13 Additional information

Specifications

• These specifications are applicable when the power
supply is 230 V.
Audio Section
Multi channel simultaneous power output (1 kHz, 1 %, 8 Ω)
7 ch total . . . . . . . . . . . . 770 W (SC-LX83)/700 W (SC-LX73)
Maximum power output (1 kHz, THD 10 %, 6 Ω, 1 ch Drive )
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 270 W/per channel
Rated power output (1 kHz, 6 Ω, 1 %)
Front . . . . . . . . . . . . . . . . . . . . . .190 W + 190 W (SC-LX83)
Center . . . . . . . . . . . . . . . . . . . . . . . . . . . . .190 W (SC-LX83)
Surround . . . . . . . . . . . . . . . . . . .190 W + 190 W (SC-LX83)
Surround back (Front height/wide)
. . . . . . . . . . . . . . . . . . . . . . . . . . .190 W + 190 W (SC-LX83)
Rated power output (20 Hz to 20 kHz, 8 Ω, 0.08 %)
Front . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 140 W + 140 W
Center . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 140 W
Surround . . . . . . . . . . . . . . . . . . . . . . . . . . . 140 W + 140 W
Surround back (Front height/wide). . . . . . 140 W + 140 W
Total harmonic distortion. . . . . . . . . . . . . . . . . . . . . . . . 0.05 %
Signal-to-Noise Ratio (IHF, short circuited, A network)
LINE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .103 dB
Frequency Response . . . . . . . . . . . . 5 Hz to 100 000 Hz
Input (Sensitivity/Impedance)
PHONO MM . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 mV/47 kΩ
LINE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 400 mV/47 kΩ
Output (Level/Impedance)
REC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 400 mV/2.2 kΩ
Tuner Section
Frequency Range (FM). . . . . . . . . . . . . .87.5 MHz to 108 MHz
Antenna Input (FM) . . . . . . . . . . . . . . . . . . . 75 Ω unbalanced
Frequency Range (AM) . . . 531 kHz to 1602 kHz (9 kHz step)
Antenna (AM) . . . . . . . . . . . . . . . . . Loop antenna (balanced)
Video Section
Signal level
Composite Video . . . . . . . . . . . . . . . . . . . . . . .1 Vp-p (75 Ω)
Component Video. . . . . . . . . . . . . . . . . . .Y: 1.0 Vp-p (75 Ω),
Corresponding maximum resolution
Component Video. . . . . . . . . . . . . . . . . . . . . . 1080p (1125p)
Digital In/Out Section
HDMI terminal . . . . . . . . . . . . . . . . . . . . . . . . 19-pin (Not DVI)
HDMI output type . . . . . . . . . . . . . . . . . . . . . . . . . .5 V, 100 mA
USB terminal . . . . . . . . . . . . . . . USB2.0 Full Speed (Type A)
iPod terminal . . . . . . . . . . . . . . USB, and Video (Composite)
ADAPTER PORT terminal . . . . . . . . . . . . . . . . . . .5 V, 100 mA
140
En
180 W + 180 W (SC-LX73)
180 W (SC-LX73)
180 W + 180 W (SC-LX73)
180 W + 180 W (SC-LX73)
(20 Hz to 20 kHz, 130 W, 8 Ω)
(Pure Direct Mode)
530 kHz to 1700 kHz (10 kHz step)
PB, PR: 0.7 Vp-p (75 Ω)
(Video convert off)
Integrated Control Section
Control (SR) terminal . . . . . . . . . . . . Ø 3.5 Mini-jack (MONO)
Control (IR) terminal . . . . . . . . . . . . . Ø 3.5 Mini-jack (MONO)
IR signal . . . . . . . . . . . . . . . . . .High Active (High Level: 2.0 V)
12 V Trigger terminal. . . . . . . . . . . . . Ø 3.5 Mini-jack (MONO)
12 V Trigger output type . . . . . . . . . . . . . . 12 V, Total 150 mA
RS-232C cable type . . . . . . . 9-pin, cross type, female-female
EXTENSION terminal (SC-LX73 only) . . . . . . . . . . 5 V, 150 mA
CU-RF100 terminal (SC-LX83 only) . . . . . . . . . . . . 5 V, 150 mA
Network Section
LAN terminal . . . . . . . . . . . . . . . . . . .10 BASE-T/100 BASE-TX
Remote control unit
Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . DC 3 V
Estimated line-of-sight transmission distance*
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . About 10 m
Radio frequency band. . . . . . . . . . . . . . . . . . . . . . . . . .2.4 GHz
Modulation system
. . . . . . . . . . . . . . Direct Sequence Spread Spectrum (DSSS)
Dimensions . . . . . . . . 51 mm (W) x 255 mm (H) x 34 mm (D)
Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .190 g
RF adapter
(SC-LX83 only)
Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . DC 5 V
Estimated line-of-sight transmission distance* . . . About 10 m
Radio frequency band. . . . . . . . . . . . . . . . . . . . . . . . . .2.4 GHz
Modulation system
. . . . . . . . . . . . . . Direct Sequence Spread Spectrum (DSSS)
Dimensions . . . . . . . 49 mm (W) x 21 mm (H) x 64.5 mm (D)
Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .90 g
dB
* The line-of-sight transmission distance is an estimate.
Actual transmission distances supported may differ
depending on surrounding conditions.
Miscellaneous
Power requirements
. . . . . . . . . . . . . . . . . . . AC 220 V to 230 V/240 V, 50 Hz/60 Hz
Power consumption . . . . . . . . . . . . . . . . . . . . . . . . . . . . 330 W
In standby . . . . . . . . 0.2 W (HDMI Setup – Control : OFF)
Dimensions . . . . . . 420 mm (W) x 200 mm (H) x 460 mm (D)
Weight (without package) . . . . . . . . . . . . . . . . . . . . . . 18.5 kg
(SC-LX83 only)
0.3 W (HDMI Setup – Control : ON)
