  • Page 1 Dear customer! Thank you for choosing this quality product from ASKO. We hope it will meet your expectations and fulfil your needs for many years to come. Scandinavian design combines clean lines, everyday functionality and high quality. These are key characteristics of all our products and the reason they are greatly appreciated throughout the world.

  • Page 2: Design Guide

    Proper installation is the responsibility of the installer. Product failure due to improper installation is not WARNING–R600a Refrigerant covered under the Asko Warranty. This appliance contains isobutane refrigerant, R600a, a natural gas with high environmental WARNING: compatibility. However it is also combustible.
  • Page 3 Cabinet Enclosure Dimensions For Fully Integrated Instructions The cutout depth must be 635 mm for flush installations. • The front face of the refrigerator fits flush with 635 mm 635 mm min. depth 762 mm Finished Width depth adjacent cabinets. • The refrigerator can fit into a 2020 mm minimum, 2044 mm maximum high enclosure.
  • Page 4 Refrigerator Dimensions with 19 mm Panels Case Top with Panels Door 603 mm (Case and Door only) 19 mm 750 mm Height adjustable from 3 mm 2017 to 2041 mm Clearance 164 mm 102 mm 32 mm Front with Panels Side with Panels Install Clearances Each Side...

  • Page 5: The Installation Space

    THE INSTALLATION SPACE Anti-Tip location. Do not obstruct this area. Water and Electrical Locations Electrical and water supply should be located in shaded area only as shown. PREPARING INSTALL WATER LINE Front view 2032 mm • A cold water supply is required for automatic Install Space 1956 mm icemaker operation.
  • Page 6 Product Clearances These refrigerators are equipped with a 2-position door stop. The factory-set 115° door swing can be adjusted to 90° if clearance to adjacent cabinets or walls is restricted. For 90° Door swing see page 7. 425 mm 3 mm 36 mm 50 mm Stainless Steel or Custom Panels...
  • Page 7 For a 90º door swing allow 90 mm min. clearance to a wall, for stainless steel models. 3 mm 25 mm 55 mm Stainless Steel or Custom Panels Top View 90° DOOR SWING (optional setting)
  • Page 8 SS PANEL ACCESSORY & DIMENSIONS 19 mm-Thick Solid Door Panel Option 19 mm-Thick Frame for Glass Door Options 756 mm * 756 mm * 152 mm * 584 mm * 1152 mm * 1152 mm * 191 mm * 152 mm * 86 mm * 578 mm * Check door panel dimensions for hook and bracket...

  • Page 9: Important Note

    19 mm CUSTOM PANEL DIMENSIONS NOTE! If you choose to install custom panels, they must be cut This product is designed to handle 19 mm panels to the dimensions shown. The panels will attach to the that are made of wood. door and drawers using a hook and bracket system.

  • Page 10: Custom Panel Dimensions

    CUSTOM PANEL DIMENSIONS Solid Door Version Glass Door Version...
  • Page 11 720 mm 687,2 mm 666 mm Top of Panel 5 mm Routing 50 mm 50 mm 274 mm 413 mm 5 mm Routing is required in shaded areas only Pilot holes 3 mm diameter, 8 mm depth 27 mm Solid Door Template Custom Panel 27 mm Warning: Before drilling holes for brackets, please make...
  • Page 12 687,2 mm 666 mm Top of Panel 5 mm Routing is required in shaded areas only Freezer Drawer Template Custom Panel Pilot holes 3 mm diameter, 8 mm depth 27 mm Warning: Before drilling holes for brackets, please make sure they do not line up with thin areas on the panel. 38,1 38,1 5 x 76,2 = 381 mm...
  • Page 13 720 mm 687,2 mm 666 mm Top of Panel 5 mm Routing 9 mm Routing 50 mm 50 mm 274 mm 413 mm 5 mm Routing is required in shaded areas only Pilot holes 3 mm diameter, 8 mm depth 27 mm Glass Door Template Custom Panel...

  • Page 14: Installation Instructions

    INSTALLATION INSTRUCTIONS TOOLS REQUIRED MATERIALS REQUIRED • 4 mm Allen wrench • Refrigerator Tubing kits • Utility knife • Water shut-off valve • Stepladder • Custom panels for fresh food door, freezer drawer • Bucket and Convertible drawer • Level • Velcro w/adhesive if using custom toekick.

  • Page 15: Step 1 Remove Packaging

    STEP 1 STEP 2 REMOVE PACKAGING INSTALL ANTI-TIP BRACKET • Inside Top Face of bracket should be installed at CAUTION! 203 cm. “Slot” in bracket should to be placed in center The refrigerator is top-heavy, be careful when of install Space (Typically 38 cm). moving.

  • Page 16: Step 3 Connect Water Line

    STEP 3 STEP 4 CONNECT WATER LINE CONNECT POWER • Plug the power cord into the socket. • Check to make sure power to refrigerator is on by opening the ice drawer (FF door will be banded shut) to see if interior lights are on. • The temperature controls are preset at 3°C for the Water fresh food section and -18°C in both the freezer...

  • Page 17: Step 5 Slide Unit Into Enclosure

    STEP 5 STEP 6 SLIDE UNIT INTO ENCLOSURE REMOVE TOEKICK AND VENT Roll the unit into the enclosure, being careful not to pinch The toekick must be removed to access the leveling leg the water line or power cord. system. • Remove band around EPS block in front of toekick.

  • Page 18: Step 7 Level Refrigerator

    STEP 7 STEP 8 LEVEL REFRIGERATOR INSTALL TOEKICK AND VENT All models have 4-point leveling. The front is supported • Locate the toekick, vent and screws (removed earlier). by leveling legs; the rear is supported by adjustable • A custom toekick can be installed to match or wheels.
  • Page 19 STEP 9 5. Remove the trim and hinge pocket from the top of the REVERSE DOOR SWING (If needed) refrigerator and install on the opposite sides. 6. Remove the trim and hinge pocket from the bottom Skip this step if door swing is satisfactory. of the fresh food compartment.
  • Page 20 10. To install the top hinge, turn the hinge in the 14. Install screws on the bottom hinge next. proper direction—the section of the bracket that 15. Using a Torx T-20 wrench, tighten the tension on the will be attached to the door should be at the bottom hinge springs by turning the screws from 0 to |.

  • Page 21: Step 11 Attach Hinge Guard

    STEP 10 STEP 11 ADJUST DOOR SWING (if needed) ATTACH HINGE GUARD NOTE: This refrigerator has a 2-position door stop. WARNING! When space does not allow the door to swing to 115°, you may limit the door swing to a 90°. This appliance must be installed &...

  • Page 22: Step 12 Install Door And Drawer Panels

    5. Adjust the screw posts up or down under the STEP 12 bracket on top of the door to level the panel. INSTALL DOOR AND DRAWER PANELS 6. Lock the panel to the door by installing the nuts provided onto the screw posts on top of the door. 1.

  • Page 23: Step 13 Start Icemaker

    BACK VIEW OF PANEL HOOKS AND BRACKET Fresh Food Door Convertible drawer The lower brackets on the Fresh Food & Convertible Drawer should not be installed until after the panel is in place. STEP 13 START ICEMAKER • Press the ZONE indicator on the control pad twice to select the freezer drawer.
  • Page 24 en (10-14)
