command. The cascade ports must be operationally up (no shutdown command) and have a
default port configuration with no L2 and L3 configuration. The port interfaces must be the same
type. You can configure up to eight C9010 ports in the auto-LAG. The generated auto-LAG number
is from 257 to 513.
PORT-EXTENDER CONFIGURATION mode
Dell(conf-pe-0)# cascade interface interface-type slot/port-range
• interface interface-type specifies a C9010 10-Gigabit Ethernet interface. The only
supported value is TenGigabitEthernet slot/port-range.
• slot/port-range specifies a C9010 10GbE port, including slot number and either a single port
number, a port range, or a combination of both for auto-LAG configuration.
– The range of slot numbers is from 0 to 11. In line-card slots 0 to 9, the range of port numbers
is from 0 to 23; in RPM slots 10 and 11, the range of port numbers is from 0 to 3.
– Enter a port range with or without spaces; for example, cascade interface
tengigabitethernet 0/1-5 or cascade interface tengigabitethernet 0/1 - 5.
– You can enter up to six comma-separated ranges or port numbers; for example, cascade
interface tengigabitethernet 0/1-2,8,10–12,15.
5. Verify the provisioned configuration on a C1048P.
EXEC Privilege mode
Dell# show pe brief
Dell# show pe pe-id
Dell# show interface port-channel brief
Example of Provisioning a Port Extender
Dell(conf)# feature extended-bridge
Dell(conf)# pe provision 2
Dell(conf-pe-2)# stack-unit 0 type c1048p
Dell(conf-pe-2)# cascade interface tengigabitethernet 0/1–2
Dell(conf-pe-2)# exit
Dell(conf)# interface range tengigabitethernet 0/1-2
Dell(conf-if-te-0/1–2)# no shutdown
Dell(conf-if)# end
Dell# show pe brief
-- Port Extenders Information
----------------------------------------------------------
PE-id Status
----------------------------------------------------------
2 online
NOTE: If the status of a port extender is error, communication with an attached C9010 was
unsuccessful, possibly due to a mismatch in software version (SVM) or another communication
error. Wait five minutes for an auto-upgrade of the port extender to complete. If the status does not
change to online, contact
Dell# show pe 2
Codes: A - Active, I - Inactive
Reason: CTM - Card Type Mismatch, CAM - CAM ACL Mismatch
SVM - Software Version Mismatch, UE - Unknown Error
PE-ID assigned: 2
20
Stack-size Type
1 C1048P
Dell Networking Support
--
System-MAC
34:17:eb:00:bb:11
for assistance.
Configuring the Software
