Lumens VS-LC101 User Manual

Capturevision station
Hide thumbs Also See for VS-LC101:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
VS-LC101
CaptureVision Station
User Manual - English
[Important]
To download the latest version of Quick Start Guide,
multilingual user manual, software, or driver, etc.,
please visit Lumens
http://www.Mylumens.com/support.php
ООО «Хай-Тек Медиа»
официальный дистрибьютор Lumens
+7 (495) 600-42-24 / office@hi-tech-media.ru
109029, Москва, Боенский проезд, д. 9
www.MyLumens.com
www.hi-tech-media.ru

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VS-LC101 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Lumens VS-LC101

Summary of Contents for Lumens VS-LC101

  • Page 1 CaptureVision Station User Manual - English [Important] To download the latest version of Quick Start Guide, multilingual user manual, software, or driver, etc., please visit Lumens http://www.Mylumens.com/support.php ООО «Хай-Тек Медиа» официальный дистрибьютор Lumens +7 (495) 600-42-24 / office@hi-tech-media.ru 109029, Москва, Боенский проезд, д. 9 www.MyLumens.com...

  • Page 2: Table Of Contents

    Table of Contents Copyright Information ..................3   Chapter 1 Safety Instructions ..............4     Chapter 2 Package Contents ............... 5     Chapter 3 Product Overview ................ 6     3.1  Front-End Panel Descriptions ................6  3.2  Rear-End I/O Descriptions ..................6  3.3 ...
  • Page 3     7.2.4 Connect IP Camera ......................35     7.2.5 Volume adjustment ......................36     7.2.6 Add Logo or Other Video in a Video ................37     7.2.7 Storage Device Setting ...................... 38     7.2.8 Split Screen Management ....................39  ...

  • Page 4: Copyright Information

    Lumens is a trademark that is currently being registered by Lumens Digital Optics Inc. Copying, reproducing or transmitting this file is not allowed if a license is not provided by Lumens Digital Optics Inc. unless copying this file is for the purpose of backup after purchasing this product.

  • Page 5: Chapter 1 Safety Instructions

    Chapter 1 Safety Instructions Please use the product following the safety instructions below: 1 Operation 1.1 Please use the product in the recommended operating environment. 1.2 Do not place the product in tilted position. 1.3 Do not place the product on an unstable trolley, stand or table. 1.4 Do not use this product near water or source of heat.

  • Page 6: Chapter 2 Package Contents

    Chapter 2 Package Contents VS-LC101 Quick Installation Guide Remote Control Quick Installation Guide Power Adapter Battery x 4 DIDO connector Appearance may vary depending on country/region...

  • Page 7: Chapter 3 Product Overview

    Chapter 3 Product Overview 3.1 Front-End Panel Descriptions NO. Name Function Descriptions Remote Infrared remote control reception area Control Receiver Indicator Recording/Power Function Record/Play/Pause/Stop/Menu/Channel/Split Display Shortcuts Operation Up/Down/Left/Right/Return/OK Selection Power Button Power Switch USB Port Export files to the inserted USB drive 3.2 Rear-End I/O Descriptions NO.

  • Page 8: Panel Keys Descriptions

    3.3 Panel Keys Descriptions Icon Name Function Descriptions Power Turn on and off. ● Record Start recording.  Play/Pause Play video/Pause video during playback ■ Stop Stop playback/Exit recording Menu Enter Main Menu: Playback/Recording/Settings Channel Change channels. Split Display Change monitor layout during playback ＾...

  • Page 9: Remote Control Buttons Descriptions

    3.5 Remote Control Buttons Descriptions When using the remote control, please point the remote control at the infrared reception area on the front panel of the product to ensure that the signal is successfully received. The valid angle of the remote control is +/- 30°, and the vertical range is within 10 m.
  • Page 10 Icon Name Function Descriptions Return Return to the previous menu or cancel selection Split Display Change monitor layout during playback  Top, Bottom, LC101: Move up/down/left/right and select item Left and Right Camera: Rotate camera lens Select and activate menu item Exit Exit all settings pages or dialogue windows and return to display window...

  • Page 11: Chapter 4 System Requirements

      Computer (or Laptop) x 1  Router x 1 (Giga routers are recommended)  Lumens Webcam x 1-3; e.g. VC-A20P x 3  Network cables x 3-5  HDMI or VGA cable x 2 Speaker x 1 ...

  • Page 12: Chapter 5 Instruction For Installation

    Insert a USB or eSATA external hard drive as the storage Device device Connect the WAN port to the router and computer to remotely control the VS-LC101 Network Connect an IP camera (e.g. VC-A20P) as the image input Image Input...
  • Page 13 5.1.1 Digital I/O Pin Descriptions Pin NO. Function 5.1.2 Digital I/O Connection Descriptions VS-LC101 Digital I/O DIDO connector 5.TxD 4.RTS 3.RxD 2.CTS 1.Gnd...

  • Page 14: Initial Setup

    5.2.2 Confirming the VS-LC101 IP Address  Press the button on the VS-LC101 remote control to open the OSD menu.  Scroll right to [Setting] and press [OK] to enter the settings screen.  Scroll down to [About] and press [OK] to enter the page and confirm the IP address.
  • Page 15 VS-LC101 IP Address 5.2.3 Connecting to the VS-LC101 Webpage (Incl., log in) [Remark 1] To remotely control the VS-LC101, the network interface card on the computer must be set to auto-retrieve the IP address.  Open the computer’s Internet browser.
  • Page 16 5.2.4 Settings 1 Confirm Time Setting  Confirm the time setting. The time can be manually set or chosen from other NTP servers if modifications are required. 2 Format Hard Drive  Open the [Local Storage Setting] page   ...
  • Page 17 3 Connect IP Camera      Open the [Source Setting] page.  Click on [Discovery] and then [Refresh].  After the search is complete, the available camera will be shown in the list. Select the camera.  Enter the VC-A20P account name and password. Administrator: admin Password: 9999 ...
  • Page 18      CH2: IP camera  Select camera  Select available image input for CH3 and CH4.  Click [X] on the upper right to close the settings window.  Click [Apply] to apply the settings. 5 Set Audio In ...
  • Page 19 5.2.5 Confirm Various Settings 1 Confirm Split Screen Style Settings Confirm CH1 to CH4 screens. If the screen is different from the setting, please refer to 5.2.4 Settings (Image Input Settings) to reset image input.  Press the button on the remote control and check if the 9 split recording styles are consistent with the settings.

  • Page 20: Chapter 6 Osd Function Descriptions

    Chapter 6 OSD Function Descriptions Setting Menu Language Playback Record Setting Record Setting Local Storage Start Record Volume Live Broadcast Export Lecture Screen Adjustment Network Delete Lecture Streaming Output Resolution PPT Index About...

  • Page 21: Setting Menu

    1. Disconnect with PC The connection and pairing settings of the PPT 2. Clear paired PC Index software can be used to remove the connection or clear paired PCs About 1. NA VS-LC101 information; e.g. IP address, available capacity, etc…...

  • Page 22: Basic Instruction

    6.2 Basic Instruction Monitor menu, remote control, and panel instructions are provided below. 6.2.1 I would like to view screenshots or videos  Press [Menu] on the remote control or panel to access the main menu.  Use [] to select [Playback]. Press [OK] to enter. ...
  • Page 23 6.2.4 In-Recording Actions /   Remote Control or Panel: Press to pause recording; press ■ to stop recording.  In-Recording rapid key note insertion: Press [C] on the remote control to insert a key note. 6.2.5 Switch Preview screen layout The display screen is set to CH1 full screen by default.
  • Page 24  Press [] on the remote control to select channel.  Press [OK] to switch channel to full-screen mode. Press [OK] to restore channel to the original size. [Remark] If the selected channel is a camera, the VS-LC101 can be used to control the camera. 6.2.8 Maximize Display Settings Each channel in the Split Display can be independently enlarged.
  • Page 25 Use the Main menu:  Press [Menu] on the remote control or panel to access the main menu.  Use [] to select [Setting]. Press [OK] to enter  Use [] to select [Resolution]. Press [OK] to enter  Press [] and [OK] to set the resolution (1920 x 1080 / 1280 x 720 / 1280 x 1024 / 1024 x 768 / Auto) Name Description...
  • Page 26 6.2.12 I would like to export lecture Recordings and images can be exported to portable storage devices, enabling users to view the content easily. Prior to export, ensure that the storage device (e.g., portable flash disk or hard drive) is plugged into the USB port on the front panel of the host device. A progress meter is displayed during export.

  • Page 27: Chapter 7 Web Page Function Description - System Configuration

    [Remark 1] To remotely control the VS-LC101, the network interface card on the computer must be set to auto-retrieve the IP address.  Open the web browser on the PC and enter the IP address of VS-LC101; e.g. http://192.168.2.118  Select [System Configuration].

  • Page 28: System Configuration

    7.1 System Configuration [Remark] After the desired settings are adjusted, press [Apply] on the bottom-right of the screen to apply the adjustments. 7.1.1 System Information Page 1 Device Setting 1.1 Host Name: Name of the host device 1.2 IP Address: IP address of the host device 1.3 Time Zone: Current selected time zone 1.4 Current Time: System time can be adjusted manually/automatically 2 System Configuration: Change Username and Password...

  • Page 29: Video Source Setting Page

    7.1.2 Video Source Setting page Source Setting: Video Source: Video priority Audio Source: Set input audio Discovery Network Camera: Network camera list, including located, connected, and previously connected network cameras...

  • Page 30: Network Setting Page

    7.1.3 Network Setting page DHCP: Automatically allocate IPs based on the connected router Manual Configuration: Manually enter network information 7.1.4 Record Setting page Basic Settings: Audio Delay: Set audio delay time after video is transmitted Line out Loop Through: Activate/Deactivate line out loop through. A high-frequency high-pitched sound is played back if audio from the speaker is picked up by the microphone, amplified, and retransmitted from the same speaker;...
  • Page 31 Countdown: A countdown timer before recording Video Systems: NTSC or PAL can be selected Storage Setting: Recording Mode: Movie mode (single-stream) Encode Profile: Offers 15 encoding formats and user customization Inject Logo: Select screen position for the drop down menu and press to upload or insert a logo image Add Head/Tail to Video: To add a head or tail to the video, press...

  • Page 32: Local Storage Setting

    7.1.5 Local Storage Setting Storage device: Set local storage device Storage Setting: Enable Local Storage: Save record file Cycling Record: Enabling the cycle record function can prevent recording error when storage device is full Disk Select: When two or more storage devices are installed, the priority of the devices can be 7.1.6 Layout Manager Display Layout: Select the default screen display layout;...

  • Page 33: Lecture Manager Configuration

    7.1.7 Lecture Manager Configuration Lecture Information: Record lecture tables; edit, delete and download lecture information 7.1.8 Photo Manager page Photo Manager: Sorted by date; delete and download images...

  • Page 34: Event Log

    7.1.9 Event Log: Browse event message, warning, and error logs 7.1.10 About Firmware Update: Update product firmware Export: Export settings Import: Select and upload update file...

  • Page 35: System Configuration Operation

    7.2 System Configuration Operation 7.2.1 Change Host Name  Go to [System Information]. Change host name, click [Apply] on the bottom right to apply change. 7.2.2 Change System Time  Go to [System Information]. Change date and time using NTP service or manually.

  • Page 36: Connect Ip Camera

    7.2.4 Connect IP Camera Switch to [Discovery] in [Source Setting]. Cameras can be added automatically or manually. 7.2.4.1 Automatic Search  Ensure the camera is connected to the host.  Detect Network Camera: Click [Refresh] to detect network camera. A ? appears in the status field when a device is detected or added.

  • Page 37: Volume Adjustment

    7.2.4.3 Network Camera Information 1. Enter the username and password to connect the network camera. Images can be captured with the camera once the login details are accepted. 2. Camera quality information and brightness settings 3. Camera screen zoom in/out 4.

  • Page 38: Add Logo Or Other Video In A Video

     To adjust Line in 1 and Line in 2 input audio, change . Mic1 and Mic2 are interchangeable.  To adjust HDMI1 and HDMI2 audio, change the HDMI input volume.  The volume of the audio source can be adjusted from 0 to 50. 7.2.6 Add Logo or Other Video in a Video Enable [Record Setting] 7.2.6.1 Inserting a logo into Video...

  • Page 39: Storage Device Setting

    7.2.7 Storage Device Setting Open [Local Storage Setting] For initial hard disk installation, follow the following installation instructions:  Format hard drive: Select hard disk and click . A query window will appear to confirm format. Click “Yes” to begin formatting. After formatting is complete, close the message box to complete the process.

  • Page 40: Split Screen Management

    7.2.8 Split Screen Management Open [Display Layout]. This page enables users to add, delete, or reset screen layout. Add split screen templates 7.2.8.1  Select a layout from the top section.  Drag the left channel into the right section. ...

  • Page 41: Lecture Manager

     Click [Delete] at the bottom of the layout. A reminder will appear. Click [OK] to delete the layout. Change Display Layout/Record Layout 7.2.8.3 Select a layout as one of the 9 presets.  Select a layout. Click [Select] at the bottom. The layout window will appear. Select layout to change the layout.

  • Page 42: Edit Lecture Keynote

    Edit Lecture Information 7.2.9.3  Select lecture and click to access [Edit Lecture Information]. Enter lecture information and click [Submit] to complete editing. 7.2.10 Edit Lecture Keynote  Select lecture and click to access [Edit Lecture Information] page.  Edit Lecture Keynote: Enter title in and click to apply the changes.

  • Page 43: Startup Screen

    Configuration/Director and click [Apply] on the bottom right to accept changes.  Check [Show Characters] to show the characters that are being typed to ensure that the password is properly set. [Remark] Re-log in once the administration account has been changed. 7.2.12 Startup Screen ...

  • Page 44: Chapter 8 Webpage Function Description-Director

    Before using the Director functions, following the below instructions to log in. [Remark 1] To remotely control the VS-LC101, the network interface card on the computer must be set to auto-retrieve the IP address.  Open the web browser on the PC and enter the VS-LC101IP address; e.g.

  • Page 45: Director Instructions

    8.1 Director Instructions 8.1.1 Director Introduction Recording Display Layout Channel Display Preset Recording Display Input/Output Volume Control Self-Defined Display Layout Camera Control...

  • Page 46: Director Instructions

    : Add Key Note : Set Auto-Keynote Time 4 Channel 1 – 4: Recording angle control; Lumens network cameras must be used 5 Preset recording display layouts; rapid switching between layouts 6 Recording Layout/Preview Layout: Self-defined recording display layout and monitor display layout...

  • Page 47: Director Page Instructions - Record Setting

    8.1.3 Director Page Instructions - Record Setting 1 Video System: NTSC or PAL can be selected 2 Line out Loop Through: Activate/Deactivate line out loop through A high-frequency high-pitched sound is played back if audio from the speaker is picked up by the microphone, amplified, and retransmitted from the speaker;...

  • Page 48: Director Instructions

    8.2 Director Instructions 8.2.1 Basic Recording Operations  Click to start recording  Click to pause recording  Click to stop recording 8.2.2 Change Display Layout 8.2.2.1 Rapidly switch between display layout channels  Double-click the right template to rapidly switch between recording display layout channels 8.2.2.2 Self-Defined Recording Display Layout ...

  • Page 49: Network Camera Control

     Timed: Set to automatically add a keynote at a set time while recording [Remark 1] When using PPT index, a keynote is automatically added each time a page is changed [Remark 2] Keynotes can be renamed or deleted in the configuration page. Refer 7.2.10 Edit Lecture Keynote for detailed instructions 8.2.4 Network Camera Control...

  • Page 50: Chapter 9 Troubleshooting

    Chapter 9 Troubleshooting This chapter describes problems you may encounter while using VS-LC101. If you have questions, please refer to related chapters and follow all the suggested solutions. If the problem still occurred, please contact our distributors or service center.
  • Page 51 (e.g., infrared digital whiteboards) may interfere panel keys are with the signal of the remote control. Please keep the VS-LC101 away from such devices. Lecture information is The system uses the FireBreadthed VLC plugin to view lecture information.
