Summary of Contents for Mazda 2013 CX-9

  • Page 4 HIROSHIMA, JAPAN Important Notes About This Manual Keep this manual in the glove box as a handy reference for the safe and enjoyable use of your Mazda. Should you resell the vehicle, leave this manual with it for the next owner.

  • Page 5: How To Use This Manual

    Mazda. By reading your manual, you can Please refer to the manual for a detailed find out about the features, important explanation.

  • Page 6: Table Of Contents

    Table of Contents Your Vehicle at a Glance Interior, exterior views and part identification of your Mazda. Essential Safety Equipment Use of safety equipment, including seats, seat belt system, child-restraint systems and SRS air bags. Knowing Your Mazda Explanation of basic operations and controls; opening/closing and adjustment of various parts.

  • Page 8: Your Vehicle At A Glance

    Your Vehicle at a Glance Interior, exterior views and part identification of your Mazda. Interior Overview ................1-2 Interior Equipment (View A) ............ 1-2 Interior Equipment (View B) ............ 1-3 Interior Equipment (View C) ............ 1-4 Exterior Overview ................. 1-5 Front ..................

  • Page 9: Interior Overview

    Your Vehicle at a Glance Interior Overview Interior Equipment (View A) Door-lock knob ....................page 3-29 Power door lock switch ..................page 3-29 Power window lock switch ................page 3-44 Power window switches ..................page 3-40 Outside mirror switch ..................page 3-64 TCS-OFF switch ....................

  • Page 10: Interior Equipment (View B)

    Your Vehicle at a Glance Interior Overview Interior Equipment (View B) Audio control switches ..................page 6-50 SRS air bags ...................... page 2-54 Cruise control switches ..................page 5-20 Information display ..................page 6-165 Climate control system ..................page 6-2 Hazard warning flasher switch ................

  • Page 11: Interior Equipment (View C)

    Your Vehicle at a Glance Interior Overview Interior Equipment (View C) Overhead lights ....................page 6-163 SRS air bags ...................... page 2-54 Seat belt ......................page 2-19 Rear entertainment system ................. page 6-64 Center console ....................page 6-173 Remote fuel-filler lid release ................page 3-48 Cup holders ......................

  • Page 12: Exterior Overview

    Your Vehicle at a Glance Exterior Overview Front Hood ........................page 3-49 Windshield wiper blades ..................page 8-28 Moonroof ......................page 3-50 Door lock ......................page 3-28 Fuel-filler lid ...................... page 3-47 Tires ........................page 8-34 Light bulbs ......................page 8-40 The equipment and installation position varies by vehicle...

  • Page 13: Rear

    Your Vehicle at a Glance Exterior Overview Rear Liftgate ......................page 3-33 Rear wiper blade ....................page 8-30 Child safety lock ....................page 3-32 Outside mirror ....................page 3-64 Tires ........................page 8-34 Light bulbs ......................page 8-40 Rear view monitor ................... page 6-151 The equipment and installation position varies by vehicle...
  • Page 14 Essential Safety Equipment Use of safety equipment, including seats, seat belt system, child-restraint systems and SRS air bags. Seats ....................2-2 Front Seats (Manually Operated Seats) ........2-2 Front Seats (Electrically Operated Seats) ........2-4 Second-Row Seats ..............2-9 Third-Row Seat ............... 2-13 Head Restraints ...............

  • Page 15: Front

    The result in serious injury. Consult an driver could lose control of the vehicle Authorized Mazda Dealer if there is and have an accident. any need to remove or reinstall the CAUTION front seats.
  • Page 16 Essential Safety Equipment Seats Do not drive with the seatback Make sure the lever returns to its original unlocked: position and the seat is locked in place by All of the seatbacks play an attempting to push it forward and important role in your protection in a backward.

  • Page 17: Front Seats (Electrically Operated Seats)

    Consult an Authorized Mazda Dealer if there is any need to remove or reinstall the front seats. Down Do not drive with damaged front seats: Driving with damaged front seats is dangerous.
  • Page 18 Essential Safety Equipment Seats qSeat Recline CAUTION WARNING Ø The seat-bottom power adjustment is operated by motors. Do not drive with either front seat Avoid extended operation because reclined: excessive use can damage the Sitting in a reclined position while the motors.
  • Page 19 Essential Safety Equipment Seats í qSeat Position Memory To change the seatback angle, press the front or rear side of the reclining switch. The driver's seat position memory Release the switch at the desired position. function allows you to program a desired seat position and outside mirror angle position.
  • Page 20 Essential Safety Equipment Seats 2. Press the SET button followed by one NOTE of the programming buttons (1, 2, or 3) When the ignition is switched to ACC or off, within about 5 seconds. A beep sound a pre-programmed seat position can be is heard after the programming is activated regardless of the selector lever completed.
  • Page 21 Essential Safety Equipment Seats qLumbar Support Adjustment NOTE If the seat and outside mirror angles are (Driver's Seat) already adjusted to the positions you are Manually operated activating, the seat and outside mirrors do not move (a beep sound is not heard). To increase the seat firmness, pull the The advanced key/retractable key cannot be lever forward.

  • Page 22: Second-Row Seats

    Essential Safety Equipment Seats Do not drive with the seatback Second-Row Seats unlocked: All of the seatbacks play an WARNING important role in your protection in a Do not stack cargo higher than the vehicle. Leaving the seatback seatbacks: unlocked is dangerous as it can allow Stacking luggage or other cargo passengers to be ejected or thrown higher than the seatbacks is...
  • Page 23 Essential Safety Equipment Seats qSeat Slide qSeat Recline WARNING To move the seat forward or backward, raise the bar and slide the seat to the Do not drive with the seats reclined: desired position and release the bar. Sitting in a reclined position while the vehicle is moving is dangerous because you do not get the full protection from the seat belts.
  • Page 24 Essential Safety Equipment Seats qThird-Row Seat Access CAUTION After folding the second-row seat When returning a rear-reclined seatback and sliding the seat forward, you seatback to its upright position, can access the third-row seat easily. make sure you hold onto the seatback with your other hand while Entering/exiting the third-row seat area operating the lever.
  • Page 25 Essential Safety Equipment Seats 4. Pull the lever and fold the seatback CAUTION forward. Ø When folding a seatback, always hold onto the seatback with your other hand while operating the lever. If the seatback is not supported, it will flip forward suddenly and could cause injury.

  • Page 26: Third-Row Seat

    Essential Safety Equipment Seats Returning seatbacks to their original Third-Row Seat positions WARNING 1. Lift the seatback to its original position. Do not stack cargo higher than the Make sure the seatback is secured by seatbacks: attempting to lightly move it forward Stacking luggage or other cargo and back.
  • Page 27 Essential Safety Equipment Seats Never allow a passenger to sit or stand 2. Pull the strap and fold the seatback on the folded seatback while the forward. vehicle is moving: Driving with a passenger on the folded seatback is dangerous. Allowing a child to sit up on the folded seatback while the vehicle is moving is particularly dangerous.
  • Page 28 Essential Safety Equipment Seats 2. Fasten the strap to its original position Head Restraints between the seatback and folding board. Your vehicle is equipped with head restraints on all outboard seats and the second-row center seat. The head restraints are intended to help protect you and the passengers from neck injury.
  • Page 29 Essential Safety Equipment Seats qNormal Head Restraints Second-Row outboard seat/Third-Row outboard seat Height adjustment To raise a head restraint, pull it up to the desired position. To lower the head restraint, press the stop- catch release, then push the head restraint down.
  • Page 30 Essential Safety Equipment Seats í qFoldable Head Restraints í Seat Warmer The third-row seats are equipped with The front seats are electrically heated. The foldable head restraints. ignition must be switched ON. NOTE The foldable head restraints cannot be adjusted or removed. To fold the head restraint, pull the strap and fold the head restraint downward.
  • Page 31 Essential Safety Equipment Seats NOTE WARNING If the ignition is switched off while the seat Ø Be careful when using the seat warmer is operating (High or Low) and warmer. The heat from the seat then switched ON again, the seat warmer warmer may be too hot for some will automatically operate at the people, as indicated below, and...

  • Page 32: Seat Belt Systems

    Seat Belt Precautions Seat belts help to decrease the possibility of severe injury during accidents and sudden stops. Mazda recommends that the driver and all passengers always wear seat belts. Your vehicle has the following types of seat belts. Seating Position...
  • Page 33 Using a damaged seat belt is dangerous. An accident could damage the belt webbing of the seat belt in use. A damaged seat belt cannot provide adequate protection in a collision. Have an Authorized Mazda Dealer inspect all seat belt systems in use during an accident before they are used again.
  • Page 34 Essential Safety Equipment Seat Belt Systems CAUTION Belt retraction may become difficult if the belts and rings are soiled, so try to keep them clean. For more details about cleaning the seat belts, refer to “Cleaning the Lap/Shoulder Belt Webbing” (page 8-64). qPregnant Women and Persons with Serious Medical Conditions Pregnant women should always wear seat belts.
  • Page 35 Essential Safety Equipment Seat Belt Systems qAutomatic Locking Mode Always use the automatic locking mode to keep the child-restraint system from shifting to an unsafe position in the event of an accident. To enable seat belt automatic locking mode, pull it all the way out and connect it as instructed on the child-restraint system. It will retract down to the child-restraint system and stay locked on it.

  • Page 36: Point Type Seat Belt

    Essential Safety Equipment Seat Belt Systems WARNING 3-Point Type Seat Belt Positioning the Shoulder Portion of the qFastening the Seat Belt Seat Belt: Improper positioning of the shoulder 1. Grasp the seat belt tongue. portion of the seat belt is dangerous. 2.
  • Page 37 If it is still not retracting Seat Belt: properly, have it inspected at an Authorized Improper positioning of the shoulder Mazda Dealer. portion of the seat belt is dangerous. Always make sure the shoulder To secure the outboard-third row seat...

  • Page 38: Front Seat Belt Pretensioner And Load Limiting Systems

    Even if the pretensioners have not deployed, the load limiting function must be checked by an Authorized Mazda Dealer. 2-25...
  • Page 39 Ask an Authorized Mazda possible. Dealer how to safely dispose of the qAir Bag/Front Seat Belt pretensioner system or how to scrap a pretensioner-equipped vehicle.
  • Page 40 ON. If any of these occur, Driving the vehicle with the air bag/ consult an Authorized Mazda Dealer as front seat belt pretensioner system soon as possible. The system may not warning beep sounding is dangerous.

  • Page 41: Center-Rear Position Seat Belt (Second-Row Seats)

    Essential Safety Equipment Seat Belt Systems WARNING Center-Rear Position Seat Belt (Second-Row Seats) Using the Seat Belt Guide: Not using the seat belt guide is Before using the center-rear lap/shoulder dangerous. If the seat belt guide is belt make sure tongue (A) and anchor not used, the shoulder portion of the buckle (B) are fastened.
  • Page 42 Essential Safety Equipment Seat Belt Systems 3. Insert the seat belt tongue (C) into the 4. Position the lap belt as low as possible, seat belt buckle (D) until you hear a not on the abdominal area, then adjust click sound. the shoulder belt so that it fits snugly against your body.
  • Page 43 Authorized To stow the seat belt, retract the belt, put Mazda Dealer. the seat belt tongues (A) and (C) together qRetracting the Center Seat Belt and insert each tongue into the respective ceiling recess.
  • Page 44 Essential Safety Equipment Seat Belt Systems qRe-attaching the Seat Belt after the To pull out the seat belt, press the area indicated in the figure upward with your Middle Row Seatbacks are finger and slide the belt forward. Then Returned to their Upright Positions slowly pull out the seat belt from the To re-attach the center seat belt after the ceiling recess.

  • Page 45: Seat Belt Extender

    If you sell your Mazda, do When ordering an extender, only order not leave your seat belt extender in one that provides the necessary additional the vehicle.

  • Page 46: Seat Belt Warning Light

    Essential Safety Equipment Seat Belt Systems Do not leave a seat belt extender Seat Belt Warning Light connected to the buckle: Leaving a seat belt extender connected to the buckle without using the seat belt is dangerous. When the seat belt extender is connected to the driver's seat belt buckle (or front passenger) seat, the SRS driver's (or front passenger's) air...

  • Page 47: Seat Belt Reminder

    For the sound activates again. safety of the driver and front passenger, Mazda Placing items on the front passenger seat recommends not deactivating the belt may cause the front passenger seat belt reminder.

  • Page 48: Child Restraint

    Even if the front passenger air bag is shut off, Mazda strongly recommends that children be properly restrained and child-restraint systems of all kinds are properly secured on the rear seats which are the best place for children.
  • Page 49 Essential Safety Equipment Child Restraint WARNING Use the correct size child-restraint system: For effective protection in vehicle accidents and sudden stops, a child must be properly restrained using a seat belt or child-restraint system depending on age and size. If not, the child could be seriously injured or even killed in an accident. Follow the manufacturer's instructions and always keep the child-restraint system buckled down: An unsecured child-restraint system is dangerous.
  • Page 50 Essential Safety Equipment Child Restraint Vehicles with a front passenger air bag have a warning label attached as shown below. The warning label reminds you not to put a rear-facing child-restraint system on the front passenger seat at any time. Do not install a front-facing child-restraint system on the front passenger seat unless it is unavoidable: In a collision, the force of a deploying air bag could cause serious injury or death to...
  • Page 51 Essential Safety Equipment Child Restraint Seating a child in a child-restraint system on the front passenger seat is dangerous under certain conditions (With Driver and Front Passenger Occupant Classification System): Your vehicle is equipped with front passenger seat weight sensors. Even with the front passenger seat weight sensors, if you must use the front passenger seat to seat a child, using a child-restraint system on the front passenger seat under the following conditions increases the danger of the front passenger air bag deploying...
  • Page 52 NOTE Your Mazda is equipped with LATCH lower anchors for attachment of specially designed LATCH child-restraint systems in the rear seats. When using these anchors to secure a child-restraint system, refer to “LATCH Child-Restraint Systems” (page 2-49).

  • Page 53: Child-Restraint System Installation Position

    Essential Safety Equipment Child Restraint Child seat Child-Restraint System A child seat restrains a child's body using Installation Position the harness. In this owner's manual, explanation of child-restraint systems is provided for the following three types of popular child- restraint systems: infant seat, child seat, booster seat.

  • Page 54: Installing Child-Restraint Systems

    Follow these instructions when using a installed on the seats that take tethers to child-restraint system, unless you are be effective. In your Mazda, tethered attaching a LATCH-equipped child- child-restraint systems can only be restraint system to the rear LATCH lower anchors.
  • Page 55 Essential Safety Equipment Child Restraint 2. If the seat in which you install a child- 7. Push the child-restraint system firmly restraint system has a seat slide into the vehicle seat. Be sure the belt function, slide the seat as far back as retracts as snugly as possible.
  • Page 56 Essential Safety Equipment Child Restraint Anchor bracket location WARNING Use the tether and tether anchor only for a child-restraint system: Using the tether or tether anchor to secure anything but a child-restraint system is dangerous. This could weaken or damage the tether or tether anchor and result in injury.
  • Page 57 Essential Safety Equipment Child Restraint qThird-Row Seats Child-Restraint 3. To get the retractor into the automatic locking mode, pull the shoulder belt System Installation portion of the seat belt until the entire The third-row seats cannot accommodate length of the belt is out of the retractor. LATCH-type child-restraint systems or tethers, therefore these systems must be installed on the other seat positions such...

  • Page 58: For Children

    You should not be able bags: to pull the shoulder belt out of the retractor Mazda vehicles equipped with side air bag will have a “SRS AIRBAG” tag on the while the system is in the automatic locking mode.
  • Page 59 Essential Safety Equipment Child Restraint Never use a rear-facing child-restraint Do not allow a child or anyone to lean system in the front seat with an air bag over or against the side window of a that could deploy: vehicle with side and curtain air bags: Rear-facing child-restraint systems It is dangerous to allow anyone to on the front seat are particularly...
  • Page 60 Essential Safety Equipment Child Restraint 3. Place the child-restraint system on the 7. (With Driver and Front Passenger seat without putting your weight on the Occupant Classification System) seat and fasten the seat belt. See the Make sure the front passenger air bag manufacturer's instructions on the deactivation indicator light illuminates child-restraint system for belt routing...
  • Page 61 Authorized Mazda Dealer as soon as possible. 2-48...

  • Page 62: Latch Child-Restraint Systems

    Child Restraint LATCH Child-Restraint Systems Your Mazda is equipped with LATCH lower anchors for attachment of specially designed LATCH child-restraint systems in the second-row seats. Both anchors must be used, otherwise the seat will bounce around and put the child in danger. Most LATCH child- restraint systems must also be used in conjunction with a tether to be effective.
  • Page 63 Essential Safety Equipment Child Restraint qLATCH Child-Restraint System 6. If your child-restraint system came equipped with a tether, that means it is Installation Procedure (Second- very important to properly secure the Row Outboard Seats) tether for child safety. Please carefully 1.
  • Page 64 Essential Safety Equipment Child Restraint qLATCH Child-Restraint System WARNING Installation Procedure (Second- Use the tether and tether anchor only Row Center Seat) for a child-restraint system: The LATCH lower anchors at the center Using the tether or tether anchor to of the second-row seat are much further secure anything but a child-restraint apart than the sets of LATCH lower...
  • Page 65 Essential Safety Equipment Child Restraint 3. Expand the area between the seat WARNING bottom and the seatback slightly to Use the tether and tether anchor only verify the locations of the LATCH for a child-restraint system: lower anchors. Using the tether or tether anchor to secure anything but a child-restraint system is dangerous.
  • Page 66 Essential Safety Equipment Child Restraint Anchor bracket position Tether strap position Tether strap Forward 2-53...

  • Page 67: Srs Air Bags

    Essential Safety Equipment SRS Air Bags Supplemental Restraint System (SRS) Precautions The front and side supplemental restraint systems (SRS) include 6 air bags. Please verify the air bags equipped on your vehicle by locating the “SRS AIRBAG” location indicators. These indicators are visible in the area where the air bags are installed. The air bags are installed in the following locations: The steering wheel hub (driver air bag) The front passenger dashboard (front passenger air bag)
  • Page 68 Essential Safety Equipment SRS Air Bags If your vehicle is also equipped with a driver and front passenger occupant classification system, refer to the Driver and Front Passenger Occupant Classification System (page 2-68) for details. If your vehicle is equipped with a driver and front passenger occupant classification system, the front passenger air bag deactivation indicator light illuminates for a specified time after the ignition is switched ON.
  • Page 69 Essential Safety Equipment SRS Air Bags Never use a rear-facing child-restraint system in the front seat with an air bag that could deploy: Rear-facing child-restraint systems on the front seat are particularly dangerous even though you may feel assured that a front passenger air bag will not deploy based on the fact that the front passenger air bag deactivation indicator light illuminates.
  • Page 70 Essential Safety Equipment SRS Air Bags Sit in the center of the seat and wear seat belts properly: Sitting too close to the side air bag modules or placing hands on them, or sleeping up against the door or hanging out the windows is extremely dangerous. The side and curtain air bags inflate with great force and speed directly expanding along the door on the side the car is hit.
  • Page 71 Ø Do not use tires or wheels other than those specified for your Mazda: Use of any tire or wheel other than those specified for your Mazda (page 10-6) is dangerous. Use of such wheels will prevent the vehicle's accident detections system from accurately detecting a collision or roll-over accident resulting in incorrect or unexpected air bag deployment and the possibility of serious injuries.
  • Page 72 Should you sell your Mazda, we urge you to tell the new owner of its air bag systems and that familiarization with all instructions about them, from the Owner's Manual, is important.

  • Page 73: Supplemental Restraint System Components

    Essential Safety Equipment SRS Air Bags Supplemental Restraint System Components Driver/Front passenger inflators and air bags Crash and roll-over sensor, and diagnostic module (SAS unit) Front seat belt pretensioner and load limiting systems (page 2-25) Front air bag sensor Side crash sensors Air bag/front seat belt pretensioner system warning light (page 2-64) Side and curtain inflators and air bags Front passenger air bag deactivation indicator light (page 2-68)

  • Page 74: How The Srs Air Bags Work

    SRS Air Bags How the SRS Air Bags Work Your Mazda is equipped with the following types of SRS air bags. SRS air bags are designed to work together with the seat belts to help to reduce injuries during an accident.
  • Page 75 Essential Safety Equipment SRS Air Bags (With Driver and Front Passenger Occupant Classification System) In addition, the front passenger air bag is designed to only deploy in accordance with the total seated weight on the front passenger seat. For details, refer to the driver and front passenger occupant classification system (page 2-68).
  • Page 76 Essential Safety Equipment SRS Air Bags qCurtain Air Bags The curtain air bags are mounted in the front and rear window pillars, and the roof edge along both sides. When the air bag crash sensors detect a side impact of greater than moderate force, the curtain air bag inflates quickly and helps to reduce injury mainly to the rear outboard passenger's head caused by directly hitting interior parts such as a door or window.
  • Page 77 A system malfunction is indicated if the warning light constantly flashes, constantly illuminates or does not illuminate at all when the ignition is switched ON. If any of these occur, consult an Authorized Mazda Dealer as soon as possible. The system may not operate in an accident.

  • Page 78: Srs Air Bag Deployment Criteria

    Essential Safety Equipment SRS Air Bags SRS Air Bag Deployment Criteria This chart indicates the applicable SRS equipment that will deploy depending on the type of collision. (The illustrations are the representative cases of collisions.) Types of collision A severe frontal/near frontal A severe side A roll-over/near A rear collision...

  • Page 79: Limitations To Srs Air Bag

    Essential Safety Equipment SRS Air Bags Limitations to SRS Air Bag In severe collisions or roll-overs such as those described previously in “SRS Air Bag Deployment Criteria”, the applicable SRS air bag equipment will deploy. However, in some accidents, the equipment may not deploy depending on the type of collision and its severity.
  • Page 80 Essential Safety Equipment SRS Air Bags Limitations to roll-over detection: The following illustration is an example of an accident that may not be detected as a roll- over accident. Therefore, the front seat belt pretensioners and curtain air bags may not deploy.
  • Page 81 Essential Safety Equipment SRS Air Bags í Driver and Front Passenger Occupant Classification System First, please read “Supplemental Restraint System (SRS) Precautions” (page 2-54) carefully. NOTE This system is equipped on models for the U.S., Canadian and Puerto Rican markets. qDriver Seat Slide Position Sensor Your vehicle is equipped with a driver seat slide position sensor as a part of the supplemental restraint system.
  • Page 82 ON and does not illuminate as indicated in the above chart, do not allow a child to sit in the front passenger seat and consult an Authorized Mazda Dealer as soon as possible. The system may not work properly in an accident.
  • Page 83 Essential Safety Equipment SRS Air Bags WARNING Do not decrease the total seated weight on the front passenger seat: When an adult or large child sits on the front passenger seat, decreasing the total seated weight on the front passenger seat required for air bag deployment is dangerous.
  • Page 84 Essential Safety Equipment SRS Air Bags Do not increase the total seated weight on the front passenger seat: When an infant or small child sits on the front passenger seat, increasing the total seated weight on the front passenger seat is dangerous. The front passenger seat weight sensors will detect the increased total seated weight, which could result in the unexpected deployment of the front passenger front and side air bags and seat belt pretensioner system in an accident and may cause serious injury.
  • Page 85 If the front passenger air bag deactivation indicator light still illuminates, move the passenger to the rear seat. If sitting in the rear seat is not possible, slide the front passenger seat as far back as possible. Consult an Authorized Mazda Dealer as soon as possible.

  • Page 86: Monitoring And Maintenance

    The air bag systems do not require regular maintenance. But if any of the following occurs, take your vehicle to an Authorized Mazda Dealer as soon as possible: The air bag system warning light flashes. The air bag system warning light remains illuminated.
  • Page 87 Improper disposal of an air bag or a vehicle with live air bags in it can be extremely dangerous. Unless all safety procedures are followed, injury can result. Ask an Authorized Mazda Dealer how to safely dispose of an air bag or how to scrap an air bag equipped vehicle.

  • Page 88: Knowing Your Mazda

    Knowing Your Mazda Explanation of basic operations and controls; opening/closing and adjustment of various parts. Advanced Keyless Entry and Start System ........ 3-2 í Advanced Keys ..............3-2 Operation Using Advanced Keyless Functions ......3-7 Operation Using Advanced Key Functions ......3-13 Advanced Key Suspend Function ...........

  • Page 89: Advanced Keyless Entry And Start System

    Knowing Your Mazda Advanced Keyless Entry and Start System í Advanced Keys The advanced keyless functions (advanced keyless entry and start system) enable the following operations while the advanced key is being carried (page 3-7). Locking/unlocking the doors and the liftgate without operating the key.
  • Page 90 (not in the vehicle) for use if you need to make a replacement key. Also write down the code number and keep it in another safe and handy place, but not in the vehicle. If your key is lost, consult your Authorized Mazda Dealer with the code number ready.
  • Page 91 Advanced Key) on page 5-58. If this occurs, you will have to use the auxiliary key if you need to start the engine immediately.Refer to Advanced Key Battery Dead Warning on page 3-19. Additional advanced keys can be obtained at an Authorized Mazda Dealer. Up to 6 advanced keys can be used with the advanced keyless functions per vehicle.
  • Page 92 Knowing Your Mazda Advanced Keyless Entry and Start System qAdvanced Key Maintenance Replacing the battery at an Authorized Mazda Dealer is recommended to prevent CAUTION damage to the advanced key. If replacing the battery by yourself, follow the Ø Make sure the battery is installed instruction below.
  • Page 93 Knowing Your Mazda Advanced Keyless Entry and Start System 3. Insert the small, flathead screwdriver 5. Insert a new battery with the positive into the gap between the cover and the pole facing up, and then cover the transmitter, and then rotate the battery with the battery cap.

  • Page 94: Operation Using Advanced Keyless Functions

    Mazda Dealer. liftgate. If your advanced key is lost or stolen, Exterior transmitter bring all remaining advanced keys to an Authorized Mazda Dealer as soon as possible for a replacement and to make the lost or stolen advanced key inoperative. CAUTION Radio equipment like this is governed by laws in the United States.
  • Page 95 Knowing Your Mazda Advanced Keyless Entry and Start System qLocking, Unlocking with Request Starting the engine Switch The operational range for starting the engine includes nearly the entire cabin All doors and the liftgate can be locked/ area except for the luggage compartment.
  • Page 96 Knowing Your Mazda Advanced Keyless Entry and Start System NOTE NOTE (Without theft-deterrent system) The request switch on the driver's door can The hazard warning lights will flash once to be used to close the power windows and the indicate that the doors and the liftgate are moonroof from Outside.Refer to Opening/...
  • Page 97 Knowing Your Mazda Advanced Keyless Entry and Start System qStarting the Engine The setting can be changed so that the doors and the liftgate are locked Ignition switch positions automatically without pressing the request switch (page 10-8). As there is no traditional key, some of the (Auto-lock function) ignition switch functions are different.
  • Page 98 Knowing Your Mazda Advanced Keyless Entry and Start System NOTE WARNING When the ignition is switched ON, the sound of Before leaving the driver's seat, always the fuel pump motor operating near the fuel switch the ignition to OFF, set the tank can be heard.
  • Page 99 Knowing Your Mazda Advanced Keyless Entry and Start System 1. Make sure the advanced key is being NOTE carried. In the following cases, the KEY warning light (red) illuminates and the engine will not start. 2. Occupants should fasten their seat The advanced key battery is dead.

  • Page 100: Operation Using Advanced Key Functions

    Knowing Your Mazda Advanced Keyless Entry and Start System NOTE Operation Using Advanced In extremely cold weather or after the Key Functions vehicle has not been driven in several days, let the engine warm up without operating qKeyless Entry System the accelerator.
  • Page 101 Knowing Your Mazda Advanced Keyless Entry and Start System Transmitter Lock button To lock the doors and the liftgate, press with power liftgate the lock button. A beep sound will be Operation indicator Lock button heard once and the hazard warning lights light will flash once.
  • Page 102 10-8. Power liftgate button The system can be set to unlock all doors by performing a single operation. If your Mazda has a power liftgate (page Refer to Personalization Features on page 3-35), the transmitter can open/close the 10-8. liftgate.
  • Page 103 Knowing Your Mazda Advanced Keyless Entry and Start System Declaration of Conformity Keyless entry system 3-16...

  • Page 104: Advanced Key Suspend Function

    Knowing Your Mazda Advanced Keyless Entry and Start System qAuxiliary Key Function Advanced Key Suspend Use the auxiliary key stored in the Function advanced key in the event of a dead transmitter battery or malfunction. If one advanced key is left in the vehicle...

  • Page 105: Warning And Beep Sounds

    Authorized switched to ACC and the door is open Mazda Dealer as soon as possible. due to the activation of the warning Refer to Ignition Switch (page 5-2). beep sound indicating that the ignition is not switched off.
  • Page 106 Knowing Your Mazda Advanced Keyless Entry and Start System qRequest Switch Inoperable The advanced key is placed in areas where it is difficult for the system to Warning Beep detect the signal (page 3-7). If the request switch for a front door or the...

  • Page 107: When Warning Indicator/Beep Is Activated

    When the KEY warning light (red) remains illuminated in the auxiliary key to continue driving the instrument cluster. vehicle. Have the vehicle inspected at an Authorized Mazda Dealer as soon as possible. 3-20...

  • Page 108: Doors And Locks

    This could result in If your key is lost, consult your Authorized someone being badly injured or even Mazda Dealer and have your code number killed. Children may find these new ready. kinds of keys to be an interesting toy...

  • Page 109: Keyless Entry System Í

    To install a new battery, refer to Maintenance (page 3-24). Additional transmitters can be obtained at an Authorized Mazda Dealer. Up to 3 transmitters can be used with the keyless entry system per vehicle. Bring all transmitters to an Authorized Mazda Dealer when additional transmitters are required.
  • Page 110 Knowing Your Mazda Doors and Locks qTransmitter NOTE Doors and the liftgate can be locked by pressing the lock button while any other Lock button door or the liftgate is open. Also, the hazard Unlock button warning lights will not flash and the horn will not sound.
  • Page 111 Knowing Your Mazda Doors and Locks qTransmitter Maintenance NOTE (Without theft-deterrent system) If the buttons on the transmitter are The hazard warning lights will flash twice to inoperable and the operation indicator indicate that all doors and the liftgate are light does not flash, the battery may be unlocked.
  • Page 112 Knowing Your Mazda Doors and Locks 2. Insert a screwdriver into the slot and 5. Put in the new battery (CR1620 or push the tab to remove the key from equivalent) with the positive pole ( the transmitter. facing down.
  • Page 113 If you have a problem with the keyless entry system, consult an Authorized Mazda Dealer. If your transmitter is lost or stolen, consult an Authorized Mazda Dealer as soon as possible for a replacement and to make the lost or stolen transmitter inoperative. CAUTION Radio equipment like this is governed by laws in the United States.
  • Page 114 Knowing Your Mazda Doors and Locks qDeclaration of Conformity Keyless entry system 3-27...

  • Page 115: Door Locks

    Knowing Your Mazda Doors and Locks After closing the doors, always verify Door Locks that they are securely closed: Doors not securely closed are WARNING dangerous, if the vehicle is driven Always take all children and pets with with a door not securely closed, the...
  • Page 116 Knowing Your Mazda Doors and Locks qLocking, Unlocking with To lock any door with the door-lock knob from the outside, press the door-lock knob Transmitter (With Advanced Key) to the lock position and close the door. The doors can be locked/unlocked by...
  • Page 117 Knowing Your Mazda Doors and Locks (With retractable type key) Locking, unlocking with door-lock The vehicle lock-out prevention feature switch prevents you from locking yourself out of All doors and the liftgate lock the vehicle. With the key in the ignition automatically when lock side is pressed.
  • Page 118 Knowing Your Mazda Doors and Locks Settings can be changed using the Auto lock/unlock function following operation. WARNING Function Function Do not pull the inner handle on a front number door: The auto door-lock function is disabled. Pulling an inner handle on a front...
  • Page 119 Knowing Your Mazda Doors and Locks qRear Door Child Safety Locks NOTE There are only a total of five auto lock/unlock These locks are intended to help prevent settings available. Be sure to press the unlock children from accidentally opening the side of the driver's door-lock switch the correct rear doors.

  • Page 120: Liftgate

    Knowing Your Mazda Doors and Locks CAUTION Liftgate Ø When loading or unloading WARNING luggage in the luggage Never allow a person to ride in the compartment, turn off the engine. luggage compartment: Otherwise, you could get burned Allowing a person to ride in the by the heat of the exhaust gas.
  • Page 121 Knowing Your Mazda Doors and Locks qLocking, Unlocking with Transmitter NOTE If the vehicle battery is dead or there is a (With Retractable Type Key) malfunction in the electrical system and the The liftgate can be locked/unlocked by liftgate cannot be unlocked, perform the...
  • Page 122 Authorized and, if left unnoticed, could result in Mazda Dealer as soon as possible. serious injury or death if an occupant were to fall out of the vehicle. Manually closing the liftgate...
  • Page 123 Knowing Your Mazda Doors and Locks NOTE CAUTION Do not apply unnecessary force to the Ø When closing the power liftgate, power liftgate when it is opening/closing make sure there are no foreign electrically. Unnecessary force on the objects around the striker. If...
  • Page 124 Knowing Your Mazda Doors and Locks Opening/Closing the power liftgate Operation from the driver's seat (To open/close) If the vehicle has satisfied all the following operation conditions, the power Press the power liftgate switch for about liftgate can be opened using the power one second or more while the liftgate is in function.
  • Page 125 Knowing Your Mazda Doors and Locks NOTE CAUTION If the power liftgate switch/power liftgate close Sensors are installed on both ends of switch/power liftgate button on the transmitter the power liftgate. Be careful not to is pressed or the outside handle is operated...
  • Page 126 Knowing Your Mazda Doors and Locks Power liftgate drop prevention NOTE mechanism If the liftgate handle is pulled while the easy closure function is operating, the The power liftgate drop prevention liftgate can be opened. mechanism activates if the system detects...

  • Page 127: Power Windows

    Knowing Your Mazda Doors and Locks qOperating the Front Power Windows Power Windows NOTE The ignition must be switched ON for the Each passenger power window can be power windows to operate. operated with each door switch when the WARNING...
  • Page 128 Knowing Your Mazda Doors and Locks Normal opening/closing Power window system initialization procedure To open a power window to the desired position, lightly hold down the switch. If the battery was disconnected during To close the power window to the desired vehicle maintenance, or for other reasons position, lightly pull up the switch.
  • Page 129 If you are unable to cancel the function the front power windows, carry out the despite carrying out the cancellation following procedure using the master procedure, consult an Authorized Mazda control switches. Dealer. 1. Switch the ignition ON and complete...
  • Page 130 Knowing Your Mazda Doors and Locks qOperating the Rear Power Windows NOTE Depending on driving conditions, a closing The power windows may be operated power window could stop and start opening when the power window lock switch on when the window feels a shock that is the driver's door is in the unlocked similar to something blocking it.
  • Page 131 Opening and the Moonroof from Outside Because nobody likes getting into a very hot car, Mazda has introduced a way to The front power windows and the open the two front windows and the moonroof can be opened or closed from...
  • Page 132 Knowing Your Mazda Doors and Locks Retractable type key WARNING Use the remote auto-window and the Lock button auto-moonroof function only when you can see the vehicle and it is in a secure Unlock button area: Do not let children play with your keys.
  • Page 133 Knowing Your Mazda Doors and Locks To stop this operation, turn the key to the 2. Turn the key clockwise and hold until center position, then turn it the windows and the moonroof are counterclockwise again. completely closed. After the doors and...

  • Page 134: Fuel-Filler Lid And Cap

    CAUTION Always use only a genuine Mazda fuel-filler cap or an approved equivalent, available at an Authorized Mazda Dealer. The wrong cap can result in a serious malfunction of the fuel and emission control systems.
  • Page 135 Knowing Your Mazda Doors and Locks qFuel-Filler Lid CAUTION To open, pull the remote fuel-filler lid If the check fuel cap warning light release. illuminates, the fuel-filler cap may not be properly installed. If the warning light illuminates, park your...

  • Page 136: Hood

    Knowing Your Mazda Doors and Locks 3. Grasp the support rod in the padded Hood area and secure it in the support rod hole indicated by the arrow to hold the WARNING hood open. Always check that the hood is closed...

  • Page 137: Moonroof Í

    Knowing Your Mazda Doors and Locks qClosing the Hood í Moonroof 1. Check under the hood area to make The moonroof can be opened or closed certain all filler caps are in place and electrically only when the ignition is all loose items (e.g.
  • Page 138 After To fully close automatically, momentarily washing your Mazda or after it rains, wipe the press the front of the slide switch or pull water off the moonroof before operating it to the tilt switch.
  • Page 139 Knowing Your Mazda Doors and Locks qEngine-off Moonroof Operation qSunshade The moonroof can be operated for about The sunshade can be opened and closed 40 seconds after the ignition is switched by hand. from ON to ACC or switched off with all doors closed.

  • Page 140: Security System

    Knowing Your Mazda Security System CAUTION Immobilizer System (With Advanced Key) Do not allow the following when starting the engine with the auxiliary The immobilizer system allows the engine key due to an advanced key dead to start only with an advanced key the battery or other malfunction.
  • Page 141 Authorized Mazda Dealer. Always keep a spare advanced key in case one is lost. If an advanced key is lost, consult an Authorized Mazda Dealer as soon as possible. If you lose an advanced key (including auxiliary key), an Authorized Mazda Dealer...
  • Page 142 Knowing Your Mazda Security System Declaration of Conformity Immobilizer system 3-55...
  • Page 143 Go to an Authorized If the engine does not start with the Mazda Dealer and have it checked. If the correct advanced key, and the security engine is shut off while the indicator light is indicator light keeps illuminating or flashing, you will not be able to restart it.

  • Page 144: Immobilizer System (Without Advanced Key)

    Add-On Immobilizer System Equipment (Without Advanced Key) Mazda cannot guarantee the immobilizer system's operation if the system has been The immobilizer system allows the engine modified or if any add-on equipment has to start only with a key the system been installed.
  • Page 145 Ø A key ring rests on the key grip. If a key is lost, contact an Authorized Mazda Dealer as soon as possible. If you lose a key, an Authorized Mazda Dealer will reset the electronic codes of your remaining keys and immobilizer system.
  • Page 146 Knowing Your Mazda Security System Declaration of Conformity Immobilizer system 3-59...
  • Page 147 Disarming shut off the engine. Go to an Authorized The system is disarmed when the ignition Mazda Dealer and have it checked. If you is switched ON with the correct ignition shut off the engine while the light is key.

  • Page 148: Theft-Deterrent System Í

    Knowing Your Mazda Security System NOTE í Theft-Deterrent System If the battery goes dead while the theft- deterrent system is armed, the horn will If the theft deterrent system detects an activate and the hazard warning lights will inappropriate entry into the vehicle, which flash when the battery is charged or replaced.
  • Page 149 Knowing Your Mazda Security System qTo Turn off an Armed System NOTE Auto re-lock function An armed system can be turned off by any After unlocking with the transmitter or the one of the following methods: request switch, all doors and the liftgate Unlock a door with the key.
  • Page 150 Authorized Mazda Dealer. qTheft-Deterrent Labels A label indicating that your vehicle is equipped with a Theft-Deterrent System is in the glove compartment. Mazda recommends that you affix it to the lower rear corner of a front door window. 3-63...

  • Page 151: Steering Wheel And Mirrors

    Knowing Your Mazda Steering Wheel and Mirrors Steering Wheel Mirrors WARNING qOutside Mirrors Never adjust the steering wheel while Check the mirror angles before driving. the vehicle is moving: Mirror type Adjusting the steering wheel while the vehicle is moving is dangerous.
  • Page 152 Knowing Your Mazda Steering Wheel and Mirrors 2. Depress the mirror switch in the NOTE appropriate direction. If the left/right power outside mirror selector switch is in the center position, or the selector Selector switch Outside mirror lever is shifted to a position other than the R position, the outside mirrors return to their on- road position automatically.
  • Page 153 Knowing Your Mazda Steering Wheel and Mirrors qRearview Mirror Reducing glare from headlights WARNING Manual day/night mirror Push the day/night lever forward for day Do not stack cargo or objects higher driving. Pull it back to reduce glare of than the seatbacks: headlights from cars at the rear.
  • Page 154 Knowing Your Mazda Steering Wheel and Mirrors NOTE Do not use glass cleaner or suspend objects on or around the light sensor. Otherwise, light sensor sensitivity will be affected and may not operate normally. Light sensor Light sensor For information regarding the 3 buttons...
  • Page 155 3-68...

  • Page 156: Before Driving Your Mazda

    Before Driving Your Mazda Important information about driving your Mazda. Fuel and Engine Exhaust Precautions ........4-2 Fuel Requirements ..............4-2 Emission Control System ............4-3 Engine Exhaust (Carbon Monoxide) ......... 4-4 Before Starting the Engine ............4-5 Before Getting In ..............4-5 After Getting In .................

  • Page 157: Fuel And Engine Exhaust Precautions

    Fuel with a lower rating could cause the emission control system to lose effectiveness. It could also cause engine knocking and serious engine damage. Your Mazda will perform best with fuel listed in the table. Fuel Octane Rating...

  • Page 158: Emission Control System

    Ø USE ONLY UNLEADED FUEL. Ø Do not drive your Mazda with any sign of engine malfunction. Ø Do not coast with the ignition switched off. Ø Do not descend steep grades in gear with the ignition switched off.

  • Page 159: Engine Exhaust (Carbon Monoxide)

    When inhaled, it can cause loss of consciousness and death. If you smell exhaust gas inside your vehicle, keep all windows fully open and contact an Authorized Mazda Dealer immediately. Do not run the engine when inside an enclosed area: Running the engine inside an enclosed area, such as a garage, is dangerous.

  • Page 160: Before Starting The Engine

    Before Driving Your Mazda Before Starting the Engine Before Getting In After Getting In Be sure the windows, outside mirrors, Are all doors closed and locked? and outside lights are clean. Is the seat adjusted properly? Inspect inflation pressures and Are the inside and outside mirrors condition of tires.

  • Page 161: Driving Tips

    Break-In Period Money-Saving Suggestions No special break-in is necessary, but a few How you operate your Mazda determines precautions in the first 1,000 km (600 how far it will travel on a tank of fuel. Use miles) may add to the performance, these suggestions to help save money on economy, and life of your Mazda.

  • Page 162: Hazardous Driving

    Before Driving Your Mazda Driving Tips For more traction in starting on Hazardous Driving slippery surfaces such as ice or packed snow, use sand, rock salt, chains, qDriving on Slippery Surface carpeting, or other nonslip material WARNING under the front wheels.
  • Page 163 Before Driving Your Mazda Driving Tips qRoll-over qEmergency Maneuvering WARNING WARNING Avoid sharp turns, excessive speed and Do not perform abrupt maneuvers abrupt maneuvers when driving this when driving the vehicle in an vehicle: emergency situation: Sharp turns, excessive speed and...

  • Page 164: Floor Mat

    Before Driving Your Mazda Driving Tips Floor Mat Rocking the Vehicle WARNING WARNING Make sure the floor mats are hooked Do not spin the wheels at more than 56 on the retention pins to prevent them km/h (35 mph), and do not allow...

  • Page 165: Winter Driving

    30 kPa (0.3 kgf/cm , 4.3 psi) or salt. more than recommended on the tire Ask an Authorized Mazda Dealer to pressure label (driver's door frame), but perform the following precautions: never more than the maximum cold-tire Have the proper ratio of antifreeze in pressure shown on the tires.
  • Page 166 If your vehicle is equipped with the tire pressure monitoring system, the system may not function correctly when using tire chains. Install the chains on the front tires only. Do not use chains on the rear tires. Please consult an Authorized Mazda Dealer. 4-11...

  • Page 167: Driving In Flooded Area

    Before Driving Your Mazda Driving Tips Driving In Flooded Area Overloading WARNING WARNING Dry wet brakes by driving very slowly Be careful not to overload your vehicle: and applying the brakes lightly until The gross axle weight rating (GAWR) brake performance returns to normal:...

  • Page 168: Driving On Uneven Road

    Before Driving Your Mazda Driving Tips Driving on Uneven Road Your vehicle's suspension and underbody can be damaged if driven on rough/uneven roads or over speed bumps at excessive speeds. Use care and reduce speed when traveling on rough/uneven roads or over speed bumps.

  • Page 169: Towing

    Never overload vehicle or trailer. Consult an Authorized Mazda Dealer if you need further details. CAUTION Do not tow a trailer during the first 1,000 km (600 miles) of your new Mazda. If you do, you may damage the engine, transaxle, differential, wheel bearings, and other power train components.
  • Page 170 Before Driving Your Mazda Towing TRAILER TOWING-LOAD TABLE Because vehicle weights vary, adjustments must be made to meet the requirements in this table. Model Item Without Towing With Towing Package Package MAX. FRONTAL 2.97 m (32 ft 4.65 m (50 ft AREA Add trailer's weight, load and hitch;...
  • Page 171 Before Driving Your Mazda Towing GVWR: Gross Vehicle Weight Rating WARNING Always keep tow loads within specified limits as indicated in the Trailer Towing-Load Table: Attempting to tow loads greater than those specified is dangerous as it may cause serious handling and performance problems that could result in personal injury or vehicle damage, or both.
  • Page 172 Before Driving Your Mazda Towing WARNING Always make sure the trailer hitch is securely attached before departure: An unsecured trailer hitch is dangerous as it causes greater trailer sway from crosswinds, rough roads or other causes, resulting in loss of control and a serious accident.
  • Page 173 Towing Tips Verify that your Mazda maintains a near-normal attitude when a loaded or unloaded trailer is connected. Do not drive if it has an abnormal front-up or front-down position.
  • Page 174 Stop and re-inspect all lights and connections after driving a short distance. Driving Your Mazda will handle differently with a trailer in tow, so practice turning, backing, and stopping in a traffic-free area. Take time to get accustomed to the extra weight and length.
  • Page 175 Before Driving Your Mazda Towing Ascending a hill Shift into a lower gear to reduce the possibility of overloading or overheating the engine, or both. Descending a hill Shift into a lower gear and use engine compression as a braking effect.
  • Page 176 Before Driving Your Mazda Towing 3. Release the parking brake (also the foot brake) and pull away from the wheel blocks. Stop; apply the parking brake and shift into P. 4. Have a helper retrieve the wheel blocks. Fuel consumption Trailer towing causes higher fuel consumption.
  • Page 177 4-22...
  • Page 178 Driving Your Mazda Explanation of instruments and controls. Starting and Driving ..............5-2 Ignition Switch ................5-2 Starting the Engine ..............5-4 Turning the Engine Off ............. 5-5 Brake System ................5-5 Automatic Transaxle Controls ..........5-11 Power Steering ................ 5-17 í...

  • Page 179: Starting And Driving

    Driving Your Mazda Starting and Driving qIgnition Switch Positions Ignition Switch With advanced Auxiliary key (with advanced key) NOTE When starting the engine using the advanced key, refer to Starting the Engine (page 3-10). When starting the engine with the...
  • Page 180 Driving Your Mazda Starting and Driving NOTE WARNING When the ignition is switched ON, the sound of Do not stop the engine while the the fuel pump motor operating near the fuel vehicle is moving: tank can be heard. This does not indicate an Stopping the engine while the vehicle abnormality.

  • Page 181: Starting The Engine

    Driving Your Mazda Starting and Driving NOTE Starting the Engine In extremely cold weather or after the vehicle has not been driven in several days, NOTE let the engine warm up without operating Engine-starting is controlled by the spark the accelerator.

  • Page 182: Turning The Engine Off

    Turning the Engine Off Brake System WARNING qFoot Brake Do not stop the engine while the Your Mazda has power-assisted brakes vehicle is moving: that adjust automatically through normal Stopping the engine while the vehicle use. is moving for any reason other than in an emergency is dangerous.
  • Page 183 Driving Your Mazda Starting and Driving WARNING CAUTION Ø Do not drive with your foot held Do not coast with the engine stalled or turned off, find a safe place to stop: on the brake pedal. Doing so could Coasting with the engine stalled or result in the following: turned off is dangerous.
  • Page 184 Driving Your Mazda Starting and Driving qParking Brake Setting the parking brake Depress the brake pedal, then depress the WARNING parking brake pedal fully. Before leaving the driver's seat, always switch the ignition to OFF, set the parking brake and make sure the shift...
  • Page 185 System Warning Light NOTE Having to add brake fluid is sometimes an indicator of leakage. Consult an Authorized Mazda Dealer as soon as possible even if the brake light is no longer illuminated. WARNING Do not drive with the brake system warning light illuminated.
  • Page 186 ABS. for unsafe and reckless driving, Should this happen, consult an Authorized excessive speed, tailgating (following Mazda Dealer as soon as possible. another vehicle too closely), driving NOTE on ice and snow, and hydroplaning...
  • Page 187 This causes a loud screeching illuminated. Have the vehicle towed to noise to warn that the pads should be an Authorized Mazda Dealer to have replaced. the brakes inspected as soon as possible:...

  • Page 188: Automatic Transaxle Controls

    Driving Your Mazda Starting and Driving Automatic Transaxle Controls Various Lockouts: Indicates that you must depress the brake pedal to shift (The ignition must be switched to ACC or ON). Indicates the shift lever can be shifted freely into any position.
  • Page 189 Driving Your Mazda Starting and Driving qTransaxle Ranges WARNING The shift lever must be in P or N to If the engine is running faster than idle, operate the starter. do not shift from N or P into a driving...
  • Page 190 Driving Your Mazda Starting and Driving qActive Adaptive Shift (AAS) qManual Shift Mode Active Adaptive Shift (AAS) This mode gives you the feel of driving a automatically controls the transaxle shift manual transaxle vehicle by operating the points to best suit the road conditions and shift lever and allows you to control driver input.
  • Page 191 Driving Your Mazda Starting and Driving Indicators Shifting Manual shift mode indicator Manually Shifting up In manual shift mode, the “M” of the shift (M1 → M2 → M3 → M4 → M5 → M6) position indicator in the instrument panel To shift up to a higher gear, tap the shift illuminates.
  • Page 192 Driving Your Mazda Starting and Driving Manually Shifting down Second gear fixed mode ( M6 → M5 → M4 → M3 → M2 → When the shift lever is tapped back ( while the vehicle is stopped or driven at To shift down to a lower gear, tap the shift about 15 km/h (9.3 mph) or less, the...
  • Page 193 Driving Your Mazda Starting and Driving During deceleration, the gears shift down On a steep downgrade, downshifting automatically when speed is reduced to helps maintain safe speed and prolongs the following: brake life. Gear Vehicle speed qDriving Tips M6 → M5 47 km/h (29 mph) M5 →...

  • Page 194: Power Steering

    Driving Your Mazda Starting and Driving Power Steering All-Wheel Drive (AWD) í Operation Power steering is only operable when the engine is running. If the engine is off or if AWD provides excellent driveability on the power steering system is inoperable,...
  • Page 195 RSC might help if you get into If the AWD warning light illuminates, trouble, but then it might not be able contact an Authorized Mazda Dealer. to allow you to fully recover, always If the AWD warning light flashes: drive carefully with the vehicle's height in mind.
  • Page 196 Driving Your Mazda Starting and Driving Tire chains WARNING Install tire chains to the front tires. Never spin a wheel that is off the Do not use tire chains on the rear ground: wheels. Spinning a wheel that is off the...

  • Page 197: Cruise Control

    Driving Your Mazda Starting and Driving qActivation/Deactivation Cruise Control To activate the system, press the ON With cruise control, you can set and switch. automatically maintain any speed of more The cruise main indicator light than about 30 km/h (19 mph).
  • Page 198 Driving Your Mazda Starting and Driving qTo Increase Cruising Speed 3. Set the cruise control by pressing the cruise control SET /SET - switch up Follow either of these procedures. or down at the desired speed. The cruise control is set at the moment the...
  • Page 199 Driving Your Mazda Starting and Driving Your vehicle has a tap-down feature that To increase speed using accelerator allows you to decrease your current speed pedal in decrements of 1.6 km/h (1 mph) by a Depress the accelerator pedal to accelerate momentary tap of the cruise control SET - to the desired speed.

  • Page 200: Traction Control System (Tcs)

    Driving Your Mazda Starting and Driving Press the CANCEL switch. Traction Control System (TCS) The Traction Control System (TCS) enhances traction and safety by controlling engine torque and braking. When the TCS detects driving wheel slippage, it lowers engine torque and operates the brakes to prevent loss of traction.
  • Page 201 Indicator Light Refer to TCS OFF Switch on page 5-25. If the light remains illuminated and the TCS is not switched off, take your vehicle to an Authorized Mazda Dealer. The dynamic stability control may have a malfunction. NOTE...
  • Page 202 Driving Your Mazda Starting and Driving qTCS OFF Switch NOTE When TCS is on and you attempt to free the If the vehicle speed is less than 15 km/h vehicle when it is stuck, or drive it out of (9 mph), press the TCS OFF switch to freshly fallen snow, the TCS will activate.

  • Page 203: Dynamic Stability Control (Dsc)/Roll Stability Control (Rsc)

    Driving Your Mazda Starting and Driving WARNING Dynamic Stability Control (DSC)/Roll Stability Do not rely on the dynamic stability control as a substitute for safe driving: Control (RSC) The dynamic stability control (DSC)/ Roll Stability Control (RSC) cannot The Dynamic Stability Control (DSC)
  • Page 204 Take your vehicle to an observed: Authorized Mazda Dealer. Ø Use tires of the correct size specified for your Mazda on all four wheels. Ø Use tires of the same manufacturer, brand and tread pattern on all four wheels.

  • Page 205: Tire Pressure Monitoring System

    Driving Your Mazda Starting and Driving í Tire Pressure Monitoring System The tire pressure monitoring system (TPMS) monitors the pressure for each tire. If tire pressure is too low in one or more tires, the system will inform the driver via the warning light in the instrument panel and by the warning beep sound.
  • Page 206 Driving Your Mazda Starting and Driving CAUTION Each tire, including the spare (if provided), should be checked monthly when cold and inflated to the inflation pressure recommended by the vehicle manufacturer on the vehicle placard or tire inflation pressure label. (If your vehicle has tires of a different size than the size indicated on the vehicle placard or tire inflation pressure label, you should determine the proper tire inflation pressure for those tires.)
  • Page 207 Authorized Mazda Dealer or a tire repair station. Do not ignore the TPMS Warning Light: Ignoring the TPMS warning light is dangerous, even if you know why it is illuminated.
  • Page 208 Leaks need to be addressed by more than simply refilling the trouble tire as leaks are dangerous - take it to an Authorized Mazda Dealer which has all the equipment to fix tires, TPMS systems and order the best replacement tire for your vehicle.
  • Page 209 The easiest way to do it is to have an Consult an Authorized Mazda Dealer. Authorized Mazda Dealer change your tire and A system error activation may occur in complete ID signal code registration.
  • Page 210 Replacing tires and wheels CAUTION Ø When replacing/repairing the tires or wheels or both, have the work done by an Authorized Mazda Dealer, or the tire pressure sensors may be damaged. Ø The wheels equipped on your Mazda are specially designed for installation of the tire pressure sensors.

  • Page 211: Blind Spot Monitoring (Bsm) System

    Driving Your Mazda Starting and Driving í Blind Spot Monitoring (BSM) System The Blind Spot Monitoring (BSM) system is designed to assist the driver by monitoring blind spots on both sides of the vehicle to the rear in certain situations such as when changing lanes on roads and freeways.
  • Page 212 Vehicles with lower body height such as sports cars. Have the radar sensors inspected at an Authorized Mazda Dealer if any shock is applied to the rear bumper, even in a minor accident. If the vehicle is driven with a damaged radar sensor, the system may not operate properly resulting in an accident.
  • Page 213 Driving Your Mazda Starting and Driving The following conditions may affect the visibility of the BSM warning lights on the outside mirror, making it difficult to confirm the illumination of the lights: Ice or snow adheres to the surface of the outside mirrors.
  • Page 214 If the ignition is switched off with the BSM consult an Authorized Mazda Dealer. system turned off, the system becomes For repairs or paintwork around the radar operable automatically when the ignition is sensors, or replacement of the bumper, switched ON.
  • Page 215 Driving Your Mazda Starting and Driving qSafety Certification Radiation Hazard This BSM (blind spot monitoring) device emits intentional electromagnetic radiation in the 24 GHz to 25 GHz frequency range. The total radiated average power over the entire bandwidth is below _ 14 dBm (40 μW). The active emitting antenna surface is 72 cm therefore the radiated power density in front of the BSM device is 0.55 μW/cm...
  • Page 216 Driving Your Mazda Starting and Driving NOTE During printing time of this user manual the approvals listed above are granted. Further countries may become available or actual certification identifiers may be subject to change or update. WARNING Changes or modifications not expressively approved by the party responsible for compliance could void the user's authority to operate the equipment.

  • Page 217: Parking Sensor System

    Driving Your Mazda Starting and Driving Parking Sensor System The parking sensor system uses ultrasonic sensors to detect obstructions around the vehicle while parking the vehicle in a garage or during parallel parking when the vehicle is driven at a speed of about 10 km/h (6 mph) or less. The system is equipped with an assist device to notify the driver of the approximate distance from the vehicle to the surrounding obstruction using a beep sound.
  • Page 218 Very tall objects, and those which are wide at the top Small, short objects Always have the system inspected at an Authorized Mazda Dealer if any shock is applied to the bumpers, even in a minor accident. If the sensors are deviated, they cannot detect obstructions.
  • Page 219 Driving Your Mazda Starting and Driving qSensor Detection Range The sensors detect obstructions within the following range. Unit: cm (in) A: About 150 (About 59.1) Rear corner sensor detection range B: About 150 (About 59.1) Rear sensor detection range qPark Assist Sensors Switch The switch can be used when the ignition is switched ON, the shift lever is in any position except reverse (R), and the vehicle speed is about 10 km/h (6 mph) or less.
  • Page 220 Driving Your Mazda Starting and Driving Operation Conditions The system can be used when the ignition is switched ON. The sensors detect obstructions under the following conditions: Sensor Condition Rear Sensor The shift lever is in reverse (R). Rear Corner Sensor The shift lever is in reverse (R), and the vehicle speed is about 10 km/h (6 mph) or less.
  • Page 221 How to check The system may have a malfunction. Have the vehicle inspected at an Authorized The beep sound is not heard. Mazda Dealer as soon as possible. 1 consecutive beep Corner Left Sensor Remove any foreign material from the sensor area. If...

  • Page 222: Instrument Cluster And Indicators

    Driving Your Mazda Instrument Cluster and Indicators Meters and Gauges Speedometer ...................... page 5-46 Odometer, Trip Meter and Trip Meter Selector ..........page 5-46 Tachometer ......................page 5-47 Engine Coolant Temperature Gauge ..............page 5-47 Fuel Gauge ......................page 5-48 Dashboard Illumination ..................
  • Page 223 Driving Your Mazda Instrument Cluster and Indicators qSpeedometer The speedometer indicates the speed of the vehicle. qOdometer, Trip Meter and Trip Trip meter A Meter Selector Odometer The display mode can be changed between trip meter A and trip meter B by...
  • Page 224 Driving Your Mazda Instrument Cluster and Indicators qEngine Coolant Temperature Gauge The trip meter records the total distance the vehicle is driven until the meter is The engine coolant temperature gauge again reset. Return it to “0.0” by holding shows the temperature of the engine the selector depressed for 1 second or coolant.
  • Page 225 Driving Your Mazda Instrument Cluster and Indicators qFuel Gauge The fuel gauge shows approximately how much fuel is remaining in the tank when the ignition is switched ON. We recommend keeping the tank over 1/4 full. When the low fuel warning light...

  • Page 226: Warning/Indicator Lights And Beep Sounds

    Driving Your Mazda Warning/Indicator Lights and Beep Sounds Warning/Indicator Lights Warning/Indicator lights will appear in any of the highlighted areas Signal Warning/Indicator Lights Page Brake System Warning Light 5-51 Malfunction Warning Light 5-52 Charging System Warning Light 5-53 Engine Oil Pressure Warning Light...
  • Page 227 Driving Your Mazda Warning/Indicator Lights and Beep Sounds Signal Warning/Indicator Lights Page Low Fuel Warning Light 5-55 Check Fuel Cap Warning Light 5-55 Seat Belt Warning Light 5-55 Door-Ajar Warning Light 5-55 Low Washer Fluid Level Warning Light 5-55 Automatic Transaxle Warning Light...
  • Page 228 Parking brake warning indicator of leakage. Consult an Authorized The light illuminates when the parking Mazda Dealer as soon as possible even if the brake is applied with the ignition switched brake light is no longer illuminated. to START or ON. It turns off when the WARNING parking brake is fully released.
  • Page 229 ABS. Should this happen, consult an Authorized Mazda Dealer as soon as possible. NOTE When the engine is jump-started to charge This warning light illuminates for a few...
  • Page 230 WARNING Do not drive with both the ABS warning light and brake warning light illuminated. Have the vehicle towed to an Authorized Mazda Dealer to have the brakes inspected as soon as possible: Driving when the brake system This warning light illuminates when the...
  • Page 231 The fuel tank level being very low or switched ON. If any of these occur, approaching empty. consult an Authorized Mazda Dealer as The engine's electrical system has a soon as possible. The system may not problem.
  • Page 232 Driving Your Mazda Warning/Indicator Lights and Beep Sounds qLow Fuel Warning Light qDoor-Ajar Warning Light Low fuel warning light This warning light in the fuel gauge This warning light illuminates when any signals that the fuel tank will soon be door or liftgate is not securely closed.
  • Page 233 If the an electrical problem. Continuing to light does not stop flashing, contact an drive your Mazda in this condition Authorized Mazda Dealer. could cause damage to your WARNING transaxle. Consult an Authorized Mazda Dealer as soon as possible.
  • Page 234 When replacing/repairing the tires or immediately and avoid sudden wheels or both, have the work done maneuvering and braking: by an Authorized Mazda Dealer, or If the tire pressure monitoring system the tire pressure sensors may be warning light illuminates or flashes, damaged.
  • Page 235 - take it to an Authorized Mazda Dealer which has all the equipment to fix tires, TPMS systems and order the best replacement tire for your vehicle.
  • Page 236 Have the vehicle The start knob has not been returned inspected at an Authorized Mazda to the OFF position, the driver's Dealer as soon as possible. door is open, and the advanced key is removed from the vehicle.
  • Page 237 Driving Your Mazda Warning/Indicator Lights and Beep Sounds qHeadlight High-Beam Indicator NOTE The advanced key can be set so that the KEY Light indicator light (green) does not flash even if the battery power is low. Refer to Personalization Features on page 10-8.
  • Page 238 If the light remains illuminated and the seconds when the ignition is switched TCS is not switched off, take your vehicle ON. If the TCS or DSC/RSC is operating, to an Authorized Mazda Dealer. The the indicator light flashes. dynamic stability control may have a malfunction.
  • Page 239 Driving Your Mazda Warning/Indicator Lights and Beep Sounds qLights-On Indicator Light Cruise Main Indicator Light (Amber) The indicator light illuminates amber when the ON switch is pressed and the cruise control system is activated. Cruise Set Indicator Light (Green) The indicator light illuminates green when a cruising speed has been set.

  • Page 240: Beep Sounds

    35 minutes. Have your vehicle inspected at an If the ignition is switched off or the Authorized Mazda Dealer as soon as ignition is switched to ACC with the key possible. inserted, a continuous beep sound will be heard when the driver's door is opened.
  • Page 241 The warning beep operates when the turn signal lever is operated to the side where the BSM warning light is illuminated. NOTE The system can be personalized so that the BSM warning beep does not operate. Consult an Authorized Mazda Dealer. í 5-64 Some models.

  • Page 242: Switches And Controls

    Driving Your Mazda Switches and Controls Lighting Control qHeadlights Turn the headlight switch to turn the headlights, other exterior lights and dashboard illumination on or off. NOTE To prevent discharging the battery, do not leave the lights on while the engine is off unless safety requires them.
  • Page 243 Driving Your Mazda Switches and Controls Type A Switch Position Type B Headlights Taillights Parking lights License lights Side-marker lights Dashboard illumination With AUTO position Type A Type B 5-66...
  • Page 244 Driving Your Mazda Switches and Controls ― Type A Switch Position ― Type B Headlights Taillights Parking lights Auto Auto License lights Side-marker lights Dashboard illumination AUTO (Auto-light control) When the headlight switch is in the AUTO position and the ignition is switched ON, the light sensor senses the surrounding lightness or darkness and automatically turns the headlights, other exterior lights and dashboard illumination on or off (see chart above).
  • Page 245 To adjust the brightness of the dashboard illumination: Refer to Dashboard Illumination on page 5-48. The sensitivity of the AUTO lights may be changed by an Authorized Mazda Dealer. Refer to Personalization Features on page 10-8.
  • Page 246 Driving Your Mazda Switches and Controls qFlashing the Headlights Type A To flash the headlights, pull the lever fully towards you (the headlight switch does not need to be on). The lever will return to the normal position when released.
  • Page 247 Driving Your Mazda Switches and Controls í í qHeadlight Leveling qDaytime Running Lights The number of passengers and weight of Some countries require moving vehicles cargo in the luggage compartment change to have their lights on (daytime running the angle of the headlights.

  • Page 248: Turn And Lane-Change Signals

    Driving Your Mazda Switches and Controls Lane-change signals Turn and Lane-Change Move the lever slightly toward the Signals direction of the change ―until the indicator flashes― and hold it there. It Turn Signals will return to the off position when Move the signal lever down (for a left released.

  • Page 249: Fog Lights Í

    Driving Your Mazda Switches and Controls NOTE í Fog Lights The fog lights will turn off when the headlights are set at high beam. Use this switch to turn on the fog lights. (With auto-light control) The fog lights will improve visibility at If the fog light switch is in the ON position night and during foggy conditions.

  • Page 250: Windshield Wipers And Washer

    Authorized could result in an accident. Mazda Dealer as soon as possible. Drive to the side of the road and park off the right-of- Only use windshield washer fluid way. Wait until the weather clears before trying mixed with anti-freeze protection in to drive with the wipers inoperative.
  • Page 251 Driving Your Mazda Switches and Controls Type A Switch Position Wiper operation Type Type Single wipe cycle (mist) Intermittent Low speed High speed With AUTO position INT ring Type B INT ring Switch Position Wiper operation Type Type Single wipe cycle (mist)
  • Page 252 Driving Your Mazda Switches and Controls Type A CAUTION Ø Do not shade the rain sensor by Higher sensitivity adhering a sticker or a label on the windshield. Otherwise the rain Switch sensor will not operate correctly. Center position Rain sensor...
  • Page 253 Driving Your Mazda Switches and Controls Ø When the wiper lever is in the NOTE AUTO position and the ignition is Switching the auto-wiper lever from the switched ON, the wipers may OFF to the AUTO position while driving at...

  • Page 254: Rear Window Wiper And Washer

    Type B If the washer does not work, inspect the fluid level (page 8-26). If it's normal, consult an Authorized Mazda Dealer. Turn the wiper on by turning the rear wiper/washer switch. ON ― Normal INT ― Intermittent...

  • Page 255: Rear Window Defroster

    Driving Your Mazda Switches and Controls qRear Window Washer Rear Window Defroster To spray washer fluid, turn the rear wiper/ The rear window defroster clears frost, washer switch to the position. After fog, and thin ice from the rear window.

  • Page 256: Horn

    Driving Your Mazda Switches and Controls í qMirror Defroster Horn To turn on the mirror defrosters, switch To sound the horn, press the mark on the ignition ON and press the rear window the steering wheel. defroster switch (page 5-78).

  • Page 257: Hazard Warning Flasher

    Driving Your Mazda Switches and Controls Hazard Warning Flasher The hazard warning lights should always be used when you stop on or near a roadway in an emergency. The hazard warning lights warn other drivers that your vehicle is a traffic hazard and that they must take extreme caution when near it.

  • Page 258: Homelink Wireless Control System

    Driving Your Mazda Switches and Controls í HomeLink Wireless Control System There are two types of HomeLink Wireless Control systems; type A and B. Check the indication on the backside of the rearview mirror and the description corresponding to your vehicle.
  • Page 259 Driving Your Mazda Switches and Controls NOTE WARNING FCC ID: NZLMOBHL4 Do not use the HomeLink system with CANADA: 4112A-MOBHL4 any garage door opener that lacks the This device complies with part 15 of the FCC safety stop and reverse feature: Rules.
  • Page 260 Driving Your Mazda Switches and Controls The HomeLink system provides 3 buttons NOTE which can be individually selected and To program the remaining two HomeLink buttons, begin with “Programming”― step 1. programmed using the transmitters for current, on-market devices as follows: If the indicator light blinks rapidly for 1.
  • Page 261 Driving Your Mazda Switches and Controls Gate operator/Canadian Programming Reprogramming the HomeLink system Canadian radio-frequency laws require To program a device to HomeLink using a transmitter signals to “time-out” (or quit) HomeLink button previously trained, after several seconds of transmission ―...
  • Page 262 Driving Your Mazda Switches and Controls The HomeLink system replaces up to 3 WARNING hand-held transmitters with a single built- Do not use the HomeLink system with in component in the auto-dimming mirror. any garage door opener that lacks the...
  • Page 263 Driving Your Mazda Switches and Controls The HomeLink system provides 3 buttons NOTE which can be individually selected and FCC ID: NZLOBIHL3 programmed using the transmitters for CANADA:4112A-OBIHL3 current, on-market devices as follows: This device complies with FCC rules part 15.
  • Page 264 Driving Your Mazda Switches and Controls 5. Press and hold the just-trained HomeLink should now activate your HomeLink button and observe the rolling code equipped device. indicator light. NOTE If the indicator light stays on constantly, To program the remaining two HomeLink buttons, begin with “Programming”―...
  • Page 265 Driving Your Mazda Switches and Controls Operating the HomeLink System Press the programmed HomeLink button to operate a programmed device. The code will continue being transmitted for a maximum of 20 seconds. Reprogramming the HomeLink system To program a device to HomeLink using a...

  • Page 266: Interior Comfort

    Interior Comfort Use of various features for drive comfort, including air-conditioning and audio system. Climate Control System ......6-2 Rear View Monitor ......6-151 í Operating Tips ........6-2 Rear View Monitor ...... 6-151 Vent Operation (Front) ......6-4 Fully Automatic Type ......6-6 Interior Equipment ......
  • Page 267 It is necessary to change the filter periodically as indicated qOutside/Recirculated Air Position in scheduled maintenance (page 8-4). Consult an Authorized Mazda Dealer for Use the outside air position in normal replacement of the cabin air filter. conditions. The recirculated air position...

  • Page 268: Climate Control System

    Interior Comfort Climate Control System qSunlight/Temperature Sensor The fully automatic air conditioner function measures inside and outside temperatures, and the intensity of direct sunlight. It then sets temperatures inside the passenger compartment accordingly. CAUTION Do not obstruct either sensor, otherwise the automatic air conditioner will not operate properly.

  • Page 269: Vent Operation (Front)

    Interior Comfort Climate Control System Vent Operation (Front) Open Open Close Close qAdjusting the Vents Directing airflow You can direct air flow by moving the adjustment knob. Opening/closing vents The two outside vents can be opened and closed with wheel. NOTE When using the air conditioner, mist may come out from the vents.
  • Page 270 Interior Comfort Climate Control System qSelecting the Airflow Mode Dashboard Vents Defroster and Floor Vents Defroster Vents Dashboard and Floor Vents Floor Vents...

  • Page 271: Fully Automatic Type

    Interior Comfort Climate Control System Fully Automatic Type Climate control information is displayed on the information display. Information display Air intake display AUTO DUAL Airflow display Mode selector display Ambient temperature /Temperature setting display (front passenger) Temperature setting display (driver) Windshield defroster switch Air intake selector Driver temperature control dial...
  • Page 272 Interior Comfort Climate Control System qControl Switches Pressing the OFF switch shuts off the climate control system. AUTO switch Temperature control dial Cold By pressing the AUTO switch the This dial controls temperature. Turn it following functions will be automatically clockwise for hot and counterclockwise controlled in accordance with the selected for cold.
  • Page 273 Interior Comfort Climate Control System Mode selector switch NOTE The air conditioning operates when the A/C switch is pressed even if the fan is off. The air conditioner may not function when the outside temperature approaches 0 °C (32 °F). (Indicator light remains on even when system is off.) Air intake selector The desired airflow mode can be selected...
  • Page 274 Interior Comfort Climate Control System OUTSIDE (Ambient Temperature) Individual operation mode (indicator switch light illuminated) The set temperature can be controlled individually for the driver and front passenger. Interconnection mode (indicator light turned off) The set temperature for the driver and front passenger is controlled simultaneously.
  • Page 275 Interior Comfort Climate Control System NOTE NOTE In the position, the air conditioner is Setting the temperature to the maximum automatically turned on and the mode is high or low will not provide the desired automatically selected to defrost the temperature at a faster rate.
  • Page 276 Interior Comfort Climate Control System NOTE Press the windshield defroster switch to change the mode to the interconnection mode automatically. The system does not change to the individual operation mode by pressing the DUAL switch or turning the front passenger temperature control dial. Use the temperature control dial to increase the air flow temperature and defog the windshield more quickly.

  • Page 277: Vent Operation (Rear)

    Interior Comfort Climate Control System Vent Operation (Rear) qAdjusting the Vents Directing airflow You can direct air flow by moving the adjustment knob. NOTE When using the air conditioner, mist may come out from the vents. This is not a sign of trouble but a result of humid air being suddenly cooled.
  • Page 278 Interior Comfort Climate Control System qSelecting the Airflow Mode For vehicles with rear full-auto air conditioning, the airflow mode can be selected according to the purpose of use. Instrument panel Vents Floor Vents Instrument panel and Floor Vents 6-13...

  • Page 279: Fully Automatic Type (Rear)

    Interior Comfort Climate Control System Fully Automatic Type (Rear) Front AUTO switch REAR switch Rear Mode selector display AUTO SYNC Temperature setting display Rear airflow display Temperature control Fan control switch switch OFF switch AUTO switch Mode selector switch qControl Switches AUTO switch Rear switch Press the rear switch to operate the rear air...
  • Page 280 Interior Comfort Climate Control System Amount of airflow Mode selector switch Selection of airflow mode OFF switch The desired airflow mode can be selected (page 6-13). Pressing the OFF switch shuts off the qOperation of Automatic Air climate control system. Conditioning Temperature control switch Operation from front seats...
  • Page 281 Interior Comfort Climate Control System NOTE NOTE If the AUTO switch is pressed while the If the AUTO switch is pressed while the front A/C switch is off, the rear air front A/C switch is off, the rear air conditioning operates only to circulate air. conditioning operates only to circulate air.

  • Page 282: Audio System

    Interior Comfort Audio System Antenna Operating Tips for Audio System qAM/FM Radio Antenna WARNING The antenna is printed onto the window glass. Do not adjust the audio control switches while driving the vehicle: CAUTION Adjusting the audio while driving the When washing the inside of the vehicle is dangerous as it could window which has an antenna, use a...
  • Page 283 Interior Comfort Audio System qRadio Reception Signals from an FM transmitter are similar to beams of light because they do not AM characteristics bend around corners, but they do reflect. AM signals bend around such things as Unlike AM signals, FM signals cannot buildings or mountains and bounce off the travel beyond the horizon.
  • Page 284 Interior Comfort Audio System Flutter/Skip noise Strong signal noise Signals from an FM transmitter move in This occurs very close to a transmitter straight lines and become weak in valleys tower. The broadcast signals are between tall buildings, mountains, and extremely strong, so the result is noise and other obstacles.
  • Page 285 Interior Comfort Audio System qOperating Tips for CD Player The CD revolves at high speed within the unit. Defective (cracked or badly Condensation phenomenon bent) CDs should never be used. Immediately after turning on the heater when the vehicle is cold, the CD or optical components (prism and lens) in the CD player may become clouded with condensation.
  • Page 286 Interior Comfort Audio System A new CD may have rough edges on Use discs that have been legitimately its inner and outer perimeters. If a disc produced. If illegally-copied discs such with rough edges is used, proper as pirated discs are used, the system setting will not be possible and the CD may not operate properly.
  • Page 287 Interior Comfort Audio System qOperating tips for MP3 Do not insert any disc with a peel-off seal affixed to it. NOTE This unit may not be able to play Supply of this product only conveys a license certain CD-R/CD-RWs made using a for private, non-commercial use and does not computer or music CD recorder due to convey a license nor imply any right to use this...
  • Page 288 Interior Comfort Audio System If a disc has both music data (CD-DA) Folder and MP3 files, playback of the two file : Folder : Track (File) types differs depending on how the disc was recorded. Packet written discs cannot be played on this unit.

  • Page 289: Caution

    Interior Comfort Audio System The number of characters which can be Multi-session displayed is restricted. A session is the complete amount of data recorded from the beginning to the end of CAUTION a single period of CD-ROM, CD-R/CD- This unit can only play MP3 files that RW data recording.

  • Page 290: Could Result In Noise Or A

    Interior Comfort Audio System WMA files written under specifications other than the indicated specification Abbreviation for Variable Bit Rate. While may not play normally or files or folder CBR (Constant Bit Rate) is generally names may not display correctly. used, VBR varies the bit rate for audio The file extension may not be provided compression according to compression depending on the computer operating...

  • Page 291: Audio System

    Interior Comfort Audio System qOperating Tips for USB device Song, artist, and album name information in the AAC file is recorded This unit supports playback of MP3/ as data termed WMA/AAC files recorded to USB device. “iTunes, m4a, Meta-Data applicable”, and this information is displayable.

  • Page 292: Playable Aac File Specifications

    Interior Comfort Audio System Playable MP3 file specifications Playable WMA file specification Playable MP3 files are as follows: Playable WMA files are as follows: Item Content Item Content MPEG1 AUDIO LAYER Windows Media Audio Specification Version 7.0, 8.0, 9.0 MPEG2 AUDIO LAYER Specification (standard) 8/11.025/12 kHz (LOW)
  • Page 293 Ø If data in the iPod is lost while it is qOperating Tips for iPod connected to the unit, Mazda cannot guarantee recovery of any This unit supports playback of music files lost data.

  • Page 294: Audio Set

    Interior Comfort Audio System Audio Set CAUTION Do not press the panel strongly or press it with a sharp-pointed object. Otherwise, the panel could be damaged. Power/Volume/Display/Sound Controls ............page 6-30 Operating the Radio ................... page 6-34 Operating the Satellite Radio ................page 6-38 Operating the Compact Disc (CD) Player ............
  • Page 295 Interior Comfort Audio System qPower/Volume/Display/Sound Controls Audio button Setup button Phone button Navigation button Power/Volume Audio control dial dial Power ON/OFF Contrast adjustment Switch the ignition to ACC or ON. : Higher contrast Press the power/volume dial to turn the : Lower contrast audio system on.
  • Page 296 Interior Comfort Audio System 2. Touch the on-screen button. Daytime/nighttime screen setting The daytime or nighttime screen can be Audio sound adjustment selected even if the headlights are Press the audio control dial or touch the illuminated or turned off (when bright on-screen button to display the screen is required at night or dark screen sound setting screen.
  • Page 297 Interior Comfort Audio System ® AudioPilot ® AudioPilot 2 automatically adjusts audio volume and sound quality in accordance with the level of noise entering the vehicle ® interior while driving. When AudioPilot 2 is turned on, the system automatically calculates the conditions for optimum hearing of sound which may be difficult to hear depending on exterior noise.
  • Page 298 MEMO 6-33...
  • Page 299 Interior Comfort Audio System qOperating the Radio Audio button Seek tuning buttons Manual tuning dial Radio ON (Unconnected Satellite Radio) Touch the on-screen tab to select (Connected Satellite Radio) AM. Touch the on-screen tab to Press the audio button ( ) and touch select FM1 and FM2.
  • Page 300 Interior Comfort Audio System 3. Repeat this operation for the other Manual tuning stations and bands you want to store. Turning the manual tuning dial will When receiving a programmed change the frequency higher or lower. frequency, select AM, FM1, or FM2 NOTE and touch the preset on-screen button.
  • Page 301 Interior Comfort Audio System NOTE NOTE Radio text information is a function of FM Only one Genre can be selected. radio. Text information is not displayed in the Touch the on-screen button to following: return to the FM1 or FM2 main screen. During reception It may not be possible to receive any station...
  • Page 302 Interior Comfort Audio System Benefits of HD Radio™ Technology NOTE If an analog broadcast is received once and (Information) is received while HD1 is The song title, artist name and genre will selected, the audio unit switches to the appear on the screen when available by station automatically.
  • Page 303 Interior Comfort Audio System í qOperating the Satellite Radio Audio button Seek tuning buttons Manual tuning dial NOTE What is satellite radio? This equipment has been tested and found to With over 130 channels, SIRIUS Satellite comply with the limits for a Class B digital Radio brings you more of what you love.
  • Page 304 SIRIUS radio mode selection Exclusive to Sirius. If your vehicle is equipped Touch the on-screen tab on the with Sirius, your new Mazda includes a free audio screen to receive the previously introductory subscription with a limited term received SIRIUS channel.
  • Page 305 Interior Comfort Audio System 2. Long-press any of the preset on-screen NOTE buttons. Do not perform the following operation while “Updating Channels XXX %”, NOTE “Updating Receiver” is displayed. Otherwise, Six stations can be stored in each bank, the updating procedure will be canceled. SIRIUS1, SIRIUS2 and SIRIUS3 for Turning off the audio power convenient access to your favorite stations.
  • Page 306 Interior Comfort Audio System When the on-screen button is Scan tuning touched, playback starts from the Touch the on-screen button to beginning of the current program. automatically sample stations. Scanning When the on-screen button is stops at each station for about five touched twice, playback starts from the seconds.
  • Page 307 Interior Comfort Audio System NOTE Parental unlock Touch the on-screen button during Channels locked using the parental lock all the settings to return to the previous function can be unlocked. display. 1. Select a channel to be unlocked by Touch the on-screen button during the turning the manual tuning dial.
  • Page 308 Interior Comfort Audio System 4. After inputting the four digits, touch NOTE on-screen button to confirm Master code: the four digits. The Master Code is used to initialize or re- initialize the code in the event that the code is 5.
  • Page 309 Interior Comfort Audio System Storing songs, artists, and sports team Seek alert setting names On or off switching to song seek, artist seek, or game alert function, and deletion NOTE of stored information can be performed. A maximum of 10 songs, artists, and sports Touch the on-screen button and the team names each can be stored.
  • Page 310 MEMO 6-45...
  • Page 311 Interior Comfort Audio System qOperating the Compact Disc (CD) Player CD eject button CD slot Audio button Track up/Fast- forward button Track down/ Reverse button File dial Ejecting the CD Type Playable data Press the CD eject button ( ) to eject the Music data (CD-DA) Music/MP3/WMA/ MP3/WMA/AAC file...
  • Page 312 Interior Comfort Audio System Fast-forward/Reverse Displaying file list The desired file list in the CD can be Operations using audio panel viewed. Press and hold the fast-forward button ) to advance through a track at high During music CD playback speed.
  • Page 313 Interior Comfort Audio System (Selection from inside folder in which a Repeat playback song is currently being played) During music CD playback 1. Press the on-screen button to Touch the on-screen button during select the song list. playback to play the song currently being ”...

  • Page 314: Usb Port

    Use a commercially-available, non- NOTE impedance (3.5 ) stereo mini plug cable. on-screen button is displayed only Contact an Authorized Mazda Dealer for if a whole title cannot be displayed at one details. time. In addition, audio can be played from the...

  • Page 315: Audio Control Switch Operation

    The talk button, pick-up button, and hang- up button are operable with the audio unit turned off. Mazda has installed this system to prevent distraction while driving the vehicle and using audio controls on the dashboard. Always make safe driving your first priority.
  • Page 316 Interior Comfort Audio System qAdjusting the Volume (Radio) Press and hold the seek switch in the up or To increase the volume, press up the down position to seek all usable stations volume switch. at a higher or lower frequency whether programmed or not.

  • Page 317: Aux/Usb/Ipod Mode

    A commercially-available, non-impedance device, noise may occur when the (3.5 ) stereo mini plug cable is required. device is connected to the vehicle Contact an Authorized Mazda Dealer for accessory socket. (If noise occurs, details. do not use the accessory socket.)
  • Page 318 Interior Comfort Audio System NOTE Connecting with connector cable Before using the auxiliary jack /USB port, 1. Open the console lid. refer to the instruction manual for the portable audio device. 2. Pass the connection plug cord through (With auxiliary jack) the cutout of the console and insert the Use a commercially-available, non- plug into the auxiliary jack.
  • Page 319 Interior Comfort Audio System qHow to use AUX mode 1. Switch the ignition to ACC or ON. 2. Press the power/volume dial to turn the audio system on. 3. Press the audio button ( ) to display the audio screen. 4.
  • Page 320 MEMO 6-55...
  • Page 321 Interior Comfort Audio System qHow to use USB mode Audio button Track up/Fast- forward button Track down/ Reverse button Power/Volume File dial dial NOTE Type Playable data Some devices such as smart phones may USB mode MP3/WMA/AAC file require a setting change to allow USB Playback operation.
  • Page 322 Interior Comfort Audio System Fast-forward/Reverse Displaying song list The song list in the USB device can be Operations using audio panel viewed. Press and hold the fast-forward button NOTE ) to advance through a track at high speed. The song list may not display depending on the Press and hold the reverse button ( ) to conditions.
  • Page 323 USB device or there is an error in the USB device. Verify that the content recorded in the USB device has MP3/ WMA/AAC files and re-connect correctly. If the message reappears, have the unit checked by an Authorized Mazda Dealer. 6-58...
  • Page 324 MEMO 6-59...
  • Page 325 Interior Comfort Audio System qHow to use iPod mode Audio button Track up/Fast- forward button Track down/ Reverse button Power/Volume File dial dial The connectable iPods are as follows: 4. Touch the on-screen tab to iPod: 5G switch to the iPod mode and start iPod classic playback.
  • Page 326 Interior Comfort Audio System Touch the on-screen button after a Fast-forward/Reverse few seconds (depends on iPod software Operations using audio panel version) have elapsed to start playback Press and hold the fast-forward button from the beginning of the current track. ) to advance through a track at high Displaying song list speed.
  • Page 327 Touch the on-screen button two correctly. If the message reappears, have times while “ ” is displayed to cancel. the unit checked by an Authorized Mazda Dealer. (Shuffling album in list being played) Touch the on-screen button two qError Indications times during playback.

  • Page 328: Safety Certification

    Ø This CD player should not be adjusted or repaired by anyone except qualified service personnel. If servicing is required, contact an Authorized Mazda Dealer. Ø Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous laser exposure. Never operate the CD player with the top case of the unit removed.

  • Page 329: Rear Entertainment System

    Interior Comfort Rear Entertainment System í Rear Entertainment System Monitor screen release knob DISC IN indicator light Disc slot Eject button Wireless headphone signal transmitter/Remote Monitor screen control signal receiver qRear Entertainment System Outline The Rear Entertainment System has a 9.0-inch wide LCD, as well as DVD video, DVD audio, video CD, audio CD, and MP3/WMA CD playback functions.
  • Page 330 If any problem occurs, such as a foreign material penetration, spilled liquid, smoking from internal burning, or other abnormal smells, stop operation immediately and consult an Authorized Mazda Dealer. If operation is continued, it may cause an accident, fire, or electrical shock.
  • Page 331 Interior Comfort Rear Entertainment System qOperating Tips for Disc Playable discs DVD video, DVD audio , video CD, audio CD, CD-R, CD-RW, DVD-R and DVD-RW can be played. NOTE It may not be possible to play DVD video, DVD audio, video CD, audio CD, and MP3/WMA CD according to the procedures indicated in these instructions if the playback conditions have been restricted by the producer.

  • Page 332: Dolby Digital

    Interior Comfort Rear Entertainment System Recording method and disc Playable DVD Applicable digital sound size DVD video Region code must include DVD videos bearing the following logo can be “1” or “ALL”. Dolby digital played. NTSC (National Television Sys- tem Committee) recorded type.
  • Page 333 Interior Comfort Rear Entertainment System Unplayable discs Discs not bearing the logo mark indicated in the above table. Discs not including “1” or “ALL” in region code. Discs recorded in other than NTSC (e.g. PAL or SECAM). DVD-ROM, DVD-RAM, DVD RW, CD-ROM, CDV, CD-G, CVD, VSD, SVCD, SACD, photo CDs, non-conventional discs (e.g.
  • Page 334 Interior Comfort Rear Entertainment System A new disc may have rough edges on its inner and outer perimeters. If a disc with rough edges is used, proper setting will not be possible and the unit will not play the disc. Remove the rough edges in advance by using a ball-point pen or pencil as shown below.
  • Page 335 Interior Comfort Rear Entertainment System Playable DISC specification CD-R and CD-RW including MP3/WMA files can be played with this unit. Discs which conform to the following formats can be played. Name Standard Explanation Level 1 ISO9660 Level 2 CD-R, CD-RW format Joliet ISO9660 extension Romeo...
  • Page 336 Interior Comfort Rear Entertainment System This unit corresponds to multi-session recorded disc playback at a maximum of 49 sessions. Some data on multi-session recorded discs cannot be played. Playback of discs with added sessions is possible. Packet Write recorded discs cannot be played. This unit does not correspond to MP3i (MP3 interactive), MP3 PRO, and RIFF-style MP3 formats.
  • Page 337 Interior Comfort Rear Entertainment System Playable WMA file specification CD-R and CD-RW including WMA files can be played with this unit. Discs which conform to the following formats can be played. Playable WMA files are as follows: Item Content Specification Windows Media Audio Version7.0 22.05kHz .
  • Page 338 Interior Comfort Rear Entertainment System qOperation Tips for Headphones To listen to audio other than from the speakers of the Rear Entertainment System, it is necessary to use the wireless headphones that are included. Specification Item Content Transmission system Infrared light Modulation system Frequency modulation Carrier frequency...

  • Page 339: Part Names

    Interior Comfort Rear Entertainment System Part Names qRear Entertainment System Main Unit Monitor screen release knob DISC IN indicator light Disc slot Eject button Wireless headphone signal transmitter/Remote Monitor screen control signal receiver 6-74...
  • Page 340 Interior Comfort Rear Entertainment System qRemote Controller Name Name RETURN button PLAY button MENU button Slow playback button ENTER/Select button POWER button STOP button SOURCE button PAUSE button Picture adjust mode button Fast-forward button Picture adjust button Rewind button SET UP button PREVIOUS (Track down) button Number keys NEXT (Track up) button...
  • Page 341 Interior Comfort Rear Entertainment System qHeadphone Power button Volume dial Power indicator L (left) side R (right) side Infrared receiver 6-76...

  • Page 342: Before Operation

    Interior Comfort Rear Entertainment System Before Operation qDisplay Opening/Closing NOTE If the display is closed while the power is CAUTION on, it automatically turns off. The display locks in two positions when Ø Close the display while the Rear opened to 100 or 120-degrees. Entertainment System is not in use.
  • Page 343 Interior Comfort Rear Entertainment System Inserting the disc NOTE When the eject button is pressed, the disc is Insert the disc into the disc slot with the ejected halfway. label-side up. A disc can be ejected with the Rear Entertainment System turned off. qPicture Adjustment The brightness (BRIGHT), color adjustment (TINT), color density...
  • Page 344 Interior Comfort Rear Entertainment System Picture adjust button ( ): Darken Picture adjust button ( ): Lighten Adjusting the color adjustment Adjusting the contrast (definition) 1. Press the picture adjustment mode 1. Press the picture adjustment mode button (PICTURE) and select the TINT button (PICTURE) and select the mode.
  • Page 345 Interior Comfort Rear Entertainment System Full screen Cinema screen Image is displayed on the full screen. The image is enlarged upward and downward. A 4:3 and 16:9 screen ratio image are displayed with the upper/lower part of the image cut off. NOTE Because images are enlarged lengthwise for display, a horizontal streak may be seen,...
  • Page 346 Interior Comfort Rear Entertainment System qRemote Controller Using the remote controller A battery has already been installed in the Operate the Rear Entertainment System remote controller. with the remote controller except for disc Remove the electrical leak-protection insertion/ejection. insulation sheet before using the remote CAUTION controller.
  • Page 347 Battery (CR2025 LITHIUM or equivalent) 3. Press the battery case tab in the direction of the arrow until a click sound is heard. NOTE If the remote controller is inoperable even after the batteries are replaced, consult an Authorized Mazda Dealer. 6-82...

  • Page 348: Sound Output

    Interior Comfort Rear Entertainment System Sound Output qSound Output from Vehicle Speakers on-screen tab. “AUX” is displayed on the audio Press the audio button ( ) and display and it changes to the Rear Entertainment System sound. Sound/Music being played by the Rear Entertainment System can be heard from the vehicle speakers.
  • Page 349 Interior Comfort Rear Entertainment System The acceptable range for signals (infrared rays) from the Rear Entertainment System is as follows: Rear Entertainment System Wireless headphone signal (infrared rays) transmitter The signals (infrared rays) can be received in any location on the rear seats. However, the rear of the transmitter is out of the acceptable range.
  • Page 350 Interior Comfort Rear Entertainment System Replacing the battery 1. Remove the screw using a coin or equivalent, and remove the cover. Remove the batteries. Cover Screw 2. Insert two AAA-size batteries. Match the polarity of the batteries with the marks in the battery case. 3.
  • Page 351 Interior Comfort Rear Entertainment System CAUTION Ø If the battery power is depleted the headphones will not operate properly. If any of the following occurs, replace the batteries. Ø The power indicator does not illuminate even when the power is turned on. Ø...

  • Page 352: Rear Entertainment System Functions

    Interior Comfort Rear Entertainment System Rear Entertainment System Functions qMode The Rear Entertainment System has Disc and AUX modes. Mode Function Page DVD video, video CD, DVD audio, and audio CD can be 6-88 Disc mode played. AV equipment with output terminals for image and sound, AUX (Auxiliary) mode such as a video game player and a video camera, can be 6-102...

  • Page 353: Dvd Video, Dvd Audio, Video Cd, Audio Cd And Mp3/Wma Cd Playback (Disc Mode)

    Interior Comfort Rear Entertainment System qBasic Operation DVD video, DVD audio, Video CD, Audio CD and Power ON/OFF MP3/WMA CD Playback Turning on the power (Disc Mode) The Rear Entertainment System automatically turns on when any of the DVD video, DVD audio, Video CD, following operations are done with the Audio CD, and MP3/WMA CD can be ignition switched to ACC or ON.
  • Page 354 Interior Comfort Rear Entertainment System Pausing the playback CAUTION Press the PAUSE button to pause the Insert the disc with its label-side playback. (decorated side) facing upward. If the Press the PAUSE or PLAY button to disc is inserted upside-down, it may resume the playback.
  • Page 355 Interior Comfort Rear Entertainment System NOTE NOTE To return to the beginning of the previous If a title/group number not in the disc is chapter/track, press the PREV button ( input, the last title/group is played. again within 2 seconds after the button is Refer to the instruction manual attached to pressed.
  • Page 356 Interior Comfort Rear Entertainment System qAssist Functions (DVD video, DVD Language (sound and subtitle) selection (DVD video and DVD audio) audio, video CD and audio CD) Subtitle ON/OFF (DVD video) Top menu and disc menu Display angle change (DVD video and DVD audio) NOTE Sound output balance adjustment...
  • Page 357 Interior Comfort Rear Entertainment System NOTE Video CD/audio CD function menu Available languages varies depending on the DVD disc. 1. Press the DISPLAY button to display the function menu. 2. Move the cursor and select the sound select mode or subtitle select mode by operating the select button to the left or right.
  • Page 358 Interior Comfort Rear Entertainment System 2. Move the cursor to the subtitle ON/ 2. Move the cursor to the display angle OFF mode by operating the select change mode by operating the select button to the left or right. button to the left or right. 3.
  • Page 359 Interior Comfort Rear Entertainment System 3. Set the sound output to the desired 3. Select the desired mode by operating balance by operating the select button the select button up or down. up or down. (1) During DVD audio: Press the button and the settings Each time the button is pressed, the changes in the order of L+R →L →R.
  • Page 360 Interior Comfort Rear Entertainment System For example, the folder numbers for Folder/File information display folders (1), (3), and (5) in the figure are window not displayed because they do not Display mode contain MP3/WMA files. Folders and files in a hierarchy are played in the order that they are recorded on the disc by the writing software.
  • Page 361 Interior Comfort Rear Entertainment System 2. Change the display mode by operating While in TREEIDX display mode the select button up or down. 1. Move the cursor to the folder/file information display window by Display Playback mode operating the select button to the left or All files are played repeatedly.
  • Page 362 Interior Comfort Rear Entertainment System qInitial Setting Function 3. Press the ENTER button. The selected menu is highlighted to indicate that the The settings set in the initial setting menu is selected. function remain after the unit is turned off or the disc is changed.
  • Page 363 Interior Comfort Rear Entertainment System 5. Press the ENTER button. The Changing to a language other than highlighted color returns to the English and Japanese previous color to indicate that the NOTE selected item is set. Languages other than English and Japanese can be set by entering the language code in the language code list.
  • Page 364 Interior Comfort Rear Entertainment System Viewing can be restricted by setting the Changing the Rating setting parent lock level. 1. Enter the password by pressing the For example, if the level is set to 6, level 7 number keys (0 to 9) or operating the or higher viewing is locked and cannot be select button up or down.
  • Page 365 Interior Comfort Rear Entertainment System 3. Enter the country code by pressing the Country change number keys (0 to 9) or operating the NOTE select button up or down. It is necessary to set the country code because the parent lock level is different depending on the country.
  • Page 366 Interior Comfort Rear Entertainment System Mark The DVD video playback status and angle display on/off, and priority of the inserted discs can be set. 3. Enter the new password by pressing the number keys (0 to 9) or operating the select button up or down.

  • Page 367: Auxiliary Input (Aux Mode)

    Interior Comfort Rear Entertainment System NOTE Auxiliary Input (AUX mode) The display angle change is not available for discs other than multi-angle recorded In AUX mode, AV equipment such as a DVD discs. Refer to the instruction manual video game player or a video camera can accompanying the disc for details.
  • Page 368 Interior Comfort Rear Entertainment System Auxiliary terminals CAUTION The auxiliary terminals consist of one Ø Always close the cover when not in image input terminal and two sound input use. If foreign objects or liquid terminals (for left and right). penetrate the outlet, it may cause Image input terminal: Yellow a malfunction.
  • Page 369 Interior Comfort Rear Entertainment System 1. Switch the ignition off. NOTE The following electrical appliances may not 2. If a power supply is necessary, connect operate even if their electrical capacity is 100 the outlet to the power outlet. W or less. Refer to Auxiliary Terminals and Appliances requiring large amounts of Power Outlet on page 6-102.
  • Page 370 Interior Comfort Rear Entertainment System 5. Press the SOURCE button and select the AUX mode. Refer to Mode on page 6-87. 6. Operate the equipment following the instruction manual accompanying the equipment. 6-105...

  • Page 371: Language Code List

    Interior Comfort Rear Entertainment System Language Code List Language Code Language Code Abkhazian 1001 Greek 1411 Afar 1000 Greenlandic 2011 Afrekaans 1005 Guarani 1613 Albanian 2816 Gujarati 1620 Amharic 1012 Hausa 1700 Arabic 1017 Hebrew 1822 Armenian 1724 Hindi 1708 Assamase 1018 Hungarian...
  • Page 372 Interior Comfort Rear Entertainment System Language Code Language Code Nauru 2300 Tigrinya 2908 Nepali 2304 Tonga 2914 Norwegian 2314 Tsonga 2918 Occtian 2402 Tukmen 2910 Oriya 2417 Turkish 2917 Oromo 2412 2922 Panjabi 2500 Ukrainian 3010 Pashto, Pushto 2518 Urdu 3017 Persian 1500...

  • Page 373: Country Code List

    Interior Comfort Rear Entertainment System Country Code List Country Code Country Code Afghanistan 1005 Cape Verde 1221 Albania 1011 Cayman Islands 2024 Algeria 1325 Central African Republic 1205 American Samoa 1018 Chad 2903 Andorra 1003 Chile 1211 Angola 1014 China 1213 Anguilla 1008...
  • Page 374 Interior Comfort Rear Entertainment System Country Code Country Code French Southern Territories 2905 Lao People's Democratic 2100 Gabon 1600 Latvia 2121 Gambia 1612 Lebanon 2101 Georgia 1604 Lesotho 2118 Germany 1304 Liberia 2117 Ghana 1607 Libyan Arab Jamahiriya 2124 Gibraltar 1608 Liechtenstein 2108...
  • Page 375 Interior Comfort Rear Entertainment System Country Code Country Code Nigeria 2306 South Africa 3500 Niue 2320 South Georgia and the South 1618 Sandwich Islands Norfolk Island 2305 Spain 1418 Northern Mariana Islands 2215 Sri Lanka 2110 Norway 2314 Sudan 2803 Oman 2412 Suriname...
  • Page 376 Interior Comfort Rear Entertainment System Country Code Wallis and Futuna Islands 3205 Western Sahara 1407 Yemen 3404 Yugoslavia 3420 Zaire See Congo, The 3517 Democratic Republic of the Zambia 3512 Zimbabwe 3522 6-111...

  • Page 377: Error Message

    Interior Comfort Rear Entertainment System Error Message qMessage Incorrect region code An error message is displayed if a disc Disc mode error message other than one with region code 1 or Use of Non-supported Disc including region 1 is inserted. An error message is displayed if a non- supported DVD-ROM disc, a non- supported disc format or a disc (PAL,...
  • Page 378 Interior Comfort Rear Entertainment System System errors (Common to each mode) Power malfunction An error message is displayed if the power supply to the rear entertainment system drops (About 9.5 V or less), and the power is turned off. The power is restored when the power supply to the rear entertainment system is 10 V or more.

  • Page 379: Symptoms And Actions

    If any malfunction is suspected, verify the following before requesting a repair. If the problem cannot be solved after performing the procedure, have the system inspected at an Authorized Mazda Dealer. Some functions are not available depending on the disc. Read the instruction manual attached to the disc before operating.
  • Page 380 Interior Comfort Rear Entertainment System Symptom Cause Action There are The LCD is high tech equipment with a subtle spots 99.99% effective sensor resolution. ― However, please be aware that 0.01% luminescent pixel failure or pixel continuous spots on the illuminated pixels may exist.

  • Page 381: Bluetooth

    Interior Comfort Bluetooth® í Bluetooth® ® Bluetooth Hands-Free outline ® When a Bluetooth device (mobile phone) is connected to the vehicle's Hands-Free unit via radio wave transmission, a call can be made or received by pressing the talk button, pick-up button, hang-up button, or voice command on the steering wheel, or by operating the panel.
  • Page 382 Interior Comfort Bluetooth® qComponent Parts Audio unit Talk button, Pick-up button and Hang-up button Talk button Pick-up button Hang-up button Microphone Microphone Audio unit ® The audio unit is used for volume adjustment and touch panel operation. Bluetooth information is displayed in the display. The screen is switched by touching the tab for each function to be used.
  • Page 383 To use Bluetooth audio and Hands-Free, Consult an Authorized Mazda Dealer, ® the device equipped with Bluetooth Mazda's call center or Web support to be programmed to the unit using the center for information regarding following procedure. A maximum of ®...
  • Page 384 (Peripheral necessary to change the link. The order of device). device priority after the link has been 6. Select “Mazda” from the device list changed is maintained even when the searched by the device. ignition is switched off. ®...
  • Page 385 4. Touch the on-screen button. ® 5. Touch the on-screen button. The Mazda Bluetooth Hands-free system can be used to make calls or operate the NOTE audio unit using voice recognition which If you want to delete all of the pairing devices, includes numerous convenient commands.
  • Page 386 Interior Comfort Bluetooth® 6. Follow the prompts to receive the NOTE appropriate voice guidance When activating the Phone Menu from the instructions. Main Menu, the user is informed of the available options (Call, Dial, Redial, Call Commands useable anytime during back, Setup or Emergency) via voice voice recognition navigation.

  • Page 387: Bluetooth® Hands-Free

    Interior Comfort Bluetooth® To prevent a deterioration in the voice Bluetooth® Hands-Free recognition rate and voice quality, the following points should be observed: qMaking a Call The Hands-free system cannot perform Phonebook Usage voice recognition while voice guidance or a beep sound is operating. Wait until Telephone calls can be made by saying the voice guidance or the beep sound is the contact name in the downloaded...
  • Page 388 Interior Comfort Bluetooth® 9. Prompt: “XXXXX... (Ex. “John”) NOTE XXXX (Ex. “at home”). Press the pick- If the phonebook has been already up button to call, or say Go Back to registered to the Hands-Free unit, the enter a different name.” current phonebook is overwritten during “all phonebooks download”.
  • Page 389 Interior Comfort Bluetooth® 2. Prompt: “Ready” 2. Touch the contact information you would like to call. 3. Say: [Beep] “Redial” Changing contact 4. A call is made to the most recent call in the Call history (outgoing). 1. Touch the on-screen tab.
  • Page 390 Interior Comfort Bluetooth® 5. Say: [Beep] Screen operation “XXXXXXXXXXX (Ex. “5551234”) 1. Input the telephone number using the (Telephone number)” numerical keypad. 6. Prompt: 2. Touch the on-screen button to “XXXXXXXXXXX. (Ex “5551234”) make the call. (Telephone number (first choice))” Numeral or symbol entry 7.
  • Page 391 Hands- after your accident. For the safety of Free to a mobile phone the driver and all passengers, Mazda recommends that the Automatic 911 Communication between the Hands-Free system remain activated so that a unit and a device (Mobile phone) is call will be made to 911 when needed.
  • Page 392 Interior Comfort Bluetooth® qDTMF (Dual Tone Multi- NOTE If the ignition is switched off during a Hands- Frequency Signal) Transmission Free call, the line is transferred to the device This function is used when transmitting (Mobile phone) automatically. DTMF via the Numerical Keypad. The receiver of a DTMF transmission is qTransferring a call from a device generally a home telephone answering...
  • Page 393 Interior Comfort Bluetooth® NOTE Message playback Messages that have not been read are 1. Touch the on-screen tab. downloaded first. Attached data is not downloaded. 2. Touch the message you want to have Messages up to 160-bytes can be played (read) back. downloaded.
  • Page 394 Interior Comfort Bluetooth® qAudio Operation Using Voice Erasing messages Recognition Downloaded messages can be erased. Audio on/off, audio mode switching, and 1. Touch the on-screen tab. audio operations can be done using voice 2. Touch the message you want to erase. recognition.
  • Page 395 Interior Comfort Bluetooth® 4. Prompt: “Available audio modes are: Playing selected artist AM, FM, FM1, FM2, Sirius, Sirius1, (When playing a USB or iPod) Sirius2, Sirius3, USB, iPod, Tracks from a desired artist on a USB ® ® Bluetooth audio, Pandora , CD, device or iPod can be played using voice AUX, Turn off audio”...
  • Page 396 Interior Comfort Bluetooth® Playing selected album Playing selected playlist (When playing a USB or iPod) (When playing a USB or iPod) The tracks from a desired album on a The tracks from a desired playlist on a USB device or iPod can be played using USB device or iPod can be played using voice recognition.
  • Page 397 Interior Comfort Bluetooth® Playing selected genre Scan (When playing a USB or iPod) (When playing a Radio, Sirius satellite Tracks from a desired genre on a USB radio, CD, or BT audio (AVRCP1.4)) device or iPod can be played using voice The scan function for the radio, Sirius recognition.
  • Page 398 Interior Comfort Bluetooth® Refer to How to Use the Bluetooth® Pause/Resume Audio System on page 6-141. (When playing a CD, USB, iPod, BT ® audio (AVRCP1.0/1.3/1.4), Pandora Track up Refer to Operating the Compact Disc 1. Press the talk button. (CD) Player on page 6-46.
  • Page 399 Interior Comfort Bluetooth® (When playing a CD) (When playing BT audio) 1. Press the talk button. 1. Press the talk button. 2. Prompt: “Ready” 2. Prompt: “Ready” 3. Say: [Beep] “Repeat (or Repeat Off)” 3. Say: [Beep] “Shuffle” 4. Repeat is performed or stopped. 4.
  • Page 400 Interior Comfort Bluetooth® 2. Prompt: “Ready” Refer to Operating the Radio on page 6-34. 3. Say: [Beep] “Auto memory seek” 1. Press the talk button. 4. Auto memory seek is performed. 2. Prompt: “Ready” Auto memory preset function 3. Say: [Beep] “Frequency” (When playing the Radio) Auto memory preset can be selected using 4.
  • Page 401 Interior Comfort Bluetooth® 3. Say: [Beep] “Next channel” Next preset selection (When playing the Radio) 4. The next channel is selected. 1. Press the talk button. Selecting the previous channel 2. Prompt: “Ready” 1. Press the talk button. 3. Say: [Beep] “Next preset” 2.
  • Page 402 Interior Comfort Bluetooth® Refer to How to Use Pandora® on page Bookmark function 6-143. ® (When playing Pandora The bookmark function can be run using 1. Press the talk button. voice recognition. 2. Prompt: “Ready” Refer to How to Use Pandora® on page 6-143.
  • Page 403 Bluetooth® qGracenote Database The Gracenote media database is used to improve voice recognition of artist and album names with the Mazda Hands Free system. To make best use of the voice recognition, install the most recent database. CAUTION For information related to the most recent Gracenote database which can be used and how to install it, go to the Mazda Hands Free Website: http://www.mazdahandsfree.com...
  • Page 404 Interior Comfort Bluetooth® ® Gracenote End User License Agreement This application or device contains software from Gracenote, Inc. of Emeryville, California (“Gracenote”). The software from Gracenote (the “Gracenote Software”) enables this application to perform disc and/or file identification and obtain music-related information, including name, artist, track, and title information (“Gracenote Data”) from online servers or embedded databases (collectively, “Gracenote Servers”) and to perform other functions.
  • Page 405 Interior Comfort Bluetooth® Updating the database The Gracenote media database can be updated using USB device. 1. Connect a USB device containing the software for updating Gracenote. 2. Touch the on-screen button. 3. Touch the on-screen button. 4. Touch the on-screen button to scroll the display.

  • Page 406: Bluetooth® Audio

    Interior Comfort Bluetooth® NOTE Bluetooth® Audio ® To make sure that your Bluetooth audio ® device is Ver. 1.0, 1.3 or 1.4, refer to the Applicable Bluetooth specification ® Owner's Manual for the Bluetooth audio Ver. 2.0 or higher device. ®...
  • Page 407 Interior Comfort Bluetooth® 3. Press the audio button ( ) and Reverse then touch the on-screen tab to Press and hold the reverse down button ® switch to the Bluetooth audio mode ) or touch and hold the and start playback. screen button.
  • Page 408 Interior Comfort Bluetooth® Shuffle playback (only AVRCP Ver. 1.4) NOTE Some information may not display depending Folder shuffle on the device, and if the information cannot be displayed, “No Song Name” is indicated. Touch the on-screen button during playback to play the songs in the folder shuffle.
  • Page 409 Interior Comfort Bluetooth® NOTE Display scroll The skip function may not be available If a whole title cannot be displayed at one depending on the device. time, touch the on-screen button on The number of skips is limited by the right side of the title. ®...

  • Page 410: Troubleshooting

    The ignition switch has been turned off. If none of the above conditions apply, refer to the following to see if any of the problem symptoms correspond to your device. If the problem cannot be resolved, consult an Authorized Mazda Dealer or Mazda ® Bluetooth Hands-Free Customer Service.
  • Page 411 Bluetooth function and the Find Mode/Visible setting on the device ― are turned on. If pairing is still not possible after this, contact an Authorized Mazda Dealer or Mazda ® Bluetooth Hands-Free Customer Service. ® ® Unable to perform pairing...
  • Page 412 Interior Comfort Bluetooth® Voice recognition related problems Symptom Cause Solution method Poor voice recognition Excessive, slow speech. Regarding the causes indicated on Excessive, forceful speech the left, be careful with how you False recognition of numbers (shouting). speak. In addition, when numbers are Speaking before the beep sound spoken in a sequence, recognition has ended.
  • Page 413 Interior Comfort Bluetooth® Other problems Symptom Cause Solution method The indication for the remaining The indication method is different ― battery is different between the between the vehicle and the device. vehicle and the device When a call is made from the The number has not been registered If the number has been registered vehicle, the telephone number is...

  • Page 414: Safety Certification

    Interior Comfort Bluetooth® Safety Certification FCC: CB2MAZGEN6HFT NOTE This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
  • Page 415 Interior Comfort Bluetooth® The term “IC: ” before the radio certification number only signifies that Industry Canada technical specifications were met. The antenna used for this transmitter must not be co- located or operating in conjunction with any other antenna or transmitter. End-users and installers must be provided with installation instructions and transmitter operating conditions for satisfying RF exposure compliance.

  • Page 416: Rear View Monitor

    Interior Comfort Rear View Monitor í Rear View Monitor The rear view monitor is a visual assist system when reversing the vehicle that provides images from the rear of the vehicle. WARNING The rear view monitor is only a visual assist device when reversing the vehicle. The images on the screen may be different from the actual conditions.
  • Page 417 If the camera temperature changes rapidly, such as by pouring hot water on it under cold temperature conditions, the rear view monitor may not operate correctly. When replacing the tires, consult an Authorized Mazda Dealer. Replacing the tires could result in deviation of the guide lines which appear on the display.
  • Page 418 Interior Comfort Rear View Monitor qDisplayable Range on the Screen The images on the screen may be different from the actual conditions. (Screen display) Garnish Bumper (Actual view) Object NOTE The displayable range varies depending on the vehicle and road conditions. The displayable range is limited.
  • Page 419 Interior Comfort Rear View Monitor qViewing the Display Guide lines which indicate the width of the vehicle (yellow) are displayed on the screen as a reference to the approximate width of the vehicle in comparison to the width of the parking space you are about to back into.
  • Page 420 Interior Comfort Rear View Monitor qRear View Monitor Operation The operation of the rear view monitor when reversing the vehicle varies depending on the traffic, road, and vehicle conditions. The amount of steering and the timing also varies depending on conditions, so confirm the surrounding conditions directly with your eyes and steer the vehicle in accordance with the conditions.
  • Page 421 Interior Comfort Rear View Monitor 5. Once they are parallel, straighten the wheels and back your vehicle slowly into the parking space. Continue checking the vehicle's surroundings and then stop the vehicle in the best possible position. (If the parking space has division lines, check whether the vehicle width guide lines are parallel to them.) (Display condition) (Vehicle condition)
  • Page 422 Interior Comfort Rear View Monitor NOTE Because there may be a difference between the displayed image, such as indicated below, and the actual conditions when parking, always verify the safety at the rear of the vehicle and the surrounding area directly with your eyes. In the image of the parking space (or garage) displayed below, even though the back end and distance guide lines appear parallel in the monitor, they may not actually be parallel on the ground.
  • Page 423 Interior Comfort Rear View Monitor qVariance Between Actual Road Conditions and Displayed Image Some variance occurs between the actual road and the displayed road. Such variance in distance perspective could lead to an accident. Note the following conditions that may cause a variance in distance perspective.
  • Page 424 Interior Comfort Rear View Monitor When there is a steep grade behind the vehicle When there is a steep upgrade (downgrade) behind the vehicle, the object displayed on the screen appears farther (downgrade: closer) than the actual distance. Appears Appears farther than closer than actual...
  • Page 425 Interior Comfort Rear View Monitor Three-dimensional object on vehicle rear Because the distance guide lines are displayed based on a flat surface, the distance to the three-dimensional object displayed on the screen is different from the actual distance. (Screen display) (Actual condition) (Actual distance) B>C=A Sensed distance on screen A>B>C...
  • Page 426 Interior Comfort Rear View Monitor Reset All of the screen setting values can be reset to their initial settings. 1. Press the setup button ( ) to display the picture quality adjustment screen. 2. Touch the on-screen button. 3. Touch the on-screen button.

  • Page 427: Interior Equipment

    Interior Comfort Interior Equipment qVanity Mirrors Sunvisors To use the vanity mirror, lower the When you need a sunvisor, lower it for sunvisor. use in front or swing it to the side. The vanity mirror light will illuminate when you open the cover. Sunvisor qSide Extension Sunvisors The visor extender extends the sunvisor's...

  • Page 428: Interior Lights

    Interior Comfort Interior Equipment qOverhead Lights Interior Lights When the center/rear overhead light qIlluminated Entry System switch is in the DOOR position, the center/rear overhead light can be turned When the illuminated entry system on or off using the front overhead light operates, the overhead light (switch is in switch.
  • Page 429 Interior Comfort Interior Equipment qLuggage Compartment Light Center/Rear Switch Switch Overhead Lights Luggage Compartment Light Position Position Light off Light off Light on or off in accordance with the Light on when the liftgate is open operation of front overhead light switch qCourtesy Lights Light on...

  • Page 430: Information Display

    Interior Comfort Interior Equipment Information Display Climate control display (Front passenger)/ Ambient temperature display Climate control display (Driver) Trip computer Clock Clock adjustment buttons qInformation Display Functions The information display has the following functions: Clock Ambient Temperature Display (Outside Temperature Display) Climate Control Display Trip Computer 6-165...
  • Page 431 Interior Comfort Interior Equipment qClock qAmbient Temperature Display When the ignition is switched to ACC or When the ignition is switched ON, press ON, the time is displayed. the OUTSIDE switch (page 6-6) to display the ambient temperature. Time setting NOTE 1.
  • Page 432 Press the INFO switch to change the display mode. If you have any problems with your trip computer, consult an Authorized Mazda When you've slowed to about 5 km/h (3 Dealer. mph), - - - L/100 km (- - -mpg) will be Current fuel economy mode displayed.
  • Page 433 Interior Comfort Interior Equipment CANADA CANADA To clear the data being displayed, press NOTE the INFO switch for more than 1.5 Even though the distance-to-empty display second. may indicate a sufficient amount of After pressing the INFO switch, - - - L/ remaining mileage before refueling is 100 km (- - - mpg) will be displayed for required, refuel as soon as possible if the...

  • Page 434: Cup Holder

    Interior Comfort Interior Equipment U.S.A. Cup Holder WARNING Never use a cup holder to hold hot liquids while the vehicle is moving: Using a cup holder to hold hot liquids while the vehicle is moving is dangerous. If the contents spill, you could be scalded.
  • Page 435 Interior Comfort Interior Equipment qFront qRear To use the cup holder, push the release Second-row seat button. Cup holders are located in the armrest. To fit small items in the cup holder, Third-row seat remove the flexible divider. Cup holders are located in the third-row seat side trims.

  • Page 436: Bottle Holder

    Interior Comfort Interior Equipment í Left-side Bottle Holder Bottle holders are on the inside of the doors. Bottle holder CAUTION Do not use the bottle holders for containers without caps. The contents may spill when the door is opened or closed. í...

  • Page 437: Storage Compartments

    Interior Comfort Interior Equipment qOverhead Console Storage Compartments This console box is designed to store WARNING accessories. Push and release to open. Keep storage boxes closed when driving: Driving with the storage boxes open is dangerous. To reduce the possibility of injury in an accident or a sudden stop, keep the storage boxes closed when driving.
  • Page 438 Interior Comfort Interior Equipment qCenter Console Use the loops in the luggage compartment to secure cargo with a rope or net. The To open, push the button. tensile strength of the loops is 196 N (20 kgf, 44 lbf). Do not apply excessive force to the loops as it will damage them.
  • Page 439 Interior Comfort Interior Equipment 2. Secure the trunk board using the straps on the third-row seatbacks. Shopping bag hook (tensile strength:3 kg (6.6 lb)) qRear Coat Hooks Side cargo sub-compartment WARNING Open the cover. Never hang heavy or sharp objects on the assist grips and coat hooks: Hanging heavy or sharp-ended objects such as a coat hanger from...
  • Page 440 Interior Equipment qLuggage Compartment Accessory Sockets Golf bags can be carried in the luggage Only use genuine Mazda accessories or compartment. the equivalent requiring no greater than To carry two golf bags, use the following 120 W (DC 12 V, 10 A).

  • Page 441: Accessory Sockets

    Do not use accessories that require more than 120 W (DC 12 V, 10 A). Ø Do not use accessories that are not genuine Mazda accessories or the equivalent. Ø Close the cover when the accessory socket is not in use to...

  • Page 442: Power Outlet Í

    Interior Comfort Interior Equipment í Power Outlet The power outlet is positioned as shown in the figure. For more details, refer to “Auxiliary terminals and power outlet” (page 6-102). í 6-177 Some models.
  • Page 443 6-178...

  • Page 444: In Case Of An Emergency

    In Case of an Emergency Helpful information on what to do in an emergency. Parking in an Emergency ............. 7-2 Parking in an Emergency ............7-2 Flat Tire ..................7-3 Spare Tire and Tool Storage ............7-3 Changing a Flat Tire ..............7-8 Overheating .................

  • Page 445: Parking In An Emergency

    In Case of an Emergency Parking in an Emergency Parking in an Emergency The hazard warning lights should always be used when you stop on or near a roadway in an emergency. The hazard warning lights warn other drivers that your vehicle is a traffic hazard and that they must take extreme caution when near it.

  • Page 446: Flat Tire

    In Case of an Emergency Flat Tire Spare Tire and Tool Storage Spare tire and tools are stored in the locations illustrated in the diagram. Spare tire carrier bolt socket Flat tire belt Tiedown eyelet Jack lever Lug wrench Jack...
  • Page 447 In Case of an Emergency Flat Tire qJack To secure the jack 1. Insert the wing bolt into the jack with To remove the jack the jack screw pointing right and turn 1. Open the cargo sub-compartment. the wing bolt clockwise to temporarily tighten it.
  • Page 448 In Case of an Emergency Flat Tire qSpare Tire CAUTION Your Mazda has a temporary spare tire. Ø When using the temporary spare The temporary spare tire is lighter and tire, driving stability may decrease smaller than a conventional tire, and is...
  • Page 449 In Case of an Emergency Flat Tire 3. Remove the cover. 5. Slowly turn the lug wrench counterclockwise until the spare tire reaches the ground and the cable becomes loose. Cover 4. Attach the socket to the spare tire Spare tire carrier bolt, the jack lever to the socket, and the lug wrench to the opposite end of the jack lever.
  • Page 450 In Case of an Emergency Flat Tire NOTE To secure the spare tire A flat tire which has been removed from the 1. Place the tire with the outer side facing vehicle for repair cannot be carried in the upward, rotate the small lever on top of spare tire carrier.

  • Page 451: Changing A Flat Tire

    CAUTION may be cut. Have it repaired at an Authorized (With Tire Pressure Monitoring Mazda Dealer as soon as possible. System) The wheels equipped on your Mazda are specially designed for installation of the tire pressure sensors. Do not...
  • Page 452 In Case of an Emergency Flat Tire qRemoving a Flat Tire NOTE Make sure the jack is well lubricated before 1. Loosen the lug nuts by turning them using it. counterclockwise one turn each, but do (With Tire Pressure Monitoring System) not remove any lug nuts until the tire Be sure to register the tire pressure sensor has been raised off the ground.
  • Page 453 Use only the jack provided with your Tire blocks Mazda: Using a jack that is not designed for your Mazda is dangerous. The vehicle could slip off the jack and seriously injure someone. Never place objects under the jack: Jacking the vehicle with an object under the jack is dangerous.
  • Page 454 Going under the vehicle while it is Mazda is firmly in position and that it jacked up is dangerous as it could cannot slip or move. result in death or serious injury if the vehicle were to fall off the jack.
  • Page 455 Spare Tire If you lose this key, consult an Authorized Mazda Dealer or use the lock 1. Remove dirt and grime from the manufacturer's order form, which is with mounting surfaces of the wheel and the registration card.
  • Page 456 Because the wheel studs and lug nuts Applying oil or grease to lug nuts and on your Mazda have metric threads, bolts is dangerous. The lug nuts using a non-metric nut is dangerous. could loosen while driving and cause...
  • Page 457 In Case of an Emergency Flat Tire 7. Remove the belt for securing the flat tire. 8. Return the third-row seatback to its original position. Refer to Split-Folding the Third-Row Seat on page 2-14. 9. Remove the tire blocks and store the tools and jack.
  • Page 458 In Case of an Emergency Flat Tire 14. Have the flat tire repaired or replaced as soon as possible. WARNING Do not drive with any tires that have incorrect air pressure: Driving on tires with incorrect air pressure is dangerous. Tires with incorrect pressure could affect handling and result in an accident.

  • Page 459: Overheating

    Stop the engine and call an Authorized Mazda Dealer. Do not remove either cooling system caps when the engine and 6. Make sure the cooling fan is operating,...
  • Page 460 Carefully add coolant as required (page 8-23). CAUTION If the engine continues to overheat or frequently overheats, have the cooling system inspected. The engine could be seriously damaged unless repairs are made. Consult an Authorized Mazda Dealer. 7-17...

  • Page 461: Emergency Starting

    In Case of an Emergency Emergency Starting Jump-Starting Jump-starting is dangerous if done incorrectly. So follow the procedure carefully. If you feel unsure about jump-starting, we strongly recommend that you have a competent service technician do the work. WARNING Follow These Precautions Carefully: To ensure safe and correct handling of the battery, read the following precautions carefully before using the battery or inspecting it.
  • Page 462 In Case of an Emergency Emergency Starting Keep all flames, including cigarettes, and sparks away from open battery cells: Flames and sparks near open battery cells are dangerous. Hydrogen gas, produced during normal battery operation, could ignite and cause the battery to explode. An exploding battery can cause serious burns and injuries.

  • Page 463: Push-Starting

    1. Make sure the booster battery is 12 V Push-Starting and that its negative terminal is grounded. Do not push-start your Mazda. 2. If the booster battery is in another NOTE vehicle, don't allow both vehicles to You can't start a vehicle with an automatic touch.

  • Page 464: Emergency Towing

    Towing Description Do not tow the vehicle pointed We recommend that towing be done only backward with driving wheels on the by an Authorized Mazda Dealer or a ground. This may cause internal commercial tow-truck service. damage to the transaxle.

  • Page 465: Tiedown Hooks

    In Case of an Emergency Emergency Towing WARNING Tiedown Hooks Always tow a AWD vehicle with all four CAUTION wheels off the ground: Towing a AWD vehicle with either the Do not use the front and rear front or rear wheels on the ground is tiedown eyelets for towing the dangerous as the drive train could be vehicle.
  • Page 466 In Case of an Emergency Emergency Towing Rear Rear Lug wrench 4. Hook the tying rope to the tiedown CAUTION eyelet. Do not use excessive force as it may Front damage the cap or scratch the painted bumper surface. NOTE Remove the cap completely and store it so as not to lose it.

  • Page 467: Recreational Towing

    In Case of an Emergency Emergency Towing CAUTION Recreational Towing An example of “recreational towing” is If the tiedown eyelet is not securely tightened, it may loosen or disengage towing your vehicle behind a motorhome. from the bumper when tying down The transaxle is not designed for towing the vehicle.

  • Page 468: Maintenance And Care

    Maintenance and Care How to keep your Mazda in top condition. Introduction .................. 8-2 Introduction ................8-2 Scheduled Maintenance ..............8-4 Scheduled Maintenance (U.S.A., Canada, and Puerto Rico) ..8-4 Scheduled Maintenance (Mexico) ........... 8-10 Owner Maintenance ..............8-17 Owner Maintenance Schedule ..........8-17 Owner Maintenance Precautions ..........

  • Page 469: Introduction

    If you elect to perform maintenance yourself or have your vehicle serviced at a location other than an Authorized Mazda Dealer, Mazda requires that all fluids, parts and materials must meet Mazda standards for durability and performance as described in this manual.
  • Page 470 Maintenance and Care Introduction Any auto repair shop using parts equivalent to your Mazda's original equipment may perform maintenance. But we recommend that it always be done by an Authorized Mazda Dealer using genuine Mazda parts.

  • Page 471: Scheduled Maintenance

    Maintenance and Care Scheduled Maintenance Scheduled Maintenance (U.S.A., Canada, and Puerto Rico) Follow Schedule 1 if the vehicle is operated mainly where none of the following conditions apply. Repeated short-distance driving Driving in dusty conditions Driving with extended use of brakes Driving in areas where salt or other corrosive materials are used Driving on rough or muddy roads Extended periods of idling or low-speed operation...
  • Page 472 Maintenance and Care Scheduled Maintenance qSchedule 1 Number of months or kilometers (miles), whichever comes first Months Maintenance Interval ×1000 km ×1000 miles 22.5 37.5 52.5 ENGINE Inspect every 168,000 km (105,000 miles) Drive belts Replace every 240,000 km (150,000 miles) Engine oil Engine oil filter COOLING SYSTEM...
  • Page 473 *2 According to state/provincial and federal regulations, failure to perform maintenance on these items will not void your emissions warranties. However, Mazda recommends that all maintenance services be performed at the recommended time or mileage/kilometer period to ensure long-term reliability.
  • Page 474 Maintenance and Care Scheduled Maintenance qSchedule 2 Number of months or kilometers (miles), whichever comes first Months Maintenance Interval ×1000 km ×1000 miles ENGINE Inspect every 160,000 km (100,000 miles) Drive belts Replace every 240,000 km (150,000 miles) Puerto Rico Replace every 5,000 km (3,000 miles) or 3 months Engine oil Others...
  • Page 475 Maintenance and Care Scheduled Maintenance Number of months or kilometers (miles), whichever comes first Months Maintenance Interval ×1000 km ×1000 miles CHASSIS and BODY Brake lines, hoses and connections Brake fluid level Disc brakes Tire (Rotation) Rotate every 8,000 km (5,000 miles) Tire inflation pressure and tire wear Steering operation and linkages Power steering fluid level...
  • Page 476 *2 According to state/provincial and federal regulations, failure to perform maintenance on these items will not void your emissions warranties. However, Mazda recommends that all maintenance services be performed at the recommended time or mileage/kilometer period to ensure long-term reliability.

  • Page 477: Scheduled Maintenance (Mexico)

    Maintenance and Care Scheduled Maintenance Scheduled Maintenance (Mexico) Follow Schedule 1 if the vehicle is operated mainly where none of the following conditions apply. Repeated short-distance driving Driving in dusty conditions Driving with extended use of brakes Driving in areas where salt or other corrosive materials are used Driving on rough or muddy roads Extended periods of idling or low-speed operation Driving for long periods in cold temperatures or extremely humid climates...
  • Page 478 Maintenance and Care Scheduled Maintenance qSchedule 1 Number of months or kilometers, whichever comes first Maintenance Interval Months ×1000 km 90 100 110 120 ENGINE Inspect every 40,000 km or 2 years Drive belts Replace every 240,000 km Engine oil Engine oil filter COOLING SYSTEM Cooling system...
  • Page 479 *2 According to state/provincial and federal regulations, failure to perform maintenance on these items will not void your emissions warranties. However, Mazda recommends that all maintenance services be performed at the recommended time or kilometer period to ensure long-term reliability.
  • Page 480 Maintenance and Care Scheduled Maintenance qSchedule 2 Number of months or kilometers, whichever comes first Maintenance Interval Months ×1000 km ENGINE Inspect every 40,000 km or 2 years Drive belts Replace every 240,000 km Engine oil Engine oil filter COOLING SYSTEM Cooling system Replace at first 190,000 km or 10 years;...
  • Page 481 *2 According to state/provincial and federal regulations, failure to perform maintenance on these items will not void your emissions warranties. However, Mazda recommends that all maintenance services be performed at the recommended time or kilometer period to ensure long-term reliability.
  • Page 482 Maintenance and Care Scheduled Maintenance (Cont.) Number of months or kilometers, whichever comes first Maintenance Interval Months ×1000 km 95 100 105 110 115 120 ENGINE Inspect every 40,000 km or 2 years Drive belts Replace every 240,000 km Engine oil Engine oil filter COOLING SYSTEM Cooling system...
  • Page 483 *2 According to state/provincial and federal regulations, failure to perform maintenance on these items will not void your emissions warranties. However, Mazda recommends that all maintenance services be performed at the recommended time or kilometer period to ensure long-term reliability.

  • Page 484: Owner Maintenance

    The owner or a qualified service technician should make these vehicle inspections at the indicated intervals to ensure safe and dependable operation. Bring any problem to the attention of an Authorized Mazda Dealer or qualified service technician as soon as possible.

  • Page 485: Owner Maintenance Precautions

    Refer to Introduction (page 8-2) for owner's responsibility in protecting your investment. For details, read the separate Mazda Warranty statement provided with the vehicle. If you are unsure about any servicing or maintenance procedure, have it done by an Authorized Mazda Dealer.
  • Page 486 Maintenance and Care Owner Maintenance WARNING Do not perform maintenance work if you lack sufficient knowledge and experience or the proper tools and equipment to do the work. Have maintenance work done by a qualified technician: Performing maintenance work on a vehicle is dangerous if not done properly. You can be seriously injured while performing some maintenance procedures.

  • Page 487: Engine Compartment Overview

    Maintenance and Care Owner Maintenance Engine Compartment Overview Engine coolant reservoir Brake fluid reservoir Power steering Battery Fuse block fluid reservoir Relay box Windscreen washer Engine oil dipstick fluid reservoir Engine oil-filler cap 8-20...

  • Page 488: Engine Oil

    Lubricant Standardization and Approval Committee (ILSAC), comprised of U.S. qRecommended Oil and Japanese automobile manufacturers. U.S.A. and CANADA 5W-20 recommended: Mazda Genuine Oil is used in your Mazda –40 –20 –30 –10 vehicle and is the recommended 5W-20 lubricant. Mazda Genuine 5W-20 Oil is –40 –20...
  • Page 489 Maintenance and Care Owner Maintenance 4. Pull out the dipstick, wipe it clean, and reinsert it fully. (ILSAC) The quality designation SM, or ILSAC must be on the label. 5. Pull it out again and examine the level. The level is normal if it is between MIN and MAX.

  • Page 490: Engine Coolant

    When the engine and radiator are hot, scalding coolant and steam may shoot out under pressure and cause serious injury. NOTE Changing the coolant should be done by an Authorized Mazda Dealer. 8-23...
  • Page 491 If the “FL22” mark is shown on or near the Ø Radiator coolant will damage cooling system cap, it is recommended to use paint. Mazda Genuine FL22 engine coolant (page Rinse it off quickly if spilled. 8-4). Ø Use only soft (demineralized) water in the coolant mixture.

  • Page 492: Brake Fluid

    If it immediately flush your eyes with is excessively low, have the brake system water and get medical attention. inspected by an Authorized Mazda Brake fluid spilled on a hot engine Dealer. could cause a fire.

  • Page 493: Power Steering Fluid

    The level must be kept between MAX and climates in which the vehicle will be operated. MIN. Visually examine the lines and hoses for leaks and damage. If new fluid is required frequently, consult an Authorized Mazda Dealer. 8-26...

  • Page 494: Body Lubrication

    Maintenance and Care Owner Maintenance Inspect fluid level in the washer fluid Body Lubrication reservoir; add fluid if necessary. All moving points of the body, such as door and hood hinges and locks, should be lubricated each time the engine oil is changed.

  • Page 495: Wiper Blades

    Be careful not to pinch hands or fingers as it may cause injury, or damage the wipers. When washing or servicing your Mazda, make sure the wiper lever is in the OFF position. Contamination of either the windshield or the blades with foreign matter can reduce wiper effectiveness.
  • Page 496 Maintenance and Care Owner Maintenance 4. Tilt the blade assembly and remove it 6. Remove the metal stiffeners from each from the arm. blade rubber and install them in the new blade. CAUTION CAUTION To prevent damage to the windshield Ø...
  • Page 497 Maintenance and Care Owner Maintenance 7. Carefully insert the new blade rubber. 2. Firmly rotate the wiper blade to the Then install the blade assembly in the right until it unlocks, then remove the reverse order of removal. blade. CAUTION qReplacing Rear Window Wiper Blade To prevent damage to the rear...
  • Page 498 Maintenance and Care Owner Maintenance 4. Remove the metal stiffeners from each blade rubber and install them in the new blade. CAUTION Don't bend or discard the stiffeners. You need to use them again. 5. Carefully insert the new blade rubber. Then install the blade assembly in the reverse order of removal.

  • Page 499: Battery

    Maintenance and Care Owner Maintenance Battery WARNING Wash hands after handling the battery and related accessories: Battery posts, terminals and related accessories contain lead and lead compounds, chemicals known to the State of California to cause cancer and reproductive harm. Read the following precautions carefully before using the battery or inspecting to ensure safe and correct handling: Always wear eye protection when working near the battery:...
  • Page 500 Maintenance and Care Owner Maintenance Keep all flames, including cigarettes, and sparks away from open battery cells: Flames and sparks near open battery cells are dangerous. Hydrogen gas, produced during normal battery operation, could ignite and cause the battery to explode. An exploding battery can cause serious burns and injuries.

  • Page 501: Tires

    Using Wrong-Sized Tires: accident. Do not use any part for the Using any other tire size than what is tire valve cap that is not a Mazda- specified for your Mazda (page 10-6) genuine part. is dangerous. It could seriously affect...
  • Page 502 Maintenance and Care Owner Maintenance í The Tire Pressure Monitoring System NOTE does not alleviate the need to check the Always check tire pressure when tires are tire condition every day, including cold. whether the tires all look inflated properly. Warm tires normally exceed recommended Inspect all tire pressure monthly pressures.
  • Page 503 Out-of-balance wheel When replacing/repairing the tires or Severe braking wheels or both, have the work done by an Authorized Mazda Dealer, or After rotation, inflate all tire pressures to the tire pressure sensors may be specification (page 10-6) and inspect the damaged.
  • Page 504 Maintenance and Care Owner Maintenance If a tire wears evenly, a wear indicator The temporary spare tire is easier to will appear as a solid band across the handle because of its construction which tread. is lighter and smaller than a conventional Replace the tire when this happens.
  • Page 505 When replacing/repairing the WARNING tires or wheels or both, have the work done by an Authorized Always use wheels of the correct size Mazda Dealer, or the tire on your vehicle: pressure sensors may be Using a wrong-sized wheel is damaged.
  • Page 506 MEMO 8-39...

  • Page 507: Light Bulbs

    Maintenance and Care Owner Maintenance Light Bulbs With xenon fusion headlights With halogen headlights Overhead light (Front)/Map lights Overhead light (Front)/Map lights Overhead light (Center) Overhead light (Center) Overhead light (Rear) Overhead light (Rear) Vanity mirror Vanity mirror lights lights Side turn Side turn signal lights...
  • Page 508 Exterior Light Bulbs Headlights (With xenon fusion headlights) Low/High beam bulbs You cannot replace the low/high beam bulbs by yourself. The bulbs must be replaced at an Authorized Mazda Dealer. 8-41...
  • Page 509 NOTE To replace the bulb, contact an Authorized Mazda Dealer If the halogen bulb is accidentally touched, it should be cleaned with rubbing alcohol before being used. Use the protective cover and carton of the replacement bulb to dispose of the old bulb promptly out of the reach of children.
  • Page 510 Running lights/Parking lights (With xenon fusion headlights) Due to the complexity and difficulty of the procedure, the LED bulbs must be replaced by an Authorized Mazda Dealer. NOTE 6. Turn the socket and bulb assembly to LED bulb replacement is not possible because remove it.
  • Page 511 6. Install the new bulb in the reverse order of the removal procedure. 7. Install the coolant reservoir. If you are unsure of how tight the bolts should be, have them inspected at an Authorized Mazda Dealer. Bolt tightening torque 6.9―11.8 N·m (kgf·m, ft·lbf) (0.7―1.2, 5.1―8.7) 4.
  • Page 512 , High-mount brake light Due to the complexity and difficulty of the procedure, the LED bulbs must be replaced by an Authorized Mazda Dealer. NOTE LED bulb replacement is not possible because it is built into the unit. Replace the unit.
  • Page 513 Maintenance and Care Owner Maintenance 2. Turn the bolts counterclockwise and Rear turn signal lights remove them. Rear side-marker light 3. Pull the unit rearward to remove it. 5. Disconnect the bulb from the socket. 4. Turn the socket and bulb assembly 6.
  • Page 514 5. Install the new bulb in the reverse order of the removal procedure. NOTE To replace the bulb, contact an Authorized Mazda Dealer. License plate lights 1. Make sure the ignition is switched off, and the headlight switch is off.
  • Page 515 Maintenance and Care Owner Maintenance qReplacing Interior Light Bulbs Luggage compartment light Overhead light (Front)/Map lights, Overhead light (Center, Rear), Luggage compartment light, Courtesy lights, Vanity mirror lights 1. Wrap a small flathead screwdriver with a soft cloth to prevent damage to the lens, and then remove the lens by carefully prying on the edge of the lens with the flathead screwdriver.

  • Page 516: Fuses

    If the same fuse blows again, avoid using that system and consult an Authorized Mazda Dealer as soon as possible. 4. Pull the fuse straight out with the fuse puller provided on the fuse block qFuse Replacement located in the engine compartment.
  • Page 517 2. Remove the fuse block cover or the WARNING relay box cover. Do not replace the main fuse by Fuse block yourself. Have an Authorized Mazda Dealer perform the replacement: Replacing the fuse by yourself is dangerous because the MAIN fuse is a high current fuse. Incorrect...
  • Page 518 Maintenance and Care Owner Maintenance qFuse Panel Description Fuse block (Engine compartment) FUSE DESCRIPTION PROTECTED COMPONENT RATING MAIN 150 A For protection of all circuits ― ― ― ENGINE 20 A Engine control system H/L R 15 A Headlight (RH) í...
  • Page 519 Maintenance and Care Owner Maintenance FUSE DESCRIPTION PROTECTED COMPONENT RATING ABS (SOL) 30 A 25 A Power door locks ROOM 15 A Overhead light OUTLET CTR 15 A Accessory socket (Center) OUTLET RR 15 A Accessory socket (Rear) í í AC PWR 15 A Moonroof...
  • Page 520 Maintenance and Care Owner Maintenance í Relay box (Engine compartment) FUSE DESCRIPTION PROTECTED COMPONENT RATING 7.5 A Engine control system ― ― ― ― ― ― í 8-53 Some models.
  • Page 521 Maintenance and Care Owner Maintenance Fuse block (Glove box) FUSE DESCRIPTION PROTECTED COMPONENT RATING OUTLET FR 15 A Accessory socket (Front) MIRROR 7.5 A Power control mirror C/U-IG1 15 A For protection of various circuits METER 10 A Instrument cluster 7.5 A ABS, Air bag ENG.
  • Page 522 Maintenance and Care Owner Maintenance FUSE DESCRIPTION PROTECTED COMPONENT RATING 7.5 A Engine control system ― ― ― ― ― OUTLET CTR ― ― OUTLET RR WIPER 30 A Windshield wiper and washer P.WIND 30 A Power windows (Driver-side) 8-55...

  • Page 523: Appearance Care

    Occurrence Prevention Industrial pollutants and vehicle emissions It is necessary to have your Mazda drift into the air and mix with rain or dew to form acids. These acids can settle on a washed and waxed to preserve its finish vehicle's finish.
  • Page 524 The rings Chipped paint can lead to rust forming on can damage your vehicle's finish. your Mazda. Before this happens, repair the damage by using Mazda touch-up paint Prevention according to the instructions in this section.

  • Page 525: Exterior Care

    NOTE Keep hands and scrapers clear of Mazda is not responsible for scratches the windshield when the wiper caused by automatic car washes or lever is in the AUTO position and improper washing.
  • Page 526 Maintenance and Care Appearance Care WARNING CAUTION Ø Do not use steel wool, abrasive Dry off brakes that have become wet by driving slowly, releasing the cleaners, or strong detergents accelerator pedal and lightly applying containing highly alkaline or the brakes several times until the brake caustic agents on chrome-plated performance returns to normal: or anodized aluminum parts.
  • Page 527 CAUTION coated with anti-corrosive material. If your Mazda is damaged and needs metal parts repaired or replaced, Thoroughly flush the underbody and make sure the body shop applies...
  • Page 528 Maintenance and Care Appearance Care NOTE WARNING Do not use a wire brush or any abrasive Dry wet brakes by driving very slowly cleaner, polishing compound, or solvent on and applying the brakes lightly until aluminum wheels. They may damage the brake performance is normal: coating.

  • Page 529: Interior Care

    Maintenance and Care Appearance Care High water temperature and high water Interior Care pressure car washers are available depending on the type of high pressure WARNING car washer device. If the car washer Do not spray water in the cabin: nozzle is put too close to the vehicle or Splashing water on electrical parts aimed at one area for an extended...
  • Page 530 Maintenance and Care Appearance Care Leather NOTE Because genuine leather is a natural Remove dust and sand first using a material, its surface is not uniform and it vacuum cleaner or other means, then wipe may have natural scars, scratches, and dirt off using a soft cloth with a leather wrinkles.
  • Page 531 Appearance Care To keep the fabric looking clean and WARNING fresh, take care of it. Otherwise its color Have an Authorized Mazda Dealer will be affected, it can be stained easily, replace damaged seat belts and its fire-resistance may be reduced.
  • Page 532 Maintenance and Care Appearance Care qCleaning the Floor Mats Rubber floor mats should be cleaned with mild soap and water only. WARNING Do not use rubber cleaners, such as tire cleaner or tire shine, when cleaning rubber floor mats: Cleaning the rubber floor mats with rubber cleaning products makes the floor mats slippery.
  • Page 533 8-66...

  • Page 534: Customer Information And Reporting Safety Defects

    Reporting Safety Defects ....... 9-45 Reporting Safety Defects (U.S.A.) ..9-45 Warranty ..........9-15 Reporting Safety Defects (Canada) ... 9-46 Warranties for Your Mazda ....9-15 Outside the United States and Service Publications ......9-47 Canada ..........9-16 Service Publications ......9-47 Outside the United States ....

  • Page 535: Customer Assistance

    Answers to many questions, including how to locate or contact a local Mazda dealership in the U.S., can be found here. E-mail: click on “Contact Us” located on the “Inside Mazda” tab, or at the bottom of the page at www.mazdaUSA.com...

  • Page 536: Customer Assistance (Puerto Rico)

    Mazda North American Operations realizes that mutual agreement on some issues may not be possible. As a final step to ensure that your concerns are being fairly considered, Mazda North American Operations has agreed to participate in a dispute settlement program administered by the Better Business Bureau (BBB) system, at no cost to you the consumer.

  • Page 537: Customer Assistance (Mexico)

    Mazda or one of our dealers, and a statement of the relief you are seeking. 5. BBB AUTO LINE staff may try to help resolve your dispute through mediation. If...
  • Page 538 AND the nonconformity has been subject to repair two or more times by Mazda or its agents AND the buyer or lessee has directly notified Mazda of the need for the repair of the nonconformity; OR...
  • Page 539 11. If you accept the arbitrator's decision, Mazda will be bound by the decision, and will comply with the decision within a reasonable time not to exceed 30 days after we receive notice of your acceptance of the decision.
  • Page 540 Your complete and permanent satisfaction is of primary concern to Mazda. All Authorized Mazda Dealers have both the knowledge and tools to keep your Mazda in top condition. In our experience, any questions, problems, or complaints regarding the operation of your Mazda or any other general service transactions are most effectively resolved by your dealer.
  • Page 541 If a specific item of concern arises, where a solution cannot be reached between an owner, Mazda, and/or one of its dealers (that all parties cannot agree upon), the owner may wish to use the services offered by the Canadian Motor Vehicle Arbitration Plan (CAMVAP).
  • Page 542 1 (800) 207-0685 Ontario 1 (800) 207-0685 Atlantic Canada 1 (800) 207-0685 Quebec 1 (800) 207-0685 qRegional Offices REGIONAL OFFICES AREAS COVERED MAZDA CANADA INC. WESTERN REGION ALBERTA, 8171 ACKROYD ROAD BRITISH COLUMBIA, SUITE 2000 MANITOBA, RICHMOND B.C. SASKATCHEWAN, V6X 3K1...
  • Page 543 1 Discuss the matter with an Authorized Mazda Dealer. This is the quickest and best way to address the issue. If your concern has not been resolved by the CUSTOMER RELATIONS, SALES, SERVICE, or PARTS MANAGER, then please contact the GENERAL MANAGER of the dealership or the OWNER.
  • Page 544 Mazda vehicle or servicing by Mazda Dealer personnel, we recommend that you take the following steps: qContact Your Mazda Dealer Discuss the matter with an Authorized Mazda Dealer. This is the quickest and best way to address the issue. If your concern has not been resolved by the CUSTOMER RELATIONS, SALES, SERVICE, or PARTS MANAGER, then please contact the GENERAL MANAGER of the dealership or the OWNER.
  • Page 545 Customer Information and Reporting Safety Defects Customer Assistance 2. Year and model of vehicle 3. Vehicle Identification Number (17 digits, noted on your registration or title or located on the upper driver's side corner of the dash) 4. Purchase date and current mileage 5.

  • Page 546: Mazda Importer/Distributors

    Irvine, CA 92623-9734 U.S.A. (905) 787-7000 (outside Canada) TEL: 1 (800) 222-5500 (in U.S.A.) qPUERTO RICO/U.S. Virgin Island (949) 727-1990 (outside U.S.A.) Plaza Motors Corp. (Mazda de Puerto Rico) P.O. Box 362722, San Juan, Puerto Rico 00936-2722 TEL: (787) 641-9300...
  • Page 547 Customer Information and Reporting Safety Defects Mazda Importer/Distributors Triple J Saipan, Inc. (d.b.a. Triple J Motors) P.O. Box 500487 Saipan, MP 96950-0487 TEL: (670) 234-7133/3051 9-14...

  • Page 548: Warranty

    Customer Information and Reporting Safety Defects Warranty Warranties for Your Mazda New Vehicle Limited Warranty Powertrain Limited Warranty Safety Restraint System Limited Warranty Anti-perforation Limited Warranty Federal Emission Control Warranty/California Emission Control Warranty Emission Defect Warranty Emission Performance Warranty Emission Control Warranty...

  • Page 549: Outside The United States And Canada

    Proper repair facilities, tools, testing equipment, and replacement parts may not be available. The Mazda warranty applies only to Mazda vehicles registered and normally operated in the United States, its territories, and Canada. 9-16...

  • Page 550: Outside The United States

    We strongly recommend that you NOT take your Mazda outside the United States. However, in the event that you are moving to Canada permanently, Mazda vehicles built for use in the United States could be eligible for exportation to Canada with specific vehicle modifications to comply with the Canadian Motor Vehicle Safety Standards (CMVSS).

  • Page 551: Outside Canada

    We strongly recommend that you NOT take your Mazda outside Canada. However, in the event that you are moving to the United States permanently, Mazda vehicles built for use in Canada could be eligible for exportation to the United States with specific vehicle modifications to comply with the United States Federal Motor Vehicle Safety Standards (FMVSS).

  • Page 552: Registering Your Vehicle In A Foreign Country (Except United States And Canada)

    Parts, servicing techniques, and tools necessary to maintain and repair your vehicle may be unavailable. There might not be an Authorized Mazda Dealer in the country you plan to take your vehicle. The Mazda warranty is valid only in certain countries.

  • Page 553: Add-On Non-Genuine Parts And Accessories

    Non-genuine parts and accessories for Mazda vehicles can be found in stores. These may fit your vehicle, but they are not approved by Mazda for use with Mazda vehicles. When you install non-genuine parts or accessories, they could affect your vehicle's performance or safety systems;...

  • Page 554: Cell Phones

    Customer Information and Reporting Safety Defects Cell Phones Cell Phones Warning WARNING Please comply with the legal regulations concerning the use of communication equipment in vehicles in your State or Province: Use of any electrical devices such as cell phones, computers, portable radios, vehicle navigation or other devices by the driver while the vehicle is moving is dangerous.

  • Page 555: Event Data Recorder

    EDR. Mazda will not disclose any of the data recorded in an EDR to a third party unless: A written agreement from the vehicle owner or the lessee is obtained...

  • Page 556: Uniform Tire Quality Grading System (Utqgs)

    Customer Information and Reporting Safety Defects Uniform Tire Quality Grading System (UTQGS) Uniform Tire Quality Grading System (UTQGS) This information relates to the tire grading system developed by the U.S. National Highway Traffic Safety Administration for grading tires by tread wear, traction, and temperature performance.
  • Page 557 These grades will be added to the sidewalls of passenger vehicle tires over the next several years according to a schedule established by the NHTSA and the tire manufacturers. The grade of tires available as standard or optional equipment on Mazda vehicles may vary with respect to grade.

  • Page 558: Tire Information (Except Canada)

    Customer Information and Reporting Safety Defects Tire Information (except Canada) Tire Labeling Federal law requires tire manufacturers to place standardized information on the sidewall of all tires. This information identifies and describes the fundamental characteristics of the tire and also provides a tire identification number for safety standard certification and in case of a recall.
  • Page 559 Customer Information and Reporting Safety Defects Tire Information (except Canada) 11. Max. load rating 12. Tread wear, traction and temperature grades 13. Max. permissible inflation pressure 14. SAFETY WARNING P215/65R15 95H is an example of a tire size and load index rating. Here is an explanation of the various components of that tire size and load index rating.
  • Page 560 Customer Information and Reporting Safety Defects Tire Information (except Canada) “H” is the speed rating. The speed rating denotes the maximum speed for which the use of the tire is rated. Letter Rating Speed Rating 99 mph 106 mph 112 mph 118 mph 124 mph 130 mph...
  • Page 561 Customer Information and Reporting Safety Defects Tire Information (except Canada) Tread Wear, Traction and Temperature Grades Tread wear: The tread wear grade is a comparative rating based on the wear rate of the tire when tested under controlled conditions on a specified government test course. For example, a tire graded 150 would wear one and one-half (1 1/2) times as well on the government course as a tire graded 100.
  • Page 562 Customer Information and Reporting Safety Defects Tire Information (except Canada) qInformation on Temporary Tires Please refer to the sample below. 1. Temporary tires 2. Nominal width of tire in millimeters 3. Ratio of height to width (aspect ratio) 4. Diagonal 5.
  • Page 563 Customer Information and Reporting Safety Defects Tire Information (except Canada) “70” is the aspect ratio. This two-digit number indicates the tire's ratio of height to width. “D” is the tire construction symbol. D indicates “diagonal ply construction”. “16” is the wheel rim diameter in inches. “90”...

  • Page 564: Location Of The Tire Label (Placard)

    Customer Information and Reporting Safety Defects Tire Information (except Canada) Location of the Tire Label (Placard) You will find the tire label containing tire inflation pressure by tire size and other important information on the driver's side B-pillar or on the edge of the driver's door frame. SAMPLE qRecommended Tire Inflation Pressure On the tire label you will find the recommended tire inflation pressure in both kPa and psi...
  • Page 565 Customer Information and Reporting Safety Defects Tire Information (except Canada) WARNING Always check the tire inflation pressures on a regular basis according to the recommended tire inflation pressure on the tire label and in conjunction with the information in this owner's manual: Driving your vehicle with under-inflated tires is dangerous.
  • Page 566 Customer Information and Reporting Safety Defects Tire Information (except Canada) qGlossary of Terms Tire Placard: A label indicating the OE tire sizes, recommended inflation pressure, and the maximum weight the vehicle can carry. Tire Identification Number (TIN): A number on the sidewall of each tire providing information about the tire brand and manufacturing plant, tire size, and date of manufacture.

  • Page 567: Tire Maintenance

    Customer Information and Reporting Safety Defects Tire Information (except Canada) Tire Maintenance Improper or inadequate vehicle maintenance can cause tires to wear abnormally. Here are some important maintenance points: qTire Inflation Pressure Inspect all tire pressure monthly (including the spare) when the tires are cold. Maintain recommended pressures for the best ride, top handling, and minimum tire wear.
  • Page 568 Customer Information and Reporting Safety Defects Tire Information (except Canada) qReplacing a Tire WARNING Always use tires that are in good condition: Driving with worn tires is dangerous. Reduced braking, steering, and traction could result in an accident. If a tire wears evenly, a wear indicator will appear as a solid band across the tread. Replace the tire when this happens.
  • Page 569 Customer Information and Reporting Safety Defects Tire Information (except Canada) CAUTION If you feel a sudden vibration or ride disturbance while driving or you suspect your tire or vehicle has been damaged, immediately reduce your speed. Drive with caution until you can safely pull off the road. Stop and inspect the tire for damage. If the tire is under-inflated or damaged, deflate it, remove the tire and rim and replace it with your spare tire.

  • Page 570: Vehicle Loading

    Customer Information and Reporting Safety Defects Tire Information (except Canada) Vehicle Loading This section will guide you in the proper loading of your vehicle and/or trailer, to keep your loaded vehicle weight within its design rating capability, with or without a trailer. Properly loading your vehicle will provide maximum return of vehicle design performance.
  • Page 571 Customer Information and Reporting Safety Defects Tire Information (except Canada) Payload is the combination weight of cargo and passengers that the vehicle is designed to carry. The maximum payload for your vehicle can be found on the Tire and Load Information label on the driver's door frame or door pillar.
  • Page 572 Customer Information and Reporting Safety Defects Tire Information (except Canada) CARGO Cargo Weight includes all weight added to the Base Curb Weight, including cargo and optional equipment. When towing, trailer tongue load or king pin weight is also part of cargo weight.
  • Page 573 Customer Information and Reporting Safety Defects Tire Information (except Canada) GAWR (Gross Axle Weight Rating) is the maximum allowable weight that can be carried by a single axle (front or rear). These numbers are shown on the Safety Compliance Certification Label located on the driver's door frame or door pillar. The total load on each axle must never exceed its GAWR.
  • Page 574 Customer Information and Reporting Safety Defects Tire Information (except Canada) SAMPLE WARNING Exceeding Axle Weight Rating Limits: Exceeding the Safety Certification Label axle weight rating limits is dangerous and could result in death or serious injury as a result of substandard vehicle handling, performance, engine, transmission and/or structural damage, serious damage to the vehicle, or loss of control.
  • Page 575 Customer Information and Reporting Safety Defects Tire Information (except Canada) GCW (Gross Combination Weight) is the weight of the loaded vehicle (GVW) plus the weight of the fully loaded trailer. GCWR (Gross Combination Weight Rating) is the maximum allowable weight of the vehicle and the loaded trailer - including all cargo and passengers - that the vehicle can handle without risking damage.
  • Page 576 Customer Information and Reporting Safety Defects Tire Information (except Canada) WARNING Exceeding GVWR or GAWR Specifications: Exceeding the GVWR or the GAWR specified on the certification label is dangerous. Exceeding any vehicle rating limitation could result in a serious accident, injury, or damage to the vehicle.

  • Page 577: Steps For Determining The Correct Load Limit

    Customer Information and Reporting Safety Defects Tire Information (except Canada) Steps for Determining the Correct Load Limit Steps for Determining Correct Load Limit- (1) Locate the statement “The combined weight of occupants and cargo should never exceed XXX kg or XXX lbs.” on your vehicle's placard. (2) Determine the combined weight of the driver and passengers that will be riding in your vehicle.

  • Page 578: Reporting Safety Defects

    7755 Irvine Center Drive Irvine, California 92618-2922 P.O. Box 19734 Irvine, CA 92623-9734 Customer Assistance Center or toll free at 1 (800) 222-5500 If you live outside of the U.S.A., please contact the nearest Mazda Distributor shown (page 9-13) in this booklet. 9-45...

  • Page 579: Reporting Safety Defects (Canada)

    Customer Information and Reporting Safety Defects Reporting Safety Defects Reporting Safety Defects (Canada) Canadian customers who wish to report a safety-related defect to Transport Canada, Defect Investigations and Recalls, may telephone the toll free hotline 1-800-333-0510, or contact Transport Canada by mail at: Transport Canada, ASFAD, Place de Ville Tower C, 330 Sparks Street, Ottawa ON K1A 0N5.

  • Page 580: Service Publications

    Factory-authorized Mazda service publications are available for owners who wish to do some of their own maintenance and repair. When requesting any of our publications through an Authorized Mazda Dealer, refer to the chart below. If they do not have what you need in stock, they can order it for you.
  • Page 581 Customer Information and Reporting Safety Defects Service Publications qSERVICE HIGHLIGHTS: Provides description and operation of the many systems of your Mazda. qNAVIGATION SYSTEM OWNER'S MANUAL: This booklet contains information regarding the proper operation and use of the navigation system. This is not a technician's manual.
  • Page 582 Specifications Technical information about your Mazda. Identification Numbers ............... 10-2 Vehicle Information Labels ............. 10-2 Specifications ................10-4 Specifications ................10-4 Personalization Features ............10-8 Personalization Features ............10-8 10-1...

  • Page 583: Identification Numbers

    Identification Numbers qChassis Number Vehicle Information Labels Open the cover shown in the figure to qVehicle Identification Number check the chassis number. The vehicle identification number legally identifies your vehicle. The number is on a plate attached to the cowl panel located on the left corner of the dashboard.
  • Page 584 Identification Numbers qTire Pressure Label qEngine Number Forward 10-3...
  • Page 585 API Service GL-5 (SAE 75W-140) Rear differential oil API Service GL-5 (SAE 80W-90) Power steering fluid Mazda Genuine ATF M-III, M-V, or equivalent (e.g. Dexron® II) Brake fluid SAE J1703, or FMVSS116 DOT-3 NOTE Refer to Introduction on (page 8-2) for owner's responsibility in protecting your investment.
  • Page 586 Specifications qCapacities (Approximate Quantities) Item Capacity With oil filter replacement 5.2 L (5.5 US qt, 4.6 Imp qt) Engine oil Without oil filter replacement 4.7 L (5.0 US qt, 4.2 Imp qt) Mexico 12.1 L (12.8 US qt, 10.6 Imp qt) Coolant With Towing Package 12.1 L (12.8 US qt, 10.6 Imp qt)
  • Page 587 NOTE The tires have been optimally matched with the chassis of your vehicle. When replacing tires, Mazda recommends that you replace tires of the same type originally fitted to your vehicle. For details, contact an Authorized Mazda Dealer. í...
  • Page 588 Specifications Check the tire pressure label for tire size and inflation pressure. Refer to Tire Inflation Pressure on page 8-34. Standard tire Inflation pressure Tire size Front Rear P245/60R18 104H 250 kPa (36 psi) 250 kPa (36 psi) P245/50R20 102V 230 kPa (34 psi) 230 kPa (34 psi) Temporary spare tire...

  • Page 589: Personalization Features

    Personalization Features Personalization Features The following “Personalization Features” are available. These settings can only be changed by an Authorized Mazda Dealer. Item Feature Factory Setting Available Settings Standard The headlight illumination on/off timing based (Illuminates under Auto headlight on/off on surrounding lightness/darkness can be...

  • Page 590: Index

    Index 11-1...
  • Page 591 Index Accessory Socket ......6-175 Battery Add-On Non-Genuine Parts and Emergency starting ....7-18 Accessories ........9-20 Maintenance ....... 8-32 Advanced Key ........3-2 Specifications ......10-4 Advanced key maintenance ..3-5 Beep Sounds Advanced key suspend Blind spot monitoring system function ........
  • Page 592 Index Bulb Replacement ......8-40 Driving on Uneven Road ....4-13 Driving Tips ........4-6 Automatic transaxle ....5-16 Break-in period ......4-6 Capacities .......... 10-5 Driving in flooded area ....4-12 Carbon Monoxide ....... 4-4 Driving on uneven road ..... 4-13 Cargo Securing Loops ....
  • Page 593 Index Flasher HomeLink Wireless Control Hazard warning ......5-80 System ..........5-81 Headlights ........5-65 Hood Release ........3-49 Flat Tire ..........7-3 Horn ..........5-79 Changing ........7-8 Spare tire and tool storage .... 7-3 Fluids Classification ......10-4 Ignition Owner maintenance ....
  • Page 594 Index Keyless Entry System ....... 3-22 Overloading ........4-12 Keys ..........3-21 Paint Damage ........8-56 Label Information ......10-2 Parking Brake ........5-7 Lane-Change Signals ......5-71 Parking in an Emergency ....7-2 Liftgate ..........3-33 Parking Sensor System ..... 5-40 Light Bulbs Park assist sensor switch ....
  • Page 595 Index Registering Your Vehicle in A Foreign Specifications ........10-4 Country ..........9-19 Speedometer ........5-46 Rocking the Vehicle ......4-9 SRS Air Bags Roll-over ..........4-8 Driver and front passenger occupant classification system ....2-68 How the SRS air bags work ..2-61 Limitations to SRS air bag ..
  • Page 596 Index Warning Lights ......... 5-49 Tire Pressure Monitoring System ..5-28 ABS ..........5-52 System error activation ....5-32 Air bag system ......5-54 Tire pressure monitoring system Automatic transaxle ....5-55 warning light ......5-30 AWD .......... 5-56 Tires and wheels ......5-32 Brake system ......
  • Page 597 11-8...

Table of Contents
