Progear Fitness Air Elliptical Pro 1307 Owner's Manual

Hide thumbs Also See for Air Elliptical Pro 1307:
Table of Contents

Advertisement

Quick Links

Air Elliptical Pro
IMPORTANT: Read all instructions carefully before using this product. Retain this
owner's manual for future reference.
The specifications of this product may vary from this photo and, subject to change without
notice.
Item #1307
OWNER'S MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Air Elliptical Pro 1307 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Progear Fitness Air Elliptical Pro 1307

Summary of Contents for Progear Fitness Air Elliptical Pro 1307

  • Page 1 Air Elliptical Pro IMPORTANT: Read all instructions carefully before using this product. Retain this owner’s manual for future reference. The specifications of this product may vary from this photo and, subject to change without notice. Item #1307 OWNER’S MANUAL...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS SERVICE -------------------------------------------------------------------------- 2 LABEL PLACEMENT ----------------------------------------------------------- 3 PRODUCT SAFETY ------------------------------------------------------------ 4 OVERVIEW DRAWING -------------------------------------------------------- 5 PARTS LIST ----------------------------------------------------------------------- 6 HARDWARE LIST & TOOLS -------------------------------------------------- 8 ASSEMBLY ------------------------------------------------------------------------ 9 COMPUTER ----------------------------------------------------------------------- 17 ADJUSTMENTS ------------------------------------------------------------------ 19 MAINTENANCE ------------------------------------------------------------------ 21 TROUBLESHOOTING ---------------------------------------------------------- 22 WARM UP -------------------------------------------------------------------------- 24 WARRANTY ----------------------------------------------------------------------- 25...

  • Page 3: Service

    SERVICE IMPORTANT: FOR NORTH AMERICA ONLY To request product service and order replacement parts, please call our customer service department at: 1-866-924-1688 Monday through Friday, 8:00 AM-5:00 PM Pacific Standard Time, service@paradigmhw.com or email us at: Please visit our website at www.paradigmhw.com. Please have the following information ready when requesting for service: Your name Phone number...

  • Page 4: Label Placement

    LABEL PLACEMENT...

  • Page 5: Product Safety

    PRODUCT SAFETY Basic precautions should always be followed, including the following safety instructions when using this equipment. Read all instructions before using this equipment. 1. Before exercising and to avoid injuring your muscles, it is highly recommended that you perform warm-up exercise for each muscle group. Please refer to Warm Up section of the Owner’s Manual.

  • Page 6: Overview Drawing

    OVERVIEW DRAWING...

  • Page 7: Parts List

    PARTS LIST Description Qty No. Description 001 Handrail Arm End Cap Ø25 2 023 Bolt M8x43 002 Right Handrail Arm Ø25x2 1 024 Washer Ø8.2xØ16x1.5 Handrail Arm Foam Grip 2 025 Nylon Nut M8 Ø23xØ30x310 Handrail Arm Plastic Bushing 2 026 Right Crank 7" Ø32x1.5 005 Bolt 3/8"x20 2 027 Spring Washer 1/2"...
  • Page 8 PARTS LIST Description Qty No. Description 046 Tension Bracket 2 072 Bearing Nut I 7/8" 047 Spring Washer Ø6 2 073 Washer 7/8" 048 Nut M6 2 074 Nut 7/8" 049 Fan Wheel Ø510x56.5 1 075 Left Crank 7" 050 Fan Wheel Axle M10x154 1 076 Left Foot Bar 051 Spacer Ø14xØ10.2x19 1 077 Left Handrail...

  • Page 9: Hardware List & Tools

    HARDWARE LIST & TOOLS...

  • Page 10: Assembly

    ASSEMBLY Tool: Open-Ended Flat Wrench 1. Front/Rear Stabilizers and Adjustable Levelers Installation: Step A: Align the Front Stabilizer (54) onto the front curve of the Mainframe (59). Make sure the arrow is pointing UP on the front stabilizer and that the Transport Wheels (93) position toward the front and parallel off the floor.
  • Page 11 ASSEMBLY Tools: #6 Allen Wrench #6 Allen Wrench with Phillips Screwdriver Open-Ended Flat Wrench 2. Handrails, Foot Bars and Rotation Rod Installation: Step D: Using two flat wrenches, remove M10 Bolt (11), Washer (13) and M10 Nylon Nut (14) PRE-ASSEMBLED to the end of the Right Foot Bar (17R). Attach the Right Foot Bar (17R) onto the bottom end of the Right Handrail (9) with the above hardware that were removed.
  • Page 12 ASSEMBLY Tool: Important: Installing right bolt into right #8 Allen Wrench crank can only be done by Important: turning right (clockwise). Installing left bolt into left crank can only be done by turning left (counterclockwise). R for right bolt L for left bolt 3.
  • Page 13 ASSEMBLY Hardware: (21) Right Bolt for Right Crank Ø16x119 1 PC (22) Wave Washer Ø16.2xØ26xδ0.3 2 PCS (27) 1/2" Spring Washer 2 PCS (28) 1/2” Nylon Nut for Right Crank 1 PC (64) Left Bolt for Left Crank Ø16x119 1 PC (87) 1/2”...
  • Page 14 ASSEMBLY Tool: #6 Allen Wrench with Phillips Screwdriver 4. Hand Pulse Handlebar Support Frame, Tension Control Knob, Bottle Holder, and Hand Pulse Handlebar Installation: Step L: Attach the Hand Pulse Handlebar Support Frame (41) onto the Mainframe (59) with four Bolts (36). Using the #6 Allen Wrench with Phillips Screwdriver, tighten the bolts until firm.
  • Page 15 ASSEMBLY Step P: Install the Tension Control Knob (37) by inserting the tab into a square hole on the Hand Pulse Handlebar Support Frame (41) and push down on the knob slightly in order to align the opening with the bolt hole. Using the screwdriver, tighten one M5 Bolt (38) until firm.
  • Page 16 ASSEMBLY Tools: Open-Ended Flat Wrench #6 Allen Wrench 5. Right and Left Foot Pedals Installation: Step S: Attach two Foot Pedal Support Brackets (18) onto both the Right/Left Foot Bars (17, 76) with four M8 Bolts (23) and the other ends with four Washers (24) and four M8 Nylon Nuts (25).
  • Page 17 ASSEMBLY Tool: #6 Allen Wrench 6. Right/Left Handrail Arms and Computer Installation: Step V: Insert the Right Handrail Arm (2) onto the Right Handrail (9) and secure with two M8 Bolts (36) and two Spring Washers (80). Using a #6 Allen wrench, tighten the bolts until firm.

  • Page 18: Computer

    COMPUTER SPECIFICATIONS: TIME ---------------------------------------------------- 00:00-99:59 MIN: SEC SPEED ------------------------------------------------- 0.0-99.9 MPH DISTANCE -------------------------------------------- 0.00-99.99 MILE CALORIES -------------------------------------------- 0-9999 CAL PULSE ------------------------------------------------- 40-240 BPM USING YOUR COMPUTER The computer can be activated by pressing the MODE button or by pedaling. If you leave the equipment idle for 4 minutes, the power will turn off automatically.
  • Page 19 COMPUTER HOW TO INSTALL THE BATTERIES: Remove the battery cover on the back of the computer. Place two "SIZE-AA" batteries into the battery housing. Insure the batteries are correctly positioned and the battery springs are in proper contact with the batteries. Re-install the battery cover.

  • Page 20: Adjustments

    ADJUSTMENTS Adjusting the Tension Control Knob To increase the tension, turn the tension control knob in a clockwise direction. To decrease the tension, turn the tension control knob in a counterclockwise direction. Tension Control Knob After prolong use of the elliptical trainer, the strap will begin to stretch out and it will become necessary to tighten the strap for optimum performance.
  • Page 21 ADJUSTMENTS Adjusting the Rear Stabilizer End Cap or Adjustable Leveler Turn the rear stabilizer end cap on the rear stabilizer or adjustable leveler on the Adjustable Leveler mainframe as needed to level the elliptical trainer. Rear Stabilizer End Cap...

  • Page 22: Maintenance

    MAINTENANCE Regular maintenance of your elliptical is necessary to extend the life of your machine and allow it to continue to function properly. Please keep the elliptical, especially the computer console, out of direct sunlight to prevent screen damage or premature wear. Cleaning Keep the machine clean and free of any debris by vacuuming around the moving parts and wiping the machine down with a clean cotton cloth.

  • Page 23: Troubleshooting

    TROUBLESHOOTING PROBLEM SOLUTION 1. Check that the batteries are inserted properly with the correct polarity (see marking inside the battery compartment). The computer will not power up. 2. Check that the battery springs are in proper contact with batteries. 3. Remove the old batteries and replace with the new batteries.
  • Page 24 TROUBLESHOOTING PROBLEM SOLUTION Make sure both the Adjustable Levelers (57) The elliptical is not sturdy enough. are touching the ground. Make sure the elliptical is leveled. Please refer to page 20. Undo the buckle of the plastic clip and then pull the top strap on the front of the unit away Tension adjustment doesn't work.

  • Page 25: Warm Up

    WARM UP Quadriceps Stretch With one hand against a wall for balance, reach behind you and pull your right foot up. Bring your heel as close to your buttocks as possible. Hold for 15 counts and repeat with left foot up. Inner Thigh Stretch Sit with the soles of your feet together with your knees pointing outward.

  • Page 26: Warranty

    WARRANTY MANUFACTURER’S LIMITED WARRANTY Paradigm Health & Wellness warrants to the original purchaser that this product is free from defects in material and workmanship when used for the purpose intended, under the conditions that it has be installed and operated in accordance with Paradigm’s Owner’s Manual. Paradigm’s obligation under this warranty applies to the following: COMPONENT LENGTH OF WARRANTY...

  • Page 27: Fax Form

    FAX FORM Paradigm Health & Wellness, Inc. PARTS REQUEST FAX FORM Please fax this form to (1-626-810-2166) OR YOU CAN EMAIL CUSTOMER SERVICE REQUESTS TO service@paradigmhw.com NAME: _______________________________________________________ ADDRESS: ____________________________________________________ CITY ______________ STATE ______________ ZIP ___________________ TELEPHONE: (Day) _____________________________________________ (Night) ____________________________________________ (Email Address) ____________________________________ SERIAL#: __________________________________________ ITEM/MODEL#: _____________________________________...
