Maintenance and repairs must be done by authorized personnel only. To prevent injury, always unplug the MODEL_______________________________ machine before doing any repairs. SERIAL NUMBER______________________ For new books write to: Pacific Steamex, Inc. PART NUMBER________________________ 2259 S. Sheridan Muskegon, MI 49442-6252 DATE PURCHASED_____________________ 03/01...
BELT REPLACEMENT Note: Throughout this manual there are references to Drawing 1 and Drawing 2. See Page 8 for Drawing 1 and Page 10 for Drawing 2. 1. Empty both the solution and recovery tanks. 2. To access the belt, the machine will either need to be placed upside down or laid on its’...
Page 3
BELT REPLACEMENT 8. Now take out the two axle shaft retaining screws located on either side of the brush housing to release the brush assembly. 9. Remove the old belt, loop the new belt over the brush cog and drive pulley.
Page 4
BRUSH MOTOR REPLACEMENT 1. Follow steps 1-6 in the “Belt Replacement” section, however remove the brush motor bracket bolts in step 6 on page 2. Then proceed as follows. 2. Disconnect the white and black leads. 3. Remove the ground wire from the ground post in the brush housing.
PUMP REPLACEMENT 1. Remove the brush housing assembly. Refer to “Belt Replacement”, steps 1-5. 2. Disconnect the black and white leads from the pump. 3. Now remove the hoses from the pump. Loosen each hose clamp. Slightly heat the hoses up, then twist and pull the hoses off the elbows. Remove the pump.
VACUUM MOTOR REPLACEMENT 1. Remove the brush housing assembly. Refer to “Belt Replacement”, steps 1-5. Hose Clamp 2. Remove the rear cover, reference Drawing 1, Item 37. Follow these steps: a) Disconnect the quick connects on the hose (Drawing 1, Items 34 & 35). Rear Cover b) Take off the hose clamp.
Page 7
VACUUM MOTOR REPLACEMENT 5. Return the machine to the upright position and lift off the recovery tank. 6. Take out the two screws that attach the control panel (Drawing 1, Item 10) to the solution tank. 7. Remove the screw that holds the solution tank bracket (Drawing 1, Item 70) to the body of the machine.
Page 8
DRAWING 1 - Machine Vacuum Motor Mounting Sets (3): 73-75 PUMP: Access from bottom of machine by removing brush housing, then remove 4 plate screws located under recovery tank. 63, 64 Inline Strainer Assembly 03/01...
Page 9
DRAWING 1 - Machine Parts List ITEM PART NO. DESCRIPTION QTY. ITEM PART NO. DESCRIPTION QTY. 962007 Screw 980002 Washer, 1/4 Lock 980004 Washer, 1/4 Flat 962151 Screw, 1/4-20 x 4 HHCS SS 248201 Spacer, Tank Handle W189D Screw, 1/4-20 x 3/4 HH SS 243902 Handle, Recovery Tank 243403...
