Service manual
GCS29 NFH - GCS30NFH
Contents
Introduction.....................................................................................................................3
Product overview............................................................................................................4
Option and settings .....................................................................................................6
Anomalies signalling ...................................................................................................8
Option and settings ........................................................................................................9
Anomalies signalling ....................................................................................................8
Components description................................................................................................11
Components values........................................................................................................13
Manual test procedure ................................................................................................17
Manual test procedure ................................................................................................18
Dismounting instructions................................................................................................19
Lower Hinge regulating.................................................................................................27
Wiring diagrams...............................................................................................................28
Exploded view.................................................................................................................30
Manufacturer reserves the possibilities to modifiy this manual without notice.
1a EDiTION - 2014
-
466000288 rev.000
Advertisement
Table of Contents
Related Manuals for Asko GCS29NFH
Summary of Contents for Asko GCS29NFH
-
Page 1: Table Of Contents
Service manual GCS29 NFH - GCS30NFH Contents Introduction........................3 Product overview......................4 Option and settings .....................6 Anomalies signalling ....................8 Option and settings ......................9 Anomalies signalling ....................8 Components description....................11 Components values......................13 Manual test procedure ....................17 Manual test procedure ....................18 Dismounting instructions....................19 Lower Hinge regulating....................27 Wiring diagrams.......................28 Exploded view.........................30 Manufacturer reserves the possibilities to modifiy this manual without notice. - Page 2 Service manual GCS29NFH - GCS30NFH...
-
Page 3: Introduction
Service manual GCS29NFH - GCS30NFH Introduction You are holding the service manual for the generation of touch control cooling product. There are different types of up-right no frost freezer touch series: . The following page presents the different versions, to help you identify the machine types. -
Page 4: Product Overview
Service manual GCS29NFH - GCS30NFH Type overview Upright no frost freezer touch display version PRE-ALARM DISPLAY TEMPERATURE SUPER ON / OFF DOOR OPEN and ALARM FREEZER SETTING FUNCTION ALARM TEMPERATURE Appliance is provided with an electronic module touch version placed inside the control panel that allow to select various temperature positions available and within the range -16°C to -24°C. - Page 5 Service manual GCS29NFH - GCS30NFH Type overview Internal view of the appliance No frost radiator in the freezer c o m p a r t m e n t Internal view of the appliance...
-
Page 6: Option And Settings
Service manual GCS29NFH - GCS30NFH Option and settings touch display type Touch display type STARTING THE APPLIANCE - F2583NF TOUCH-DISPLAY ON / OFF DISPLAY FREEZER TEMPERATURE ADJUSTMENT SUPER FUNCTION PREALLARME E ALLARME TEMPERATURA DOOR OPEN ALARM IMPORTANT WARNING IMPORTANT Whenever the product has been lying horizontally during... - Page 7 Service manual GCS29NFH - GCS30NFH Option and settings touch display type Touch display type STARTING THE APPLIANCE - MOD. F2583NF TOUCH-DISPLAY PRE-ALARM MODE AND FREEZER TEMPERATURE The pre-alarm mode is indicated by the temperature appearing intermittently on the freezer display, by the flashing white ALARM PRE-ALARM INDICATION symbol and by the audible alarm.
-
Page 8: Anomalies Signalling
Service manual GCS29NFH - GCS30NFH Anomalies and signalling touch display type Touch display type Checking and procedures --- ANOMALIES MANAGING --- (troubleshooting) SIGNAL ON THE DISPLAY: "-E" or "E-" If display shows the flashing symbol "-E" or "E-" , this means that a temperature sensor is defective: Flashing signal "-E"... -
Page 9: Option And Settings
Service manual GCS29NFH - GCS30NFH Option and settings touch leds type Touch leds type ON / OFF TEMPERATURE ADJUSTMENT SUPER FUNCTION ALARM FUNCTION IMPORTANT WARNING IMPORTANT Whenever the product has been lying horizontally during Before plugging the appliance in, make sure that the power... - Page 10 Service manual GCS29NFH - GCS30NFH Anomalies and signalling touch display type Touch display type Checking and procedures --- ANOMALIES MANAGING --- (troubleshooting) SIGNAL ON THE DISPLAY: "-E" or "E-" If display shows the flashing symbol "-E" or "E-" , this means that a temperature sensor is defective: Flashing signal "-E"...
-
Page 11: Components Description
Service manual GCS29NFH - GCS30NFH Components description (freezer compartment - no frost radiator kit) Defrosting end sensor This sensor signals the end for defrosting-time to the electronic module. Motor Fan The fan runs in parallel to the compressor Not restorable thermo-fuses... - Page 12 Service manual GCS29NFH - GCS30NFH Components description (reed and magnet postion) Magnet position At the internal upper part of the door cover for the freezer compartment is mounted the magnet that when move under the control panel sends the signal to the reed to stop the...
-
Page 13: Components Values
Service manual GCS29NFH - GCS30NFH Components values (Components - datasheet) WARNING! Values shown at the side view are exclusively related to the freezer compartment temperature sensor of this appliance. Freezer compartment temperature sensor FRD038 - F12496 OHM values detected at the related temperature Verifying procedure - Disconnect the appliance from main electricity supply. - Page 14 Service manual GCS29NFH - GCS30NFH Components values (Components - datasheet) WARNING! Values shown at the side view are exclusively related to the defrosting sensor of this appliance. Defrosting sensor FRD127 --- F12788 OHM values detected at the related temperature Verifying procedure - Disconnect the appliance from main electricity supply.
- Page 15 Service manual GCS29NFH - GCS30NFH Components values (Components - datasheet) WARNING! Values shown at the side view are exclusively related to the defrosting sensor with integrated thermofuses of this appliance. Defrosting sensor with integrated thermo-fuses FRD145 --- F12998 O H M v a l u e s d e t e c t e d a t t h e re l a t e d t e m p e r a t u re Verifying procedure - Disconnect the appliance from main electricity supply.
- Page 16 Service manual GCS29NFH - GCS30NFH Components values (Components - datasheet) WARNING! Values shown in this page are exclusively related to the heating element and the thermo-fuses for this appliance. Heating element and thermo-fuses OHM values A fast checking for the right functioning of the heating element and the thermo-fuses can be done...
-
Page 17: Manual Test Procedure
Service manual GCS29NFH - GCS30NFH Manual test procedure (Manual test procedure) Touch display type Autotest procedure to check the right functioning of the electronic module components Manual test activation: Touch display type procedure GCS29-30NFH CB11../CB17..1- Switch off the electronic module by touching the button Off/Standby 2- Keep touching for 4 seconds about the button "Super": a sound of a beep will confirm the access to manual test... -
Page 18: Manual Test Procedure
Service manual GCS29NFH - GCS30NFH Manual test procedure Touch leds type (Manual test procedure) Autotest procedure to check the right functioning of the electronic module components Manual test activation: Touch leds type procedure GCS29-30NFH CB11../CB17..1- Switch off the electronic module by touching the button Off/Standby 2- Keep touching for 4 seconds about the button "Super": a sound of a beep will confirm the access to manual test mode. -
Page 19: Dismounting Instructions
Service manual GCS29NFH - GCS30NFH Dismounting procedure (upper door and support removing procedure) upper door view support removed: rotate the support in counterclockwise support turned lateral view sense: the door will be free and we can remove it. Assemble the door to the pin... - Page 20 Service manual GCS29NFH - GCS30NFH Dismounting procedure (no frost radiator kit area access) No frost radiator kit opening Radiator kit in the freezer compartment fixing point between the diffuser parts diffuser: 3 upper part fixing h o o k diffuser: 2...
- Page 21 Service manual GCS29NFH - GCS30NFH Dismounting procedure (no frost radiator kit area access) Fixing upper screw No frost radiator kit opening view 1- After have removed the diffuser parts go to the back side of the appliance: Apply a protection to the condenser upper part...
- Page 22 Service manual GCS29NFH - GCS30NFH Dismounting procedure (no frost radiator kit area access) Upper conveyer removed view No frost radiator kit opening The opening of the radiator kit can now be done obviously only in a partial way because the suction Exit point of pipe is still connected to the compressor.
- Page 23 Service manual GCS29NFH - GCS30NFH Dismounting procedure (no frost radiator kit - motorfan replacing) Motorfan replacing fixing hook detail Motorfan position on the radiator kit Joint support for motorfan Motor fan is mounted on his support inserted in a joint on the radiator kit from...
- Page 24 Service manual GCS29NFH - GCS30NFH Dismounting procedure (no frost radiator kit - motorfan replacing) Remove the fan by manually pull it Fan removed view from the central point. Remove the back side support making free the fixing hooks at both lateral sides of the support.
- Page 25 Service manual GCS29NFH - GCS30NFH Dismounting procedure Handle: Installation/replacing 1 - ASKO step 2 Handle view 4 - Unscrew at the lateral side 2 - Fixing screw at the lower side (view) 5 - remove the handle 6 - remove the handle support...
- Page 26 Service manual GCS29NFH - GCS30NFH Dismounting procedure Electronic module: Installation/replacing 1 -remove the closing cap of the hole's screw which are pressure m o u n t e d : t h e n re m o v e t h e fixing screws at both the lower s i d e s o f t h e c o n t ro l p a n e l .
-
Page 27: Lower Hinge Regulating
Service manual GCS29NFH - GCS30NFH Lower Hinge regulating (door alignment) Door alignment is possible by regulating the lower hinge fixing the screw in the optimal postion. Door alignment regulating holes... -
Page 28: Wiring Diagrams
Service manual GCS29NFH - GCS30NFH Wiring diagram (Wiring diagram ) TOUCH-DISPLAY TYPE ref. code 460618148... - Page 29 Service manual GCS29NFH - GCS30NFH Wiring diagram (Wiring diagram) TOUCH-LEDS TYPE ref. code 460618145...
-
Page 30: Exploded View
Exploded view 999046580 Service manual GCS29NFH - GCS30NFH...
