Sharp LC-32LE210 Service Manual

Led lcd colour television
Hide thumbs
Table of Contents

Advertisement

Quick Links

DVB-T / DVB-C (HDTV), PAL
ELECTRICAL SPECIFICATIONS .............................................................................. 2
IMPORTANT SERVICE SAFETY PRECAUTIONS...................................................... 3
OPERATION MANUAL ............................................................................................... 6
DIMENSIONS ......................................................................................................... 10
REMOVING OF MAJOR PARTS ................................................................................................ 11
SERVICE ADJUSTMENTS ..................................................................................... 16
SOFTWARE UPDATING .................................................................................... 28
MAJOR ICs INFORMATION ..................................................................................... 29
SOURCE OF DOCUMENTATION ..................................................................................... 38
CHASSIS LAYOUT .................................................................................................. 39
WIRING DIAGRAMS ......................................................................................... 43
BLOCK DIAGRAMS ......................................................................................... 45
SCHEMATIC DIAGRAMS ......................................................................................... 51
PRINTED WIRING BOARDS ..................................................................................... 69
REPLACEMENT PARTS LIST .................................................................................. 76
CABINET AND MECHANICAL PARTS .......................................................................... 89
PACKING OF THE SET ........................................................................................... 91
/ SECAM
B/G, I
In the interests of user safety (required by safety
regulations in some countries) the set should be re-
stored to its original condition and only parts identical
to those speci¿ ed should be used.
CONTENTS
SERVICE MANUAL
LED LCD
COLOUR TELEVISION
SYSTEM COLOUR TELEVISION
B/G, D/K, L/L'
MODELS
LC-32LE210E/RU
LC-32LE210EB/RUB
LC-32LE220E/RU
LC-32LE220EB/RUB
LC-32LB220E/RU
LC-32LB220EB/RUB
LC-32LS220E/RU
LC-32LS220EB/RUB
1
LC-32LE210
LC-32LE220
SE00LC32LE210
th
Issued: 16
September 2010
This document has been published to
be used for after sales service only.
The contents are subject to chage without notice.

Advertisement

Table of Contents
loading

Related Manuals for Sharp LC-32LE210

Summary of Contents for Sharp LC-32LE210

  • Page 1: Table Of Contents

    LC-32LE210 LC-32LE220 SERVICE MANUAL SE00LC32LE210 Issued: 16 September 2010 LED LCD COLOUR TELEVISION DVB-T / DVB-C (HDTV), PAL / SECAM SYSTEM COLOUR TELEVISION B/G, I B/G, D/K, L/L’ MODELS LC-32LE210E/RU LC-32LE210EB/RUB LC-32LE220E/RU LC-32LE220EB/RUB LC-32LB220E/RU LC-32LB220EB/RUB LC-32LS220E/RU LC-32LS220EB/RUB In the interests of user safety (required by safety...
