CHAPTER 2.
LC80LE632U

OPERATION MANUAL

[1] OPERATION MANUAL

Part Names

TV (Front/Side)
POWER
button
MENU
button
INPUT
button
Channel
buttons
(CH / )
Volume
buttons
(VOL / )
TV (Rear )
AC INPUT terminal
USB 2
terminal
*1 Connecting the AC cord.
*2 External equipment connection.
*3 Details on the Audio Select function.
*1
*1
Antenna/
Cable in
DIGITAL AUDIO
OUTPUT terminal
ETHERNET
terminal
AUDIO IN terminal
(shared for PC IN
and HDMI 1) *3
Service Manual
OPC sensor *2
Remote
control sensor
*1 Button operations.
*2 OPC: Optical Picture Control
*2
2 – 1
Center Icon
illumination
RS-232C terminal
PC IN terminal
VIDEO 2
terminals
VIDEO 1
terminals
COMPONENT
terminals
AUDIO OUT terminal
USB 1 terminal
HDMI 1 terminal
ARC:Audio Return Channel
HDMI 2 terminal
HDMI 3 terminal
HDMI 4 terminal
*2
*2
