Technical Specifications - Dell C1048P Getting Started Manual

Technical Specifications

The following tables describe the technical specifications for the C1048P port extender.
Table 3. Chassis Physical Design
Parameter
Height
Width
Depth
Chassis weight
Table 4. Environmental Parameters
Parameter
Operating temperature
Maximum operating humidity
Storage temperature
Storage relative humidity
Table 5. AC Power Requirements
Parameter
Nominal input voltage
Maximum AC power supply input
current (based on 1200W output
for 100/120V lines and 1600W
output for 200/240V lines)
Maximum steady state current
consumption for main PSU with an
MPS1000 external power supply
bank
Maximum power consumption for
main PSU with an MPS1000
external power supply bank
Technical Specifications
Specifications
1.7 inches (4.35 cm)
17.32 inches (44 cm)
15.23 inches (38.7 cm)
15 lbs (6.8 kg) with factory installed components
44.31 lbs (20.1 kg) fully loaded
Specifications
32°F to 113°F (0°C to 45°C)
95% (non-condensing)
–40°F to 149°F (–40°C to 65°C)
85% (non-condensing)
Specifications
100-240 VAC 50/60 Hz
8.9 A @ 100V per AC power supply
7.9 A @ 120V per AC power supply
3.85 A @ 200V per AC power supply
3.55 A @ 240V per AC power supply
110V circuit: ~15.8A
220V circuit: ~7.7A
1,738W @ 110V
1,694W @ 220V
