Beckett DP800 Manual page 3

DP SERIES
SUBMERSIBLE
PUMPS
HAVING TROUBLE?
NEED REPLACEMENT PARTS?
CONTACT CUSTOMER SERVICE AT
1-866-466-4319
DP800
2C
2A
1
2D
2E
KEY
1 PUMP BODY W/CORD
2 ROTOR ASSEMBLY (INCLUDES A-E)
2A MAGNET AXLE
2B IMPELLER
2C SHAFT
2D THRUST WASHERS
2E END CAPS
3 GASKET
4 VOLUTE HOUSING
5 PHILLIPS HEAD SCREWS
6 INTAKE STRAINER ASSY
7 T- FITTING
8 1" ID HOSE ADAPTOR
9 T-FITTING ADAPTOR
DP1800
1
2D
2E
DP1200
1
2E
8
3
2B
4
5
9
DESCRIPTION
2C
2A
2B
2C
2A
2B
2D
7
6
DP800 DP1200
PART # PART #
096-110095 096-050595
096-110094 096-110097
078-110272 078-110274
078-110271 078-110275
090-070154 090-070160
090-040015 090-040021
078-110157 078-110079
078-110031 078-110078
078-110005 078-110261
090-010063 090-010063
096-110009 096-110009
078-110276 078-110276
078-110273 078-110273
078-110306 NA
3
4
5
7
8
3
4
5
7
DP1800 QTY
PART # NEEDED
096-050596
096-110099
078-110278
078-110279
090-070239
090-040023 2
078-110277 2
078-110078
078-110260
090-010063 4/6
096-110009 2
078-110276
NA
NA
3 3
6
6
1
1
1
1
1
1
1
1
1
3
1
