18
SPECIFICATIONS
1. Frequency range
FM
87~108 MHz
MW
520~1610 kHz
SW1
3000~8000 kHz
SW2
8000~17000 kHz
SW3
17000~28000 kHz
2. Sensitivity
FM (S/N=30dB)
Less than 5μV
MW (S/N=26dB)
Less than 0.5mV/m
SW (S/N=26dB)
Less than 30μV
3. Selectivity
＞40 dB (±200kHz)
FM
＞40 dB (±9kHz)
MW
＞40 dB (±5kHz)
SW
4. FM Stereo crosstalk
Less than 20 dB
5. Output (Distortion 10%)
1000 mW
6.External Antenna input
FM
75
Ohm
MW/SW
50
Ohm
7. Power supply
Batteries:
D size , UM1(alkaline) X 4
DC adaptor:
DC 6V 500mA, negative
φ
Outside diameter:φ5.5mm, core diameter: 2mm
φ102mm, 2W/8Ohm
8. Speake
φ3.5mm, 8~32 Ohm, Stereo type
9. Earphone Jack
10. Dimensions Approx. : 272(W) X 173(H) X 88(D) mm
11. Weight :
1400g (Batteries not included)
,
