- GENERAL SPECIFICATIONS -

Freq Response: 100hz to 10Khz.
Upper Frequency limit is
Intentionally limited by a
Low Pass Filter.
Sampling Size/Rate: 16 Bit, All standard rates are
supported up to 48Khz.
Computer OS: Windows 98SE/ME/2000/XP
Windows Vista / Windows 7
MAC OS 9.1 or later
MAC OS X 10.00 or later
Radio In/Out Z: 600 Ohm (nom). TX/RX Levels
are fully adjustable for
compatibility with Hi-Z and
Low-Z radio connections.
Auto-PTT Delay: Adjustable "Hang Time"
30 ms to >3 seconds
PTT Circuit: Relay, 90V 3AMP (max)
Radio Connector: TX/RX Audio,PTT,GND - RJ-45
RX Audio/Spkr - 3.5mm Mono
Computer Connector: USB 1.1/2.0 Compatible
Standard USB "A" type Conn.
Other Connectors: Aux. Speaker - 3.5mm Mono
Case: Extruded Aluminum - 6061T4
Dimensions: 1.6" x 3.2" x 3.6"
Operating Temp: -30C to +60C
