- Page 1 280W Multi Function tool Original manual Now you have purchased a Workzone® product you can rest assured in the knowledge that as well as your 3 year parts and labour guarantee you have the added peace of mind of dedicated helplines and web support.
-
Page 2: Table Of Contents
Introduction General Information and safety instructions Assembly and parts list Instructions Other useful information CE Declaration Warranty card aFTEr SalES SuPPOrT 0203-5142281 1800-719901 www.servotool.eu WOT-280 OTM6016 Ma UK 1206-18.indd 2 6/18/12 11:25 AM... -
Page 3: Introduction
Congratulations! You have made an excellent choice with the purchase of this quality Workzone® product. By doing so you now have the assurance and peace of mind which comes from purchasing a product that has been manufactured to the highest standards of performance and safety, supported by the high quality standards of ALDI. -
Page 4: General Information And Safety Instructions
Power tools create sparks which may ignite the dust or fumes. c. Keep children and bystanders away while operating a power tool. Distractions can cause you to lose control. aFTEr SalES SuPPOrT 0203-5142281 1800-719901 www.servotool.eu WOT-280 OTM6016 Ma UK 1206-18.indd 4 6/18/12 11:25 AM... - Page 5 Do not force the power tool. Use the correct power tool for your application. The correct power tool will do the job better and more safely at the rate for which it aFTEr SalES SuPPOrT 0203-5142281 1800-719901 www.servotool.eu WOT-280 OTM6016 Ma UK 1206-18.indd 5 6/18/12 11:25 AM...
-
Page 6: Additional Safety Instructions
Extra paper extending beyond the sanding pad can also cause serious lacerations. aFTEr SalES SuPPOrT 0203-5142281 1800-719901 www.servotool.eu WOT-280 OTM6016 Ma UK 1206-18.indd 6 6/18/12 11:25 AM... -
Page 7: Electrical Safety
N or coloured black. • The wire which is coloured brown must be connected to the terminal which is marked with the letter L or coloured red. aFTEr SalES SuPPOrT 0203-5142281 1800-719901 www.servotool.eu WOT-280 OTM6016 Ma UK 1206-18.indd 7 6/18/12 11:25 AM... -
Page 8: Assembly And Parts List
1. On/Off switch 2. Speed control 3. Sanding sole 4. Diamond saw blade 5. Sandpaper 6. Scraper 7. E-cut saw blade 8. Segmented HSS saw blade aFTEr SalES SuPPOrT 0203-5142281 1800-719901 www.servotool.eu WOT-280 OTM6016 Ma UK 1206-18.indd 8 6/18/12 11:25 AM... - Page 9 Switch button 800608 Bearing 608 zz 204136 Bearing 625Z spher shaped 204137 Gearbox 24 till 28 + 18 204135 Flange + screw 30 + 31 aFTEr SalES SuPPOrT 0203-5142281 1800-719901 www.servotool.eu WOT-280 OTM6016 Ma UK 1206-18.indd 9 6/18/12 11:25 AM...
- Page 10 SalES SuPPOrT 0203-5142281 1800-719901 www.servotool.eu WOT-280 OTM6016 Ma UK 1206-18.indd 10 6/18/12 11:25 AM...
- Page 11 If the sandpaper is worn in a particular spot, you can remove it, turn it 120° and refit it or replace it. Warning! Switch the machine off and unplug the machine before mounting the accessories. aFTEr SalES SuPPOrT 0203-5142281 1800-719901 www.servotool.eu WOT-280 OTM6016 Ma UK 1206-18.indd 11 6/18/12 11:25 AM...
-
Page 12: Instructions
If the dirt does not come off use a soft cloth moistened with soapy water. Never use solvents such as petrol, alcohol, ammonia water, etc. These solvents may damage the plastic parts. aFTEr SalES SuPPOrT 0203-5142281 1800-719901 www.servotool.eu WOT-280 OTM6016 Ma UK 1206-18.indd 12 6/18/12 11:25 AM... - Page 13 The product and the user manual are subject to change. Specifications can be changed without further notice. aFTEr SalES SuPPOrT 0203-5142281 1800-719901 www.servotool.eu WOT-280 OTM6016 Ma UK 1206-18.indd 13 6/18/12 11:25 AM...
-
Page 14: Trouble Shooting
There’s dirt inside the motor or the runs irregular. carbon brushes are worn. • Replace the carbon brushes or bring the machine to a specialized repair centre. aFTEr SalES SuPPOrT 0203-5142281 1800-719901 www.servotool.eu WOT-280 OTM6016 Ma UK 1206-18.indd 14 6/18/12 11:25 AM... -
Page 15: Other Useful Information
Protect yourself against the effects of vibration by maintaining the tool and its accessories, keeping your hands warm, and organizing your work patterns aFTEr SalES SuPPOrT 0203-5142281 1800-719901 www.servotool.eu WOT-280 OTM6016 Ma UK 1206-18.indd 15 6/18/12 11:25 AM... - Page 16 1 Instruction manual 1 Quick start quide 1 After Sales support card Check the appliance, any loose parts and accessories for damage caused during transportation aFTEr SalES SuPPOrT 0203-5142281 1800-719901 www.servotool.eu WOT-280 OTM6016 Ma UK 1206-18.indd 16 6/18/12 11:25 AM...
- Page 17 SalES SuPPOrT 0203-5142281 1800-719901 www.servotool.eu WOT-280 OTM6016 Ma UK 1206-18.indd 17 6/18/12 11:25 AM...
-
Page 18: Ce Declaration
DEclARAtion oF conFoRMitY We declare under our sole responsibility that this product WOT-280, 280W Multifunction tool is in conformity and accordance with the following standards and regulations: EN60745-1, EN60745-2-4, EN55014-1, EN55014-2, EN61000-3-2, EN61000-3-3 2006/42/EC, 2006/95/EC, 2004/108/EC, 2002/95/EC, 2002/96/EC 01-05-2012... -
Page 19: Warranty Card
0203-5142281 www.servotool.eu Circuit Tech ltd. 1800-719901 Units 1/9 Stanley Mill • Kirkebrok Road • Deane, MODEL: WOT-280, 10/2012, 52892 Bolton Lancs, England • BL3 4JE Contact and internet: www.servotool.eu Fax: (+44)(0)1204-659607 YEar WarranTY OTM6016 Ma UK 1206-18.indd 19... - Page 20 1206-18 OTM6016 Ma UK 1206-18.indd 20 6/18/12 11:25 AM...
