Air Conditioning Technical Data Wall mounted unit EEDEN13-004A FTXN-L9... -
Page 3: Table Of Contents
• Indoor Unit • Wall mounted unit • FTXN-L9 TABLE OF CONTENTS FTXN-L9 Features ............. 2 Specifications . -
Page 4: Features
• Indoor Unit • Wall mounted unit • FTXN-L9 Features U n i o o r N - L I n d F T X • Indoor unit silent operation: "silent" button on the remote control • Vertical auto swing moves the discharge flaps up and down for lowers the operation sound of the indoor unit by 3dBA efficient air and temperature distribution throughout the room •... -
Page 5: Specifications
• Indoor Unit • Wall mounted unit • FTXN-L9 Specifications 2-1 Technical Specifications FTXN25L9 FTXN35L9 FTXN50L9 FTXN60L9 Power input Cooling Nom. 0.740 1.025 1.535 1.920 Heating Nom. 0.700 0.930 1.500 1.710 Casing Colour White Material High impact polystyrene Dimensions Unit... -
Page 6: Electrical Specifications
• Indoor Unit • Wall mounted unit • FTXN-L9 Specifications 2-1 Technical Specifications FTXN25L9 FTXN35L9 FTXN50L9 FTXN60L9 Fan motor Quantity Model MWM10/15J-501 MWMY20/25JR Index of Protection Insulation grade Class "E" Poles Drive Direct drive Speed Steps 3 steps, turbo, quiet, auto... -
Page 7: Dimensional Drawings
• Indoor Unit • Wall mounted unit • FTXN-L9 Dimensional drawings 3 - 1 Dimensional Drawings • Split - Sky Air • Indoor Unit... -
Page 8: Piping Diagrams
• Indoor Unit • Wall mounted unit • FTXN-L9 Piping diagrams 4 - 1 Piping Diagrams • Split - Sky Air • Indoor Unit... -
Page 9: Wiring Diagrams
• Indoor Unit • Wall mounted unit • FTXN-L9 Wiring diagrams 5 - 1 Wiring Diagrams - Single Phase • Split - Sky Air • Indoor Unit... - Page 10 • Indoor Unit • Wall mounted unit • FTXN-L9 Wiring diagrams 5 - 1 Wiring Diagrams - Single Phase • Split - Sky Air • Indoor Unit...
-
Page 11: Sound Data
• Indoor Unit • Wall mounted unit • FTXN-L9 Sound data 6 - 1 Sound Level Data • Split - Sky Air • Indoor Unit... - Page 12 • Indoor Unit • Wall mounted unit • FTXN-L9 Sound data 6 - 1 Sound Level Data • Split - Sky Air • Indoor Unit...
- Page 13 • Indoor Unit • Wall mounted unit • FTXN-L9 Sound data 6 - 1 Sound Level Data • Split - Sky Air • Indoor Unit...
- Page 15 All content is copy- righted by Daikin Europe N.V. Naamloze Vennootschap - Zandvoordestraat 300, B-8400 Oostende - Belgium - www.daikin.eu - BE 0412 120 336 - RPR Oostende...
