INSTALLATION INSTRUCTIONS

WhispAire
Quiet Hood

IMPORTANT SAFETY INSTRUCTIONS

WARNING - TO REDUCE THE RISK OF FIRE,
ELECTRIC SHOCK, OR INJURY TO PERSONS,
OBSERVE THE FOLLOWING:
1. Use this unit only in the manner intended by the manufacturer. If you
have any questions, contact the manufacturer at the address or
telephone number listed in the warranty.
2. Before servicing or cleaning unit, switch power off at service panel
and lock service panel to prevent power from being switched on
accidentally. When the service disconnecting means cannot be
locked, securely fasten a prominent warning device, such as a tag,
to the service panel.
3. Installation work and electrical wiring must be done by
qualified person(s) in accordance with all applicable codes and
standards - including fire-rated construction codes and standards.
4. Sufficient air is needed for proper combustion and exhausting
of gases through the flue (chimney) of fuel burning equipment
to prevent backdrafting. Follow the heating equipment manufacturer's
guidelines and safety standards such as those published by the
National Fire Protection Association (NFPA), and the American
Society for Heating, Refrigeration and Air Conditioning Engineers
(ASHRAE), and local code authorities.
5. When cutting or drilling into wall or ceiling, do not damage
electrical wiring and other hidden utilities.
6. Ducted fans must always be vented to the outdoors.
7. To reduce the risk of fire, use only metal ductwork.
8. When applicable local regulations comprise more restrictive
installation and/or certification requirements, the aforementioned
requirements prevail on those of this document and the installer
agrees to conform to these at his own expenses.
TO REDUCE THE RISK OF A RANGE TOP GREASE FIRE:
1. Never leave surface units unattended at high settings. Boilovers
cause smoking and greasy spillovers that may ignite. Heat oils slowly
on low or medium setting.
2. Always turn hood ON when cooking at high heat or when flambeing
food (i.e.: Crêpes Suzette, Cherries Jubilee, Peppercorn Beef Flambé).
3. Clean ventilating fans frequently. Grease should not be allowed to
accumulate on fan or filter.
4. Use proper pan size. Always use cookware appropriate for the size
of the surface element.
TO REDUCE THE RISK OF INJURY TO PERSONS IN THE EVENT OF
A RANGE TOP GREASE FIRE, OBSERVE THE FOLLOWING* :
1. SMOTHER FLAMES with a close-fitting lid, cookie sheet, or metal
tray, then turn off the burner. BE CAREFUL TO PREVENT BURNS.
If the flames do not go out immediately, EVACUATE AND CALL
THE FIRE DEPARTMENT.
2. NEVER PICK UP A FLAMING PAN - you may be burned.
3. DO NOT USE WATER, including wet dishcloths or towels - a violent
steam explosion will result.
4. Use an extinguisher ONLY if:
A. You know you have a Class ABC extinguisher, and you already
know how to operate it.
B. The fire is small and contained in the area where it started.
C. The fire department is being called.
D. You can fight the fire with your back to an exit.
*Based on "Kitchen Fire Safety Tips" published by NFPA.
Range Hood
READ & SAVE THESE INTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
1. For indoor use only.
2. For general ventilating only. Do not use to exhaust hazardous or
explosive materials and vapors.
3. To reduce the risk of fire or electrical shock, this range hood should not
be used with an additional solid-state speed control device.
4. To reduce the risk of shock, disconnect power before servicing.
5. To reduce the risk of fire and to properly exhaust air, be sure to duct
air outside. Do not vent exhaust air into spaces within walls or
ceilings or into attics, crawl spaces or garages.

PLAN THE INSTALLATION

1. Mounting height MUST BE at a minimum of 22" and at a maximum
of 30" above the cooking surface from the bottom edge of the range
hood.
2. The hood shall be mounted to the bottom of a standard wall cabinet. If
the hood must be mounted directly to a wall, secure the hood to wall
studs.
3. All wiring must comply with local codes and the unit must be properly
grounded. Connection should be made to a 110-120 VAC lighting
circuit (15A) in the circuit breaker or fuse box.
This range hood is "Convertible", it may be installed as a ducted or
as a non-ducted unit.
IF THE RANGE HOOD IS TO BE NON-DUCTED:
Purchase non-ducted (duct-free) charcoal filter Model RFQTC.
IF THE RANGE HOOD IS TO BE DUCTED:
Ductwork can be installed vertically or horizontally
Duct runs should be as short as possible
Avoid the use of elbows
Use metal foil duct tape at all joints
Do not use duct smaller than the discharge on the hood
For 7" round ductwork installation, use 7" round damper, Model BP87
and 7" adaptor, Model K4892000, both sold separately
REGISTER YOUR PRODUCT ON LINE AT
• For NuTone WA6500 Series: www.nutone.ca
• For Broan QT20000 Series: www.broan.ca
1
WA6500 SERIES
QT20000 SERIES
30040600E
