Spark 58N Owner's Operation And Installation Manual

Unvented (vent-free) gas fireplace with electronic ignition system

Advertisement

Quick Links

SPARK MODERN FIRES
UNVENTED (VENT-FREE) GAS FIREPLACE
WITH ELECTRONIC IGNITION SYSTEM
OWNER'S OPERATION AND INSTALLATION MANUAL
WARNING: If the information in this manual
is not followed exactly, a fire or explosion
may result causing property damage,
personal injury, or loss of life.
— Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
— WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do
not use any phone in your building.
• Immediately call your gas supplier
from a neighbor's phone. Follow the
gas supplier's instructions.
• If you cannot reach your gas supplier,
call the fire department.
— Installation and service must be
performed by a qualified installer,
service agency, or the gas supplier.
This is an unvented gas-fired heater. It uses
air (oxygen) from the room in which it is
installed. Provisions for adequate combus-
tion and ventilating air must be provided.
Refer to page 4, Air for Combustion and
Ventilation.
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
Version française de ce manuel est disponible à partir du site WEB : www.sparkfires.com
MODELS: 5 8 (N,P)
WARNING: Improper installation, adjust-
ment, alteration, service, or maintenance
can cause injury or property damage. Refer
to this manual for correct installation and
operational procedures. For assistance or
additional information consult a qualified in-
staller, service agency, or the gas supplier.
T
This appliance may be installed in an
aftermarket,* permanently located, manu-
factured (mobile) home, where not prohib-
ited by local codes.
This appliance is only for use with the type
of gas indicated on the rating plate. This
appliance is not convertible for use with
other gases.
* Aftermarket: Completion of sale, not for purpose of resale, from
the manufacturer
Report # 321-F-10-5
