: 187 mm 147.6 [5.81"] 34.2 [1.35"] Ø181.1 Ø205.0 [7.13"] [8.07"] CMS 403ICTe Hole Cut-out Size: 187 mm 147.6 [5.81"] 34.2 [1.35"] Ø181.1 Ø205.0 [7.13"] CMS 3.0 Series Operation Manual rev 3.0.0...
  • Page 16 CMS 503DC BM Hole Cut-out Size: 190 mm 205.3 188.0 [8.08"] [7.40"] [0.18"] 205.9 181.3 [7.14"] [8.11"] CMS 503ICT BM Hole Cut-out Size: 190 mm 205.8 188.5 [8.10"] [7.42"] [0.17"] 205.9 181.3 [7.14"] [8.11"] CMS 3.0 Series Operation Manual rev 3.0.0...
  • Page 17 8. CMS Series Model Dimensions CMS 503DC LP Hole Cut-out Size: 253 mm 98.6 [3.88"] [0.17"] 274.0 244.3 [10.79"] [9.62"] CMS 503ICT LP Hole Cut-out Size: 253 mm 98.6 [3.88"] [0.17"] 274.0 244.3 [10.79"] [9.62"] CMS 3.0 Series Operation Manual rev 3.0.0...
  • Page 18 8. CMS Series Model Dimensions CMS 503DC PI Hole Cut-out Size: 190 mm 133.3 [5.25"] [0.17"] 205.9 [8.11"] CMS 503ICT PI Hole Cut-out Size: 190 mm 131.7 [5.19"] [0.17"] 181.3 205.9 [7.14"] [8.11"] CMS 3.0 Series Operation Manual rev 3.0.0...
  • Page 19 Hole Cut-out Size: 190 mm 153.5 [6.04"] Ø288.0 Ø186.4 Ø256.0 [11.34"] [7.34"] [10.08"] 136.2 [0.35"] [5.36"] CMS 503ICT PI BACKCAN Hole Cut-out Size: 190 mm 153.5 [6.04"] Ø288.0 Ø186.4 Ø256.0 [11.34"] [7.34"] [10.08"] 136.2 [0.35"] [5.36"] CMS 3.0 Series Operation Manual rev 3.0.0...
  • Page 20 CMS 603DC BM Hole Cut-out Size: 253 mm 273.3 255.8 [10.76"] [10.07"] [0.17"] 244.3 274.0 [9.62"] [10.79"] CMS 603ICT BM Hole Cut-out Size: 253 mm 273.8 256.5 [10.78"] [10.10"] [0.16"] 274.0 244.3 [10.79"] [9.62"] CMS 3.0 Series Operation Manual rev 3.0.0...
  • Page 21 8. CMS Series Model Dimensions CMS 603DC PI Hole Cut-out Size: 253 mm 100.0 [3.94"] [0.16"] 274.0 244.3 [10.79"] [9.62"] CMS 603ICT PI Hole Cut-out Size: 253 mm 100.0 [3.94"] [0.16"] 244.3 273.5 [10.77"] [9.62"] CMS 3.0 Series Operation Manual rev 3.0.0...
  • Page 22 Hole Cut-out Size: 253 mm 168.5 [6.63"] Ø351.0 Ø249.4 Ø319.0 [13.82"] [9.82"] [12.56"] 151.2 [0.35"] [5.95"] CMS 603ICT PI BACKCAN Hole Cut-out Size: 253 mm 168.5 [6.63"] Ø351.0 Ø249.4 Ø319.0 [13.82"] [9.82"] [12.56"] 151.2 [0.35"] [5.95"] CMS 3.0 Series Operation Manual rev 3.0.0...
  • Page 23 CMS 603ICT LS Hole Cut-out Size: 253 mm 273.8 256.5 [10.78"] [10.10"] [0.16"] 274.0 244.3 [10.79"] [9.62"] CMS 803DC BM Hole Cut-out Size: 295 mm 327.7 310.5 [12.90"] [12.22"] [0.20"] 319.0 286.4 [12.56"] [11.27"] CMS 3.0 Series Operation Manual rev 3.0.0...
  • Page 24 CMS 803DC PI Hole Cut-out Size: 295 mm 125.6 [4.94"] [0.20"] 286.4 319.0 [11.27"] [12.56"] CMS 803DC PI BACKCAN Hole Cut-out Size: 295 mm 168.5 [6.63"] Ø291.4 Ø397.0 Ø365.0 [11.47"] [15.63"] [14.37"] 151.2 [0.35"] [5.95"] CMS 3.0 Series Operation Manual rev 3.0.0...
  • Page 25 8. CMS Series Model Dimensions 8. CMS Series Model Dimensions CMS 803DCQ Hole Cut-out Size: 295 mm 327.7 310.5 [12.90"] [12.22"] [0.20"] 319.0 286.4 [11.27"] [12.56"] CMS 3.0 Series Operation Manual rev 3.0.0...

  • Page 26: Technical Specifications

    Safety ring located at rear of enclosure for load bearing safety bond Clamping Design Min / Max clamping range: 0.0 mm (0.0”) / Copyright (c) 2014 Tannoy Limited. All rights reserved. 20.0 mm (0.79”) Recommended clamp torque: 1.5 Nm Backcan...
  • Page 27 Steel, with weather resistant coating Safety Features Safety ring located at rear of enclosure for load bearing safety bond Copyright (c) 2014 Tannoy Limited. All rights reserved. Clamping Design Min / Max clamping range: 0.0 mm (0.0”) / 20.0 mm (0.79”) Recommended clamp torque: 1.5 Nm...
  • Page 28 “loop through” facility specifications when dealing with critical applications. Compliance UL-1480, UL-2043, CE Dimensions Copyright (c) 2014 Tannoy Limited. All rights reserved. Bezel diameter 205.9 mm (8.11”) BM Model: Front of ceiling to rear of backcan 188.0 mm (7.40”) BM Model: Front of ceiling to top of safety loop 205.3 mm (8.08”)
  • Page 29 Cable Entry Options Cable clamp & squeeze connector for conduit up to 22 mm Connectors Removable locking connector with screw terminals with Copyright (c) 2014 Tannoy Limited. All rights reserved. “loop through” facility Compliance UL-1480, UL-2043, CE Dimensions Bezel diameter 274.0 mm (10.79”)
  • Page 30 Conduit Knockouts on PI Backcan 3 Sets of horizontal positions 19 / 22 / 28 mm (0.75” / 0.87” / 1.10”) Connectors Removable locking connector with screw terminals with Copyright (c) 2014 Tannoy Limited. All rights reserved. “loop through” facility Compliance UL-1480, UL-2043, CE...
  • Page 31 Cable clamp & squeeze connector for conduit up to 22 mm specifications when dealing with critical applications. Connectors Removable locking connector with screw terminals with “loop through” facility Copyright (c) 2014 Tannoy Limited. All rights reserved. Compliance UL-1480, UL-2043, CE Dimensions Bezel diameter 274.0 mm (10.79”)
  • Page 32 “loop through” facility specifications when dealing with critical applications. Compliance UL-1480, UL-2043, CE Dimensions Copyright (c) 2014 Tannoy Limited. All rights reserved. Bezel diameter 274.0 mm (10.79”) BM Model: Front of ceiling to rear of backcan 255.8 mm (10.07”) BM Model: Front of ceiling to top of safety loop 273.3 mm (10.76”)
  • Page 33 Conduit Knockouts on PI Backcan 3 Sets of horizontal positions 19 / 22 / 28 mm (0.75” / 0.87” / 1.10”) Connectors Removable locking connector with screw terminals with Copyright (c) 2014 Tannoy Limited. All rights reserved. “loop through” facility Compliance UL-1480, UL-2043, CE...
  • Page 34 Removable locking connector with screw terminals with specifications when dealing with critical applications. “loop through” facility Compliance UL-1480, UL-2043, CE Copyright (c) 2014 Tannoy Limited. All rights reserved. Dimensions Bezel diameter 319.0 mm (12.56”) BM Model: Front of ceiling to rear of backcan 310.5 mm (12.22”)
  • Page 35 Recommended clamp torque: 1.5 Nm specifications when dealing with critical applications. Cable Entry Options Cable clamp & squeeze connector for conduit up to 22 mm Copyright (c) 2014 Tannoy Limited. All rights reserved. Connectors Removable locking connector with screw terminals with “loop through” facility...

  • Page 36: Painting

    • Paint the grille and then replace the grille cloth - several thin coats of paint will provide a better finish than one overly thick coat. • Re-bond the grille cloth to the grille over the entire area using a light spray-adhesive to avoid audible resonances. CMS 3.0 Series Operation Manual rev 3.0.0...

  • Page 37: Warranty

    No maintenance of the CMS Series loudspeaker is necessary. As part of the MUSIC Group, Tannoy is committed to providing the highest quality products, service and user experience for our customers. One element of this commitment is our after sales support which now incorporates our extended Limited Warranty.

  • Page 38: Declaration Of Conformity

    Electromagnetic compatibility. Product family standard for audio, video, audio-visual and entertainment lighting control apparatus 2009 for professional use. Immunity Name: Philippe Robineau Position: Director of Engineering Done at: Coatbridge Date: 23/11/2015 Director of Engineering Tannoy 23 November 2015 CMS 3.0 Series Operation Manual rev 3.0.0...
  • Page 39 Notes Notes CMS 3.0 Series Operation Manual rev 3.0.0...
  • Page 40 Tannoy operates a policy of continuous research and development. The introduction of new materials or manufacturing methods will always equal or exceed the published specifications. All specifications are subject to change without notice. Copyright (c) 2015 Music Group Innovation SC Ltd. All rights reserved.
