WALK THE CUSTOMER THROUGH EACH OF
THE FOLLOWING KEY DELIVERY FEATURES
☐ DEFROST - page 14-17
Press the front defrost button.
1
Set to warmest temperature setting.
2
Set to highest fan speed.
3
3
BLUETOOTH – page
22
- Demonstrate phone pairing
Refer to
www.hyundaiusa.com/bluetooth
- Demonstrate QR code
☐ BLUE LINK – pages 23-24
- Assist with creating MyHyundai.com account
- Assist with Blue Link enrollment
Show Blue Link Users Manual & tear out Voice
Commands/Quick Tip Card
- Encourage customers to press the Blue link button
after enrollment to initiate Welcome Call
CLOCK – pages 32
- Demonstrate how to set clock (including daylight
savings setting for Navigation equipped vehicles)
NAVIGATION (if applicable) – page 26
- Demonstrate navigation system POI, enter dealer address
TIRE PRESSURE MONITORING SYSTEM
(TPMS) – page 31
- Explain TPMS function of customer
- When illuminated, one or more tires are
under-inflated
- Blinks for approximately one minute then remains illuminated
when there is a malfunction with the TPMS
VEHICLE SETTINGS – pages 12-13 and 26-27
- Demonstrate vehicle settings in instrument cluster
- Demonstrate navigation use, enter dealer address
- Show radio presets
MAINTENANCE
Scheduled Maintenance
Engine Oil And Filter
2
Fuel Additives *1
1
Tire Rotation
Air Cleaner Filter
Battery Condition
Vacuum Hose
Climate Control Air Filter
(For Evaporator And Blower Unit)
Air Conditioning Refrigerant
Brake Hoses & Lines
Drive Shafts & Boots
Electronic Throttle Control
Exhaust Pipe & Muffler
Front Disc Brake/Pads, Calipers
Rear Brake Drums/Linings
Rear Brake Disc/Pads
Steering Gear Box, Linkage & Boots/
Lower Arm Ball Joint, Upper Arm Ball Joint
Suspension Mounting Bolts
Brake/Clutch Fluid
Fuel Filter
Fuel Lines, Fuel Hoses And Connections
Fuel Tank Air Filter
Parking Brake
Vapor Hose, Fuel Tank & Fuel Filler Cap
Valve Clearance
Manual Transmission Fluid
EcoShift Dual Clutch Transmission Fluid
Drive Belt (Alt, A/C)
Spark Plugs (Iridium Coated)
Coolant
*1 If TOP TIER Detergent Gasoline is not available, one bottle of additive is recommended. Additives are available from your
authorized Hyundai dealer along with information on how to use them. Do not mix other additives.
*See Owner's Manual for details.
Looking for more detailed information?
This Quick Reference Guide does not replace your vehicle's Owner's Manual, If you require
additional information or are unsure of a specific issue, you should always refer to the vehicle's Owner's Manual or contact your
authorized Hyundai dealer.
The information contained in this Quick Reference Guide was correct at the time of printing, however, specifications and equipment
can change without notice. No warranty or guarantee is being extended in this Quick Reference Guide, and Hyundai reserves the
right to change product specifications and equipment at any time without incurring obligations. Some vehicles are shown with
optional equipment. Specifications apply to U.S. vehicles only. Please contact your Hyundai dealer for current vehicle specifications.
VELOSTER TURBO
Normal Usage
Severe Usage*
1st Replace
3,000 or 6 mos.
Replace
3,000 or 3 mos.
Add'l Replace
5,000 or 6 mos.
1st Add
3,000 or 6 mos.
Add Same as Normal
Add'l Add
5,000 or 6 mos.
Perform
7,500
Perform
7,500
Inspect
7,500
Inspect
Same As Normal
Replace
30,000
Replace
More Frequently
Inspect
7,500
Inspect
Same As Normal
Inspect
7,500
Inspect
Same As Normal
Replace
15,000
Replace
More Frequently
Inspect
15,000
Inspect
Same As Normal
Inspect
15,000
Inspect
Same As Normal
Inspect
15,000
Inspect
7,500 or 6 mos.
Inspect
15,000
Inspect
Same As Normal
Inspect
15,000
Inspect
Same As Normal
Inspect
15,000
Inspect
More Frequently
Inspect
15,000
Inspect
More Frequently
Inspect
15,000
Inspect
More Frequently
Inspect
15,000
Inspect
Same As Normal
Inspect
30,000
Inspect
Same As Normal
Inspect
30,000
Inspect
Same As Normal
Inspect
30,000
Inspect
Same As Normal
Inspect
30,000
Inspect
Same As Normal
Inspect
30,000
Inspect
More Frequently
Inspect
30,000
Inspect
Same As Normal
Inspect
60,000
Inspect
Same As Normal
Inspect
37,500
Replace
75,000
Inspect
37,500
Replace
75,000
1st Inspect 60,000 or 72 mos.
Inspect
Same As Normal
Add. Inspect 15,000 or 24 mos.
Replace
105,000
Replace
More Frequently
1st Replace 120,000 or 10 yrs.
Replace
Same As Normal
Add Replace 30,000 or 24 mos.
NP150-V2014-A
(Rev 11/18/13)
2
Printing 11/21/13
VELOSTER TURBO
HYUNDAI
Quick Reference Guide
www.hyundai.com
Roadside Assistance:
Consumer Affairs:
XM
®
Blue Link:
1-800-243-7766
1-800-633-5151
1-800-967-2346
Radio:
1-855-2BLUELINK
(1-855-225-8354)
