UNVENTED (VENT-FREE) UNIVERSAL FIREBOX
SAFETY INFORMATION AND INSTALLATION MANUAL
shown with optional cabinet
mantel with base.
HDFB32CA
CIRCULATINg LOUVERED MODEL
WARNING: If the information in this manual is not fol-
lowed exactly, a fire or explosion may result causing
property damage, personal injury or loss of life.
FoR use oNly WIth A lIsted GAs-FIRed uNveNted
decoRAtIve Room heAteR Not to exceed 40,000
Btu/Hr. Do not BuilD a wooD fire.
Carefully review the instructions supplied with the
decorative type unvented room heater for the minimum
fireplace size requirement.
do Not INstAll AN ApplIANce IN thIs FIRebox
uNless thIs FIRebox meets the mINImum dImeN-
sions requireD for tHe installation.
this firebox has been tested and approved by Csa
under ansi Z21.91 for use with any ansi Z21.11.2 ap-
proved gas logs.
installer: leave this manual with the appliance.
ConsuMer: retain this manual for future reference.
For more information, visit www.desatech.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Desa HDFB32CA
Summary of Contents for Desa HDFB32CA
- Page 1 UNVENTED (VENT-FREE) UNIVERSAL FIREBOX SAFETY INFORMATION AND INSTALLATION MANUAL shown with optional cabinet mantel with base. HDFB32CA CIRCULATINg LOUVERED MODEL WARNING: If the information in this manual is not fol- lowed exactly, a fire or explosion may result causing property damage, personal injury or loss of life.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Safety Information .......... Installation ............7 Local Codes............3 Technical Service..........1 Unpacking............3 Replacement Parts ..........1 Product Features ..........3 Accessories ............13 Product Specifications ......... 4 Illustrated Parts Breakdown and Parts List..14 Locating Firebox .......... -
Page 3: Safety Information
SAFETY INFORMATION *Available from: American National Standards Institute, Inc. Continued 1430 Broadway New York, NY 10018 Keep the firebox area clear and National Fire Protection Association, Inc. free from combustible materials, Batterymarch Park gasoline and other flammable Quincy, MA 069 vapors and liquids. -
Page 4: Product Specifications
pRODUCT LOCATINg FIREBOX SpECIFICATIONS Plan where you will install the firebox. This will save time and money later when you install " the firebox. Before installation, consider the following: " 1. Where the firebox will be located. Allow for " wall and ceiling clearances (see Installa- tion Clearances, page 7). - Page 5 AIR FOR COMBUSTION deteRmINING FResh-AIR FloW FoR heAteR locAtIoN AND VENTILATION Continued Determining if You Have a Confined or unconfined space 1. Unusually Tight Construction Use this work sheet to determine if you have 2. Unconfined Space a confined or unconfined space. 3.
-
Page 6: Local Codes
AIR FOR COMBUSTION 12" AND VENTILATION Ventilation Continued Ventilation Grills Grills Into Adjoining Room, Into Adjoining The space in the previous example is a confined Option 2 Room, Remove Option 1 space because the actual Btu/Hr used is more Door into Adjoining than the maximum Btu/Hr the space can sup- Room,... -
Page 7: Installation
INSTALLATION INstAllAtIoN cleARANces NotIce: this heater is intended WARNING: maintain the for use as supplemental heat. minimum clearances. if you can, use this heater along with your provide greater clearances from primary heating system. Do not floor, ceiling and adjoining wall. install this heater as your pri- Carefully follow the instructions below. -
Page 8: Electrical Hookup
INSTALLATION Continued If your installation does not meet the mini- Electrical mum clearances in Figure 7, you must: Outlet Blower • raise the mantel to an acceptable height, • remove the mantel. Note: A ll vertical measurements are from top of fireplace Mantel Shelf opening to bottom of mantel 10"... - Page 9 INSTALLATION cAutIoN: Never touch the Continued blower wheel while in operation. WARNING: If there is a du- 5. Turn on power to duplex outlet if previ- plex electrical outlet installed in ously turned off per the warning in step 1, page 8. the right side of the bottom of 6.
- Page 10 INSTALLATION Side Brass Top Brass Trim Trim Continued Adjusting Slot Screws Plate 1. Remove 2 screws holding firebox bottom in place. 2. Lift and remove firebox bottom (see Figure 9, page 8). 3. Route flexible gas line from equipment Shim Slot shutoff valve into firebox through side.
- Page 11 INSTALLATION buIlt-IN FIRebox INstAllAtIoN Continued Built-in installation of this firebox involves installing firebox into a framed-in enclosure. Hood This makes the front of firebox flush with wall. Optional perimeter trim is available (see Ac- Hood cessories, page 13) This perimeter trim will Mounting extend past sides of firebox approximately Slot...
-
Page 12: Technical Service
You can also visit DESA Hearth Prod- IMPORTANT: When finishing your firebox, u c t s ’ Te c h n i c a l S e r v i c e w e b s i t e a t combustible materials such as wall board, www.desatech.com. -
Page 13: Accessories
Contact authorized dealers of this product w32aos - 3" Light Oak Finish, Traditional or Parts Central (see page 15). If they can’t Design supply original replacement part(s), call DESA CMa311w - 3" Painted White, Traditional Hearth Products at 1-866-67-6040 for refer- Design with Dentil Molding ral information. -
Page 14: Illustrated Parts Breakdown And Parts List
ILLUSTRATED pARTS BREAkDOwN HDfB32Ca www.desatech.com 116533-01D... -
Page 15: Parts Centrals
LIST HDfB32Ca This list contains replaceable parts used in your firebox. When ordering parts, follow the instructions listed under Replacement Parts on page 1 of this manual. Part no. descRIptIoN qtY. 10187-03 Firebox Top 101889-01 Firebrick Retainer 117538-0 Firebrick Kit... -
Page 16: Warranty Information
LIMITED wARRANTY VENT-FREE FIREBOX DESA Heating, LLC warrants this product to be free from defects in materials and components for two (2) years from the date of first purchase, provided that the product has been properly installed, operated and maintained in accordance with all applicable instructions. To make a claim under this warranty the Bill of Sale or cancelled check must be presented.
