T
ECHNICAL INFORMATION
Models No.
Description
C
ONCEPTION AND MAIN APPLICATIONS
The above model has been developed as a 9.5mm (3/8") square drive version
of Mod.BTD060, for fastening work in automobile assembling line.
S
pecification
No load speed : (min
Blows per min : (min
Drive shank : mm=( " )
Max. fastening torque
Standard bolt
Capacity
High tensile bolt
Electric brake
Reverse switch
Net weight inc. battery B9107A
O
ptional accessories
* DC14SA Charger
* Protector
* Battery 9017A
BTW070
9.6V Cordless Impact Wrench
= rpm)
-1
= bpm).
-1
Dimensions : mm ( " )
Width ( W )
66 (2-5/8)
Height ( H )
236 (9-5/16)
Length ( L )
162 (6-3/8)
0 - 2,500
0 - 3,000
Hex 9.5 (3/8)
65 Nm
(663kgf.cm, 575 in.lbs)
M5 - M12 (3/16 - 1/2)
M5 - M10 (3/16 - 3/8)
Yes
Yes
1.07Kg (2.4lbs)
NEW TOOL
P 1 / 6
L
H
W
