Controls

OSM Controls

The OSM controls on the front of the monitor provide the following
functions:
To access OSM press any of the control buttons ( , , , ) or the PROCEED or
EXIT button.
To rotate OSM between Landscape and Portrait modes, press the RESET button.
EXIT
CONTROL /
CONTROL /
PROCEED
RESET
NOTE: When RESET is pressed in the main and sub-menu, a warning window will
appear allowing you to cancel the RESET function by pressing the EXIT button.
78133551/Fix.PM5
Main Menu
Exits the OSM controls.
Moves the highlighted
area up/down to select
one of the controls
Moves the highlighted area
left / rights to select
control menus.
Has no function.
Resets the highlighted
contol menu to the factory
setting.
32
Controls
OSM
Sub-Menu
Exits to the OSM main
menu.
Moves the highlighted
area up/down to select
one of the controls
Moves the bar left /
right to increase or
decrease the adjustment.
Activates Auto Adjust
RESET functions.
and ALL
Resets the highlighted
contol to the factory
setting.
