OSSP Owner's Manual
SELF PROPELLED OVERSEEDER Owner's Manual
OS901SPS, OS901SPH
Beginning Serial #: 020416001
Accessories
Replacement Parts
CHARIOT KIT
REEL KIT
BLADE KIT
Allows the user to ride
Use to replace worn or
Use to replace worn or
behind the unit and
damaged reels.
damaged blades on the
decrease fatigue from
reel.
walking.
P/N 351601
P/N 351603
P/N 351610
Original Instructions
IMPORTANT- READ CAREFULLY BEFORE USE AND KEEP FOR FUTURE REFERENCE
Part No 351520
1
Form No F020416C
Advertisement
Table of Contents
Related Manuals for Billy Goat OS901SPS
Summary of Contents for Billy Goat OS901SPS
- Page 1 OSSP Owner’s Manual SELF PROPELLED OVERSEEDER Owner's Manual OS901SPS, OS901SPH Beginning Serial #: 020416001 Accessories Replacement Parts CHARIOT KIT REEL KIT BLADE KIT Allows the user to ride Use to replace worn or Use to replace worn or behind the unit and damaged reels.
-
Page 2: Table Of Contents
OSSP Owner’s Manual CONTENTS SPECIFICATIONS AND SOUND/VIBRATION INSTRUCTION LABELS PACKING CHECKLIST ASSEMBLY OPERATION MAINTENANCE & TROUBLESHOOTING 9-10 PARTS LIST 11-22 DECLARATION OF CONFORMITY 23-25 Part No 351520 Form No F020416C... -
Page 3: Specifications And Sound/Vibration
OSSP Owner’s Manual SPECIFICATIONS OS901SPS OS901SPH Engine: HP’ 9.0 HP (6.7kW) 9.0 HP (6.7kW) Engine: Model EX270D50021 GX270K1QA2 Engine: Type Subaru Honda Engine: Fuel Capacity 6.4 qt. (6.1 L) 5.6 qt. (5.3 L) Engine: Oil Capacity 1.06 qt. (1 L) 1.16 qt. -
Page 4: Instruction Labels
INSTRUCTION LABELS ® The labels shown below were installed on your BILLY GOAT Overseeder. If any labels are damaged or missing, replace them before operating this equipment. Item numbers from the Illustrated Parts List and part numbers are provided for convenience in ordering replacement labels. -
Page 5: Packing Checklist
OSSP Owner’s Manual PACKING CHECKLIST Your Billy Goat Overseeder is shipped from the factory in one carton. READ all safety instructions before assembling unit. TAKE CAUTION when removing the unit from the box, the Handle Assembly is attached to the unit and cables could snag. -
Page 6: Assembly
OSSP Owner’s Manual ASSEMBLY NOTE: Items in ( ) can be referenced in the Parts Illustrations and Parts Lists on pages 11-22. 1. UNFOLD the upper handle and slide handle lock loops (item 35) into place to secure the upper handle to the lower. 2. -
Page 7: Operation
OSSP Owner’s Manual OPERATION NOTE: Items in ( ) can be referenced in the Parts Illustrations and Parts Lists on pages 11-22. FOLDING HANDLE This unit is equipped with a folding upper handle for easier storage and transportation. The handle can be folded by sliding the handle lock loops (item 35) up. - Page 8 OSSP Owner’s Manual ADJUSTING SEED RATE To set the seed flow rate, loosen the knob on the indicator dial and turn it to the corresponding stop setting on the seed application chart (below or on the console) for the type and amount of seed being used. (See Fig. 4) INSTRUCTION LABEL P/N 351501 Fig.
-
Page 9: Maintenance & Troubleshooting
OSSP Owner’s Manual MAINTENANCE NOTE: Items in ( ) can be referenced in the Parts Illustrations and Parts Lists on pages 11-22. PERIODIC MAINTENANCE Periodic maintenance should be performed at the following intervals: Maintenance Operation Every Use (daily) Every 25 Hours ... - Page 10 OSSP Owner’s Manual MULE BELT REPLACEMENT 1. Wait for engine to cool and disconnect spark plug. 2. Place the rear of the unit on blocks. 3. Remove the right rear tire (item 11) and spring (item 155) attaching the housing to the frame. 4.
-
Page 11: Parts List
OSSP Owner’s Manual SLICING REEL ASSY P/N 351603 ITEM NO DESCRIPTION PART NO. SHAFT VERTICUTTING REEL OS900SP 351111 BLADE VERTICUT OS900SP 351305 SPACER PM REEL OS900SP 351261 SPACER HARDENED REEL OS900SP 351297 SPRING DISC 7/8" ID 351298 NUT 7/8"-14 NC 350341 45°... - Page 12 OSSP Owner’s Manual OSSP ENGINE ASSEMBLY PARTS DRAWING Part No 351520 Form No F020416C...
- Page 13 OSSP Owner’s Manual OSSP ENGINE ASSEMBLY PARTS LIST OS901SPH OS901SPS ITEM NO. DESCRIPTION PART NO. QTY PART NO. QTY ENGINE HONDA 9HP 430287 ENGINE SUBARU 9HP 351299 ENGINE BASE WA 351125 351125 JACKSHAFT WA 351107 351107 BELT GATES #8954-0298 351211...
- Page 14 OSSP Owner’s Manual OSSP REEL/REEL DRIVE ASSEMBLY PARTS DRAWING Part No 351520 Form No F020416C...
- Page 15 OSSP Owner’s Manual OSSP REEL/REEL DRIVE ASSEMBLY PARTS LIST OS901SPH OS901SPS ITEM NO. DESCRIPTION PART NO. PART NO. ENGINE BASE WA 351125 351125 HOUSING VERTICUTTER WA OS900SP 351101 351101 FRAME SUPPORT OS900SP WA 351126 351126 BEARING 3/4" CAST FLANGE W/ZERK...
- Page 16 OSSP Owner’s Manual OSSP HANDLE ASSEMBLY PARTS DRAWING Part No 351520 Form No F020416C...
- Page 17 OSSP Owner’s Manual OSSP HANDLE ASSEMBLY PARTS LIST OS901SPH OS901SPS ITEM NO. DESCRIPTION PART NO. PART NO. FRAME SUPPORT OS900SP WA 351126 351126 PLUG TUBE INSERT 1.25 OD 791056 791056 HANDLE FOLDING OS900SP 351406 351406 BUMPER RECESS 360298 360298 BRACKET CONSOLE OS900SP...
- Page 18 OSSP Owner’s Manual OSSP SEED BOX ASSEMBLY PARTS DRAWING Part No 351520 Form No F020416C...
- Page 19 OSSP Owner’s Manual OSSP SEED BOX ASSEMBLY PARTS LIST OS901SPH OS901SPS ITEM NO. DESCRIPTION PART NO. PART NO. FRAME SUPPORT OS900SP WA 351126 351126 SEED BOX WA 351103 351103 FRONT WHEEL 14" ASSY 351013 351013 BEARING & FLANGETTE ASSY 850232...
- Page 20 OSSP Owner’s Manual OSSP TRANSMISSION ASSEMBLY PARTS DRAWING Part No 351520 Form No F020416C...
- Page 21 OSSP Owner’s Manual OSSP TRANSMISSION ASSEMBLY PARTS LIST OS901SPH OS901SPS ITEM NO. DESCRIPTION PART NO. PART NO. TRANSAXLE 351201 351201 ENGINE BASE WA 351125 351125 FRAME SUPPORT OS900SP WA 351126 351126 JACKSHAFT WA 351107 351107 REAR WHEEL13" X 5" PNEU ASSY...
- Page 22 OSSP Owner’s Manual OSSP TRANSMISSION ASSEMBLY PARTS LIST OS901SPH OS901SPS ITEM NO. DESCRIPTION PART NO. PART NO. BRACKET TORQUE LIMITING 351294 351294 NUT 5/16"-18 SER HEX WASHER FLNG ZP 350346 350346 SCREW SPOT WELD 5/16"-18 X 3/4 W/PROJ 351263 351263 BOLT CARRIAGE 5/16"-18 X 3/4"...
-
Page 23: Declaration Of Conformity
OSSP Owner’s Manual Руccкий Latviešu English Suomi Slovenščina български език Français Nederlands Čeština Slovák Ελληνικά Norsk Svenska Dansk Hrvatski Polski Türkçe Deutsch Magyar Português Română Español Italiano Lietuvių eesti keel Δήλωση συμμόρφωσης ΕΚ Deklaracja zgodności UE EC Declaration of Conformity Декларация... - Page 24 Ölçülen Ses Gücü Garantili Ses Gücü tr M odel Operatörün Kulağındaki Ses Basınç Seviyesi (1) M akine Net Gücü El/Kol Titreşimi (2) Ağırlı k Seviyesi Seviyesi OS901SPS 105 dB(A) 104 dB(A) 84 dB(A) 6.7 kW 4.95 m/s 142 kg OS901SPH 105 dB(A)
- Page 25 OSSP Owner’s Manual (1) ISO 5395-1:2013 F.7 (EN 4871:1996) (2) ISO 5395-1:2013 G.8 (EN 12096:1997, D.1) Manufacturing Place / Keeper of Documentation Τόπος κατασκευής / Υπεύθυνος τήρησης αρχείων Miejsce produkcji / Osoba odpowiedzialna za Място на производство / Архивар τεκμηρίωσης przechowywanie dokumentów Místo výroby / Držitel dokumentace Gyártás helye / A dokumentáció...
