GE Profile Arctica PSW26SGN Dimension Manual

TM
PSW26SGN – GE Profile Arctica

Dimensions (in inches)

A B
Front View
Note: If the doors cannot be fully opened because of an obstruction or a wall on either side, a door stop should
be provided to prevent door or wall damage. If the doors cannot be opened at least 90 degrees, access to the
drawers is limited.
Specification Created 4/02
25.5 Cu. Ft. Side-By-Side Refrigerator with Dispenser
™
H
G
C
D
Top View
Height to top of hinge (in.) A
Height to top of case (in.) B
Case depth without doors (in.) C
Case depth less door handle (in.) D
Case depth with door handle (in.) E
Depth with fresh food door open 90° (in.) F
E
Width (in.) G
F
Width with doors open 90° less door handle (in.) H
Each side (in.)
Top (in.)
Back (in.)
*Width including top caps is 36-3/16.
Note: Add 9/16" for water hook-up. Hook-up fits in 5/8" back air clearance
when calculating installation depth.
If installed against a wall, allow clearance of 14-3/16" .
To remove fresh food pans, remove door bins.
Clearance required to remove fresh food full-size pan without disassembling
is 18-15/16" .
Allow additional space for any necessary leveling adjustments.
For answers to your Monogram,
GE appliance questions, visit our website at
GEAppliances.com or call
GE Answer Center ® service, 800.626.2000.
69-1/4
70-1/2
28-1/2
32-3/4
35-3/16
50-9/16
35-7/8*
36-3/16
1/8
1
1
® GE Profile ™ or
