Page 1
CUISINART™ C790SR Assembly Manual 85-3032-4 (G51217) Propane 85-3033-2 (G51218) Natural Gas LIMITED 5-YEAR WARRANTY Read and save manual for future reference. Assemble your grill immediately. Missing or damaged parts should be claimed within 30 days of purchase. For product inquiries, parts, warranty and troubleshooting support, please call 1-800-309-3452.
HARDWARE PACK TOOLS NEEDED FOR ASSEMBLY No. Description Part Number Quantity ¼"-20UNCX13 Screw 20120-13013-250 • #2 Phillips screwdriver (Long and short) ¼"-20UNCX38 Screw 20120-13038-250 • ¼” Slotted screwdriver (Long and short) ¼"-20UNCX16 Screw 20120-13016-250 • Adjustable wrench ø7 Lock Washer 41400-07000-250 •...
Page 3
PARTS LIST (PROPANE) FOR 85-3032-4 (G51217) EXPLODED DIAGRAM (PROPANE) FOR 85-3032-4 (G51217) Item Qty. Description Part No. Item Qty. Description Part No. Top Lid G512-B800-01 Upper Back Panel G512-0036-01 Lid Handle G512-0053-01 Heat Shield G512-0026-01 Thermometer G512-0085-01 Screw for Top Lid G501-0005-02 Side Shelf Table- Left G512-0600-02...
Page 4
PARTS LIST (NATURAL GAS) FOR 85-3033-2 (G51218) EXPLODED DIAGRAM (NATURAL GAS) FOR 85-3033-2 (G51218) Item Qty. Description Part No. Item Qty. Description Part No. Top Lid G512-B800-01 Upper Back Panel G512-0036-01 Lid Handle G512-0053-01 Heat Shield G512-0026-01 Thermometer G512-0085-01 Screw for Top Lid G501-0005-02 Side Shelf Table- Left G512-0600-02...
Page 5
ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS Separate the 2 different types of wheels, Attach the front brace (CK) to the left and right 2 locking wheels (EH) and 2 regular wheels (EI). cart side panels (EA and EB) Insert the U Pin (#10) into one of the regular TIP: One person should align the left side, while wheels (EI), as shown in image B.
Page 6
ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS THIS STEP REQUIRES 3 OR MORE PEOPLE. Attach the right side shelf fascia (DI) to the right DO NOT ATTEMPT ALONE. EXTREMELY side shelf table (DH), as shown. HEAVY. a. Position the top lid and burner box assembly (A and B) onto cart assembly (C) as shown.
Page 7
ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS Attach the left side shelf fascia (DB) to the left side Remove the hardware that is pre-assembled to the Front shelf table (DA). side burner valve bracket (CC), as shown in figure A. Insert the side burner valve stem through the rear of the left side shelf fascia (DB).
Page 8
ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS a. Position the side burner (DD) through the e. Attach the end of the side burner electrode wire opening in the left side burner drip pan (DC). (DE) to the underside of the side burner elec- trode, as shown in figure E.
Page 9
ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS a. Assemble the towel bar (BN) onto door (EF). Place the flame tamers (BG) into the burner box. YOU WILL NEED: TIP: Before attempting to assemble the door (EF) to the right pillar (ED), locate the two clasps on the door Hinge.
Page 10
ATTENTION: For your families safety, do not attempt to light this BBQ until you have reviewed pages 4-7 of the Cuisinart Safety & Care Manual. All Safety and Leak test MUST BE PERFORMED BY THE END USER, prior to lighting this BBQ.
