Tigertronics SignaLink Installation & Operation Manual

Grants Pass, Oregon
- INTRODUCTION -
The Tigertronics SignaLink opens up a whole new world of
digital communication possibilities. Now you can operate all
of today's most popular modes without having to purchase
an expensive multimode controller. The SignaLink bridges
the gap between your computer's sound card and your radio
to provide instant compatibility with a multitude of
sophisticated communications programs.
available for every imaginable mode including PSK-31,
MT63, RTTY, SSTV, APRS, and Packet. More than 80
programs are available through our web site alone and many
more can be found by searching the Internet software
archives.
The SignaLink is designed and manufactured using only the
highest quality components. Assembly is done using "state
of the art" robotic production equipment. Strict testing of
every unit and our high level of quality control insures you of
a premium quality product that will provide many years of
dependable service. A great deal of effort has gone into the
design and manufacture of the SignaLink and we are very
proud to make it available
- INSTALLATION OVERVIEW -
The SignaLink is very easy to install and operate. However,
if it is not installed and operated correctly, you will not
realize its best performance and in extreme cases you can
damage your other equipment. Therefore, it is extremely
important that you take the time to read these installation
instructions carefully to avoid any possible problems.
SignaLink
154 Hillview Drive Grants Pass, Oregon 97527
(541) 474-6700 Fax: (541) 474-6703 Internet: http://www.tigertronics.com
Installation & Operation
after completing the installation you have any difficulty,
please refer to the "Troubleshooting" section near the end of
this manual. It covers most of the common problems that
you might run into. Technical Support for the SignaLink is
also available if you need it. Please see the "Technical
Support" section of this manual for more information.
If you purchased the optional SignaLink Accessory Kit, then
you should have everything that you need to complete the
installation and start operating. If not, then you will need to
purchase the following items from your local electronics
supply store:
Programs are
To verify your radio wiring you will need a multimeter. A
3/32" Allen Wrench will be needed to remove the
SignaLink's cover and needle-nosed pliers would be very
helpful to install the programming jumpers. You will need
some software for testing when the installation is complete.
Sample software selections for popular modes (PSK-31,
RTTY, CW, etc.) are supplied on the optional Accessory Kit
CDROM. If you did not purchase the accessory kit, then you
will want to select some software from our web site and
download it for installation and testing.
CAUTION – Before applying power to the SignaLink read
this entire section thoroughly. Both the SignaLink and your
radio can be damaged by improper installation.
The SignaLink requires a power source of 6.75 to 15 volts
DC at 10 milliamps. This is low enough that it can usually
If
™
Sound Card - Radio Interface
- WHAT YOU WILL NEED -
You will need two Shielded audio cables with a
•
3.5mm stereo plug installed on each end. These
cables must be long enough to attach the SignaLink
to your sound card's Mic and Speaker jacks.
If your radio does not provide speaker audio on the
•
microphone connector (see your radio manual), then
you will also need one shielded audio cable with
3.5mm mono plug installed on each end. This cable
is to connect your radio's External Speaker or
Headphone Jack to the SignaLink so it can be
relatively short. A length of two feet is about right.
- CONNECTING POWER -
