SPLIT-TYPE AIR CONDITIONERS
OUTDOOR UNIT
SERVICE MANUAL
Models
MUZ-GE25VA -
MUZ-GE35VA -
MUZ-GE42VA -
MUZ-GE50VA -
MUZ-GE25/35/42VA
NOTE:
RoHS compliant products have <G> mark on the spec name plate.
E1
E1
E1
E1
E1
E1
E1
E1
CONTENTS
1. TECHNICAL CHANGES ··································· 3
2. PART NAMES AND FUNCTIONS ····················· 4
3. SPECIFICATION ················································ 5
4. NOISE CRITERIA CURVES ······························ 7
5. OUTLINES AND DIMENSIONS ························ 8
6. WIRING DIAGRAM ············································ 9
7. REFRIGERANT SYSTEM DIAGRAM ············· 15
8. PERFORMANCE CURVES ····························· 17
9. ACTUATOR CONTROL ··································· 31
10. SERVICE FUNCTIONS ···································· 32
11. TROUBLESHOOTING ····································· 32
12. DISASSEMBLY INSTRUCTIONS ···················· 50
PARTS CATALOG (OBB516)
