Residential and OutdOOR WOOd buRning FiReplace
OWneR's OpeRatiOn and installatiOn Manual
ICC-ES #ESR-2542
MOdels (V)s36 seRies
SAVE THIS BOOK
This book is valuable. In addition to instructing you
on how to install and maintain your appliance, it also
contains information that will enable you to obtain re-
placement parts or accessory items when needed. Keep
it with your other important papers.
This fireplace is approved for use as a wood burning
fireplace or for use with a vented gas log approved to
ANS Z21.60, Z21.84 or RGA 2-72 standards or for use
with a vent-free gas log heater approved to ANS Z21.11.2
standard. A DESA hood must be installed when using a
vent-free log heater (see Accessories, page 16).
This wood burning fireplace complies with UL127-
CAN/ULS-S610-M87 standard as a FACTORY BUILT
APPLIANCE.
FOR CANADA: The authority having jurisdiction (such
as the municipal building department, fire department,
etc.) should be contacted before installation to deter-
mine the need to obtain a permit.
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
For more information, visit www.desatech.com
Advertisement
Table of Contents
Related Manuals for Desa S36 Series
Summary of Contents for Desa S36 Series
- Page 1 Residential and OutdOOR WOOd buRning FiReplace OWneR’s OpeRatiOn and installatiOn Manual ICC-ES #ESR-2542 MOdels (V)s36 seRies SAVE THIS BOOK This book is valuable. In addition to instructing you on how to install and maintain your appliance, it also contains information that will enable you to obtain re- placement parts or accessory items when needed.
-
Page 2: Table Of Contents
Before beginning installation of this fireplace, • Do not place clothing or other read these instructions through completely. flammable materials on or near • This DESA Heating, LLC fireplace and its components are safe when installed ac- the appliance. cording to this installation manual. Unless •... -
Page 3: Specifications
speciFicatiOns ELECTRICAL 1" AIRSPACE OUTLET TO COMBUSTIBLE RIGHT SIDE GAS LINE 0" TO MATERIAL KNOCK OUTS TOP SPACERS NO COMBUSTIBLE MATERIAL ON FACE 8.125" 2.5" 7.092" 8.717" 11.217" AIR KIT KNOCK OUT LEFT SIDE GAS LINE COMBUSTIBLE KNOCK OUTS WALL BOARD 3/4"... -
Page 4: Fireplace Installation
FiReplace installatiOn FRAMING 1. Frame opening for fireplace using the SELECTING LOCATION dimensions shown in Figures 1 and 2. To determine the safest and most efficient 2. If fireplace is to be installed directly on location for the fireplace, you must take into carpeting, tile (other than ceramic) or any consideration the following guidelines: combustible material other than wood... - Page 5 FiReplace installatiOn WARNING: Hearth extension Continued is to be installed only as shown DRAIN PAN (DP36) in Figure 3. For outdoor installations, the fireplace enclo- sure must allow for adequate drainage and MANTELS fresh air ventilation. It is recommended that A mantel may be installed if desired (see a sealed, corrosion resistant catch pan with Figure 4).
-
Page 6: Venting Installation
Venting installatiOn WARNING: The opening in OPTIONAL OUTSIDE AIR KIT collar around chimney at top of (MODEL AK4/AK4F) fireplace must not be obstruct- The installation of an outside air kit should be ed. Never use blown insulation performed during the rough framing of the fire- to fill chimney enclosure. - Page 7 Venting installatiOn OFFSET RISE CHIMNEY LENGTH Continued 48" 36" 24" 18" 12" " " ELBOW SET ONLY When connecting chimney directly to the fireplace, " " the inner flue pipe section must be installed first " " with the lanced side up. The outer pipe section 15"...
- Page 8 Venting installatiOn Existing Ceiling Continued Frame See Detail A Firestop 2" Min. Spacer Screws or Staples (Min. of 8) Straps Figure 10 - Firestop Spacer with Living Straps Space Above Ceiling Detail B See Detail B Angle Firestop Screws or Staples Firestop (Min.
- Page 9 Venting installatiOn Storm Collar Installation (SC1 or SC2) Place storm collar over pipe and slide down Continued until it is snug against the open edge of the flashing (see Figure 14). Use SC1 for all round terminations and SC2 for all terminations with "...
- Page 10 Venting installatiOn Continued Terminations with 16" slip pipe sections are 10 FOOT RULE available. The RTT-8DM and RTTL-8DM are All flue gas outlet chimney terminations must approved for flashing installations. When extend a minimum of 3 feet in height above the needed, these adjustable terminations may be highest point where it passes through the roof used in combination with the pipe assembly to...
-
Page 11: Optional Gas Line Installation
Venting installatiOn Continued EFFECTIVE HEIGHT OF EFFECTIVE HEIGHT OF TERMINATION CAP TERMINATION CAP MINIMUM HEIGHT OF 22 FT. (WITH TWO ELBOW SETS) MAXIMUM HEIGHT OF 50 FT. MAXIMUM EFFECTIVE HEIGHT OF EFFECTIVE HEIGHT OF HEIGHT 50 FT. TERMINATION CAP TERMINATION CAP (ANY SYSTEM) 14.5 FT. -
Page 12: Optional Gas Line
OptiOnal gas line WARNING: To avoid the risk of installatiOn damaging the fireplace materials Continued and increasing the risk of spread- ing a fire, do not use the fireplace CAUTION: All gas piping to cook or warm food. and connections must be tested for leaks after the installation WARNING: If the fireplace is completed. -
Page 13: Maintenance Guidelines
If you wish to install an unvented (vent-free) OpeRatiOn and gas log set, only unvented gas log sets which Maintenance have been found to comply with the standard guidelines for unvented room heaters, ANSI Z21.11.2 are to be installed in this fireplace. Continued A fireplace equipped with glass doors oper- OUTSIDE AIR AND DAMPER... -
Page 14: Parts
WOOD BURNING FIREPLACE MODELS S36, S36H, S36R, S36RH, VS36(1), VS36H(1), VS36R AND VS36RH 37/38 www.desatech.com 111026-01F... - Page 15 WOOD BURNING FIREPLACE MODELS S36, S36H, S36R, S36RH, VS36(1), VS36H(1), VS36R AND VS36RH This list contains replaceable parts used in your fireplace. When ordering parts, see Replace- ment Parts on page 16 of this manual. NO. PART NO. DESCRIPTION QTY.
-
Page 16: Technical Service
You may have further questions about installation, operation, or troubleshooting. If so, contact DESA Heating, LLC at 1-866-672-6040. When calling please have your model and serial num- bers of your heater ready. You can also visit DESA Heating, LLC’s web site at www.desatech.com. - Page 17 accessORies Continued STORM COLLAR SC1-1 For RT-8DM and RTL-8DM 30° OFFSET AND RETURN SC1-2 For RTT-8DM and RTTL-8DM 30E-8DM FIRESTOP SPACER V3600FS-8DM OUTSIDE AIR KIT FOR SIDE WALL INSTALLATION - AK4 HEARTH ExTENSION HE-36 OUTSIDE AIR KIT FOR FLOOR INSTALLATION AK4F DRAIN PAN DP36 ROUND TOP...
- Page 18 nOtes _____________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ _____________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ _____________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ www.desatech.com 111026-01F...
- Page 19 nOtes _____________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ _____________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ _____________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ 111026-01F www.desatech.com...
- Page 20 DESA Heating, LLC 2701 Industrial Drive Bowling Green, KY 42101 www.desatech.com 1-866-672-6040 111026-01 111026 01 Rev. F 06/08 NOT A UPC...
